Summary of Contents for Pro-face PS-4600 Series

  • Page 1 - ...
  • Page 2 Neither Pro-face nor any of its affiliates or subsidiaries shall be responsible or liable for misuse of the information contained herein.

  • Page 3: Table Of Contents

    PS-4600 Series User Manual Table of Contents Safety Information ......About the Book ....... . .
  • Page 4 Table of Contents 8.2 AC Power Supply Unit, Battery Unit and UPS ..... AC Power Supply Unit Description and Installation ....Uninterruptible Power Supply (UPS) Battery Unit Description and Installation .

  • Page 5: Safety Information

    PS-4600 Series User Manual Safety Information § Important Information NOTICE Read these instructions carefully, and look at the equipment to become familiar with the device before trying to install, operate, or maintain it. The following special messages may appear throughout this documentation or on the equipment to warn of potential hazards or to call attention to information that clarifies or simplifies a procedure.
  • Page 6 PLEASE NOTE Electrical equipment should be installed, operated, serviced, and maintained only by qualified personnel. No responsibility is assumed by Pro-face for any consequences arising out of the use of this material. A qualified person is one who has skills and knowledge related to the construction and operation of electrical equipment and its installation, and has received safety training to recognize and avoid the hazards involved.

  • Page 7: About The Book

    PS-4600 Series User Manual About the Book At a Glance Document Scope This manual describes the configuration and usage of PS-4600 Series (Hereafter referred to as the “Industrial Personal Computer”). The configuration number format is as follows: Character Number Prefix (1-4)
  • Page 8 About the Book Character Number Prefix (1-4) Part Number Exam- PFXP Operating System None Windows Embedded Standard 2009 MUI Windows XP Pro Japanese Windows XP Pro MUI Windows Embedded Standard 7 Premium MUI (32-bit) Windows 7 Ultimate MUI (32-bit) Windows 7 Ultimate MUI (64-bit) Storage Device None CFast 4 GB...
  • Page 9 You can download these technical publications and other technical information from our website “Otasuke Pro!” at http://www.pro-face.com/otasuke/. Global Code A global code is assigned to every Pro-face product as a universal reference. For more information on product models and their matching global codes, please refer to the following URL.
  • Page 10 About the Book Product Related Information Some Industrial Personal Computers are certified for use in Class I, Division 2 hazardous locations as defined in ANSI/ISA 12.12.01 or CSA C22.2 N213. Observe the following: DANGER HAZARD OF ELECTRIC SHOCK, EXPLOSION OR ARC FLASH Remove all power from the device before removing any covers or elements of ...
  • Page 11 PS-4600 Series User Manual Operating system  Installed hardware  Installed software  WARNING UNINTENDED EQUIPMENT OPERATION Use only Pro-face software with the devices described in this manual. Failure to follow these instructions can result in death, serious injury, or equipment damage.
  • Page 12 About the Book...

  • Page 13: Part I General Overview

    Magelis Industrial Personal Computer 12” General Overview EIO0000001596 04/2013 PS-4600 Series User Manual General Overview Subject of this Part This part provides an overview of the Industrial Personal Computer products. What Is in This Part? This part contains the following chapters:...
  • Page 14 General Overview...

  • Page 15: Chapter 1 Important Information

    Magelis Industrial Personal Computer 12” Important Information EIO0000001596 04/2013 PS-4600 Series User Manual Important Information General This chapter describes specific aspects related to the operation of the Industrial Personal Computer. What Is in This Chapter? This chapter contains the following topics:...

  • Page 16: Federal Communications Commission Radio Frequency Interference Statement - For U.s.a

    Important Information Federal Communications Commission Radio Frequency Interference Statement - For U.S.A. FCC Radio Interference Information This equipment has been tested and found to comply with the Federal Communications Commission (FCC) limits for a Class A digital device, pursuant to Part 15 of the FCC Rules.

  • Page 17: Qualified Personnel

    PS-4600 Series User Manual Qualified Personnel General Only qualified personnel can install, operate, and maintain the product. A qualified person is one who has skills and knowledge related to the construction, operation, and installation of electrical equipment, and has received safety training to recognize and avoid the hazards involved.

  • Page 18: Certifications And Standards

    Important Information Certifications and Standards Agency Certifications Pro-face submitted this product for independent testing and qualification by third- party agencies. These agencies have certified this product as meeting the following standards: Underwriters Laboratories Inc., UL 508 and CSA C22.2 N142, Industrial Control Equipment Underwriters Laboratories Inc., ANSI/ISA 12.12.01 and CSA C22.2 N213,...
  • Page 19 PS-4600 Series User Manual Hazardous Substances This product is compliant with: WEEE, Directive 2012/19/EU  RoHS, Directive 2011/65/EU  RoHS China, Standard SJ/T 11363-2006  REACH regulation EC 1907/2006  End of Life (Battery) The product contains electronic boards. It must be disposed of in specific treatment channels.

  • Page 20: European (Ce) Compliance

    Important Information European (CE) Compliance CE Compliance Note The products described in this manual comply with the European Directives concerning Electromagnetic Compatibility and Low Voltage (CE marking) when used as specified in the relevant documentation, in applications for which they are specifically intended, and in connection with approved third-party products.

  • Page 21: Hazardous Location Installations - For Usa And Canada

    ANSI/ISA 12.12.01 or CSA C22.2 N213 certification appears on the product labeling. Do not install any Pro-face or OEM components, equipment, or accessories  unless these have also been qualified as suitable for use in Class I, Division 2, Groups A, B, C, and D locations.
  • Page 22 Important Information DANGER POTENTIAL FOR EXPLOSION Always confirm the ANSI/ISA 12.12.01 and CSA C22.2 N213 hazardous  location rating of your device before installing or using it in a hazardous location. To power on or power off a Industrial Personal Computer installed in a Class I, ...
  • Page 23 PS-4600 Series User Manual Power Switch DANGER HAZARD OF ELECTRIC SHOCK, EXPLOSION OR ARC FLASH Remove all power from the device before removing any covers or elements of  the system, and prior to installing or removing any accessories, hardware, or cables.
  • Page 24 Important Information Cable Connections DANGER POTENTIAL FOR EXPLOSION Always confirm the ANSI/ISA 12.12.01 and CSA C22.2 N213 hazardous  location rating of your device before installing or using it in a hazardous location. To power on or power off a Industrial Personal Computer installed in a Class I, ...
  • Page 25 PS-4600 Series User Manual Operation and Maintenance The systems have been designed for compliance with relevant spark ignition tests for front USB connection only. DANGER POTENTIAL FOR EXPLOSION In addition to the other instructions in this manual, observe the following rules when...
  • Page 26 Important Information...

  • Page 27: Chapter 2 Physical Overview

    Magelis Industrial Personal Computer 12” Physical Overview EIO0000001596 04/2013 PS-4600 Series User Manual Physical Overview Subject of this Chapter This chapter provides a physical overview of the Industrial Personal Computer. What Is in This Chapter? This chapter contains the following topics:...

  • Page 28: Package Contents

    Physical Overview Package Contents Items The following items are included in the package of the Industrial Personal Computer. Before using the Industrial Personal Computer, confirm that all items listed here are present: Industrial Personal Computer: 1 Installation Fasteners: 10 per set only for Standard Models. ...
  • Page 29 PS-4600 Series User Manual DC Terminal Block (For the DC Industrial Personal Computer only) AC Terminal Block (For the AC Industrial Personal Computer only) This Industrial Personal Computer has been carefully packed, with special attention to quality. However, should you find anything damaged or missing, contact your...

  • Page 30: Industrial Personal Computer - Description

    Physical Overview Industrial Personal Computer - Description Introduction The following Industrial Personal Computer 12" - description shows the port interfaces, the expansion slots, the Slide-in Disk, the CFast slot and the power supplies. During operation, surface temperatures of the heat sink may reach more than 70 C (158 F).
  • Page 31 PS-4600 Series User Manual NOTICE UNINTENDED EQUIPMENT OPERATION Do not use the front USB while the machine is in operation.  Always keep the cover in place during normal operation.  Failure to follow these instructions can result in equipment damage.
  • Page 32 Physical Overview Top View Location for optional fan necessary for the operation with HDD storage device into Slide- in Disk Bottom View USB2 USB1 ETH1 (10/100/1000 MBit) ETH2 (10/100/1000 MBit) USB3 USB4 DVI-I MIC, Line IN, Line out COM2 10 COM1 11 Add-on interface module slot 2 (IF2) 12 Add-on interface module slot 1 (IF1) 13 Ground connection...

  • Page 33: Industrial Personal Computer Led And Push Button Description

    NOTE: Modifying products to install an HDD into a Slide-in Disk when it was not installed from factory, requires to change the unit firmware settings for proper behavior of the fan (that are required when running with HDD into a Slide-in Disk) - Please contact Pro-face support if you want to proceed such modification.
  • Page 34 Physical Overview Status LED The following table describes the meaning of the status LEDs on the Industrial Personal Computer: Color State Meaning [Power] Green Supply voltage is OK. Flashing The device has booted, the battery status is low. The data buffering is provided for approximately 500 hours from the point when the battery ca- pacity is recognized as insufficient.

  • Page 35: Chapter 3 Characteristics

    Magelis Industrial Personal Computer 12” Characteristics EIO0000001596 04/2013 PS-4600 Series User Manual Characteristics Subject of this Chapter This chapter lists the product characteristics. What Is in This Chapter? This chapter contains the following topics: Topic Page Industrial Personal Computer Characteristics...

  • Page 36: Industrial Personal Computer Characteristics

    NOTE: Modifying products to install an HDD into a Slide-in Disk when it was not installed from factory, requires to change the unit firmware settings for proper behavior of the fan (that are required when running with HDD into a Slide-in Disk) - Please contact Pro-face support if you want to proceed such modification.
  • Page 37 NOTE: Modifying products to install an HDD into a Slide-in Disk when it was not installed from factory, requires to change the unit firmware settings for proper behavior of the fan (that are required when running with HDD into a Slide-in Disk) - Please contact Pro-face support if you want to proceed such modification.
  • Page 38 Characteristics Display Characteristics Element 12" Screen Size Graphics XGA TFT active matrix (1024 x 768 pixels) Number of Colors 16 million Brightness Control Step less adjustment Touch Sensitive Analog resistive film, resolution 4,096 x 4,096 Screen LED - Life span > 50,000 h @ 25 C (77 F) Backlight Multiple touch operation on the Industrial Personal Computer having analog- resistive touch panel may cause unexpected input around the center of touched...
  • Page 39 PS-4600 Series User Manual Operating Systems Element Characteristics HDD or SSD: Windows® XP Professional SP3/Windows® 7 Ultimate Operating System CFast : Windows® Embedded Standard 2009/Windows® Embed- ded Standard 7 Premium *1 For details on languages supported by pre-installed operating systems, read "The List of OS Pre-installed Languages for Multi-language"...
  • Page 40 —   Slovenian —   Spanish     Swedish    Thai —   Turkish    Ukrainian — —  *1 The languages can be downloaded from Pro-face website "Otasuke Pro!". http://www.pro-face.com/otasuke/...

  • Page 41: Industrial Personal Computer Interface Characteristics

    PS-4600 Series User Manual Industrial Personal Computer Interface Characteristics Serial Interface Element Characteristics Amount Type RS-232C, modem-capable, not electrically isolated UART 16550-compatible, 16-byte FIFO Transfer Rate Maximum 115 kbps Connection D-Sub 9 pin, plug (see page 68) USB Interface Element Characteristics USB 2.0...

  • Page 42: Environmental Characteristics

    Characteristics Environmental Characteristics Characteristics The environmental characteristics of the Industrial Personal Computer are as follows: Characteristics Value Standards Degree of Protection IP65, Type 4X (Indoor use only) IEC60529, UL50E when the front USB cover is closed on  the models except for Rear Mount Model Pollution Degree For use in Pollution Degree 2 environment EN/IEC 61131-2...

  • Page 43: Chapter 4 Dimensions/Assembly

    Magelis Industrial Personal Computer 12” Dimensions/Assembly EIO0000001596 04/2013 PS-4600 Series User Manual Dimensions/Assembly Subject of this Chapter This chapter describes Industrial Personal Computer dimensions and installation panels. What Is in This Chapter? This chapter contains the following topics: Topic Page...

  • Page 44: Industrial Personal Computer Dimensions

    Dimensions/Assembly Industrial Personal Computer Dimensions Standard Models - 0, 1 and 2 Slot Dimensions The figure shows the dimensions of the Industrial Personal Computer 12": 59,5 1.30 9.72 2.34 0.35 0.14 14,5 12.32 0.57 11.81 0.26 8.86 NOTE: Measurement “A” depends on the number of slot PCI/PCIe cards (see page 45).
  • Page 45 PS-4600 Series User Manual Values The table provides the “A” measurement value: Industrial Personal Computer 12” “A” Value 0 slot Industrial Personal Computer 59.5 mm (2.342 in.) 1 slot Industrial Personal Computer 114.2 mm (4.496 in.) 2 slots Industrial Personal Computer 134.5 mm (5.295 in.)
  • Page 46 Dimensions/Assembly Rear Mount Model - 0, 1 and 2 Slot Dimensions The figure shows the dimensions of the 12" Rear Mount Model : 11.50 5.75 ø5 (2x) ø6 (4x) 0.08 1x45° 1x45° (Touch Panel active area) 9.69 0.10 Center of the display 245.76 (LCD active area)
  • Page 47 PS-4600 Series User Manual Values The table provides the “A” measurement value: Industrial Personal Computer 12” “A” Value 0 slot Industrial Personal Computer 67 mm (2.637 in.) 1 slot Industrial Personal Computer 121.7 mm (4.791 in.) 2 slots Industrial Personal Computer 142 mm (5.591 in.)

  • Page 48: Installation Requirements

    Dimensions/Assembly Installation Requirements Important Mounting Information Overheating can cause incorrect software behavior, therefore: Ensure that environmental characteristics (see page 42) are respected.  The Industrial Personal Computer is only permitted for operation in closed rooms.  The Industrial Personal Computer vent holes must not be covered. ...
  • Page 49 PS-4600 Series User Manual Spacing Requirements In order to provide sufficient air circulation, mount the Industrial Personal Computer so that the spacing on the top, bottom, and sides is as follows: Top, Bottom and Rear Left and Right Sides Sides...
  • Page 50 Dimensions/Assembly Panel Cut Dimensions For cabinet installation, you need to cut the correct sized opening in the installation panel. The dimensions of the opening for installing the Industrial Personal Computer are shown below: Standard Models Installation panel 301.5 +1/0 mm (11.87 +0.04/0 in.) 227.5 +1/0 mm (8.96 +0.04/0 in.) 1.6...9 mm (0.06...0.35 in.) Rear Mount Models...
  • Page 51 PS-4600 Series User Manual NOTE: Ensure the thickness of the installation panel is from 1.6 to 9 mm  (0.06 to 0.35 in.). (For Rear Mount Model, the thickness must be exactly 2.3 mm [0.09 in.].) All installation panel surfaces should be strengthened. Give due consideration to ...

  • Page 52: Industrial Personal Computer Installation

    Dimensions/Assembly Industrial Personal Computer Installation Vibration and Shocks Take extra care with respect to vibration levels when installing or moving the Industrial Personal Computer. If the Industrial Personal Computer is moved, for example, while it is installed in a rack equipped with caster wheels, it can receive excessive shock and vibration.
  • Page 53 PS-4600 Series User Manual Installing the Industrial Personal Computer Unit The installation gasket and installation fasteners are required when installing the Industrial Personal Computer. CAUTION OVERTORQUE AND LOOSE HARDWARE Do not exert more than 0.5 Nm (4.5 lb-in) of torque when tightening the ...
  • Page 54 Dimensions/Assembly Rear Mount Models Step Action Check that the gasket is correctly attached to the Industrial Personal Computer. NOTE: When checking the gasket, avoid contact with the sharp edges of the Industrial Personal Computer frame, and insert it completely into its groove. Insert the Industrial Personal Computer into the back of the smooth, flat installation panel opening (see page 50).

  • Page 55: Part Ii Implementation

    Magelis Industrial Personal Computer 12” Implementation EIO0000001596 04/2013 PS-4600 Series User Manual Implementation Subject of this Part This part describes setting up the product. What Is in This Part? This part contains the following chapters: Chapter Chapter Name Page Getting Started...
  • Page 56 Implementation...

  • Page 57: Chapter 5 Getting Started

    Magelis Industrial Personal Computer 12” Getting Started EIO0000001596 04/2013 PS-4600 Series User Manual Getting Started First Power-up License Agreement Limitations on your usage of the Windows Operating System are noted in ® Microsoft’s End User License Agreement (EULA). Read this document before first powering-up.
  • Page 58 Getting Started Newly installed applications.  Newly installed peripherals.  Newly created or modified user accounts.  Network configuration changes (for example, IP address, default gateway, and so  on). Operating System customizations (for example, background pictures, and so on). ...

  • Page 59: Chapter 6 Industrial Personal Computer Connections

    Magelis Industrial Personal Computer 12” Industrial Personal Computer Connections EIO0000001596 04/2013 PS-4600 Series User Manual Industrial Personal Computer Connections Subject of this Chapter This chapter describes the connection of the Industrial Personal Computer to the main power supply. It also describes the USB ports and identifies the serial interface pin assignment.

  • Page 60: Grounding

    Industrial Personal Computer Connections Grounding Overview The grounding resistance between the Industrial Personal Computer ground and the ground must be 100  or less. When using a long grounding wire, check the resistance and, if required, replace a thin wire with a thicker wire and place it in a duct.
  • Page 61 PS-4600 Series User Manual Shared Ground Allowed If a dedicated ground is not possible, use a shared ground, as shown below: Industrial Personal Computer Shared Ground not Allowed Do not connect the Industrial Personal Computer to ground through other devices...
  • Page 62 Industrial Personal Computer Connections Grounding Procedure The Industrial Personal Computer ground has 2 connections: DC Supply voltage (see page 65) or AC Supply voltage (see page 67)  Ground connection pin  Ground connection pin (functional earth connection pin) Supply voltage Grounding strip Switching cabinet When grounding, follow the procedure below:...
  • Page 63 PS-4600 Series User Manual Grounding I/O Signal Lines DANGER POTENTIAL FOR EXPLOSION Always confirm the ANSI/ISA 12.12.01 and CSA C22.2 N213 hazardous  location rating of your device before installing or using it in a hazardous location. To power on or power off a Industrial Personal Computer installed in a Class I, ...

  • Page 64: Connecting The Dc Power Cord

    Industrial Personal Computer Connections Connecting the DC Power Cord Precaution When connecting the power cord to the power connector on the Industrial Personal Computer, first ensure that the power cord is disconnected from the DC power supply. DANGER HAZARD OF ELECTRIC SHOCK, EXPLOSION OR ARC FLASH Remove all power from the device before removing any covers or elements of ...
  • Page 65 PS-4600 Series User Manual Wiring and Connecting the Terminal Block The table below describes how to connect the power cord to the DC Industrial Personal Computer: Step Action Remove all power from the Industrial Personal Computer and confirm that the DC power supply has been disconnected from its power source.

  • Page 66: Connecting The Ac Power Cord

    Industrial Personal Computer Connections Connecting the AC Power Cord Precaution When connecting the power cord to the power connector on the Industrial Personal Computer, first ensure that the power cord is disconnected from the AC power supply. DANGER HAZARD OF ELECTRIC SHOCK, EXPLOSION OR ARC FLASH Remove all power from the device before removing any covers or elements of ...
  • Page 67 PS-4600 Series User Manual Wiring and Connecting the Terminal Block The table below describes how to connect the power cord to the AC Industrial Personal Computer: Step Action Confirm that the power cord is unplugged from the power supply. Remove the AC terminal block from the power connector and connect the power cord to the AC terminal block as shown below: Use 75 °C (167 °F) wire.

  • Page 68: Industrial Personal Computer Interface Connections

    Industrial Personal Computer Connections Industrial Personal Computer Interface Connections Introduction The information below describes usage of the interface connections of the Industrial Personal Computer in Class I, Division 2 Groups A, B, C, and D hazardous locations. DANGER POTENTIAL FOR EXPLOSION Always confirm the ANSI/ISA 12.12.01 and CSA C22.2 N213 hazardous ...
  • Page 69 PS-4600 Series User Manual Front USB Connections Non-incendive equipment (keyboards, mouse) are permitted for use on the Industrial Personal Computer (Associated Non-incendive Field Wiring Apparatus) front USB 5. In addition to being non-incendive, any equipment connected to the front USB 5 must satisfy the following criteria.
  • Page 70 Industrial Personal Computer Connections 3. If the electrical parameters of the cable are unknown, the following values may be used: = 196.85 pF/m (60 pF/ft)  cable = 0.656 H/m (0.20 H/ft)  cable 4. Wiring methods must be in accordance with the electrical code of the country in use.
  • Page 71 PS-4600 Series User Manual The table shows the D-Sub 9 pin assignments: Assignment D-Sub 9 pin plug connector: Any excessive weight or stress on communication cables may disconnect the equipment. CAUTION LOSS OF POWER Ensure that communication connections do not place excessive stress on the ...
  • Page 72 Industrial Personal Computer Connections...

  • Page 73: Chapter 7 Configuration Of The Bios

    Magelis Industrial Personal Computer 12” Configuration of the BIOS EIO0000001596 04/2013 PS-4600 Series User Manual Configuration of the BIOS What Is in This Chapter? This chapter contains the following topics: Topic Page BIOS Options Main Menu Advanced Menu - PCI and PCIe configuration - USB Configuration...

  • Page 74: Bios Options

    BIOS stands for “Basic Input Output System”. It is the most basic communication between the user and the hardware. The BIOS used in the Industrial Personal Computer is produced by Pro-face. The BIOS Setup Utility lets you modify basic system configuration settings. These settings are stored in CMOS and in an EEPROM (as a backup).
  • Page 75 PS-4600 Series User Manual Function Displays the boot menu. Lists all bootable devices that are connected to the system. Use the up cursor  and down cursor  and then press the [Enter] key to select the boot device. Pause Pressing the [Pause] key stops the POST.
  • Page 76 Configuration of the BIOS You can use the following keys after entering the BIOS setup: Function General help. Cursor  Moves to the previous item. Cursor  Goes to the next item. Cursor  Moves to the previous item. Cursor  Goes to the next item.

  • Page 77: Main Menu

    PS-4600 Series User Manual Main Menu Main Menu When you press the [DEL] key during startup, the Main BIOS setup menu appears. The figure shows the Main menu: The table shows the Main menu setting options: BIOS Setting Description Setting Op-...
  • Page 78 Configuration of the BIOS Platform Information The figure shows the Main submenu:...
  • Page 79 PS-4600 Series User Manual The table shows the Platform Information menu setting options: BIOS Setting Description Setting Options Effect Processor Information Name Displays the processor architecture. None – Brand String Displays the processor type. Frequency Displays the processor frequency. Processor ID Displays the processor ID.

  • Page 80: Advanced Menu - Pci And Pcie Configuration - Usb Configuration

    Configuration of the BIOS Advanced Menu - PCI and PCIe configuration - USB Configuration Advanced Menu The table shows the accessible submenus from the Advanced menu: BIOS Setting Description Setting Options Effect Graphics Configuration Configures graphics settings. Enter Opens submenu OEM Features Configuration of OEM features.
  • Page 81 PS-4600 Series User Manual Advanced PCI Configuration The table shows the Advanced PCI Configuration setting options: BIOS Setting Description Setting Op- Effect tions Above 4G De- Option to enable/disable 64-bit capable de- Disabled Disables this function. coding vices to decode those in the address space Enabled Enables this function.
  • Page 82 Configuration of the BIOS Advanced PIRQ Routing & IRQ Reservation The table shows the Advanced PIRQ routing & IRQ reservation options: BIOS Setting Description Setting Op- Effect tions PIRQA Option for setting the PIRQ A. Auto Automatic assignment by the BIOS and operating system.
  • Page 83 PS-4600 Series User Manual BIOS Setting Description Setting Op- Effect tions PIRQE Option for setting the PIRQ E. Auto Automatic assignment by the BIOS and operating system. IRQ3, IRQ4, Manual assignment. IRQ5, IRQ6, IRQ10, IRQ11, IRQ14, IRQ15 PIRQF Option for setting the PIRQ F.
  • Page 84 Configuration of the BIOS Advanced PCI Express Configuration Menu The table shows the Advanced PCI Express Configuration Menu options: BIOS Setting Description Setting Op- Effect tions PCI Express Configuration of the PCI Express settings. Enter Opens the submenu. Settings PCI Express Configuration of the PCI Express GEN 2 Enter Opens the submenu.
  • Page 85 PS-4600 Series User Manual Advanced PCI Express Settings The table shows the Advanced PCI Express Settings options: BIOS Setting Description Setting Options Effect Relaxed Order- Option to activate/deactivate relaxed Disabled Disables this function. ordering. Enabled Enables this function. Extended Tag...
  • Page 86 Configuration of the BIOS BIOS Setting Description Setting Options Effect Link Training Option to define how many microsec- 10...1000 Time setting in µs. Timeout (µs) onds the software waits before the link training bit in the link status register is queried.
  • Page 87 PS-4600 Series User Manual BIOS Setting Description Setting Op- Effect tions AtomicOp Re- Option to enable/disable the AtomicOp re- Disabled Disables this function. quester Enable quester. Enabled Enables this function. AtomicOp que- ries are only initiated when the bus master enable bit is set in the com- mand register.
  • Page 88 Configuration of the BIOS Advanced PCI Express Graphics (PEG) Port The table shows the Advanced PCI Express Graphics (PEG) Port options: BIOS Setting Description Setting Op- Effect tions PCI Express Option to set the PCI Express Graphics Disabled Internal PEG interface devices are Graphics (PEG) port.
  • Page 89 PS-4600 Series User Manual BIOS Setting Description Setting Op- Effect tions Option for setting a power-saving function Disabled Disables this function. PEG0 ASPM for the PEG0 port if it does not require full Auto Automatic assignment by the BIOS power.
  • Page 90 Configuration of the BIOS BIOS Setting Description Setting Op- Effect tions Option for setting the L0 power-saving Disabled Disables this function. ASPM L0s function. Root port Enables the power-saving function only for the root port. Endpoint Enables the power-saving function only for the endpoint port.
  • Page 91 PS-4600 Series User Manual Advanced PCI Express Root Port WARNING UNGUARDED MACHINERY CAN CAUSE SERIOUS INJURY Defining improper settings can cause instability or device problems. It is therefore, we strongly recommended that these settings only be changed by experienced users.
  • Page 92 Configuration of the BIOS BIOS Setting Description Setting Op- Effect tions Fatal error reporting Enabled Enables this function. Option for reporting fatal errors detected. Disabled Disables this function. All of the functions in a multifunction device is monitored. The report for the root port takes place internally inside the root com- plex.
  • Page 93 PS-4600 Series User Manual BIOS Setting Description Setting Op- Effect tions Extra Bus Re- Option for setting extra bus reserved for 0...7 – served bridges behind this root bridge. Reserved Mem- Option for setting reserved memory for this 0...20 –...
  • Page 94 Configuration of the BIOS BIOS Setting Description Setting Op- Effect tions xHCI Mode Option for setting the xHCI controller. Smart auto The USB 3.0 ports are not han- dled as USB 3.0 until after the operating system has started. Before that they are handled as USB 2.0 ports.
  • Page 95 PS-4600 Series User Manual BIOS Setting Description Setting Op- Effect tions Per port USB Dis- Option to enable/disable individual USB Enter Opens the submenu. able Control ports. Legacy USB support Option for setting legacy USB support. USB Enabled Enables this function.
  • Page 96 Configuration of the BIOS Advanced Per Port USB Disable Control The table shows the Per Port USB Disable Control options: BIOS Setting Description Setting Op- Effect tions USB Port num- Option to enable/disable the USB4 port. Disabled Disables the USB port. ber 0 Enabled Enables the USB port.
  • Page 97 PS-4600 Series User Manual Advanced Per Port Legacy USB Support Control The table shows the Per Port Legacy USB Support Control options: BIOS Setting Description Setting Op- Effect tions USB0 Port Lega- Option to enable/disable legacy support for Disabled Disables the USB port.

  • Page 98: Boot Menu

    Configuration of the BIOS Boot Menu Boot Menu The table shows the Boot menu setting options: BIOS Setting Description Setting Options Effect Boot Device Pri- Configuration of boot Enter Opens the submenu Boot Device ority order. Priority (see page 99). Boot Configura- Configuration of boot Enter...
  • Page 99 PS-4600 Series User Manual Boot Device Priority Settings The table shows the Boot Priority Selection setting options: BIOS Setting Description Setting Options Effect NOTE: Only devices that are Boot Priority Se- You can define the Device based lection drive used to boot up recognized by the system are the machine.
  • Page 100 Configuration of the BIOS BIOS Setting Description Setting Op- Effect tions Storage Option Option to boot from storage option Do not launch Does not boot from storage option ROM Launch ROM. ROM. Policy UEFI ROM only Boots from UEFI ROM. Legacy ROM Boots from legacy ROM.

  • Page 101: Security Menu

    PS-4600 Series User Manual Security Menu Security Menu The table shows the Security menu setting options: BIOS Setting Description Setting Options Effect Administrator Pass- Function to enter/change Enter Enter password. word the administrator pass- word. Hard Disk Security User Passwords...
  • Page 102 Configuration of the BIOS Hard Disk Security Master Passwords BIOS Setting Description Setting Options Effect Primary Slave HDD With a valid user password, you can Enter Enter password. Master Password change or configure hard drives without rebooting the device.

  • Page 103: Exit Menu

    PS-4600 Series User Manual Exit Menu Exit Menu The table shows the Exit menu setting options: BIOS Setting Description Setting Op- Effect tions Save Changes BIOS setup is closed with this item. Yes/No and Exit Changes made are saved in CMOS after confirmation.
  • Page 104 Configuration of the BIOS The switch positions at delivery represents the optimum BIOS default values and should not be changed.

  • Page 105: Chapter 8 Hardware Modifications

    Magelis Industrial Personal Computer 12” Hardware Modifications EIO0000001596 04/2013 PS-4600 Series User Manual Hardware Modifications Subject of this Chapter This chapter is about the hardware modifications for the Industrial Personal Computer. You can use optional units, main memory and CFast cards manufactured by Pro- face, as well as commercial devices and boards with this product.

  • Page 106: Before Modifications

    Hardware Modifications Before Modifications Before Modifications Overview DANGER HAZARD OF ELECTRIC SHOCK, EXPLOSION OR ARC FLASH Remove all power from the device before removing any covers or elements of  the system, and prior to installing or removing any accessories, hardware, or cables.
  • Page 107 PS-4600 Series User Manual WARNING RISK OF BURNS Do not touch the surface of the heat sink during operation. Failure to follow these instructions can result in death, serious injury, or equipment damage. CAUTION OVERTORQUE AND LOOSE HARDWARE Do not exert more than 0.5 Nm (4.5 lb-in) of torque when tightening the ...

  • Page 108: Ac Power Supply Unit, Battery Unit And Ups

    Hardware Modifications AC Power Supply Unit, UPS Battery Unit Overview This section describes the AC Power Supply Module, the UPS Battery Unit and the UPS principle. What Is in This Section? This section contains the following topics: Topic Page AC Power Supply Unit Description and Installation Uninterruptible Power Supply (UPS) Battery Unit Description and Installation...

  • Page 109: Ac Power Supply Unit Description And Installation

    PS-4600 Series User Manual AC Power Supply Unit Description and Installation Overview The AC Power Supply Unit can optionally be mounted on the Industrial Personal Computer to allow the Industrial Personal Computer to be operated with 100...240 Vac. The figure shows a Industrial Personal Computer equipped with the AC Power...
  • Page 110 Hardware Modifications AC Power Supply Unit Description The table gives the technical data of the AC Power Supply Unit integrated in the Industrial Personal Computer: Features Values Nominal Input Voltage 100...240 Vac Frequency 50/60 Hz Starting Current < 20 A (cold restart, 100% load and 100 Vac) Power Failure Bypass >...
  • Page 111 PS-4600 Series User Manual Installing the AC Power Supply Unit Before installing a AC Power Supply Unit, shut down Windows® in an orderly fashion and remove all power from the device. DANGER HAZARD OF ELECTRIC SHOCK, EXPLOSION OR ARC FLASH Remove all power from the device before removing any covers or elements of ...
  • Page 112 Hardware Modifications Step Action The AC Power Supply Unit can now be moved parallel to the Industrial Personal Computer in the direction indicated by the arrows in the figure below: Plug the power supply plug into the socket on the Industrial Personal Computer. Be sure that the housing is parallel and the plug on the AC Power Supply Unit is insert- ed in the socket on the Industrial Personal Computer.
  • Page 113 PS-4600 Series User Manual CAUTION OVERTORQUE AND LOOSE HARDWARE Do not exert more than 0.5 Nm (4.5 lb-in) of torque when tightening the  installation fastener, enclosure, accessory, or terminal block screws. Tightening the screws with excessive force can damage the plastic installation fastener.
  • Page 114 Hardware Modifications Step Action Remove the 4 Torx screws (T20) showed in the following figure: The AC Power Supply Unit can now be moved parallel to the Industrial Personal Computer in the direction indicated by the arrows in the figure below: CAUTION OVERTORQUE AND LOOSE HARDWARE Do not exert more than 0.5 Nm (4.5 lb-in) of torque when tightening the...

  • Page 115: Uninterruptible Power Supply (Ups) Battery Unit Description

    PS-4600 Series User Manual Uninterruptible Power Supply (UPS) Battery Unit Description and Installation Overview WARNING EXPLOSION, FIRE, OR CHEMICAL HAZARD Handling and storage: Store in cool, dry and well ventilated rooms with impermeable surfaces and  appropriate containment in case of leakage.
  • Page 116 Hardware Modifications UPS Principle With the optional integrated UPS Interface Board, the Industrial Personal Computer system completes write operations even after a power loss. When the UPS Interface Board detects a power loss, it switches to battery operation immediately without interruption.
  • Page 117 PS-4600 Series User Manual UPS Battery Unit Description The UPS Battery Unit is subject to wear and should be replaced regularly (at least following the specified life span). The figure shows the UPS Battery Unit: The table provides the technical data on the UPS Battery Unit:...
  • Page 118 Hardware Modifications The figure shows the dimensions of the UPS battery unit:...
  • Page 119 PS-4600 Series User Manual UPS Connection Cable The UPS connection cable has two different shapes of 4-pin connectors to help prevent a cable connector from being inserted in the incorrect connector (UPS battery or Industrial Personal Computer side). The table provides the technical data for the UPS connection cable:...
  • Page 120 Hardware Modifications Installing Instructions Before installing The UPS system, shut down Windows® in an orderly fashion and remove all power from the device. DANGER HAZARD OF ELECTRIC SHOCK, EXPLOSION OR ARC FLASH Remove all power from the device before removing any covers or elements of ...
  • Page 121 PS-4600 Series User Manual Step Action Connect the UPS Connection Cable to the UPS Battery Unit, whereby the red and black wires are connected to the supply voltage (orange screw clamp terminal block). Be sure to use the right connection terminals (red wire for +; black wire for -).
  • Page 122 Hardware Modifications Drilling Template of UPS Battery Unit For mounting the UPS Battery Unit, use the following figure as the drilling template:...

  • Page 123: Interface Modules

    PS-4600 Series User Manual Interface Modules Overview This section describes the 3 interface modules and of the installation. What Is in This Section? This section contains the following topics: Topic Page Interface Module Installation COM Expansion Board Description UPS Interface Board Description...

  • Page 124: Interface Module Installation

    Hardware Modifications Interface Module Installation Overview Before installing or removing an interface module, shut down Windows® in an orderly fashion and remove all power from the device. DANGER HAZARD OF ELECTRIC SHOCK, EXPLOSION OR ARC FLASH Remove all power from the device before removing any covers or elements of ...
  • Page 125 PS-4600 Series User Manual Interface Module Position The figure shows the slot positions: Slot 2 (IF2) Slot 1 (IF1) NOTE: Take into account the interface module restrictions as identified in the table below. After replacing or installing an interface module, restore BIOS default settings via Exit Menu (see page 103).
  • Page 126 Hardware Modifications Interface Module Installation NOTICE ELECTROSTATIC DISCHARGE Take the necessary protective measures against electrostatic discharge before attempting to remove the Industrial Personal Computer cover. Failure to follow these instructions can result in equipment damage. NOTE: Be sure to remove all power before attempting this procedure. The table describes how to install an interface module: Step Action...
  • Page 127 PS-4600 Series User Manual Step Action Remove the marked Torx screws (T10) and slot cover: Insert the interface module in the slot and fasten it to the Industrial Personal Computer with 2 Torx screws (T10): NOTE: The recommended torque to tighten these screws is 0.5 Nm (4.5 lb-in).
  • Page 128 Hardware Modifications CAUTION OVERTORQUE AND LOOSE HARDWARE Do not exert more than 0.5 Nm (4.5 lb-in) of torque when tightening the  installation fastener, enclosure, accessory, or terminal block screws. Tightening the screws with excessive force can damage the plastic installation fastener. When installing or removing screws, ensure that they do not fall inside the ...

  • Page 129: Com Expansion Board Description

    PS-4600 Series User Manual COM Expansion Board Description Overview The figure shows the COM Expansion Board: Switch A terminating resistor for the serial interface is already integrated on the interface module. There is a switch to connect or disconnect the terminating resistor, but the Industrial Personal Computer unit needs to be opened in order to reach it.
  • Page 130 Hardware Modifications Cable Serial Interface The table provides the technical data of the cable serial interface: Element Characteristics Signal Lines Cable cross section RS232 4 x 0.16 mm² (26 AWG), tinned Cu. wire Cable cross section RS422 4 x 0.25 mm² (24 AWG), tinned Cu. wire Cable cross section RS485 4 x 0.25 mm²...
  • Page 131 PS-4600 Series User Manual The table shows the D-Sub 9 pin assignments: Assignment RS232 RS422/485 D-Sub9 pin plug connector: N.C. TXD\ N.C. N.C. N.C. N.C. RXD\ N.C. N.C. N.C. Any excessive weight or stress on communication cables may disconnect the equipment.

  • Page 132: Ups Interface Module Description

    Hardware Modifications UPS Interface Board Description Overview The figure shows the UPS Interface Board: UPS Interface Module Description NOTE: The UPS Interface Board can only be operated in interface module slot 1 (see page 126). The table provides the technical data for the UPS Interface Board integrated in the Industrial Personal Computer: Features Values...

  • Page 133: Slot Expansion

    PS-4600 Series User Manual Slot Expansion Overview This section shows the installation of the slot expansion. It describes the Slide-in Slot, the Slide-in Disk drive and the PCI/PCIE cards. What Is in This Section? This section contains the following topics:...

  • Page 134: Slot Expansion Installation

    Hardware Modifications Slot Expansion Installation Overview Before installing a slot expansion, shut down Windows® in an orderly fashion and remove all power from the device. DANGER HAZARD OF ELECTRIC SHOCK, EXPLOSION OR ARC FLASH Remove all power from the device before removing any covers or elements of ...
  • Page 135 PS-4600 Series User Manual NOTE: This procedure describes how to install a slot expansion with 1 or 2 slots. The table below describes how to install a slot expansion: Step Action Disconnect the power cord to the Industrial Personal Computer.
  • Page 136 Hardware Modifications Step Action Mount the slot expansion on the rear side of the Industrial Personal Computer, using the Torx screws (T20) included in the delivery: NOTE: The recommended torque to tighten these screws is 1.2 Nm (10.6 lb-in).
  • Page 137 PS-4600 Series User Manual Step Action Install the side cover on the slot expansion using the 4 marked Torx screws (T10) (2 were removed and 2 are included in the delivery): The Industrial Personal Computer can now be mounted back in the control cab- inet, see Industrial Personal Computer Installation (see page 52).

  • Page 138: Slide-In Slot Installation

    Hardware Modifications Slide-in Slot Installation Overview Before installing or removing any Slide-in Slot, shut down Windows® in an orderly fashion and remove all power from the device. DANGER HAZARD OF ELECTRIC SHOCK, EXPLOSION OR ARC FLASH Remove all power from the device before removing any covers or elements of ...
  • Page 139 PS-4600 Series User Manual The table below describes how to install a Slide-in Slot: Step Action Disconnect the power cord to the Industrial Personal Computer. Touch the housing or ground connection (not the power supply) to discharge any electrostatic charge from your body.
  • Page 140 Hardware Modifications Step Action Remove the slide-in slot cover from the side cover. This is done by pressing in the 6 marked snap arms and removing the slot cover: Install the Slide-in Slot in the slot expansion. Be sure to insert the Slide-in Slot in the black guide rails at the top and bottom of the slot expansion: Slide-in Slot guide rails Slide-in Slot...
  • Page 141 PS-4600 Series User Manual Step Action Install the side cover on the slot expansion using the 4 marked Torx screws (T10): The Industrial Personal Computer can now be mounted back in the control cab- inet, see Industrial Personal Computer Installation (see page 52).
  • Page 142 Hardware Modifications Slide-in Disk Drive The Slide-in Slot Adapter Unit is an interface where Slide-in Disk drives can be installed. The following figure shows the Slide-in Disk drives: Hard disk Slide-in Disk Adapter Unit Slide-in Slot Adapter Unit Slide-in Slot Adapter Unit Slide-in Disk Adapter Unit CFast card The Slide-in Disk Adapter Unit is an interface where a CFast card can be installed.
  • Page 143 PS-4600 Series User Manual The following figure shows the Slide-in Disk Adapter Unit: DVD Multi Drive The DVD Multi Drive can be used with a Slide-in Slot. The following figure shows the DVD Multi Drive:...

  • Page 144: Pci/Pcie Card Installation

    Hardware Modifications PCI/PCIe Card Installation Overview Before installing or removing a PCI/PCIe card, shut down Windows® in an orderly fashion and remove all power from the device. DANGER HAZARD OF ELECTRIC SHOCK, EXPLOSION OR ARC FLASH Remove all power from the device before removing any covers or elements of ...
  • Page 145 PS-4600 Series User Manual PCI/PCIe Card Dimensions Depending on the bus type, you can use standard PCI 2.2 half-size cards or PCI Express (PCIe) half-size cards. NOTE: PCI/PCIe cards cannot exceed the following dimensions. The figure shows the dimensions of the standard half-size PCI card:...
  • Page 146 Hardware Modifications PCI Card Slot Position The figure shows the PCI card slot position: Slot expansion and slide-in module PCI/PCIe slot 1 PCI/PCIe slot 2 NOTE: The slot position is required for configuration (see page 80). Take into account the PCI/PCIe card type restriction: Industrial Personal Com- Quantity puter...
  • Page 147 PS-4600 Series User Manual The table below describes how to install a PCI/PCIe card: Step Action Disconnect the power cord to the Industrial Personal Computer. Touch the housing or ground connection (not the power supply) to discharge any electrostatic charge from your body.
  • Page 148 Hardware Modifications Step Action Remove the PCI slot cover from the slot expansion. Remove the marked Torx screws (T10) and the slot cover:...
  • Page 149 PS-4600 Series User Manual Step Action Install the PCI/PCIe card in the slot expansion. Be sure to insert the PCI/PCIe card in the black guide rail in the top of the slot expansion. Fasten the PCI/PCIe card using the marked (previously removed) Torx screws (T10):...
  • Page 150 Hardware Modifications Step Action Install the side cover on the slot expansion using the 4 marked Torx screws (T10): CAUTION OVERTORQUE AND LOOSE HARDWARE Do not exert more than 0.5 Nm (4.5 lb-in) of torque when tightening the  installation fastener, enclosure, accessory, or terminal block screws. Tightening the screws with excessive force can damage the plastic installation fastener.

  • Page 151: Slide-In Disk Drive And Fan Kit

    PS-4600 Series User Manual Slide-in Disk Drive and Fan Kit Overview This section describes the installation of the Slide-in Disk drive and fan kit. What Is in This Section? This section contains the following topics: Topic Page Slide-in Disk Drive Description and Installation...

  • Page 152: Slide-In Disk Drive Description And Installation

    Hardware Modifications Slide-in Disk Drive Description and Installation Overview Before installing or removing any Slide-in Disk drive, shut down Windows® in an orderly fashion and remove all power from the device. DANGER HAZARD OF ELECTRIC SHOCK, EXPLOSION OR ARC FLASH Remove all power from the device before removing any covers or elements of ...
  • Page 153 (that are required when running with HDD into a Slide-in Disk) - Please contact Pro-face support if you want to proceed such modification. The table below describes how to install a Slide-in Disk drive:...
  • Page 154 Hardware Modifications Step Action Slide the cover plate up to remove it: Free the plastic removal strip fastened to the side of the Slide-in Disk drive: (If no Slide-in Disk drive is present, proceed to step 9.) Pull firmly on the removal strip to remove the Slide-in Disk drive: When inserting a Slide-in Disk drive, be sure to align it with the guide rails.
  • Page 155 PS-4600 Series User Manual CAUTION OVERTORQUE AND LOOSE HARDWARE Do not exert more than 0.5 Nm (4.5 lb-in) of torque when tightening the  installation fastener, enclosure, accessory, or terminal block screws. Tightening the screws with excessive force can damage the plastic installation fastener.

  • Page 156: Fan Kit Installation And Removing

    (that are required when running with HDD into a Slide-in Disk) - Please contact Pro-face support if you want to proceed such modification. The table below describes how to install a fan kit:...
  • Page 157 PS-4600 Series User Manual Step Action Align the fan kit parallel to the Industrial Personal Computer and press it in until it latches. Make sure the fan kit is inserted so that the connections match-up: Removing Fan Kit The table below describes how to remove a fan kit:...

  • Page 158: Main Memory Cards And Cfast Cards

    Hardware Modifications Main Memory Cards and CFast Cards Overview This section describes the installation of the main memory and CFast cards. What Is in This Section? This section contains the following topics: Topic Page CFast Card Installation and Removal Main Memory Card Description and Installation...

  • Page 159: Cfast Card Installation And Removal

    CFAST CARD DAMAGE AND DATA LOSS Remove all power before making any contact with an installed CFast card.  Use only CFast cards manufactured by Pro-face. The performance of the  Industrial Personal Computer has not been tested using CFast cards from other manufacturers.
  • Page 160 Hardware Modifications Inserting the CFast Card The procedure describes how to insert the CFast card: Step Action Shut down Windows® in an orderly fashion and remove all power from the de- vice. Open the CFast card cover. Insert the CFast card firmly into the CFast card slot, and check that the eject but- ton pops out.

  • Page 161: Main Memory Card Description And Installation

    PS-4600 Series User Manual Main Memory Card Description and Installation Overview These 204-pin DDR3 main memory cards and range in size from 1 GB to 8 GB. The figure shows the main memory card: Main Memory Card Restriction If two RAM cards with the same size (for example 2 GB) are inserted into the controller, then dual-channel memory technology is supported.
  • Page 162 Hardware Modifications Main Memory Card Exchange Before installing or removing a main memory card, shut down Windows® in an orderly fashion and remove all power from the device. DANGER HAZARD OF ELECTRIC SHOCK, EXPLOSION OR ARC FLASH Remove all power from the device before removing any covers or elements of ...
  • Page 163 PS-4600 Series User Manual The table describes how to exchange a main memory card: Step Action Disconnect the power cord to the Industrial Personal Computer. Touch the housing or ground connection (not the power supply) to discharge any electrostatic charge from your body.
  • Page 164 Hardware Modifications Step Action If inserting a new main memory card, align the notch on the plug-side of the memory card with the notch above the slot. The main memory card can now be carefully pressed into the slot until the fastening clamps are engaged. Slot Memory card Notch above the slot...

  • Page 165: Raid

    PS-4600 Series User Manual RAID RAID Introduction Only Core i3 pre-installed models are supported by Intel® Rapid Storage Technology. Supported Intel chipset and operating system information is available at the Intel® web page. The information is to enable a user to properly set up and configure a system using Intel®...
  • Page 166 Hardware Modifications To create the RAID system as Mirrored = RAID1 use the MAIN MENU: You can use the following keys after entering the BIOS setup: Function Up cursor  Go to previous item. Down cursor  Go to the next item. Enter Select an item or open a submenu.
  • Page 167 PS-4600 Series User Manual Create RAID Volume To recreate the RAID system as Mirrored = RAID1 use the CREATE VOLUME MENU: The table shows the Configuration Utility - Create RAID volume: Parameter Description Setting Effect Options Name Option for entering the RAID name.
  • Page 168 Hardware Modifications Delete RAID Volume You can delete an existing RAID by using the DELETE VOLUME MENU to format the RAID drive, making it non-RAID. The drive to be deleted must be selected and then deleted by pressing DEL: NOTE: This option deletes all data on the drive, including the operating system. Reset Disks to Non-RAID You can delete an existing RAID volume by using the RESET RAID DATA.
  • Page 169 PS-4600 Series User Manual Recovery Volume Options You can enable/disable recover disk and master disk by using the RECOVERY VOLUME OPTIONS: Configuration for SATA RAID Option When installation is complete, a Intel® Rapid Storage Technology icon is available in the task bar.
  • Page 170 Hardware Modifications...

  • Page 171: Part Iii Installation

    Magelis Industrial Personal Computer 12” Installation EIO0000001596 04/2013 PS-4600 Series User Manual Installation Subject of this Part This part describes the product installation. What Is in This Part? This part contains the following chapters: Chapter Chapter Name Page System Monitor...
  • Page 172 Installation...

  • Page 173: Chapter 9 System Monitor

    Magelis Industrial Personal Computer 12” System Monitor EIO0000001596 04/2013 PS-4600 Series User Manual System Monitor Subject of this Chapter This chapter describes the system monitor features of the Industrial Personal Computer. What Is in This Chapter? This chapter contains the following topics:...

  • Page 174: System Monitor Interface

    System Monitor System Monitor Interface Overview The System Monitor software enables you to monitor the following system parameters: Temperature   SMART  Battery  Depending on the configuration (see page 180), if thresholds are exceeded the System Monitor Software alerts via a popup message (see page 178), sound, buzzer and an entry in the windows event log.
  • Page 175 PS-4600 Series User Manual Icon specific tab (Refer to the table below). Item name and status Minimize the System Monitor to the system tray. Resets alarmed item. Disable buzzer and sound. Only active when sound or buzzer is playing. The following table describes the icons of the system parameter tab:...
  • Page 176 System Monitor Temperature Status The following figure shows the Temperature tab: The following table describes the status messages of temperature parameters: Status Meaning Pass No alarm detected Error Alarm (limit exceeded) Disabled No alarm monitoring Service is not running Fan Status NOTE: Only available with the fan kit option and an HDD into Slide-in Disk slot.
  • Page 177 PS-4600 Series User Manual Status Meaning Pass No alarm detected Error Alarm (a fan does not function as expected) Disabled No alarm monitoring Service is not running SMART Status The SMART status monitors the hard disk. The following figure shows the SMART tab: NOTE: In addition to the Status column, the SMART tab shows a column for the device lifetime.
  • Page 178 System Monitor Battery Status The following figure shows the Battery tab: The following table describes the status message of the battery parameters: Status Meaning Pass No alarm detected. Error Battery unit detected a failure, for example, battery is disconnect- On Battery Power failure - system is running on battery.
  • Page 179 PS-4600 Series User Manual Shows the alarm or item that can be reset. Closes the System Monitor Alert window. Shows the main window. If the check box is selected, closes the window for one hour even though the alarm is active.

  • Page 180: System Monitor Setting

    System Monitor System Monitor Setting Overview You can set the System Monitor parameters and specify the type of alarm in the System Monitor applet in the Windows Control Panel. Each system parameter has its own tab. Use the following dialog box tabs to display the monitoring parameters and set up the various elements to monitor.
  • Page 181 PS-4600 Series User Manual Fan - System Monitor Properties NOTE: Only available with the fan kit option and an HDD into Slide-in Disk slot. The screenshot below shows the Fan tab: Field Description Monitor the function of the PC Select this check box to enable and begin monitoring the fans function of fans.
  • Page 182 System Monitor Field Description Monitor the function of the Select this check box to enable and begin monitoring the built-in hard disks built-in hard disks. When enabled (see page 182), set the Error action. Battery - System Monitor Properties The screenshot below shows the Battery tab: Field Description Monitor the status of the in-...

  • Page 183: Chapter 10 Maintenance

    Magelis Industrial Personal Computer 12” Maintenance EIO0000001596 04/2013 PS-4600 Series User Manual Maintenance Subject of this Chapter This chapter covers maintenance of the Industrial Personal Computer. What Is in This Chapter? This chapter contains the following topics: Topic Page Reinstallation Procedure...

  • Page 184: Reinstallation Procedure

    Maintenance Reinstallation Procedure Introduction In certain cases, it may be necessary to reinstall the operating system. Precautions to be taken: Keep static-producing materials (plastic, upholstery, carpeting) out of the  immediate work area. Do not remove ElectroStatic Discharge (ESD) sensitive components from their ...

  • Page 185: Regular Cleaning And Maintenance

    PS-4600 Series User Manual Regular Cleaning and Maintenance Introduction Inspect the Industrial Personal Computer periodically to determine its general condition. For example: Are all power cords and cables connected properly? Have any become loose?  Are all installation fasteners holding the unit securely? ...
  • Page 186 Maintenance WARNING RISK OF BURNS Do not touch the surface of the heat sink during operation. Failure to follow these instructions can result in death, serious injury, or equipment damage.
  • Page 187 PS-4600 Series User Manual Cleaning Solutions CAUTION HARMFUL CLEANING SOLUTIONS Do not clean the unit or any component of the unit with paint thinner, organic  solvents, or strong acids. Use only a mild soap or detergent that will not harm the poly carbonate material ...
  • Page 188 Maintenance Lithium Battery The Industrial Personal Computer contains one battery, for backing up the real-time clock (RTC). NOTE: The following characteristics, features and limits only apply to this accessory and can deviate from those specified for the entire device. For the device where this accessory is installed, refer to the data provided specifically for the device.
  • Page 189 PS-4600 Series User Manual Step Action 1 Disconnect the power supply to the Industrial Personal Computer. 2 Touch the housing or ground connection (not the power supply) to discharge any electrostatic charge from your body. Pull battery holder out of the Industrial Personal Computer and remove the battery.
  • Page 190 Maintenance NOTE: Replacement of the battery in the Industrial Personal Computer other than with the type specified in this document may present a risk of fire or explosion. WARNING IMPROPER BATTERY CAN PROVOKE FIRE OR EXPLOSION Replace battery only with identical type: Type CR2477N. Failure to follow these instructions can result in death, serious injury, or equipment damage.

  • Page 191: Appendices

    Magelis Industrial Personal Computer 12” EIO0000001596 04/2013 PS-4600 Series User Manual Appendices What Is in This Part? This part contains the following chapters: Chapter Chapter Name Page Accessories After-sales service...

  • Page 193: Appendix A Accessories

    Magelis Industrial Personal Computer 12” Accessories EIO0000001596 04/2013 PS-4600 Series User Manual Accessories Accessories for the Industrial Personal Computer Available Accessories Accessories are available as options. The list of accessories available for the Industrial Personal Computer is shown below: Description...
  • Page 194 Accessories Description Reference Replacement FAN kit for PS-4600 PFXZPPIUFAN2 Replacement FAN filter for PS-4600 (5 pcs) PFXZPPFTFAN2...

  • Page 195: Appendix B After-Sales Service

    Magelis Industrial Personal Computer 12” Accessories EIO0000001596 04/2013 PS-4600 Series User Manual After-sales service For details on after-sales service, refer to Pro-face website at http://www.pro-face.com/trans/en/manual/1001.html...
  • Page 196 After-sales service...

Table of Contents
