- Page 1 “Narita”Corner TV/Media Stand MS987100TX Walnut Finishing For assistance with assembly contact: MS986100TX Black Finishing Southern Enterprises Inc. Customer Service 1-800-633-5096 service@seidal.com www.seidal.com...
- Page 2 “Narita” Corner TV/Media Stand Parts List Please review all parts and hardware before disposing of any packaging. Call Customer Service if missing hardware. Do not return to store/retailer. Hardware shown actual size. Using hardware that is too long will cause damage. Before beginning assembly, separate each type of hardware.
- Page 3 “Narita” Corner TV/Media Stand Parts List Please review all parts and hardware before disposing of any packaging. Call Customer Service if missing hardware. Do not return to store/retailer. Hardware shown actual size. Using hardware that is too long will cause damage. Before beginning assembly, separate each type of hardware.
- Page 4 “Narita” Corner TV/Media Stand Assembly Instructions Assembly Instructions: Wood may scratch easily. Be careful when assembling. Do not scratch. Step 1. Unpack and lay parts on clean, padded surface like carpet or blanket. Check that you have all parts indicated on the front page.
- Page 5 “Narita” Corner TV/Media Stand Assembly Instructions Step 1. Insert the Wood Dowels(1) into predrilled holes in Bottom Panel(E) and Right Side Panel(D), as picture. Step 2. Attach Bottom Panel(E)to the Top Panel(A) with Bolt(2), then fasten them. Step 3. Attach Cam Bolt (5) to Top Panel(A).
- Page 6 “Narita” Corner TV/Media Stand Assembly Instructions Step 1. Attach the Middle Back Panel(I) and Side Back Panels(J) as pictured with Screw For Back(9), then fasten them. Quantity of 40 3.5mm x 12 mm Figure 6 Screw For Back Step 1. Attach Left Door(K) to Left Side Panel(C).
- Page 7 9 months. If this product has not been purchased from our retail affiliates (within 9 months), we are under no obligation to provide parts or replacement merchandise. Parts will not be available for items arriving fully assembled Parts will be sent if available from SEI.
- Page 8 CAUTION The top shelf of this cabinet is intended for plasma/LCD televisions having a maximum screen size of 40” and weight of 175 lb. The top shelf is NOT INTENDED for tube televisions. Each center shelf should not be loaded with more than 20 lb. Each side shelf should not be loaded with more than 15 lb.
