• When connecting a power cable to the GP unit, be sure the cable has been
unplugged from the power outlet, so that you would not get an electric shock.
• High voltage runs in the GP unit, so if you take unit apart, there is a danger of
getting an electric shock. Do not take the unit apart.
• Do not use power beyond the specified voltage range. If you do, it may cause a
fire or an electric shock.
• Do not reconstruct the GP unit. It may cause a fire or an electric shock.
• Do not use the GP in an environment with flammable gas in the surrounding
atmosphere. It may cause explosion.
• GP use a lithium battery for backing up its internal clock data. If the battery is
incorrectly replaced, the battery may explode. To avoid the danger, do not
replace the battery yourself. When the battery needs a replacement, please
consult with your local GP distributor.
• Do not use touch panel switches in life-related or important disaster prevention
situations. For safety related switches, such as an emergency switch. use a
separate mechanical switch.
• Please design your system so that the machine will not malfunction by a commu-
nication fault between the GP and its host controller. If not, there could be a
danger of injuring a person or damaging materials.
To Prevent From Damage:
• Do not hit the touch panel with a hard or heavy object, or press the touch panel
with too much force, for it may cause irreparable damage.
• Do not use GP in an environment where the surrounding temperature exceeds
the specification range, for it may damage the unit.
• Please ensure that liquids or metal do not enter the GP unit, for it may cause
malfunction or a short.
• Please avoid using the unit in areas where sudden, large changes in tempera-
ture may occur. These changes can cause condensation to form inside the
unit, possibly causing an accident.
• To prevent from heat building up inside the GP, please do not install GP where its
ventilation holes may be blocked, or where heat cannot escape. Also, please
avoid using or storing the GP in an extremely hot place.
• Do not operate the GP in areas with temperatures and humidity in express of
those levels specified to prevent the GP's touch panel from becoming warped or
bent.
• Please avoid using or storing the GP under direct sunlight or in a dusty environ-
ment.
• This unit is a delicate equipment, so please avoid using or storing the GP unit in
an environment where it can receive strong impact or vibration.
• Please avoid using or storing GP where vaporized chemicals or chemicals can
stick to it.
• Do not use paint thinner or organic solvents to clean the GP unit or display.
• Because unforeseen circumstances may befall your GP unit, be sure to back
up your screen data.
• After turning this unit OFF, be sure to wait a few seconds before turning ON
again. If the unit is started within a few seconds, it may not start up correctly.
WARNING

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the GP477R Series and is the answer not in the manual?

Questions and answers

Summary of Contents for Pro-face GP477R Series

  • Page 1 WARNING • When connecting a power cable to the GP unit, be sure the cable has been unplugged from the power outlet, so that you would not get an electric shock. • High voltage runs in the GP unit, so if you take unit apart, there is a danger of getting an electric shock.
  • Page 2: Package Contents

    Package Contents The following items are included in the package. Before using, please en- sure everything is there. GP unit (GP477R-EG11) Installation fasteners (4 pcs) Handling guide 1 sheet (this sheet) Handling Guide This unit has been carefully packed, with special attention to quality. How- ever, should you find anything damaged or missing, please contact your local GP distributor immediately.
  • Page 3 Names and Functions of GP Parts Names and Functions of GP Parts are explained below. A:Display The monitor screen that indicates screens and data of the host. High intensity EL display B:Touch Panel Runs any screen change operations and sends data to the PLC.
  • Page 4: Serial Interface

    Serial Interface This is GP’s serial port for RS-232C and RS-422 interface. Connect GP’s host here. Signal Signal Condition Condition Name Name 5V±5% output Frame ground 0.25A * Send data Send data B (RS-232C) (RS-422) Receive data Receive data B (RS-232C) (RS-422) Request send...
  • Page 5: Printer Interface

    When making a cable, please be aware of the following: <For RS-422 Connection> • The following pairs of pin #’s must be connected to each other ...#18 (CSB) <-> #19 (ERB) ...#21 (CSA) <-> #22 (ERA) • When connecting the RS-422 cable and the #9 (TRMX) and #10 (RDA) points, a termination resistance of 100Ω...
  • Page 6 AUX Interface (Input/Output) An auxiliary interface for touch switch output, system alarm output, RUN output, and remote reset input. Signal Pin Connection Pin # Contents Name TSW0 TSW1 TSW2 TSW3 Touch Switch Output (8 bit) TSW4 TSW5 TSW6 TSW7 Output: On in RUN mode; Off in standby mode or when the power is off.
  • Page 7: Installation

    Installation Confirm the Installation Gasket’s Seating It is strongly recommended that you use the gasket. Place the GP on a level surface with the display panel facing downward. Check that the GP’s installation gasket is seated securely into the gasket’s groove, which runs around the perimeter of the panel’s frame.
  • Page 8 Wiring WARNING • To avoid electric shock, be sure the Power Cable is unplugged from the power outlet when connecting the cable to the GP unit. • GP477R-EG11 can only take AC100V input. If you supply power other than AC100V, you will damage its power supply and the GP unit. •...
  • Page 9 Connect the power cable following the steps below. 1. Check to make sure the Power is Off. 2. With a plus screwdriver, remove the cover on the Power Input Termi- nal Block. 3. Disconnect the screws from the 3 terminals to be used, align the wire rings and re-insert the screws.
  • Page 10 Precaution for Grounding • From the FG terminal at the rear side of GP unit, please take grounding exclusively [within ground resistance of 100 W]. Precautions for Input/Output Signal Lines • Input and Output signal lines must be separated from the power control cables for operational circuits.
