Instruction manual
PV-DSP-1D
Version with
USB/SD player
PV-DSP-1D.9.2 (Power Voice)
Automatic
NOISE GATE
Analogue Automatic mixing amplifier (NOISE GATE system) with a power amplifier 200
Watt, free programmable PRESETS 1 and 2 and USB/SD player.
Optional cable remote control for remote shift of the presets.
Remote LIVE control by MASTER USB interface.
A complete equipment in the audio processing with DSP.-1D system.
The programming is possible by the software MWL-Control 1.1.1 or with SETTINGS/ENTER
button.
Phoenix Professional Audio GmbH
Gewerbepark Conradty 12
D-83059 KOLBERMOOR
Tel. 0049-(0)8031-30425-0
Fax. 0049-(0)8031-30425-25
www.phoenix-pa.com
info@phoenix-pa.com
shop.phoenix-pa.com
"Copyright 2016 Phoenix Professional Audio GmbH, www.phoenix-pa.com"
Phoenix logo is registered at the German Patent- and Trademark Office (TM)
DOC-220116
All brands are property of their respective owners.
Advertisement
Table of Contents
Related Manuals for Phoenix PV-DSP-1D.9.2
Summary of Contents for Phoenix PV-DSP-1D.9.2
- Page 1 Gewerbepark Conradty 12 D-83059 KOLBERMOOR Tel. 0049-(0)8031-30425-0 Fax. 0049-(0)8031-30425-25 www.phoenix-pa.com info@phoenix-pa.com shop.phoenix-pa.com “Copyright 2016 Phoenix Professional Audio GmbH, www.phoenix-pa.com“ Phoenix logo is registered at the German Patent- and Trademark Office (TM) DOC-220116 All brands are property of their respective owners.
-
Page 2: Safety Instructions
Pay attention that the mains line cannot be squeezed or damaged by sharp edges. Regularly check the device and the mains line for damages. “Copyright 2016, Phoenix Professional Audio GmbH, www.phoenix-pa.com“ Phoenix logo is registered at the German Patent- and Trademark Office (TM) All brands are property of their respective owners. - Page 3 Before the device is switched on, all faders and volume controls have to be set to zero or to minimum. “Copyright 2016, Phoenix Professional Audio GmbH, www.phoenix-pa.com“ Phoenix logo is registered at the German Patent- and Trademark Office (TM) All brands are property of their respective owners.
-
Page 4: Explanation Of The Graphic Symbols
11. Only use products and accessories specified by Phoenix Professional Audio GmbH. 12. Let maintenance operations only be carried out by qualified maintenance staff. The device has always to be maintained when it has been damaged in any way, f.i. - Page 5 Instruction manual GENERAL POWER-VOICE PV-DSP-1D.9.2 Automatic power mixer with power amplifier 200 Watt, especially developed for uses in difficult acoustic buildings (architectural acoustics). The 8 universal inputs are shiftable by DIP switches between MIC.- and LINE sensitivity. Each of the 8 universal inputs has shiftable phantom power and a HPF filter (100 Hz).
-
Page 6: Main Features
- Control software MWL-CONTROL 1.1.1 via USB interface. FRONT SIDE OF THE AMPLIFIER “Copyright 2016 Phoenix Professional Audio GmbH, www.phoenix-pa.com“ Phoenix logo is registered at the German Patent- and Trademark Office (TM) All brands are property of their respective owners. -
Page 7: Line Input
REPEAT button for approx. 3 seconds, then the device changes to normal PLAY MODE. “Copyright 2015, Phoenix Professional Audio GmbH, www.phoenix-pa.com“ Phoenix logo is registered at the German Patent- and Trademark Office (TM) All brands are property of their respective owners. -
Page 8: Sd Card Slot
The MP3 player has no FILE management function; it is recommended to play compositions on the USB stick without FILE. “Copyright 2016, Phoenix Professional Audio GmbH, www.phoenix-pa.com“ Phoenix logo is registered at the German Patent- and Trademark Office (TM) All brands are property of their respective owners. - Page 9 By pressing the button again, the reproduction of the song is activated. “Copyright 2016 Phoenix Professional Audio GmbH, www.phoenix-pa.com“ Phoenix logo is registered at the German Patent- and Trademark Office (TM) All brands are property of their respective owners.
- Page 10 Multifunctional display, with menu navigation and indication for all settings in the system managed by the SETTING/ENTER button (manual local programming). “Copyright 2016, Phoenix Professional Audio GmbH, www.phoenix-pa.com“ Phoenix logo is registered at the German Patent- and Trademark Office (TM) All brands are property of their respective owners.
-
Page 11: Level Indication
When connecting the speaker lines please pay attention to the complete load of the connected speakers. “Copyright 2016, Phoenix Professional Audio GmbH, www.phoenix-pa.com“ Phoenix logo is registered at the German Patent- and Trademark Office (TM) All brands are property of their respective owners. - Page 12 Linear (before EQ and Master) balanced input to Jack bush (LINE level, 0 dB). “Copyright 2016, Phoenix Professional Audio GmbH, www.phoenix-pa.com“ Phoenix logo is registered at the German Patent- and Trademark Office (TM) All brands are property of their respective owners.
- Page 13 Only either 100V speakers OR low-ohmed speakers can be connected - simultaneous use is not possible. “Copyright 2016, Phoenix Professional Audio GmbH, www.phoenix-pa.com“ Phoenix logo is registered at the German Patent- and Trademark Office (TM) All brands are property of their respective owners.
- Page 14 “Copyright 2016, Phoenix Professional Audio GmbH, www.phoenix-pa.com“ Phoenix logo is registered at the German Patent- and Trademark Office (TM) All brands are property of their respective owners.
- Page 15 PV-DSP-1D.XX (COM, 4/8 Ohm, 50V, 70V and 100V) with inputs of the SW-6, the construction of additional 6 speaker zones with ON/OFF switch and separate volume control is possible. “Copyright 2016, Phoenix Professional Audio GmbH, www.phoenix-pa.com“ Phoenix logo is registered at the German Patent- and Trademark Office (TM) All brands are property of their respective owners.
-
Page 16: Speaker Outputs
Automatic activation in preset No. Gallery sound ZONE 1 with separate volume control. “Copyright 2016, Phoenix Professional Audio GmbH, www.phoenix-pa.com“ Phoenix logo is registered at the German Patent- and Trademark Office (TM) All brands are property of their respective owners. -
Page 17: Gain Control
DIP-3 (ON): input low cut filter (100 Hz) to remove low frequencies, interferences and phase shift is activated. DIP-3 (OFF): the high pass filter (low cut filter, 100 Hz) is deactivated. “Copyright 2015, Phoenix Professional Audio GmbH, www.phoenix-pa.com“ Phoenix logo is registered at the German Patent- and Trademark Office (TM) All brands are property of their respective owners. - Page 18 By turning the corresponding channel trimmers clockwise the reaction lowering of the NOISE GATE system is reached. “Copyright 2015, Phoenix Professional Audio GmbH, www.phoenix-pa.com“ Phoenix logo is registered at the German Patent- and Trademark Office (TM) All brands are property of their respective owners.
- Page 19 Main sound, f.i. nave. Better speech intelligibi- Equalization by internal DSP lity. system in the Digivoice. “Copyright 2016, Phoenix Professional Audio GmbH, www.phoenix-pa.com“ Phoenix logo is registered at the German Patent- and Trademark Office (TM) All brands are property of their respective owners.
- Page 20 COM PORT No. from the shown COM PORT connections from the WINDOWS DEVICE MANAGER and try it again. “Copyright 2016 Phoenix Professional Audio GmbH, www.phoenix-pa.com“ Phoenix logo is registered at the German Patent- and Trademark Office (TM) All brands are property of their respective owners.
- Page 21 /DEFAULT SETTINGS Reset PRESETS to factory settings. All settings and information are hereby deleted! “Copyright 2016, Phoenix Professional Audio GmbH, www.phoenix-pa.com“ Phoenix logo is registered at the German Patent- and Trademark Office (TM) All brands are property of their respective owners.
-
Page 22: Software Programming
Please select the favoured „PRESET“. Two PRESET configurations can be carried out for all programming processes. “Copyright 2016, Phoenix Professional Audio GmbH, www.phoenix-pa.com“ Phoenix logo is registered at the German Patent- and Trademark Office (TM) All brands are property of their respective owners. - Page 23 After the signal „correction“ the automatic feedback limiter (adaptability) or the digital SHIFTER can be activated. “Copyright 2016, Phoenix Professional Audio GmbH, www.phoenix-pa.com“ Phoenix logo is registered at the German Patent- and Trademark Office (TM) All brands are property of their respective owners.
- Page 24 To protect speakers from too high peak levels in PA appli- cations, however, short attack times are recommendable (FAST-setting). “Copyright 2016, Phoenix Professional Audio GmbH, www.phoenix-pa.com“ Phoenix logo is registered at the German Patent- and Trademark Office (TM) All brands are property of their respective owners.
- Page 25 Please select the favoured „PRESET“. Two PRESET configurations can be carried out for all programming processes. “Copyright 2016, Phoenix Professional Audio GmbH, www.phoenix-pa.com“ Phoenix logo is registered at the German Patent- and Trademark Office (TM) All brands are property of their respective owners.
- Page 26 SAVE AS: Save a project under a new file name EXIT: Finish project and leave software. “Copyright 2016, Phoenix Professional Audio GmbH, www.phoenix-pa.com“ Phoenix logo is registered at the German Patent- and Trademark Office (TM) All brands are property of their respective owners.
- Page 27 Default Overwrite? 1-2 ENTER ENTER ENTER PASSWORD PASSWORD OPTIONS ON/OFF EXIT EXIT EXIT “Copyright 2016, Phoenix Professional Audio GmbH, www.phoenix-pa.com“ Phoenix logo is registered at the German Patent- and Trademark Office (TM) All brands are property of their respective owners.
- Page 28 ( „SAVING“). Standard display indication is shown. “Copyright 2016, Phoenix Professional Audio GmbH, www.phoenix-pa.com“ Phoenix logo is registered at the German Patent- and Trademark Office (TM) All brands are property of their respective owners.
- Page 29 Thank you very much for deciding for the Automatic POWER- VOICE PV-DSP-1D.9.2 from Phoenix Professional Audio GmbH. To be able to use this correctly und to use all technical possibilities which offers the Automatic mixing amplifier PV-DSP-1D.9.2, you have to carry out a room adaption or room equalization after the installation.
- Page 30 The green curve shows the recommended reproduction curve for speech amplification systems. The Automatic mixing amplifier PV-DSP-1D.9.2 (POWER VOICE) serie has 15 parametric input EQ. Thus even acoustically difficult rooms can be equalized very well and the microphone sensitivity can be raised without parasitic feedback.
-
Page 31: Specifications
19“- width, 483 mm (W) x 135 mm- 3 U (H) x 340 mm (D), in the range -5 C to +40 Weight: approx. 12 kg Colour: graphite 443 mm “Copyright 2016, Phoenix Professional Audio GmbH, www.phoenix-pa.com“ Phoenix logo is registered at the German Patent- and Trademark Office (TM) All brands are property of their respective owners. - Page 32 Instruction manual “Copyright 2016, Phoenix Professional Audio GmbH, www.phoenix-pa.com“ Phoenix logo is registered at the German Patent- and Trademark Office (TM) All brands are property of their respective owners.
