Introduction

The
IGS-9168GP series
is a managed Ethernet switch with
16x10/100/1000Base-T(X) ports and 8x100/1000Base-X SFP ports. With
complete support of Ethernet redundancy protocols, O-Ring (recovery time
<30ms for over 250 connected devices) and MSTP (RSTP/STP
compatible) can protect your mission-critical applications from network
interruptions or temporary malfunctions. With a wide operating
o
temperature from -40~70 C, the device can be managed centralized via
ORing's proprietary Open-Vision managment utility as well as via Web-
based interfaces, Telnet and console (CLI).

Package Contents

The device is shipped with the following items. If any of these items is
missing or damaged, please contact your customer service representative for
assistance.
Contents
Pictures
Number
IGS-9168GP
CD
DIN-rail Kit
Wall-mount Kit
Console Cable
QIG

Preparation

Before you begin installing the switch, make sure you have all of the package
contents available and a PC with Microsoft Internet Explorer 6.0 or later, for
using web-based system management tools.
Safety & Warnings
Elevated Operating Ambient:
If installed in a closed or multi-unit rack
assembly, the operating ambient temperature of the rack environment may be
greater than room ambient. Therefore, consideration should be given to
installing the equipment in an environment compatible with the maximum
ambient temperature (Tma) specified by the manufacturer.
Reduced Air Flow:
Installation of the equipment in a rack should be such
that the amount of air flow required for safe operation of the equipment is
not compromised.
Mechanical Loading:
Mounting of the equipment in the rack should be
such that a hazardous condition is not achieved due to uneven mechanical
loading.
Q I G
IGS-9168GP
G
uide

Dimension

96.4
70.5
15.0
10.9
G16
G15
G24
PWR
PWR1
G14
G13
PWR2
G23
G12
G11
G22
G10
G9
G21
10/100/1000T
100/1000X
G8
G7
G20
G6
G5
G19
G18
G4
G3
G17
G2
G1
IGS-9168GP
X 1

Panel Layouts

X 1
Front View
X 1
12
G16
G15
11
8
G14
G13
X 2
9
10
G12
G11
G10
G9
10/100/1000T
X 1
G8
G7
G6
G5
G4
G3
X 1
G2
G1
Rear View
1
1
1. Wall-mount screw holes
2. Din-rail screw holes
1907-2-29-IGS9168GP-1.0
IGS-9168GP
Circuit Overloading: Consideration should be given to the connection of the
equipment to the supply circuit and the effect that overloading of the circuits might have
on overcurrent protection and supply wiring. Appropriate consideration of equipment
nameplate ratings should be used when addressing this concern.
30.0
87.0
58.0
48.0
105.5
13
12
1
G24
PWR
2. PWR1 LED
2
PWR1
3
PWR2
3. PWR2 LED
G23
4
5
4. R.M. status LED
6
G22
5. Ring status LED
7
G21
6. Faulty relay indicator
7. Console port
100/1000X
8. Link/action LED for Gigabit Ethernet ports
G20
9. Speed LED for Gigabit Ethernet ports
G19
10. Gigabit Ethernet ports
G18
11. SFP port
12. Link/Act LED for SFP port
G17
13. Reset button
IGS-9168GP
Top Panel
PWR-2
Fault
PWR-1
1
1A@24V
V2- V2+
V1- V1+
DC 48V
2
2
1. Terminal blocks: PWR1, PWR2
(12-48V DC), Relay
2. Ground wire.
PRINTED ON RECYCLED PAPER
Industrial Managed Gigabit Switch

Installation

DIN-rail Installation

Step 1:
Slant the switch and screw the Din-rail kit onto the back of the switch, right in
the middle of the back panel.
Step 2:
Slide the switch onto a DIN-rail from the Din-rail kit and make sure the switch
clicks into the rail firmly.
R2.5
R3.95
87.9

Wall-mounting

Step 1:
Screw the two pieces of wall-mount kits onto both ends of the rear panel of the
switch. A total of six screws are required, as shown below.
Step 2:
Use the switch, with wall mount plates attached, as a guide to mark the
correct locations of the four screws.
Step 3:
Insert a screw head through the large parts of the keyhole-shaped apertures,
and then slide the switch downwards. Tighten the screws for added stability.

Network Connection

The IGS-9168GP series have
standard Ethernet ports. According
to the link type, the switch uses
CAT 3, 4, 5,5e UTP cables to
connect to any other network
devices (PCs, servers, switches,
routers, or hubs). Please refer to
the following table for cable
Version 1.0
G16
G15
G24
PWR
PWR1
G14
G13
PWR2
G23
G12
G11
G22
G10
G9
G21
10/100/1000T
100/1000X
G8
G7
G20
G6
G5
G19
G4
G3
G18
G17
G2
G1
IGS-9168GP

Cable Types and Specifications:

10/100 Base-T(X) RJ-45 Port
Pin Number
Assignments
1
TD+
2
TD-
3
RD+
4
Not used
5
Not used
6
RD-
7
Not used
8
Not used
Quick Installation Guide
