Wind Crest IOX36 Installation Instructions Manual

PLEASE READ ENTIRE INSTRUCTIONS BEFORE PROCEEDING.
INSTALLATIONS MUST COMPLY WITH ALL LOCAL CODES.
WARNING - TO REDUCE THE RISK OF FIRE, ELECTRICAL SHOCK, OR INJURY TO PERSONS,
INSERT SHOULD BE INSTALLED WITH VENTILATORS APPROVED FOR USE WITH THE
INSERT. SEE TABLE – 1 ON THIS PAGE FOR APPROVED VENTILATORS.
WARNING - TO REDUCE THE RISK OF FIRE,
ELECTRIC SHOCK, OR INJURY TO PERSONS,
OBSERVE THE FOLLOWING:
A. Installation work and Electrical Wiring Must Be Done By
Qualified Person(s) In Accordance With All Applicable
Codes & Standards. Including Fire-Rated Construction.
"WARNING" To Reduce The Risk Of Fire, Use Only Metal
Duct Work.
Sufficient air is needed for proper combustion and exhausting
B.
of gases through the flue (chimney) of fuel burning
equipment to prevent backdrafting. Follow the heating
equipment manufacturer guideline and safety standard such
as those published by the National Fire Protection
Association (NFPA) and the American Society for Heating,
CAUTION - TO REDUCE THE RISK OF FIRE AND TO PROPERLY EXHAUST AIR, BE SURE TO
DUCT AIR OUTSIDE FOR DUCTED FANS – DO NOT VENT EXHAUST AIR INTO SPACE WITHIN
WALLS OR CEILING OR INTO ATTICS, CRAWL SPACES OR GARAGES.
Read this instruction completely before starting installation. Planning the complete installation before starting any work
is highly recommended. This includes all aspects of the installation including hood location, ducting, electrical
requirements, and adequacy of mounting surfaces.
TABLE - 1
Use model VEN060I or
VEN120I for internal
ventilator. Use VEN150E for
remote ventilator
DUCTING: Use a minimum 8" round duct for VEN060I installations. Use a minimum 10" round duct for VEN120I and
VEN150E installations. See Page – 2 for Transition (Purchased Separately) Recommendations.
IMPORTANT SAFETY INSTRUCTIONS
IMPORTANT:
Save these Instructions for the Local Electrical Inspector's use.
INSTALLER:
Please leave these Installation Instructions with this unit for owner.
OWNER:
Please retain these Instructions for future reference
This Insert series has been designed to be used with the ventilators shown in Table
– 1 before cutting into cabinets, it is necessary to confirm that the correct ventilator
is being used. Your dealer should have reviewed your needs prior to your
purchase. Be sure you have the correct ventilation system.
CAUTION: To Reduce the Risk of Fire and Electrical Shock, Install This
Insert Only With Blowers Manufactured By Wind Crest.
INSTALLATION INSTRUCTIONS
INSERT MODELS –
IOX36, IOX42, IOX48, IOX54, & IOX60
Refrigeration and Air Conditioning Engineers (ASHRAE),
and the local code authorities.
C. When cutting or drilling into wall or ceiling, do not damage
electrical wiring and other hidden utilities.
D. Ducted fans must always be vented to the outdoors.
E. Before Servicing or Cleaning Unit, Switch Power off At Service
Panel And Lock Service Disconnecting Means to Prevent Power
From Being Switched On Accidentally. When The Service
Disconnecting Means Cannot be Locked, securely Fasten A
Prominent Warning Device, Such As A Tag, To The Service
Panel
Page 1 of 9
P/N 12372.00 Rev A
