  • Page 1 Encoder Modulator User Manual Variants: HDM-8512C DVB-C Mod with Mux, OSD 12x HDMI, 1x DVB-C, 128x IP | LogoOSD, MUX, 4x DVB-C, 4x MPTS HDM-8512T DVB-T Mod with Mux, OSD 12x HDMI, 1x DVB-C, 128x IP | LogoOSD, MUX, 4x DVB-T, 4x MPTS...
  • Page 2 Encoder Modulator User Manual So what is correct? Scrambler port left?
  • Page 3: About This Manual

    Encoder Modulator User Manual or is the scrambler connection a part of NMS port? (NO MAC address!) Here again, MAC address rule violations. About This Manual Intended Audience This user manual has been written to help people who have to use, to integrate and to install the product.
  • Page 4 Encoder Modulator User Manual Disclaimer No part of this document may be reproduced in any form without the written permission of the copyright owner. The contents of this document are subject to revision without notice due to continued progress in methodology, design and manufacturing. We shall have no liability for any error or damage of any kind resulting from the use of this document.
  • Page 5: Table Of Contents

    Encoder Modulator User Manual 1.4 P ............................1 RINCIPLE HART CHAPTER 2 INSTALLATION GUIDE ......................4 2.1 G ..........................4 ENERAL RECAUTIONS 2.2 P ........................... 5 OWER PRECAUTIONS 2.3 D ’ ................ 5 EVICE NSTALLATION HART LLUSTRATED AS FOLLOWING 2.4 E ........................
  • Page 6: Carrier

    Encoder Modulator User Manual Chapter 1 Introduction 1.1 Product Overview This is a professional high integration device which includes encoding, multiplexing, scrambling and modulation. It supports 8/12 HDMI input, one DVB-C tuner input and 128 IP input with Data1 (GE) and Data2 (FE) port. It also supports DVB-C or -T RF out with 4 adjacent carriers, and support Data1 (GE) output port to support 4 MPTS out.
  • Page 7: Dvb-T

    Encoder Modulator User Manual 1920×1080_50P, 1920×1080_50i, 1280×720_60P, 1280×720_50P, 720×576_50i,720×480_60i, 1920×1080_30P, 1920×1080_25P, Out-put 1280×720_30P, 1280×720_25P, 720×576_25P,720×480_30P, Bit-rate 1Mbps~13Mbps each channel Rate Control CBR/VBR GOP Structure IP…P (P Frame adjustment, without B Frame ) Encoding MPEG-1 Layer 2 Sampling rate 48KHz Audio Resolution 24-bit 64kbps,128Kbps,192kbps,224kbps,256kbps,320kbps,384kbp...
  • Page 8: Principle Chart

    Encoder Modulator User Manual function Chinese and English language Ethernet software upgrade Dimension(W×L×H) 482mm×410mm×44mm Approx weight Miscellaneous Environment 0~45℃(work);-20~80℃(Storage) Power requirements AC 110V± 10%, 50/60Hz, AC 220 ±10%,50/60Hz Power consumption 1.4 Principle Chart HDMI #1 Encoding Carrier 1 MUX 1# SCR1# DVB-C 1# IP 1...
  • Page 9: Chapter 2 Installation Guide

    Encoder Modulator User Manual RF test and RF out port Port Power supply and Grounding Pole 12HDMI input Reset Key/Data Port Indicator Indicator ASI output port(optional) DATA Port (for IP stream input/output) NMS/CAS RF in and Loop out Chapter 2 Installation Guide This section is to explain the cautions the users must know in some case that possible injure may bring to users when it’s used or installed.
  • Page 10: Power Precautions

    Encoder Modulator User Manual the power is on.  After use, securely stow away all loose cables, external antenna, and others. 2.2 Power precautions  When you connect the power source, make sure if it may cause overload.  Avoid operating on a wet floor in the open. Make sure the extension cable is in good condition ...
  • Page 11: Grounding Requirement

    Encoder Modulator User Manual Wall It can be covered with wallpaper, or brightness less paint. Fire Protection Fire alarm system and extinguisher Requiring device power, air-conditioning power and lighting power are independent to each other. Device power requires Power AC 110V±10%, 50/60Hz or AC 220V±10%, 50/60Hz. Please carefully check before running.
  • Page 12: Encoder Operation

    Encoder Modulator User Manual Connect the PC (Personal Computer) and the device with net cable, and use ping command to confirm they are on the same network segment. I.G. the PC IP address is 192.168.99.252, we then change the device IP to 192.168.99.xxx (xxx can be 1 to 254 except 252 to avoid IP conflict).
  • Page 13 Encoder Modulator User Manual Current software version information User can click any item here to enter the corresponding interface to check information or set the parameters. Figure-2 Parameters → Module 1-3 This encoder modulator maximum support up to 3 modules with 12 HDMI input. From the menu on left side of the webpage, clicking “Module1-3”, it displays the information of each encoding channel as Figure-3.
  • Page 14 Encoder Modulator User Manual General settings for the Encoding program: User can edit any item listed as needed. Video Status read area Figure-3 Parameters → TS Config: From the menu on left side of the webpage, clicking “TS Config”, it displays the interface where users can configure the TS output parameters.
  • Page 15 Encoder Modulator User Manual Input Area Output Area Operation Area Figure-4 Configure ‘Input Area’ and ‘Output Area’ with buttons in ‘Operation Area’. Instructions are as below: : To add input channel which can from GE1/GE2/Connector : To edit the input channel : To delete the input channel : To delete all inputs channel : To check input IP lock or not, green means current IP locked...
  • Page 16 Encoder Modulator User Manual Similarly, user can cancel the multiplexed programs from the right box. To select all the input programs To select all the output programs To parse programs time limitation of parsing input programs  Program Modification: The multiplexed program information can be modified by clicking the program in the ‘output’...
  • Page 17 Encoder Modulator User Manual Figure-6  TS Config→PID Bypass: From the TS Config menu on up side of the webpage, clicking “PID Bypass”, it displays the interface as Figure-7 where user can add PIDs to be passed, click the “+” symbol, input current IP channel number, then input current IP source Pid and output Pid which is customer needed , then click “set”...
  • Page 18 Encoder Modulator User Manual Figure-7 Parameters → Modulator: From the menu on left side of the webpage, clicking “Modulator”, it will display the Modulator Configuration screen as Figure-8. Here user can set modulation parameters. Figure-8 Page 13 / 23...
  • Page 19 Encoder Modulator User Manual Parameters → IP Stream: This encoder modulator supports TS to output in IP (4*MPTS) format through the DATA1 port. Click ‘IP Stream’, it will display the interface where to set IP out parameters (Figure-9). Quickly Config Channel Config Figure-9 Parameters→...
  • Page 20 Encoder Modulator User Manual Select to configure logo, caption or QRcode Select program1/2/3/4 of Module1/2/3 to apply the logo insertion, or you can select all to apply all programs and all modules Click here to comfirm the LOGO you selected Browse and select the Logo Put your logo everywhere which has been created...
  • Page 21 Encoder Modulator User Manual Put your QRcode URL here Put your QRcode everywhere Browse and select QRcode which has been created Figure-12 System → Network: Click ‘Network’, it will display the interface as Figure-13 where to set network parameters. Page 16 / 23...
  • Page 22 Encoder Modulator User Manual Figure-13 System → password From the menu on left side of the webpage, clicking “Password”, it will display the screen as Figure-14 where to set the login account and password for the web NMS. Figure-14 System → Configuration: From the menu on left side of the webpage, clicking “Configuration”, it will display the screen as Figure-15 where to save/ restore/factory setting/ backup/ load your configurations.
  • Page 23 Encoder Modulator User Manual Figure-15 System → Firmware: From the menu on left side of the webpage, clicking “Firmware”, it will display the screen as Figure-16 where to update firmware for the modulator. Page 18 / 23...
  • Page 24 Encoder Modulator User Manual Figure-16 System→ Date/Time: From the menu on left side of the webpage, clicking “Date/Time”, it will display the screen as Figure-17 where to set date and time for the device. Page 19 / 23...
  • Page 25 Encoder Modulator User Manual Figure-17 System→ Log: From the menu on left side of the webpage, clicking “Log”, it will display the log interface as Figure-18 where to check or export the Kernel/System log. Page 20 / 23...
  • Page 26 Encoder Modulator User Manual Figure-18 Page 21 / 23...
  • Page 27: Chapter 4 Troubleshooting

    Encoder Modulator User Manual Chapter 4 Troubleshooting Our ISO9001 quality assurance system has been approved by CQC organization. For guarantee the products’ quality, reliability and stability. All of our products have been passed the testing and inspection before ship out factory. The testing and inspection scheme already covers all the Optical, Electronic and Mechanical criteria which have been published by us.
  • Page 28: Chapter 5 Packing List

    Encoder Modulator User Manual Chapter 5 Packing List Encoder Modulator 1 pcs User Manual 1 pcs HDMI Cables 4 pcs Power Cord 1pcs Page 23 / 23...
