- Page 1 P R O F E S S I O N A L S O U N D E Q U I P M E N T MANUAL MPA 6-150 http://www.phoenix-pa.com; e-mail:info@phoenix-pa.com...
- Page 2 MPA - Professional Power Amplifier WARRANTY Phoenix guarantees, that every new product purchased at an authorized distributor is free of assembly and material and material defects. During the guarantee, the purchaser is entitled to repairs free of charge in cases ivolving assembly defects.
- Page 3 MPA - Professional Power Amplifier SAFETY TIPS EQUIPMENT SETUP Avoid setting up the equipment areas: - subject to direct sunlight - exposed to high temperatures - exposed to moisture - subject to high vibrations - on an uneven surface Non compliance can lead to damaging the outside frame and/ or other parts- which could shorten the allotted time of operation.
- Page 4 MPA - Professional Power Amplifier FRONT PANEL 2 3 4 9 10 1. POWER switch 3,6,9. Operating signal READY/PROTECT - signal lights up green - amplifier ready to operate - signal lights up red - signifies that, safety switch is eliminating Banging at time of startup Apearance of DC Overheating of theheatsink or transformer...
- Page 5 MPA - Professional Power Amplifier INPUT CONNECTOR UNBALANCED BALANCED OUTPUT CONNECTOR STEREO BRIDGE CH 1 CH 2 CH 1 CH 2 BRIDGE BRIDGE SOURCE SWITCHES IN 1 IN 2 IN 3 IN 4 IN 5 IN 6 STEREO STEREO STEREO BRIDGE SOURCE SOURCE...
- Page 6 MPA - Professional Power Amplifier Multichannel power amplifier MPA 6-150 Six independent amplifier channels and three bridging switches provide max. Configuration flexibility. Separate gain controls on the back panel allow convenient level balancing of all channels . It features high quality 100W RMS amplifiers per zone.
- Page 7 MPA - Professional Power Amplifier SPECIFICATIONS Output Power ( 1kHz ) Dual Channels/ Loads Output 120 75 100 70 Output Power ( 1kHz ) Mono Channels/ Loads Output N/A 300 N/A 240 N/A 200 - Frequency response 20Hz - 20kHz @ 1W +/- 1dB - Distortion THD 0,1 % @ 1kHz - Input sensitivity...
