  • Page 1 FP5000 Series User Manual FP5000-MM01-EN-PDF_02...
  • Page 2 The information provided in this documentation contains general descriptions and/or technical characteristics of the performance of the products contained herein. This documentation is not intended as a substitute for and is not to be used for determining suitability or reliability of these products for specific user applications.

  • Page 3: Table Of Contents

    FP5000 Series User Manual Table of Contents Safety Information ......About the Book....... .
  • Page 4 6.4 Front USB Cover ......... Opening the Front USB Cover.

  • Page 5: Safety Information

    FP5000 Series User Manual Safety Information Important Information NOTICE Read these instructions carefully, and look at the equipment to become familiar with the device before trying to install, operate, or maintain it. The following special messages may appear throughout this documentation or on the equipment to warn of potential hazards or to call attention to information that clarifies or simplifies a procedure.

  • Page 7: About The Book

    FP5000 Series User Manual About the Book At a Glance Document Scope This manual describes how to use this product. Validity Note This documentation is valid for this product. The technical characteristics of the device(s) described in this manual also appear online at http://www.pro-face.com.
  • Page 8 In the event the screen cannot be properly read, for example, if the backlight is not functioning, it may be difficult or impossible to identify a function. Functions that may present a hazard if not immediately executed, such as a fuel shut-off, must be provided independently of this product. The machine’s control system design must take into account the possibility of the backlight no longer functioning and the operator being unable to control the machine or making mistakes in the control of the machine.
  • Page 9 FP5000 Series User Manual WARNING UNINTENDED EQUIPMENT OPERATION Do not use this product as the only means of control for critical system functions such as motor  start/stop or power control. Do not use this equipment as the only notification device for critical alarms, such as device ...

  • Page 11: Chapter 1 Overview

    FP5000 Series User Manual Overview iDisplay_PF 12/2017 FP5000 Series User Manual Chapter 1 Overview Overview Introduction This chapter describes the panels of this product and general topics such as package contents and standards. What Is in This Chapter? This chapter contains the following topics:...

  • Page 12: Model Number Configuration

    Overview Model Number Configuration The following describes the configuration of model numbers. Digit position (model) (series) (size) (type) (LCD) (touch (power panel) supply) 6: 12.1-inch 00: Standard T: TFT P: Multi D: DC 7: 15-inch...

  • Page 13: Model Numbers

    12.1-inch FP-5600TPD PFXFP5600TPD 15-inch FP-5700TPD PFXFP5700TPD Global Code A global code is assigned to every Pro-face product as a universal model number. For more information on product models and their matching global codes, please refer to the following URL. http://www.pro-face.com/trans/en/manual/1003.html...

  • Page 14: Package Contents

    Installation gasket: 1 (attached to this product) DC power supply connector (right angle): 1 USB clamp (Type B): 1 set (1 clip and 1 tie) USB masking sticker (mini-B) FP5000 Series Installation Guide: 1 Warning/Caution Information: 1 *1 See Parts Identification and Functions (see page 27).

  • Page 15: Revision

    FP5000 Series User Manual Revision You can identify the product version (PV), revision level (RL), and the software version (SV) from the product label.

  • Page 16: Certifications And Standards

    For information on certifications and standards, such as certified models and certificates, see the product markings or the following URL: http://www.pro-face.com/trans/en/manual/1002.html Agency Certifications Schneider Electric submitted this product for independent testing and qualification by third-party listing agencies.
  • Page 17 FP5000 Series User Manual Hazardous Substances This product is a device for use in factory systems. When using this product in a system, the system should comply with the following standards in regards to the installation environment and handling: WEEE, Directive 2012/19/EU ...

  • Page 18: Federal Communication Commission Radio Frequency Interference Statement - For U.s.a

    Overview Federal Communication Commission Radio Frequency Interference Statement - For U.S.A. FCC Radio Interference Information This product has been tested and found to comply with the Federal Communications Commission (FCC) limits for a Class A digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a commercial, industrial or business environment.

  • Page 19: Hazardous Location Installation - For Usa And Canada

     ANSI/ISA 12.12.01 or CSA C22.2 N213 certification appears on the product labeling. Do not install any Pro-face or OEM components, equipment, or accessories unless these have  also been qualified as suitable for use in Class I, Division 2, Groups A, B, C, and D locations.
  • Page 20 Overview DANGER HAZARD OF ELECTRIC SHOCK, EXPLOSION, OR ARC FLASH Remove all power from the device before removing any covers or elements of the system, and  prior to installing or removing any accessories, hardware, or cables. Unplug the power cable form both this product and the power supply. ...

  • Page 21: European (Ce) Compliance

    FP5000 Series User Manual European (CE) Compliance CE Compliance Note The product described in this manual comply with the European Directives concerning Electromagnetic Compatibility and Low Voltage (CE marking) when used as specified in the relevant documentation, in application for which they are specifically intended, and in connection...

  • Page 22: Kc Markings

    Overview KC Markings...

  • Page 23: Chapter 2 Device Connectivity

    FP5000 Series User Manual Device Connectivity iDisplay_PF 12/2017 FP5000 Series User Manual Chapter 2 Device Connectivity Device Connectivity Introduction This chapter presents the equipment you can connect to this product. What Is in This Chapter? This chapter contains the following topics:...

  • Page 24: System Design

    *5 When you connect a USB (Type B) interface to the host with a USB cable, you can use the front USB (Type A) interface. *6 You can use Pro-face products. Refer to our website (http://www.pro-face.com). NOTE: When you connect more than one display to the host in the following combinations, a touch operation on one display prevents touch operations on the other.

  • Page 25: Accessories

    FP5000 Series User Manual Accessories Product name Product number Description FP-US00 Cable used for touch panel data transmission USB Cable (5 m) between a host (USB Type A) and this product (USB Type B). FP-DV01-50 DVI-D cable used to receive the image signal from DVI-D Cable (5 m) host.
  • Page 26 Device Connectivity...

  • Page 27: Chapter 3 Parts Identification And Functions

    FP5000 Series User Manual Parts Identification and Functions iDisplay_PF 12/2017 FP5000 Series User Manual Chapter 3 Parts Identification and Functions Parts Identification and Functions Introduction This chapter presents the part locations and functions. What Is in This Chapter? This chapter contains the following topics:...

  • Page 28: Fp-5600Tpd/5700Tpd

    Parts Identification and Functions FP-5600TPD/5700TPD NOTE: The figures below show FP-5600TPD. Side FP-5600TPD/5700TPD Front Rear Bottom Part Name Description Brightness sensor Brightness sensor that automatically controls the brightness of the backlight. Front USB cover USB (Type A) interface is located behind the front USB cover.

  • Page 29: Led Indications

    FP5000 Series User Manual LED Indications Status LED Color Indicator Description Green In operation LED fade Backlight is OFF (Standby Mode), or no video input signal Green/Orange Alternating Launcher is being configured (see page 81) Orange Flashing Software is starting up...
  • Page 30 Parts Identification and Functions...

  • Page 31: Chapter 4 Specifications

    FP5000 Series User Manual Specifications iDisplay_PF 12/2017 FP5000 Series User Manual Chapter 4 Specifications Specifications Introduction This chapter presents the product specifications. What Is in This Chapter? This chapter contains the following sections: Section Topic Page General Specifications Functional Specifications...

  • Page 32: General Specifications

    Specifications Section 4.1 General Specifications General Specifications What Is in This Section? This section contains the following topics: Topic Page Electrical Specifications Environmental Specifications Structural Specifications...

  • Page 33: Electrical Specifications

    FP5000 Series User Manual Electrical Specifications Specification FP-5600TPD FP-5700TPD Rated input voltage 12...24 Vdc Input voltage limits 10.8...28.8 Vdc Voltage drop 12 Vdc: 2.5 ms or less 24 Vdc: 10 ms or less Backlight ON: 100% 17 W or less...

  • Page 34: Environmental Specifications

    Specifications Environmental Specifications 0...60 C (32...140 F) Surrounding air temperature -20...60 C (-4...140 F) Storage temperature 10%...90% RH (non-condensing, wet bulb temperature 39 C [102.2 F] or Surrounding air and storage humidity less) Dust 0.1 mg/m oz/ft ) or less (non-conductive levels) Pollution degree For use in Pollution Degree 2 environment Corrosive gases...

  • Page 35: Structural Specifications

    Use Only)*/13 * On the front panel when properly installed in an enclosure and not using the front panel USB port. NOTE: The option is a front USB cover with screw by Pro-face (Model Number PFXZCDCVUS1). External W315 x H241 x D67 mm...
  • Page 36 Specifications CAUTION EQUIPMENT DAMAGE Ensure the panel is not in permanent and direct contact with oils.  Do not press on the display of this product with excessive force or with a hard object, since it  can damage the display. Also, do not press on the touch panel with a pointed object, such as the tip of a mechanical pencil or a screwdriver.

  • Page 37: Functional Specifications

    FP5000 Series User Manual Section 4.2 Functional Specifications Functional Specifications What Is in This Section? This section contains the following topics: Topic Page Display Specifications Touch Panel...

  • Page 38: Display Specifications

    Specifications Display Specifications FP-5600TPD FP-5700TPD Display type TFT Color LCD Display size 12.1-inch 15-inch Resolution 1,024 x 768 pixels (XGA) Effective display area W245.76 x H184.32 mm W304.1 x H228.1 mm (W9.68 x H7.26 in) (W11.97 x H8.98 in) Display colors 16 million colors Backlight White LED (Not user replaceable.

  • Page 39: Touch Panel

    FP5000 Series User Manual Touch Panel Touch panel type Resistive film (analog, multi-touch) Touch panel resolution 1,024 x 1,024 Touch panel service life 1 million times or more...

  • Page 40: Interface Specifications

    Specifications Section 4.3 Interface Specifications Interface Specifications What Is in This Section? This section contains the following topics: Topic Page Interface Specifications Interface Connection DVI-D Input Interface...

  • Page 41: Interface Specifications

    FP5000 Series User Manual Interface Specifications USB (Type A) interface Connector USB 2.0 (Type A) x 1 Power supply voltage 5 Vdc ±5% Maximum supply current 500 mA Maximum transmission distance 5 m (16.4 ft) USB (Type B) interface Connector USB 2.0 (Type B) x 1...

  • Page 42: Interface Connection

    Specifications Interface Connection Cable Connections DANGER POTENTIAL FOR EXPLOSION Always confirm the ANSI/ISA 12.12.01 or CSA C22.2 N213 hazardous location rating of your  device before installing or using it in a hazardous location. To apply or remove the supply power from this product installed in a Class I, Division 2 ...
  • Page 43 FP5000 Series User Manual <Type A> Circuit parameters Front USB (Type A) Open-circuit voltage = V 5.25 V Short-circuit current = I 1300 mA 265 F Associated capacitance = C 16 H Associated inductance = L <mini B> NOTE: The front USB port (mini-B) cannot be used.
  • Page 44 Consider the vibration in the environment when making this determination. Securely attach power, communication, and external accessory cables to the panel or cabinet.  Use either a USB cable by Pro-face or a commercial-type USB cable.  Use only non-incendive USB configurations.

  • Page 45: Dvi-D Input Interface

    FP5000 Series User Manual DVI-D Input Interface DANGER ELECTRIC SHOCK AND FIRE When using the SG terminal to connect an external device to this product: Verify that a short-circuit loop is not created when you set up the system. ...
  • Page 46 Specifications Recommendations: DVI-D cable by Pro-face (FP-DV01-50 <5 m>) NOTE: For noise-free operation, use the recommended DVI-D cable.  When you use a commercial-type cable, the maximum length is 5 m.  Display Resolution Resolution H. sync. V. sync. Dot clock...

  • Page 47: Chapter 5 Dimensions

    FP5000 Series User Manual Dimensions iDisplay_PF 12/2017 FP5000 Series User Manual Chapter 5 Dimensions Dimensions Introduction This chapter presents the product external dimensions. What Is in This Chapter? This chapter contains the following topics: Topic Page FP-5600TPD FP-5700TPD...

  • Page 48: Fp-5600Tpd

    Dimensions FP-5600TPD External Dimensions Front Left Bottom...
  • Page 49 FP5000 Series User Manual Dimensions with Cables *1 Rotation area of the fastener *2 Pitch of the center of installation fastener screws Right Rear Left Bottom NOTE: All the above values are designed with cable bending in mind. The dimensions given here are representative values depending on the type of connection cable in use.

  • Page 50: Fp-5700Tpd

    Dimensions FP-5700TPD External Dimensions Front Left Bottom...
  • Page 51 FP5000 Series User Manual Dimensions with Cables *1 Rotation area of the fastener *2 Pitch of the center of installation fastener screws Right Rear Left Bottom NOTE: All the above values are designed with cable bending in mind. The dimensions given here are representative values depending on the type of connection cable in use.
  • Page 52 Dimensions...

  • Page 53: Chapter 6 Installation And Wiring

    FP5000 Series User Manual Installation and Wiring iDisplay_PF 12/2017 FP5000 Series User Manual Chapter 6 Installation and Wiring Installation and Wiring Introduction This chapter describes the installation procedures and wiring principles for this product and peripheral devices. What Is in This Chapter?

  • Page 54: Installation

    When using a factory-installed front USB cover (without screw), the front surface is IP65F IP67F or Type 1 Enclosure. When using a front USB cover (with screw ) by Pro-face (Model Number PFXZCDCVUS1), the front surface is IP66F , IP67F , Type 1, Type 4X (Indoor Use Only) or Type 13 Enclosure.
  • Page 55 FP5000 Series User Manual Be sure that the surrounding air temperature and the ambient humidity are within their designated ranges. Surrounding air temperature: 0 to 60 C (32 to 140 F) (see the Environment Specifications for this product); ambient humidity: 10 to 90% RH; wet bulb temperature: maximum 39 C (102 F).
  • Page 56 Installation and Wiring You can attach a commercial-type arm or wall-mount adapter using the arm mounting holes (VESA 75 mm specification) at the back of this product. Attach the four (4) M4 attachment screws (screw length: 10 mm [0.4 in]). The torque required for these screws is 0.7 to 0.8 N•m (6.2 to 7.1 lb-in).
  • Page 57 FP5000 Series User Manual Step Action Place this product on a clean and level surface with the screen facing down. Check that the gasket of this product is seated securely into the gasket’s groove, which runs around the perimeter of the display panel frame.
  • Page 58 Installation and Wiring Step Action Using a Phillips screwdriver, gradually tighten (turn clockwise) the screws for the fasteners (top, bottom, left, and right), alternating diagonally between screws until all are secure. Be sure that the L-shaped part of the installation fastener (2 in figure below) is completely vertical.
  • Page 59 FP5000 Series User Manual Removing from the Panel DANGER HAZARD OF ELECTRIC SHOCK, EXPLOSION, OR ARC FLASH Remove all power from the device before removing any covers or elements of the system, and  prior to installing or removing any accessories, hardware, or cables.
  • Page 60 Installation and Wiring Step Action While pushing on the anti-drop lock on the top of this product with a tool such as a screwdriver, slowly remove this product from the panel. Panel Front side CAUTION RISK OF INJURY Do not drop this product when you remove it from the panel. Hold this product in place after removing the fasteners.

  • Page 61: Wiring Principles

    FP5000 Series User Manual Section 6.2 Wiring Principles Wiring Principles What Is in This Section? This section contains the following topics: Topic Page Connecting the DC Power Cord Connecting the Power Supply Grounding...

  • Page 62: Connecting The Dc Power Cord

    Installation and Wiring Connecting the DC Power Cord DANGER HAZARD OF ELECTRIC SHOCK, EXPLOSION, OR ARC FLASH Remove all power from the device before removing any covers or elements of the system, and  prior to installing or removing any accessories, hardware, or cables. Remove power before wiring this product’s power terminals.
  • Page 63 FP5000 Series User Manual *2 Items are manufactured by Phoenix Contact. Power Supply Connector Specifications: Spring Clamp Terminal Blocks This product comes with the right-angle-type power connector. NOTE: You can also use a straight-type power connector.  Right-angle type: PFXZCBCNDC2 by Pro-face.

  • Page 64: Connecting The Power Supply

    Installation and Wiring Connecting the Power Supply Precautions Excessive stress on the power connection or attempting to install this product with the power cables connected may disconnect or cause damage to the power connections. This can cause short circuits, fire or unintended equipment operation. WARNING SHORT CIRCUIT, FIRE, OR UNINTENDED EQUIPMENT OPERATION Avoid excessive force on the power cable to prevent accidental disconnection...
  • Page 65 FP5000 Series User Manual Attach a surge device to prevent damage to this product as a result of a lightning-induced power  surge from a large electromagnetic field generated from a direct lightning strike. We also strongly recommend to connect the crossover grounding wire of this product to a position close to the ground terminal of the surge protection device.

  • Page 66: Grounding

    Installation and Wiring Grounding Exclusive Grounding Always ground the FG (functional ground) terminal. Be sure to separate this product from the FG of other devices as shown below. Precautions Check that the grounding resistance is 100  or less  The FG wire should have a cross sectional area greater than 2 mm (AWG14) .

  • Page 67: Usb Cable Clamp

    Consider the vibration in the environment when making this determination. Securely attach power, communication, and external accessory cables to the panel or cabinet.  Use either a USB cable by Pro-face or a commercial-type USB cable.  Use only non-incendive USB configurations.
  • Page 68 If the provided ties are lost, you can substitute them with  PFXZFP5000USCLB1 (by Pro-face) or commercially available ties of 4.8 mm (0.19 in) width and 1.3 mm (0.05 in) thickness. While pressing the grip on the clip, insert the cable from Step 3 all the way into the USB host interface.
  • Page 69 FP5000 Series User Manual Removing USB Clamp (Type B) Remove the USB cable while pushing the grip section of the clip.

  • Page 70: Front Usb Cover

    Place your finger or a tool (such as a screwdriver) in the gap on the top of the front USB cover and pull down as illustrated. NOTE: When using the front USB cover by Pro-face (Model Number  PFXZCDCVUS1), loosen the top screw using a Phillips screwdriver.
  • Page 71 FP5000 Series User Manual Step Action The USB interface can be seen once you pull down the front USB cover. NOTICE BROKEN ENCLOSURE Do not exert more than 0.5 N•m (4.4 lb•in) of torque when tightening the screw. Failure to follow these instructions can result in equipment damage.
  • Page 72 Installation and Wiring...

  • Page 73: Chapter 7 System Specifications And Launcher

    FP5000 Series User Manual System Specifications and Launcher iDisplay_PF 12/2017 FP5000 Series User Manual Chapter 7 System Specifications and Launcher System Specifications and Launcher Introduction This chapter describes the system specifications for this product and the Launcher. What Is in This Chapter?

  • Page 74: System Specifications

    System Specifications and Launcher Section 7.1 System Specifications System Specifications What Is in This Section? This section contains the following topics: Topic Page Operating System, Drivers, Utilities Settings Workflow Installing the Drivers Installing the Utilities...

  • Page 75: Operating System, Drivers, Utilities

    7 32-bit/64-bit  ® Windows 8 32-bit/64-bit  ® Windows Embedded Standard 2009 for Pro-face products  ® Windows Embedded Standard 7 for Pro-face products  *1 For supported models, contact customer support. Dedicated drivers and utilities Dedicated drivers and utilities are required for touch input data communication between this product and the host, and adjustment of the screen display.

  • Page 76: Settings Workflow

    System Specifications and Launcher Settings Workflow Follow the steps below to configure the software. Step Action Configure the display settings from the screen properties (Screen Resolution) for your host. Install the drivers (see page 77). Install the utilities (see page 79). Configure Tablet PC (see page 87).

  • Page 77: Installing The Drivers

    FP5000 Series User Manual Installing the Drivers Communication driver Step Action Connect this product to the host with a DVI-D cable and USB cable (see page 24). ® Turn on this product and the host, and start Windows Download the drivers onto the host (see page 75).
  • Page 78 System Specifications and Launcher ® Touch panel driver (only when using Windows Step Action Connect this product to the host with a DVI-D cable and USB cable (see page 24). ® Turn on this product and the host, and start Windows Touch the screen and confirm that the curser moves.

  • Page 79: Installing The Utilities

    FP5000 Series User Manual Installing the Utilities Step Action Download the utilities onto the host. (see page 75) From the folder containing the downloaded utilities, open Drivers  Utilities. Run setup.exe, and follow the on-screen instructions to install the utilities.

  • Page 80: Launcher

    System Specifications and Launcher Section 7.2 Launcher Launcher What Is in This Section? This section contains the following topics: Topic Page About the Launcher Display Settings PC Settings...

  • Page 81: About The Launcher

    FP5000 Series User Manual About the Launcher Introduction The Launcher is a utility that displays icons to configure settings on this product with convenient touch operation. NOTE: Before using the Launcher, you need to install the required drivers and utilities. You can download the drivers and utilities from our support site at http://www.pro-...
  • Page 82 System Specifications and Launcher Icons Display Brightness Sets the backlight brightness. You can select Manual or Auto. settings When Auto is selected, a brightness sensor automatically adjusts the brightness (see page 83). Buzzer Sets the sound on/off when starting the Launcher and performing touch operations (see page 83).

  • Page 83: Display Settings

    FP5000 Series User Manual Display Settings Brightness Manual: Sets the brightness to a fixed value from 0 to 100. Auto: Automatically adjusts the brightness to the selected level using a brightness sensor. Buzzer Click Buzzer: Sets the sound on/off when you perform touch-panel operations.
  • Page 84 After you connect this product to the host, set the display parameters so that the screen can be adjusted through the Launcher. Step Action Touch or click the Launcher Set icon. In the Launcher Set dialog box, the FP5000 Series display connected to the host is displayed.
  • Page 85 Status LED NOTE: If multiple FP5000 Series displays are connected, you cannot determine through the display which number corresponds to which display. Check the status LED. Select the Screen No (screen identification number) for the display where the status LED is...
  • Page 86 LED is alternating green and orange, and touch this screen. If multiple FP5000 Series displays are connected, repeat Steps 2 to 4 for each display as required.

  • Page 87: Pc Settings

    FP5000 Series User Manual PC Settings Display ® The Windows standard setting window is displayed. For adjustment of screen contrast and black level, from Advanced settings, make the settings in the setting screen for your graphic driver. NOTE: When using Windows XP or Windows Embedded Standard 2009, for rotation settings use Standard or 180...
  • Page 88 System Specifications and Launcher...

  • Page 89: Chapter 8 Maintenance

    FP5000 Series User Manual Maintenance iDisplay_PF 12/2017 FP5000 Series User Manual Chapter 8 Maintenance Maintenance Introduction This chapter explains how to maintain this product. What Is in This Chapter? This chapter contains the following topics: Topic Page Regular Cleaning Periodic Check Points...

  • Page 90: Regular Cleaning

    Maintenance Regular Cleaning Cleaning the display NOTICE EQUIPMENT DAMAGE Power off this product before cleaning it.  Do not use hard or pointed objects to operate the touch panel as you may damage the panel  surface. Do not use paint thinner, organic solvents, or a strong acid compound to clean the unit. ...

  • Page 91: Periodic Check Points

    FP5000 Series User Manual Periodic Check Points Operation Environment Is the operating temperature within the allowable range? (0...60 C [32...140 F])  Is the operating humidity within the specified range? (10% RH to 90% RH, dry bulb temperature  of 39 C [102.2 F] or less) Is the operating atmosphere free of corrosive gasses? ...

  • Page 92: Replacing The Installation Gasket

    Maintenance Replacing the Installation Gasket Introduction The installation gasket provides protection against dust and moisture. NOTICE GASKET AGING Inspect the gasket periodically as required by your operating environment to keep the initial IP  level. Change the gasket at least once a year, or as soon as scratches or dirt become visible. ...

  • Page 93: Replacing The Backlight

    FP5000 Series User Manual Replacing the Backlight Not user replaceable. When replacement is required, contact customer support.

  • Page 94: Troubleshooting Checklist

    Maintenance Troubleshooting Checklist Introduction When a problem occurs, make sure to go through the checklist and follow the instructions given. Here are the main issues that may occur when using this product: The display is blank:  No display appears after this product is switched on ...

  • Page 95: After-Sales Service

    FP5000 Series User Manual After-sales Service For details on after-sales service, refer to our website at http://www.pro- face.com/trans/en/manual/1001.html...
