Wind Crest UL2936S Installation

WARNING:
When building a custom hood for a liner, always follow all applicable construction codes and standards.
See the illustrations and table below to locate your liner choice and use corresponding custom hood
base dimensions. For the liner installation, only the bottom of the custom hood is needed. Do not
finalize the entire custom hood yet, because an opening is needed for the insert.
Recommended
thickness:
3/4''
Insert
Liner
Model
Model
UL2936S
UIX2916S
UL2942S
UL3848S
UL3854S UIX3816S
UL3860S
*Dimension does not include 3/8" wide flange around liner.
**The inside depth shown in the table above assumes a minimum cabinet backboard thickness of 3/8".
FIG 1:
We recommend the base of the custom hood to be 3/4" thick plywood. The sides, front
and backboard (if included) of the custom hood to be 3/4" thick, assuming standard
cabinet widths.
Consider the shape and size of the insert to determine the configuration of the custom hood. For
more details, refer to the installation manual for the UIX2916S and UIX3816S inserts.
SEP12.0201
B
2
'
1/16'
A
Plywood base thickness: 3/4"
FIG 1
*Inside
Custom Hood
Exterior Width Width (A)
34
36 inches
40
42 inches
46
48 inches
52
54 inches
58
60 inches
