Ada COSMO 150 Video Operating Manual page 25

COSMO 150
25
VIDEO
Pythagorean calculation
Single Pythagorean calculation 1
This function allows to measure height or width of a building.
Press button until symbol appears on the display.
Press button . Aim at the upper point and trigger the measurement. The value is adopted.
Keep the instrument as horizontal as possible.
Press button to trigger the measurement . Then the value is adopted. You can also press and
hold down button to trigger continuous measurement. Sweep the laser back and forth and up and
down over the target point. The result is shown on the display.
Additional information: triangle area and angle between measured distances are shown above the
summary line.
