  • Page 1 PS5000 Series User Manual (Slim Panel Type Atom Model)
  • Page 2 Neither Pro-face nor any of its affiliates or subsidiaries shall be responsible or liable for misuse of the information that is contained herein. If you have any suggestions for improvements or amendments or have found errors in this publication, please notify us.

  • Page 3: Table Of Contents

    PS5000 Series (Slim Panel Type Atom Model) User Manual Table of Contents Safety Information......
  • Page 4 CANopen Interface Module Description......Profibus DP Interface Module Description ..... . NVRAM Card Description .

  • Page 5: Safety Information

    PLEASE NOTE Electrical equipment should be installed, operated, serviced, and maintained only by qualified personnel. No responsibility is assumed by Pro-face for any consequences arising out of the use of this material. A qualified person is one who has skills and knowledge related to the construction and operation of electrical equipment and its installation, and has received safety training to recognize and avoid the hazards involved.

  • Page 7: About The Book

    About the Book At a Glance Document Scope This manual describes the configuration and usage of the PS5000 Series (from now on referred to as the Slim Panel). The Slim Panel is designed to operate in an industrial environment. The configuration number format is as follows:...
  • Page 8 Software bundle None BLUE license key code WinGP license key code Pro-face remote HMI server license key code BLUE and Pro-face remote HMI server license key code WinGP and Pro-face remote HMI server license key code Customization None Spare None NOTE: All instructions applicable to the enclosed product and all safety precautions must be observed.
  • Page 9 PS5000 Series (Slim Panel Type Atom Model) User Manual Product Related Information DANGER POTENTIAL FOR EXPLOSION IN HAZARDOUS LOCATION Do not use this product in hazardous locations. Failure to follow these instructions will result in death or serious injury. WARNING...
  • Page 10 System Monitor  Operating system  Installed hardware  Installed software  WARNING UNINTENDED EQUIPMENT OPERATION Use only Pro-face software with the devices described in this manual. Failure to follow these instructions can result in death, serious injury, or equipment damage.

  • Page 11: Chapter 1 Important Information

    PS5000 Series (Slim Panel Type Atom Model) User Manual Important Information PS5000 Series (Slim Panel Type Atom Model) User Manual Chapter 1 Important Information Important Information General This chapter describes specific aspects related to the operation of the Industrial Personal Computer.

  • Page 12: Fcc Radio Frequency Interference Statement For U.s.a

    Important Information FCC Radio Frequency Interference Statement for U.S.A. FCC Radio Interference Information This equipment has been tested and found to comply with the federal communications commission (FCC) limits for a Class A digital device, according to Part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful interference in a commercial, industrial, or business environment.

  • Page 13: Certifications And Standards

     Standard AS/NZS CISPR11  Qualification Standards Pro-face voluntarily tested this product to additional standards. The additional tests performed, and the standards under which the tests were conducted, are identified in the environmental characteristics. Hazardous Substances This product is compliant with: WEEE, Directive 2012/19/EU ...
  • Page 14 Important Information KC Markings...

  • Page 15: Chapter 2 Physical Overview

    PS5000 Series (Slim Panel Type Atom Model) User Manual Physical Overview PS5000 Series (Slim Panel Type Atom Model) User Manual Chapter 2 Physical Overview Physical Overview Subject of this Chapter This chapter provides a physical overview of the Industrial Personal Computer.

  • Page 16: Package Contents

    Physical Overview Package Contents Items The following items are included in the package of the Industrial Personal Computer. Before using the Slim Panel, confirm that all items listed here are present: Slim Panel 8 x installation fasteners for Display Module ...

  • Page 17: Description

    PS5000 Series (Slim Panel Type Atom Model) User Manual Description Introduction During operation, the surface temperature of the heat sink may exceed 70 °C (158 °F). WARNING RISK OF BURNS Do not touch the surface of the heat sink during operation.
  • Page 18 Physical Overview Slim Panel W10” Multi-touch Rear View Optional AC power supply Slim Panel interface Cover for access mini PCIe card and HDD/SSD drive Panel NOTE: The cooling method is passive heat sink. Slim Panel W10” Multi-touch Bottom View DC power connector ETH2 (10/100/1000 Mbit/s) ETH1 (10/100/1000 Mbit/s) USB2 (USB 2.0)
  • Page 19 PS5000 Series (Slim Panel Type Atom Model) User Manual Slim Panel W15” Multi-touch Front View Panel Multi-touch panel Status indicator The table describes the meaning of the status indicator: Color State Meaning Blue Slim Panel is OK. Orange Stand by.
  • Page 20 Physical Overview Slim Panel W15” Multi-touch Bottom View DC power connector ETH2 (10/100/1000 Mbit/s) ETH1 (10/100/1000 Mbit/s) USB2 (USB 3.0) USB1 (USB 2.0) COM2 port RS-232/422/485 COM1 port RS-232 Optional AC power supply Slim Panel W15” Multi-touch Side View Access CFast memory card Slot for the installation fasteners Slim Panel Bottom View with Extension Kit Extension kit (PFXZPSADSSD2)

  • Page 21: Chapter 3 Characteristics

    PS5000 Series (Slim Panel Type Atom Model) User Manual Characteristics PS5000 Series (Slim Panel Type Atom Model) User Manual Chapter 3 Characteristics Characteristics Subject of this Chapter This chapter lists the product characteristics. What Is in This Chapter? This chapter contains the following topics:...

  • Page 22: Characteristics

    Characteristics Characteristics Slim Panel Characteristics The characteristics are shown below: Element Characteristics Intel chipset and ™ Atom E3827, 1.75 GHz processor Expansion slot 1 x mini PCIe Memory 4 GB, DDR3 1600 MHz, SO-DIMM SDRAM Storage memory 1 x CFast slot Watch dog timer 255 level timer interval, programmable 1...255 sec/min (setting through API) Buzzer...
  • Page 23 PS5000 Series (Slim Panel Type Atom Model) User Manual Operating Systems Each product is delivered with a preinstalled operating system according to the configuration: Operating Systems Windows Embedded 8.1 Industry 64 bits MUI Windows 7 Ultimate SP1 64 bits MUI...

  • Page 24: Interface Characteristics

    Characteristics Interface Characteristics Serial Interface Element Characteristics Type 1 x RS-232/422/RS-485, (RS-485 with auto data flow control), modem-capable, not electrically isolated and 1 x RS-232 (COM1: RS-232 only) Amount Transfer rate Maximum 115.2 kbps Connection D-Sub 9-pin, plug USB Interface Element Characteristics Type...

  • Page 25: Environmental Characteristics

    PS5000 Series (Slim Panel Type Atom Model) User Manual Environmental Characteristics Characteristics Value Degree of protection IP66 front side of display Pollution degree For use in pollution degree 2 environment Operating temperature 0...55 °C (32...131 °F) with SSD or CFast 0...45 °C (32...113 °F) with optional interface...
  • Page 26 Characteristics...

  • Page 27: Chapter 4 Dimensions / Installation

    PS5000 Series (Slim Panel Type Atom Model) User Manual Dimensions / Installation PS5000 Series (Slim Panel Type Atom Model) User Manual Chapter 4 Dimensions / Installation Dimensions / Installation Subject of this Chapter This chapter describes Industrial Personal Computer dimensions and installation panels.

  • Page 28: Dimensions

    Dimensions / Installation Dimensions W10” Multi-touch Dimensions The figure shows the dimensions without AC power supply: The figure shows the dimensions with the AC power supply (PFXZPSPUAC2) and the extension kit (PFXZPSADSSD2):...
  • Page 29 PS5000 Series (Slim Panel Type Atom Model) User Manual W15” Multi-touch Dimensions The figure shows the dimensions without AC power supply: The figure shows the dimensions with the AC power supply (PFXZPSPUAC2) and the extension kit (PFXZPSADSSD2):...

  • Page 30: Installation Requirements

    Dimensions / Installation Installation Requirements Important Mounting Information Overheating of the system can cause incorrect software behavior. To prevent the system from overheating, be aware of the following: The environment characteristics of the system must be respected.  The Slim Panel is only permitted for operation in closed rooms. ...
  • Page 31 PS5000 Series (Slim Panel Type Atom Model) User Manual Spacing Requirements In order to provide sufficient air circulation, mount the Slim Panel so that the spacing above, below, and on the sides of the unit is as follows: Air out Air in x1 >...
  • Page 32 Dimensions / Installation Panel Cut Dimensions For cabinet installation, you need to cut the correct sized opening in the installation panel. The dimensions of the opening for installing the Slim Panel are shown below: Slim Panel Cut-out W10” Multi-touch 274.6 ±0.7 mm 193.8 ±0.4 mm 2...6 mm 5 mm...

  • Page 33: Installation

    PS5000 Series (Slim Panel Type Atom Model) User Manual Installation Vibration and Shocks Take extra care with respect to vibration levels when installing or moving the Slim Panel. If you move the Slim Panel while it is installed in a rack equipped with caster wheels, it may undergo excessive shock and vibration.
  • Page 34 Dimensions / Installation Installation of the Slim Panel The installation gasket and the installation fasteners are required for the easy installation of the Slim Panel. The panel mounting process of the easy installation can be completed by one person. NOTE: For easy installation of the Slim Panel, the suggested mounting panel thickness can be up to 2 mm (0.079 in).
  • Page 35 PS5000 Series (Slim Panel Type Atom Model) User Manual Step Action Install the Slim Panel in the panel opening and push it into the wall. The snap hook holds the Slim Panel to the wall: Insert the installation fasteners securely into the slots at the top, bottom, left, and right side of the...
  • Page 36 Dimensions / Installation Step Action Insert each fastener in its corresponding slot and pull the fastener back until it is flush with the rear of the fastener hole: Tighten each of the cross-slotted fastener screws, and fasten the Slim Panel in place: NOTE: To ensure a high degree of moisture resistance, use a torque of 0.5 Nm (4.5 lb-in).
  • Page 37 PS5000 Series (Slim Panel Type Atom Model) User Manual Installation of the VESA Mounting Kit Follow these steps when installing the VESA (video electronics standards association) mounting kit: Step Action Fasten the VESA mounting kit on the rear side of the Slim Panel:...
  • Page 38 Dimensions / Installation Step Action Use the 4 screws into the dedicated holes for installing the VESA. The angle of the unit is tilted no more than the amount allowed by the mounting orientation requirements:...

  • Page 39: Chapter 5 Getting Started

    PS5000 Series (Slim Panel Type Atom Model) User Manual Getting Started PS5000 Series (Slim Panel Type Atom Model) User Manual Chapter 5 Getting Started Getting Started First Power up License Agreement Limitations on your usage of the Microsoft Windows Operating System are noted in Microsoft's End User License Agreement (EULA).
  • Page 40 Getting Started NOTICE DATA AND CONFIGURATION LOSS Disable the EWF Manager before making any permanent changes to the hardware, software,  or Operating System of the Industrial Personal Computer. Re-enable the EWF Manager after making permanent changes. This helps extend the ...

  • Page 41: Chapter 6 Slim Panel Connections

    PS5000 Series (Slim Panel Type Atom Model) User Manual Slim Panel Connections PS5000 Series (Slim Panel Type Atom Model) User Manual Chapter 6 Slim Panel Connections Slim Panel Connections Subject of This Chapter This chapter describes the connection of the Slim Panel to the main power supply. It also describes the USB ports and identifies the serial interface pin assignments.

  • Page 42: Grounding

    Slim Panel Connections Grounding Overview The grounding resistance between the Slim Panel ground wire and the ground must be 100 Ω or less. When using a long grounding wire, check the resistance and, if required, replace the wire with a thicker wire and place it in a duct. The table shows the maximum length for the wires: Wire cross-section Maximum line length...
  • Page 43 PS5000 Series (Slim Panel Type Atom Model) User Manual NOTE: Use the AC power supply for connecting the Slim Panel. When grounding, follow this procedure: Step Action Ensure all of the following is done for the system wiring: Connect the cabinet to ground.
  • Page 44 Slim Panel Connections Grounding I/O Signal Lines DANGER POTENTIAL FOR EXPLOSION IN HAZARDOUS LOCATION Do not use this product in hazardous locations. Failure to follow these instructions will result in death or serious injury. Electromagnetic radiation may interfere with the control communications of the Slim Panel. WARNING UNINTENDED EQUIPMENT OPERATION If wiring of I/O lines near power lines or radio equipment is unavoidable, use shielded cables...

  • Page 45: Connecting The Dc Power Cord

    PS5000 Series (Slim Panel Type Atom Model) User Manual Connecting the DC Power Cord Precaution When connecting the power cord to the power connector on the Slim Panel, first ensure that the power cord is disconnected from the DC power supply.
  • Page 46 Slim Panel Connections Wiring and Connecting the Terminal Block The table below describes how to connect the power cord to the DC terminal block of the Slim Panel: Step Action Remove all power from the Slim Panel and confirm that the power adapter is disconnected from its power source.

  • Page 47: Ac Power Supply Module Description And Installation

    PS5000 Series (Slim Panel Type Atom Model) User Manual AC Power Supply Module Description and Installation Overview The AC power supply module can optionally be mounted on the Slim Panel to allow the Slim Panel to be operated with 100...240 Vac.
  • Page 48 Slim Panel Connections This figure shows the dimensions of the AC power supply module: AC Power Supply The table provides technical data for the AC power supply module: Element Characteristics Input 90...260 Vac / 47...63 Hz / 1.6 A at 100 Vac Output 24 Vdc / 2.62 A maximum Inrush current...
  • Page 49 PS5000 Series (Slim Panel Type Atom Model) User Manual Wiring and Connecting the Terminal Block The table provides how to connect the AC power supply module: Step Action Remove all power from the Slim Panel and confirm that the power adapter is disconnected from its power source.
  • Page 50 Slim Panel Connections Step Action Place the terminal block in the power connector and tighten the screws: NOTE: The recommended torque to tighten these screws is 0.5 Nm (4.5 lb-in). Attach the power cord and tighten the screws: CAUTION OVERTORQUE AND LOOSE HARDWARE Do not exert more than 0.5 Nm (4.5 lb-in) of torque when tightening the installation fastener, ...

  • Page 51: Slim Panel Interface Connections

    PS5000 Series (Slim Panel Type Atom Model) User Manual Slim Panel Interface Connections Introduction DANGER POTENTIAL FOR EXPLOSION IN HAZARDOUS LOCATION Do not use this product in hazardous locations. Failure to follow these instructions will result in death or serious injury.
  • Page 52 Slim Panel Connections The table shows the D-Sub 9-pin assignments (COM1): Assignment RS-232 D-Sub 9-pin plug connector: The table shows the D-Sub 9-pin assignments (COM2): Assignment RS-232 RS-422/485 TxD-/Data- D-Sub 9-pin plug connector: TxD+/Data+ RxD+ RxD- GND/VEE Any excessive weight or stress on communication cables may disconnect the equipment. NOTE: You can select RS-232, RS-422, or RS-485 to COM2 port.

  • Page 53: Chapter 7 Configuration Of The Bios

    PS5000 Series (Slim Panel Type Atom Model) User Manual Configuration of the BIOS PS5000 Series (Slim Panel Type Atom Model) User Manual Chapter 7 Configuration of the BIOS Configuration of the BIOS What Is in This Chapter? This chapter contains the following topics:...

  • Page 54: Bios Main Menu

    Configuration of the BIOS BIOS Main Menu General Information BIOS stands for Basic Input Output System. The BIOS Setup Utility lets you modify basic system configuration settings. NOTE: To enter BIOS setup, press DEL key during startup. Main Tab When you press the [DEL] key during startup, the Main BIOS setup menu appears. This screen, like all the BIOS screens, is divided into three frames: Left: This frame displays the options available on the screen.

  • Page 55: Advanced Menu

    PS5000 Series (Slim Panel Type Atom Model) User Manual Advanced Menu Advanced BIOS Features Tab For details about the Advanced submenus, refer to: ACPI Settings  IT8768E Super I/O Configuration  Embedded Controller Configuration  S5 RTC Wake Settings ...
  • Page 56 Configuration of the BIOS Serial Port Console Redirection Submenu BIOS setting Description COM 0 Console Redirection – COM 1 Console Redirection – Legacy Console Redirection – Settings Console Redirection – CPU Configuration Submenu BIOS setting Description Execute Disable Bit Enables or disables the no-execution page protection. Intel Virtualization Technology Enable or disable Intel virtualization technology.
  • Page 57 PS5000 Series (Slim Panel Type Atom Model) User Manual LAN Controller Submenu BIOS setting Description LAN A Controller – LAN B Controller – Wake on LAN Enable – CSM Parameters Submenu BIOS setting Description CSM Support – GateA20 Active –...
  • Page 58 Configuration of the BIOS BIOS setting Description Device power-up delay Select device power-up section. Maximum time the device takes before it properly reports itself to the host controller. Auto uses a default value: for a root port it is 100 ms, for a hub port the delay is taken from the hub descriptor.

  • Page 59: Chipset Menu

    PS5000 Series (Slim Panel Type Atom Model) User Manual Chipset Menu Chipset BIOS Features Tab For details about the Chipset submenus, refer to: North Bridge  South Bridge  North Bridge Menu BIOS setting Description Intel IGD Configuration –. South Bridge Menu...

  • Page 60: Boot Menu

    Configuration of the BIOS Boot Menu Boot Settings Configuration Menu Boot setting Description Setup Prompt Select the number of seconds to wait for setup activation key. Timeout Bootup NumLock Select the keyboard NumLock state. state Quiet Boot Enables or disables Quiet Boot option. Fast Boot Enables or disables boot with initialization of a minimal set of devices required to launch active boot option.

  • Page 61: Security Menu

    PS5000 Series (Slim Panel Type Atom Model) User Manual Security Menu Security Setup Select Security Setup from the main BIOS setup menu. All Security Setup options, such as password protection, are described in this section. To access the submenu for the following items, select the item and press Enter.

  • Page 62: Save & Exit Menu

    Configuration of the BIOS Save & Exit Menu Menu BIOS setting Description Save Changes and Exit When the system configuration is complete, select this option to save changes, exiting the BIOS setup and, if necessary, reboot the computer to take into account all system configuration parameters.

  • Page 63: Chapter 8 Hardware Modifications

    PS5000 Series (Slim Panel Type Atom Model) User Manual Hardware Modifications PS5000 Series (Slim Panel Type Atom Model) User Manual Chapter 8 Hardware Modifications Hardware Modifications Subject of This Chapter This chapter describes the hardware modifications for the Industrial Personal Computer.

  • Page 64: Before Modifications

    Hardware Modifications Section 8.1 Before Modifications Before Modifications Before Making Modifications Introduction For detailed installation procedures for optional units, refer to the OEM (original equipment manufacturer) installation guide included with the optional unit. DANGER HAZARD OF ELECTRIC SHOCK, EXPLOSION OR ARC FLASH Remove all power from the device before removing any covers or elements of the system, and ...
  • Page 65 PS5000 Series (Slim Panel Type Atom Model) User Manual CAUTION OVERTORQUE AND LOOSE HARDWARE Do not exert more than 0.5 Nm (4.5 lb-in) of torque when tightening the installation fastener,  enclosure, accessory, or terminal block screws. Tightening the screws with excessive force can damage the installation fastener.

  • Page 66: Storages Modifications

    Hardware Modifications Section 8.2 Storages Modifications Storages Modifications Overview This section shows the installation of the HDD/SSD drives and the CFast card. What Is in This Section? This section contains the following topics: Topic Page HDD/SSD Drive Description and Installation CFast Card Installation...

  • Page 67: Hdd/Ssd Drive Description And Installation

    PS5000 Series (Slim Panel Type Atom Model) User Manual HDD/SSD Drive Description and Installation Overview This device does not support hot swapping. Before any hardware modification, shut down Windows in an orderly fashion and remove all power from the device.
  • Page 68 Hardware Modifications Step Action Fasten the extension kit (PFXZPSADSSD2) to the Slim Panel with the 4 studs: Install the 2.5" SATA HDD/SSD on the HDD/SSD bracket. Screw in the 4 screws on the side of HDD/SSD bracket: Connect the HDD/SSD into the SATA connector. Install it in the Slim Panel and fasten it with the 4 dampers and the 4 screws of HDD/SSD holder module to the extension kit: NOTE: The recommended torque to tighten these screws is 0.5 Nm (4.5 lb-in).
  • Page 69 PS5000 Series (Slim Panel Type Atom Model) User Manual Step Action Replace the rear cover and fasten it with the 4 screws: NOTE: The recommended torque to tighten these screws is 0.5 Nm (4.5 lb-in). CAUTION OVERTORQUE AND LOOSE HARDWARE Do not exert more than 0.5 Nm (4.5 lb-in) of torque when tightening the installation fastener,...

  • Page 70: Cfast Card Installation

    Remove all power before making any contact with an installed memory card.  Use only memory cards sold by Pro-face as accessory for this product. The performance of  the Industrial Personal Computer has not been tested using memory cards from other manufacturers.
  • Page 71 PS5000 Series (Slim Panel Type Atom Model) User Manual Inserting the CFast Card The procedure describes how to insert the CFast card. Step Action Insert the CFast card into the card slot: Press the CFast card firmly into the card slot: NOTE: You can attach Mylar from the accessory box to the CFast card for easy extraction.
  • Page 72 Hardware Modifications CFast Card Installation Refer to the relevant procedure in the software installation guide for Slim Panel and terminals. The installation guide is shipped with the product.

  • Page 73: Optional Interfaces

    PS5000 Series (Slim Panel Type Atom Model) User Manual Section 8.3 Optional Interfaces Optional Interfaces Overview This section describes the optional interfaces and their installation. What Is in This Section? This section contains the following topics: Topic Page Optional Interface Installation...

  • Page 74: Optional Interface Installation

    Hardware Modifications Optional Interface Installation Introduction Before installing or removing an interface module, shut down Windows in an orderly fashion and remove all power from the device. DANGER HAZARD OF ELECTRIC SHOCK, EXPLOSION OR ARC FLASH Remove all power from the device before removing any covers or elements of the system, and ...
  • Page 75 PS5000 Series (Slim Panel Type Atom Model) User Manual The table shows the type and the interface module part numbers: Designation Part number Interface RS-232/422/485 PFXZPBMPR42P2 2 x RS-422/485 isolated interface module PFXZPBMPR44P2 4 x RS-422/485 PFXZPBMPR22P2 2 x RS-232 isolated...
  • Page 76 Hardware Modifications The table describes how to install an interface module: Step Action Disconnect the power cord to the Slim Panel. Touch the housing or ground connection (not the power supply) to discharge any electrostatic charge from your body. Remove the four screws of the rear cover: Install the mini PCIe card onto the board: NOTE: The recommended torque to tighten these screws is 0.5 Nm (4.5 lb-in).
  • Page 77 PS5000 Series (Slim Panel Type Atom Model) User Manual Step Action Fasten the extension kit to the Slim Panel with the four studs: Replace the rear cover and fasten it with four screws: NOTE: The recommended torque to tighten these screws is 0.5 Nm (4.5 lb-in).

  • Page 78: 16Di/8Do Interface Module Description

    Hardware Modifications 16DI/8DO Interface Module Description Introduction The PFXZPBMPX16Y82 is categorized as a digital input/output module. It can be associated with a DIN rail terminal card, and is compatible with the mini PCIe card. During card installation, there is no need to set jumpers or DIP switches. Instead, all bus-related configurations such as base I/O address and interrupt are automatically done by the Plug-and-Play function.
  • Page 79 PS5000 Series (Slim Panel Type Atom Model) User Manual The figure shows the dimensions of the 16DI/8DO interface module: 16DI/8DO Interface Module The table shows technical data for the 16DI/8DO interface module: Element Characteristics General Bus type mini PCIe card revision 1.2...
  • Page 80 Hardware Modifications Element Characteristics Resolution 32 bit Maximum input frequency 1 kHz 16DI/8DO Connections The table shows the D-Sub 37-pin assignments: Assignment Description D-Sub 37-pin socket connector IDI0...15 Isolated digital input ID0...7 Isolated digital output ECOM0 External common of IDI0...7 ECOM1 External common of IDI8...15 PCOM...
  • Page 81 PS5000 Series (Slim Panel Type Atom Model) User Manual Switch and Jumper Settings The jumper JP1 on the position 0 (default), load default while reset (default). The jumper JP1 on the position 1 (enabled), keeps the last status after reset.

  • Page 82: Rs-232/422/485 Interface Module Description

    Hardware Modifications RS-232/422/485 Interface Module Description Introduction The PFXZPBMPR series are categorized as communication modules. They are all compatible with the mini PCIe card including isolated / non-isolated RS-232/422/485 communication cards for automation control. The figure shows the RS-232/422/485 interface modules: 2 x RS-232/422/485 interface module 4 x RS-232/422/485 interface module 1 x interface cables...
  • Page 83 PS5000 Series (Slim Panel Type Atom Model) User Manual The following figure shows the dimensions of the 4 x RS-232/422/485 interface module: Serial Interface The table shows technical data for the serial interfaces: Element Characteristics Part number PFXZPBMPR42P2 PFXZPBMPR22P2 PFXZPBMPR44P2...
  • Page 84 Hardware Modifications Cable Serial Interface The table shows the technical data of the cable serial interface: Element Characteristics Signal lines Cable cross section RS-232 4 x 0.16 mm² (26 AWG), tinned Cu. wire Cable cross section RS-422 4 x 0.25 mm² (24 AWG), tinned Cu. wire Cable cross section RS-485 4 x 0.25 mm²...
  • Page 85 PS5000 Series (Slim Panel Type Atom Model) User Manual The table shows the D-Sub 37-pin assignments: Assignment RS-232 RS-422/485 N.C. N.C. D-Sub 37-pin socket connector: DCD3 TxD3-/Data3- GND/VEE3 CTS3 N.C. RxD3 TxD3/Data3 N.C. DTR4 RxD4- DSR4 N.C. RTS4 N.C. TxD4...
  • Page 86 Hardware Modifications CAUTION LOSS OF POWER Ensure that communication connections do not place excessive stress on the communication  ports of the Industrial Personal Computer. Securely attach communication cables to the panel or cabinet.  Use only D-Sub 9-pin cables with a locking system in good condition. ...

  • Page 87: Ethernet Ieee Interface Module Description

    PS5000 Series (Slim Panel Type Atom Model) User Manual Ethernet IEEE Interface Module Description Introduction The PFXZPBMPRE2 is categorized as industrial communication with IEEE protocol module. It is compatible with the mini PCIe card. The figure shows the Ethernet interface module:...
  • Page 88 Hardware Modifications CAUTION LOSS OF POWER Ensure that communication connections do not place excessive stress on the communication  ports of the Slim Panel. Securely attach communication cables to the panel or cabinet.  Failure to follow these instructions can result in injury or equipment damage. Device Manager and Hardware Installation Install the driver before you install the interface module into the Slim Panel.

  • Page 89: Canopen Interface Module Description

    PS5000 Series (Slim Panel Type Atom Model) User Manual CANopen Interface Module Description Introduction The PFXZPBMPCANM2 is categorized as industrial communication with fieldbus protocol modules. It is compatible with the mini PCIe card. The figure shows the CANopen interface module:...
  • Page 90 Hardware Modifications CANopen Interface Module Description The table shows technical data for the CANopen interface module: Features Values General Bus type Mini PCIe card revision 1.2 Connector 2 x plug D-Sub 9-pin Power consumption 400 mA at 5 Vdc Communication Protocol CAN 2.0 A/B Signal support...
  • Page 91 PS5000 Series (Slim Panel Type Atom Model) User Manual Device Manager and Hardware Installation Install the driver before you install the interface module into the Slim Panel. The driver installation media for the CANopen interface module is included with the package. After the interface module...

  • Page 92: Profibus Dp Interface Module Description

    Hardware Modifications Profibus DP Interface Module Description Introduction The PFXZPBMPPBM2 is categorized as industrial communication with fieldbus protocol modules (Profibus DP master or slave). It is compatible with the mini PCIe card. NOTE: Download the firmware and configuration. Use the corresponding master or slave DTM in the configuration software SYCON.net (HILSCHER CIFX 90E-DP\ET\F\MR\ADVA/+ML).
  • Page 93 PS5000 Series (Slim Panel Type Atom Model) User Manual Features Profibus DP slave Profibus DP master Configuration data 244 bytes 244 bytes/slave Parameter data 237 bytes NOTE: To configure the master, a GSD file (device description file) is required. The settings in the used master must comply with the settings in the slave to establish communication.

  • Page 94: Nvram Card Description

    Hardware Modifications NVRAM Card Description Introduction The PFXZPBMPNR2 is categorized as industrial storage or a memory card for the mini PCIe slot. The figure shows the NVRAM card: NVRAM Card Description The table shows the technical data of the NVRAM card: Features Values General...

  • Page 95: Cellular Module

    PS5000 Series (Slim Panel Type Atom Model) User Manual Cellular Module Introduction The PFXZPBPHMC2 is categorized as a GPRS (general packet radio service). It provides a cost effective solution for wireless remote connection to distributed installations over the Internet. It is compatible with the mini PCIe card with SIM card holder.
  • Page 96 Hardware Modifications Cellular Module Description The table shows technical data for the Cellular module: Features Values General Bus type mini PCIe card revision 1.2 Connector 1 x RF antenna coaxial connectors Power consumption 3.3...3.6 Vdc < 700 mA (HSPA connected mode) Peak current 1.5 A Communication...
  • Page 97 PS5000 Series (Slim Panel Type Atom Model) User Manual Connection Principles GPRS communication requires a SIM card and a specific GPRS contract with a service provider. The GPRS connection is always initiated from the module to the GPRS network. It is not possible for a client application to open a connection by directly dialing the Cellular module.
  • Page 98 Hardware Modifications...

  • Page 99: Chapter 9 System Monitor

    PS5000 Series (Slim Panel Type Atom Model) User Manual System Monitor PS5000 Series (Slim Panel Type Atom Model) User Manual Chapter 9 System Monitor System Monitor Subject of this Chapter This chapter describes the system monitor features of the Industrial Personal Computer.

  • Page 100: System Monitor Interface

    System Monitor System Monitor Interface Overview The System Monitor 3.0 interface provides remote monitoring, a feature that helps you access multiple clients through a single console for remote device management. The System Monitor immediately recognizes equipment and provides real-time equipment maintenance, which improves system stability and reliability.
  • Page 101 PS5000 Series (Slim Panel Type Atom Model) User Manual System Monitor Console The System Monitor console acts as a server for the clients. Devices that run on the System Monitor console display the health and status information from the System Monitor clients. The console has to be made available by the clients over a network.
  • Page 102 System Monitor Click Management Service to start/stop main System Monitor management service: Tomcat Service Tomcat is an open-source Web server and servlet container. Tomcat implements several Java EE specifications including Java servlet, JavaServer pages (JSP), Java EL, and WebSocket, and provides a Java HTTP Web server environment for Java code to run in.
  • Page 103 PS5000 Series (Slim Panel Type Atom Model) User Manual Exit Click Exit to terminate server management console from tray icon and all System Monitor services are still running in the background. You can restart console from Windows/Programs menu: Remote Manage Devices Any Time, Any Where System Monitor is a Console-Server-Agent web-based structure for cloud management.
  • Page 104 System Monitor User-Friendly Map-View Interface Taking advantage of web-based features, System Monitor provides map-view interface and leverages Google and Baidu maps to help administrators locate and manage their devices more easily. In addition to the maps, System Monitor also provides for building diagrams to help pinpoint device locations in offices, factories, or wherever.
  • Page 105 PS5000 Series (Slim Panel Type Atom Model) User Manual Step Description User Log Out Click User Log Out from the right corner menu to check out the system:...

  • Page 106: Device Management - Monitoring Rules

    System Monitor Device Management - Monitoring Rules Device Management This procedure describes how to use the Device Management user interface: Step Description Device management After user login, Device is the default page.  Device management page is composed of a system hierarchy tree (left-side) and device list ...
  • Page 107 PS5000 Series (Slim Panel Type Atom Model) User Manual Step Description Add/Delete/Edit device server Add device server: Select on one of server nodes and click Add to the pop up menu option: Click Add Server to pop up the Device Server dialog for new subserver registering.
  • Page 108 System Monitor Step Description Delete /Edit device group Delete /Edit device group: Click Edit to switch to edit mode and select one of the group nodes. You can remove and edit this group node: Add/Delete/Edit device Add device: Select one of the user accounts or groups and click Add to the pop up menu option. Click Add Device to the pop up dialog for new device addition:...
  • Page 109 PS5000 Series (Slim Panel Type Atom Model) User Manual Step Description Manual add Click Add Device to pop up the Add Device dialog to add a device manually. You can input known device ID or MAC addresses that have already registered to the server and assign a current account or group.
  • Page 110 System Monitor Step Description Delete device Click Edit to switch to edit mode. You can remove and edit devices on the device list in this mode. Click the X icon for the selected device row and confirm the device warning removal: Edit device Click Edit to switch to edit mode.
  • Page 111 PS5000 Series (Slim Panel Type Atom Model) User Manual Step Description KVM viewer Click the icon from the remote control menu to connect to the device for KVM control: NOTE: you can select KVM connection method on the device agent side. System default is System Monitoring KVM (Ultra VNC), you can select other already-installed VNC, or disable this function for security concerns.
  • Page 112 System Monitor Step Description Remote control – Screen shot Click the icon from the remote control menu to snapshot the desktop screen of the remote device and save it on the local client side: Hardware monitoring status Real-time monitoring chart: Click the field Hardware Status of the device list item to display graphically hardware real-time parameters (memory, CPU usage, temperature and HD health status).
  • Page 113 PS5000 Series (Slim Panel Type Atom Model) User Manual Step Description Hardware monitoring fan status If the fan kit is not installed or the fan rpm is 0 a message will notify: fan kit not installed or defective. To get notification about status of the system fan you need to set the appropriate...
  • Page 114 System Monitor Step Description Hardware monitoring rules Click the button Hardware Monitoring Rule to pop up the hardware monitoring dialog. The dialog lists current monitoring rules for hardware parameters includes CPU, voltage, HDD, and so on: Add rules Click the button Add Rules button to add a new rule for hardware monitoring. You can select the type of monitoring hardware from the menu, input threshold values for the corresponding parameter, the last time in seconds for reaching that threshold and a notice interval for 2 contiguous events.
  • Page 115 PS5000 Series (Slim Panel Type Atom Model) User Manual Step Description Edit rules Click a row in the Hardware Monitoring Rule box to pop up the Hardware Monitoring Setting dialog box: Delete rules: Click the X icon on the left side of the schedule item to delete the schedule.
  • Page 116 System Monitor Step Description Software monitoring status Real-time process list: Click the Software Status field in the device list to display the status list for active real-time software (name, status, CPU usage, and memory): Click the process name to pop up the confirm dialog for killing a specified process, after confirming, you can kill and force the process to terminate: Software monitoring rules Click the button Software Monitoring Rules to pop up the dialog for set software monitoring rule.
  • Page 117 PS5000 Series (Slim Panel Type Atom Model) User Manual Step Description Add rules Click the button Add Rules to add a new rule for software monitoring. You can input the process name that they want to monitor, the threshold values of the CPU and memory, the last time in seconds for reaching the threshold, and the notice interval for 2 contiguous events and corresponding action.
  • Page 118 System Monitor Step Description Maintenance status You can change the maintenance status (none / to be maintained / maintaining / finished) from the menu for each device: Devices administrator Users with device management permissions can click the Admin field to pop up the selection dialog for administrator to reassign device administrator status to another account: View mode - Group status list Click the Group tab to list groups under the selected account or group node.
  • Page 119 PS5000 Series (Slim Panel Type Atom Model) User Manual Group Hardware and Software Monitoring Rules This procedure describes how to use the Group Hardware and Software Monitoring Rules user interface: Step Description Group hardware monitoring rules Click the icon on the right to pop up the dialog Set Hardware Monitoring Rule. The dialog lists current monitoring rules and parameters of each group's devices including CPU, voltage, HDD, and so on.
  • Page 120 System Monitor Step Description Add/Delete/Edit map location Add location: Select on one of account nodes and click Add button to add a new location: Input location name, address, or coordination (latitude and longitude), upload image for location displaying and click OK to add the new location: NOTE: Map view supports both Google and Baidu online map.
  • Page 121 PS5000 Series (Slim Panel Type Atom Model) User Manual Step Description Delete location Click Edit button to switch to edit mode, click X icon ahead of selected location node to delete this location: NOTE: If there are layouts or devices under selected location node, you must remove these nodes first before removing location node.
  • Page 122 System Monitor Step Description Add layout Select on one of location nodes and click Add button to add a new layout. Input layout name and description, upload image for location displaying and click OK to add the new layout: Delete layout: Click Edit button to switch to edit mode, click X icon ahead of selected layout node to delete this layout.
  • Page 123 PS5000 Series (Slim Panel Type Atom Model) User Manual Event Log This procedure describes how to use the Event Log user interface: Step Description Device event list Select user account or group to decide event range and select event log type...

  • Page 124: Account Setting - System Setting

    System Monitor Account Setting - System Setting Account Setting This procedure describes how to use the Account Setting user interface: Step Description Click Account Setting from menu of up-right corner to pop up the dialog of account setting for configuring: Default role System provides three default roles with pre-defined access rights: System Administrator, Device Administrator, and Visitors:...
  • Page 125 PS5000 Series (Slim Panel Type Atom Model) User Manual Step Description View/Add/Delete/Edit custom role In addition to default role, you can add role with user-defined user rights. Add Role: Click Add Role to pop up the dialog of Role. Input role name and corresponding user...
  • Page 126 System Monitor Step Description Add account: Select one of defaults or custom role and click Add button to pop up the dialog for creating a new account: Edit account: Click Edit button to switch to edit mode. Click arbitrary field in the account list to pop up the dialog for account editing.
  • Page 127 PS5000 Series (Slim Panel Type Atom Model) User Manual Step Description About: Display server version and local address/port for Web portal: Email service: Use SMTP protocol to send notifications via Email Service. Before applying setting, click button to send a mail to check validity of settings:...
  • Page 128 System Monitor Step Description Notification setting Click tab Device/Operation/System to catalog related notification setting. Set event notify by Email on each item to enable receiving: Advanced settings Click Advanced Settings for message language of email and SMS, cycle days of system automatically sends inspection report, system warning of low hard disk space and external SYSLOG event server setting: Event log...
  • Page 129 PS5000 Series (Slim Panel Type Atom Model) User Manual Step Description Export CSV Select data/time range to export event log as CSV format to local side: Clearance Manually or set up automatic period to clean event log: Upgrade setting Use ValidationCode_Generator.exe tool to generate MD5 check code of uploading agent upgrade package.
  • Page 130 System Monitor Step Description Web SSL setting User can switch SSL (Secure Sockets Layer) setting and select the port to open or close SSL:...

  • Page 131: Chapter 10 Software Api

    All the embedded functions are configured through an API (application programming interface) or by a DEMO tool. Pro-face provides this suite of Software API and the underlying drivers required. Also a set of user-friendly, intelligent, and integrated interfaces speed development, enhance security, and offer add-on value for Pro-face platforms.
  • Page 132 Software API...

  • Page 133: Chapter 11 Maintenance

    PS5000 Series (Slim Panel Type Atom Model) User Manual Maintenance PS5000 Series (Slim Panel Type Atom Model) User Manual Chapter 11 Maintenance Maintenance Subject of this Chapter This chapter covers maintenance of the Industrial Personal Computer. What Is in This Chapter?

  • Page 134: Reinstallation Procedure

    Maintenance Reinstallation Procedure Introduction In certain cases, it may be necessary to reinstall the operating system. Precautions to take: Keep static-producing materials (plastic, upholstery, carpeting) out of the immediate workpace.  Do not remove ESD-sensitive components from their anti-static bags until you are ready to ...

  • Page 135: Regular Cleaning And Maintenance

    PS5000 Series (Slim Panel Type Atom Model) User Manual Regular Cleaning and Maintenance Introduction Inspect the Slim Panel periodically to determine its general condition. For example: Are all power cords and cables connected properly? Have any become loose?  Are all installation fasteners holding the unit securely? ...
  • Page 136 Maintenance Lithium Battery The Industrial Personal Computer contains one battery, for backing up the real-time clock (RTC). DANGER EXPLOSION, FIRE, OR CHEMICAL HAZARD The battery must always be replaced with identical type.  For battery replacement, contact the field services department. ...

  • Page 137: Appendices

    PS5000 Series (Slim Panel Type Atom Model) User Manual PS5000 Series (Slim Panel Type Atom Model) User Manual Appendices Subject of this Part This part provides the appendices for the Industrial Personal Computer products. What Is in This Appendix? The appendix contains the following chapters:...

  • Page 139: Appendix A Accessories And Setting

    PS5000 Series (Slim Panel Type Atom Model) User Manual Accessories and Setting PS5000 Series (Slim Panel Type Atom Model) User Manual Appendix A Accessories and Setting Accessories and Setting Subject of this Chapter This chapter concerns the accessories relating to the products and the setting.

  • Page 140: Accessories For The Slim Panel

    Accessories and Setting Accessories for the Slim Panel Available Accessories Accessories are available as options. The table shows the list of accessories available for the Slim Panel: Reference Description Interfaces PFXZPBMPNR2 NVRAM mini PCIe PFXZPBMPR42P2 Interface - 2 x RS-422/485 isolated PFXZPBMPR44P2 Interface - 4 x RS-422/485 PFXZPBMPR24P2...

  • Page 141: Connectors And Setting

    PS5000 Series (Slim Panel Type Atom Model) User Manual Connectors and Setting Main Board Setting Before to access the main board, shut down Windows in an orderly fashion and remove all power from the device. DANGER POTENTIAL FOR EXPLOSION IN HAZARDOUS LOCATION Do not use this product in hazardous locations.
  • Page 142 Accessories and Setting Step Action You can access connectors and setting of the main board. The figure shows the main board of the Slim Panel: CN1 Clear CMOS CN12 SATA signal connector CN13 SATA power connector SW2 COM2 RS-232/422/485 mode setting SW3 Termination resistors select Replace the rear cover and fasten it with four screws: NOTE:...
  • Page 143 PS5000 Series (Slim Panel Type Atom Model) User Manual CAUTION OVERTORQUE AND LOOSE HARDWARE Do not exert more than 0.5 Nm (4.5 lb-in) of torque when tightening the installation fastener,  enclosure, accessory, or terminal block screws. Tightening the screws with excessive force can damage the installation fastener.
  • Page 144 Accessories and Setting Mode RS-422 slave mode RS-485 mode The default setting is RS-232. The table describes the setting for the termination resistor for COM2: Position Signal Pin 1 DATA+ (default) Pin 2 RX- (default) Pin 3 R_RX+ Pin 4 R_DATA- NOTE: This switch is used to select termination resistor (120 ohm) for long-distance transmission or device matching.
  • Page 145 PS5000 Series (Slim Panel Type Atom Model) User Manual The table describes the SATA power connector: Signal Description CN13 +V3.3 SATA SATA power output 3.3 V/1 A +V5 SATA SATA power output 5 V/1 A +V12 SATA SATA power output 12 V/0.5 A...
  • Page 146 Accessories and Setting...

  • Page 147: Appendix B After-Sales Service

    PS5000 Series (Slim Panel Type Atom Model) User Manual After-sales Service PS5000 Series (Slim Panel Type Atom Model) User Manual Appendix B After-sales Service After-sales Service After-sales Service Information For details on after-sales service, refer to Pro-face website at http://www.pro-face.com/trans/en/manual/1001.html...
  • Page 148 After-sales Service...

Table of Contents
