DC-4200 POWERCAM
PRODUCT INFORMATION
Front
Back
1. Flash
1. 'Mode' button
2. Self-timer LED
2. 'Key function' button
3. Viewfinder
3. 'LCD' button
4. Lens
4. 'Playback/thumbnail' button
5. Strap eyelet
5. 'Voice memo/delete' button
6. Tripod socket
7. TFT LCD monitor
8. Viewfinder
Side
1. USB connection
2. Video-out connection
3. DC-input connection
4. Focus switch
5. Battery cover
6. Memory card slot
7. Battery chamber
INSERT BATTERIES
1
Top
1. 'Shutter' button
2. 'Power' button
Key function buttons
1. Self-timer
/ Up
2. Zoom in
/ Right
/ Play-Pause
3. OK/Menu
4. Flash
/ Down
5. Zoom out
/ Left
1.
Open battery cover.
1
UK

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DC-4200 and is the answer not in the manual?

Questions and answers

Related Manuals for Trust DC-4200

Summary of Contents for Trust DC-4200

  • Page 1 DC-4200 POWERCAM PRODUCT INFORMATION Front Back 1. Flash 1. ‘Mode’ button 1. ‘Shutter’ button 2. Self-timer LED 2. ‘Key function’ button 2. ‘Power’ button 3. Viewfinder 3. ‘LCD’ button 4. Lens 4. ‘Playback/thumbnail’ button 5. Strap eyelet 5. ‘Voice memo/delete’ button 6.
  • Page 2 DC-4200 POWERCAM Insert batteries (polarity indicated at battery cover) Close battery cover. Recommended: use rechargeable Ni-MH batteries (www.trust.com/battery-chargers) Do not mix different types or old and new batteries. TAKING PICTURES / RECORDING VIDEOS Turn on camera Change mode: Turn mode dial.
  • Page 3 DC-4200 POWERCAM Zoom in or Zoom Out Works in -mode only. PICTURE: Press ‘shutter’. VIDEO: • Start recording: press ‘shutter’. On LCD: REC flashes. • Stop recording: press ‘shutter’. PLAYBACK ON CAMERA / TELEVISION Turn on camera. Press ‘playback/thumbnail’. •...

  • Page 4: Connect To Computer

    SET, VIDEO, select PAL/NTSC, OK) Use power adapter to save battery power. (www.trust.com/cam-access) CONNECT TO COMPUTER Turn on computer. Start Windows. Connect USB-cable to computer. Windows 98: install driver first, before connect. • Insert Trust Installation CD-ROM, • Click “install driver”, • Follow instructions.
  • Page 5 DC-4200 POWERCAM Connect USB-cable to camera. Turn on camera. Drivers installed automatically. Use power adapter to save battery power. (www.trust.com/cam-access) PLAYBACK ON COMPUTER Windows XP 1, 3 Windows 2000, ME, 98SE 2, 3...
  • Page 6 DC-4200 POWERCAM Windows XP Open folder: DCIM / 100MEDIA Select “Open folder to view files” *.JPG: Picture files *.AVI: Video files Go to step 3. *.WAV: Audio files Windows 2000, ME, 98: *.JPG: Picture files Double click “My Computer” *.AVI: Video files Double click “Removable Disk”...

  • Page 7: Install Software

    DC-4200 POWERCAM INSTALL SOFTWARE Trust Photo Upload Software Application to upload pictures to the Trust PhotoSite (www.trustphotosite.com) How to install: refer manual CD-ROM Ulead Photo Explorer 8.0 Photo Explorer has tools for acquiring, viewing, organizing, adjusting and printing digital images.
  • Page 8 DC-4200 POWERCAM Mode Setting Option(s) Remarks Still Image Size 2848 x 2048 (5,8M) Mode 2304 x 1728 (4M) *) 2048 x 1536 (3M) 1600 x 1200 (2M) Quality S.Fine (***) Fine (**) Normal (*) *) Metering Multi *) Multi: Exposure based on...
  • Page 9 DC-4200 POWERCAM Mode Setting Option(s) Remarks Sharp Soft Soft: soft edges (Sharpness) Normal Normal: sharp images Vivid Vivid: Edges are emphasized to be sharper Effect B&W Converts image to black and white. Normal *) Sepia Converts image to Sepia style...

  • Page 10: Play Games

    DC-4200 POWERCAM Mode Setting Option(s) Remarks Game Jigsaw puzzle Play a game Tetris Soko Snake Playback Slide On/Off *) Start slideshow with interval 1 Mode Repeat On/Off or 10 seconds. Repeat on/off: after one cycle run again or stops after one cycle.

  • Page 11: Insert Memory Card

    DC-4200 POWERCAM INSERT MEMORYCARD Turn off camera. Open battery cover. Insert memory card into card socket. Press till clicks. Close battery cover. Pictures stored on memory card when inserted. Format for first time use (SET, Format, Yes, ‘OK’. Memory card fits one way only. Do not force.
  • Page 12 DC-4200 POWERCAM Item Symbol Remarks 2048 x 1536 1600 x 1200 Quality Super Fine Change in Setup, Fine Normal Sharp Soft Normal Vivid Memory card Memory card inserted White Balance Automatic Change in Setup, Daylight Cloudy Fluorescent Sunset Tungsten Custom...

  • Page 13: Hand Shake

    (www.trust.com/battery-chargers). Batteries may lose power if kept inside the camera for a long time without using. Please remove the batteries while the camera is not in use Save power: turn off LCD Use power adapter when connect to computer/television (www.trust.com/cam-access)
  • Page 14 Warranty & copyright • This product has a two-year manufacturer's warranty, which is effective from the date of purchase. For more information see www.trust.com/warranty • Reproduction of this manual or any part of it is prohibited without permission from Trust International B.V.
