- Page 1 MS988900TX “Tillman” TV/Media Stand Salem Antique Oak Finishing Assembly Instructions For assistance with assembly contact: Southern Enterprises Inc. Customer Service 1-800-633-5096 service@seidal.com www.seidal.com...
- Page 2 “Tillman” TV/Media Stand Parts List Please review all parts and hardware before disposing of any packaging. Call Customer Service if missing hardware. Do not return to store/retailer. Hardware shown actual size. Using hardware that is too long will cause damage. Before beginning assembly, separate each type of hardware.
- Page 3 “Tillman” TV/Media Stand Parts List Please review all parts and hardware before disposing of any packaging. Call Customer Service if missing hardware. Do not return to store/retailer. Hardware shown actual size. Using hardware that is too long will cause damage. Before beginning assembly, separate each type of hardware.
- Page 4 “Tillman” TV/Media Stand Assembly Instructions Assembly Instructions: Wood may scratch easily. Be careful when assembling. Do not scratch. Step 1. Unpack and lay parts on clean, padded surface like carpet or blanket. Check that you have all parts indicated on the front page. Step 2.
- Page 5 “Tillman” TV/Media Stand Assembly Instructions Step 1. Insert the Wood Dowels(1) into predrilled holes in Fixed Shelf(F) and Left Middle Panel(E). Step 2. Attach the Left Middle Panel(E) to the Bottom Panel(A) and Fixed Shelf(F) with Bolt(2),then attach Front Stretcher(G) to Middle Panel (D,E), then fasten Bolt(2).
- Page 6 “Tillman” TV/Media Stand Assembly Instructions Step 1. Put the Top Panel (K) on the soft working surface. Step 2. Attach Magnet(3) to Top Panel(K) with Screw for Magnet(4). Quantity of 2 Magnet Quantity of 4 3.5mm x 15 mm Figure 6 Bolt For Magnet Step 1.
- Page 7 “Tillman” TV/Media Stand Assembly Instructions Step 1. Insert Nut(6) into predrilled holes on Drawer Face Panel(M). Step 2. Attach Drawer Side Panels(N,O) to Drawer Face Panel(M) with Bolt for Drawer(7) through outer predrilled holes in Drawer Side Panels(N,O). Step 3. Put the Drawer Bottom Panel(P) into inner grooves of Drawer Side Panels(N,O) and Drawer Face Panel(M).
- Page 8 “Tillman” TV/Media Stand Assembly Instructions Step 1. Attach Bracket(11) to the Top Panel(K) with Screw For Bracket(12). Step 2. Drill 1/4 pilot holes in near proximity of the Bracket(11) attached to the Top Panel(K) and tap the Plastic Anchor(13) into wall. Step 3.
-
Page 9: Parts Replacement Form
Parts will not be available for items arriving fully assembled Parts will be sent if available from SEI. We'd love to hear from you! Email us photos of our products in your home at sei@seidal.com... - Page 10 CAUTION The top shelf of this cabinet is intended for plasma/LCD televisions having a maximum screen size of 46” and weight of 175 lb. The top shelf is NOT INTENDED for tube televisions. Each center shelf should not be loaded with more than 20 lb. Each side shelf should not be loaded with more than 15 lb.
