Diode measurement
To avoid electrical shock or damage to
the meter, disconnect circuit power and
discharge all high-voltage capacitors
before testing diodes.
1. Press the MODE key to select the
2. Connect the + tip to the anode and the - tip to the
cathode of the diode under test.
3. The meter will show the approx. forward voltage
of the diode. If the lead connection is reversed
"OL" displayed.

Specifications

General specifications
MAX. Voltage
Sample Rate:
Display
Over Range
Low battery
Auto power off
Power source
Pollution degree 2
Altitude
Operating temp
Operating RH
Storage temp
Storage RH
Temperature Coefficient 0.5×(specified accuracy) /
Dimensions
Weight
www.burntec.com
50V MAX between terminals and earth
ground
3 times/sec for digital data
4000 count (3 3/4 digits) LCD display
"OL" indication
indication
15 minutes if there are no key presses
(2) AG13 button cell or equivalent
< 2000 m
°
32 to 104 F (0~40
<80% RH, non-condensing
°
14 to 140 F (-10~60
<70% RH, battery removed
° °
(<18 C or >28 C)
181(L)×35(W)×20(H) mm
65g. Approx. (battery included)
mode.
°
C)
°
C)
°
C
