PS-3650A /PS-3651A
User Manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PS-3650A and is the answer not in the manual?

Questions and answers

Related Manuals for Pro-face PS-3650A

Summary of Contents for Pro-face PS-3650A

  • Page 1 PS-3650A /PS-3651A User Manual...

  • Page 2: Preface

    Preface Thank you very much for purchasing a Pro-face PS-3650A/PS-3651A Unit, hereafter referred to as the PS-A. Before using the PS-A, read this manual thoroughly to familiarize yourself with the PS-A’s operation procedures and functions. NOTICE Copying this manual’s contents, either in whole or in part, is prohibited without the express permission of Digital Electronics Corporation, Japan.

  • Page 3: Essential Safety Precautions

    Essential Safety Precautions All safety-related procedures stated in this document must be followed to operate the PS-A correctly and safely. Be sure to read this and any related documents thoroughly to understand the correct operation and functions of the PS-A unit. Safety Icons Throughout this manual, these icons provide essential safety information for PS-A operation procedures requiring special attention.
  • Page 4 Do not connect or disconnect Host and PS-A unit communication cables while the PS-A is turned ON. The PS-A uses a lithium battery for backing up its internal clock data and the battery may explode if it is replaced incorrectly. When replacement is required, use a Pro-face-designated replacement product. 7.6 Replacing the Internal Battery (page7-15)
  • Page 5 Installation Be sure all cable connectors are securely attached to the PS-A unit. A loose connection may cause incorrect input or output signals. Wiring Be sure to ground the PS-A unit’s FG wire separately from other equipment FG lines. Also, be sure to use a grounding resistance of 100Ω...
  • Page 6 Do not operate or store the PS-A where chemicals evaporate, or where chemicals are present in the air. Corrosive chemicals : Acids, alkalines, liquids containing salt Flammable chemicals : Organic Solvents Do not use paint thinner or organic solvents to remove dirt or oil from the PS-A unit’s surface. Instead, use a soft cloth moistened with a diluted neutral detergent.

  • Page 7: Information Symbols

    Information Symbols This manual uses the following icons: Indicates a warning or a product limitation. Be sure to follow the instructions given with this icon to ensure the safe operation of the PS-A. Contains additional or useful information. Indicates steps used to accomplish a given task. (1) (2) Be sure to follow these steps in the order they are written.

  • Page 8: Package Contents

    Package Contents The following items are included in the PS-A unit’s package. Before using the PS-A, please check that all items listed here are present. PS-A Unit (1) Installation Guide (1) Installation Fasteners (4/set) Installation Guide Installation Gasket (1) USB Holder (2) sets (Attached to the PS-A unit) (USB Holder (1) + USB Cover (2)) x 2 Power Plug (1)

  • Page 9: Ul/Csa Approval

    UL/CSA Approval PS3650A-T41, PS3651A-T41 are UL/CSA listed products (UL File No. E220851, CSA File No.219866) Product Model No. UL/CSA Registration Model No. PS3650A-T41 3480801-02 PS3651A-T41 3480801-01 Those products conform to the following standards: • UL508 Industrial Control Equipment • CSA-C22.2 No.142-M1987 Process Control Equipment <Cautions>...

  • Page 10: Table Of Contents

    2.3 Interface Specifications................... 2-6 2.3.1 Serial Interfaces (COM1) ..................2-6 2.3.2 RAS Interface .......................2-8 2.4 Dimensions ..................... 2-9 2.4.1 PS-3650A External Dimensions ................2-9 2.4.2 PS-3651A External Dimensions .................2-10 2.4.3 Panel Cut Dimensions ..................2-11 2.4.4 Installation Fasteners..................2-11 2.4.5 Dimensions attached RS-232C/RS-485 exchangeable unit .......2-12...
  • Page 11 Chapter 3 Hardware Installation 3.1 Installation....................... 3-2 3.1.1 Installation Procedures ..................3-2 3.2 Wiring Precautions..................3-7 3.2.1 Connecting the Power Cord..................3-7 3.2.2 Connecting the Power Supply................3-10 3.2.3 Grounding ......................3-11 3.2.4 I/O Signal Line Placement .................. 3-11 3.3 Peripheral Devices Installation ..............3-12 3.3.1 Main Memory Installation ..................3-12 3.3.2 PCI Board Installation ..................3-14 3.3.3 PCMCIA (PC Card) Installation/Removal ............3-16...
  • Page 12 7.3 Periodic Inspection Items................7-5 7.4 Replacing the Installation Gasket ..............7-6 7.5 Replacing the Backlight .................. 7-8 7.5.1 Procedure for replacing the backlight of PS-3650A ..........7-9 7.5.2 Procedure for replacing the backlight of PS-3651A ..........7-12 7.6 Replacing the Internal Battery ..............7-15 Appendices 1 I/O Map ......................A-2...
  • Page 13 Memo...

  • Page 14: Chapter 1 Introduction

    Introduction 1. Prior to Operating the PS-A Unit 2. System Design 3. Accessories 4. Part Names and Functions This chapter describes peripheral devices that can be connected to PS-A Series units along with the name and functions of each part.
  • Page 15 PS-3650A / PS-3651A User Manual 1.1 Prior to Operating the PS-A Unit The following procedures are prior to use the PS-A unit. Connect the display unit and any optional devices. Connect Peripheral Devices 1.2 System Design (page1-3)/1.3 Accessories (page1-4) Connect the PS-A unit's power cord to AC Intercon- nection and turn the power switch ON.

  • Page 16: Front Access Mask

    Chapter 1 Introduction 1.1.1 Front Access Mask When you open the front maintenance hatch of the front unit, there are USB ports and a reset switch. If you want to prevent unwilling or unintentional accesses, change the DipSW settings to mask access from reset from the front side or the USB ports.

  • Page 17: System Design

    USB Key Board USB Mouse *1 Built-in accessory only *2 The Pro-face's optional devices used with the PS-A. Please refer to “1.3 Accessories”for details. *3 PS-3651A does not have an expansion board slot. PS-3650A only does. • This diagram shows only the PS-A’s internal layout and connectable devices. The...

  • Page 18: Accessories

    Chapter 1 Introduction 1.3 Accessories All accessories listed here are produced by Pro-face. Optional Item Product Name Model No. Description PSA-DDR512 Memory module 512M Bytes DIM module PSA-DDR1G Memory module 1G Bytes HDD Unit mounted a Type 2.5 Hard Disk...

  • Page 19: Part Names And Functions

    PS-3650A / PS-3651A User Manual 1.4 Part Names and Functions The following images are of a PS-3650A/PS-3651A unit. A: Display B: Touch Panel C: Power LED / RAS Status lamp (POWER) This status LED indicates the electric conduction status and operation status. The following table shows the display colors and corresponding status.
  • Page 20 This interface corresponds to USB Ver.2.0. It uses TYPE-A connector. It connects to the devices corresponding to USB. Q: PCMCIA Slot Cover Left Side (PS-3650A) Left Side (PS-3651A) R: Ethernet Interface (LAN) This interface corresponds to IEEE802.3, the Ethernet protocol (10BASE-T/100BASE-TX). It uses a modular jack connector which is RJ-45 type (Octupole).
  • Page 21 PS-3650A / PS-3651A User Manual Memo...

  • Page 22: Chapter 2 Specifications

    Specifications 1. General Specifications 2. Performance Specifications 3. Interface Specifications 4. Dimensions This chapter describes the general, functional and interface specifications of the PS-A as well as its part names and dimensions.

  • Page 23: Electrical

    PS-3650A / PS-3651A User Manual 2.1 General Specifications 2.1.1 Electrical PS-3650A PS-3651A Input Voltage AC100/240V Rated Voltage AC85 to 265V Rated Frequency 50/60Hz Allowable Voltage Drop 2.0ms (max.) Power Consumption 110VA (100W) (max.) 95VA (50W) (max.) leakage Current 2.0mA (max.) For AC100V(Ambient Temperature):30A(max.)

  • Page 24: Structural

    Chapter 2 Specifications 2.1.3 Structural PS-3650A PS-3651A Grounding resistance of 100 Ω, 2mm [0.0062inch ] or thicker wire, Grounding or your country’s applicable standard. (Same for FG and SG terminals) Rating : Equivalent to IP65f (Only not using Front USB)

  • Page 25: Performance Specifications

    PS-3650A / PS-3651A User Manual 2.2 Performance Specifications 2.2.1 Performance Specifications PS-3650A PS-3651A Intel Celeron M320 (1.3GHz) Intel ULV CeleronM (600MHz) L2 Cache Memory 512KB (Built in the CPU) Main Memory S.O DIMM socket 256 ~ 1GB (PC2700) BIOS FirstBIOS Embedded Pro (Phoenix Technologies Co.) Graphics XGA (1024 ×...

  • Page 26: Display

    Chapter 2 Specifications 2.2.2 Display Type TFT Color LCD Resolution W1,024 x H768 pixels Dot pitch W0.24mm [0.01in.] x H0.24mm [0.01in.] Effective Display Area W245.76mm [9.68in.] x H184.32mm [7.26in.] Color/Shade level 262,144 colors Backlight CFL (user replaceable) Brightness control 4 levels of adjustment Contrast Adjustment None Horizontal Direction : 120 degrees, Vertical Direction: 100 degrees...

  • Page 27: Interface Specifications

    PS-3650A / PS-3651A User Manual 2.3 Interface Specifications This section describes the specifications of each interface of the PS-A Series unit. • The PS-A unit’s serial port is not isolated. When the host (PLC) unit is also not isolated, be sure to connect the #5 SG (Signal Ground) terminal to reduce the risk of damaging the RS-232C circuit.
  • Page 28 Chapter 2 Specifications <Magnified image> DipSW Main Memory 1 2 3 4 5 6 7 8 RI/5V Changeover Switch <RI/5V change switch> The switch can change “RI/5V” for the No.9 pin of a RS-232C. The factory setting is “RI”. <Dip SW> SW No.

  • Page 29: Ras Interface

    PS-3650A / PS-3651A User Manual 2.3.2 RAS Interface Types of sockets for D-sub 9 pins are listed below. Use #4-40 (Inch Screw) fixing clamps to fix the joint of the interspace. Pin No. Signal Name Meaning Arrangement +12V 100mA DOUT 0 (+)

  • Page 30: Dimensions

    Chapter 2 Specifications 2.4 Dimensions The following dimensions apply to PS-3650A/PS-3651A units. 2.4.1 PS-3650A External Dimensions Unit: mm [in.] 301[11.85] 103[4.06] 60[2.36] 5[0.20] 313[12.32] Front side Dimensions with installation fasteners 130[5.12] 130[5.12] Front side side 130[5.12] 130[5.12] Bottom...

  • Page 31: Ps-3651A External Dimensions

    PS-3650A / PS-3651A User Manual 2.4.2 PS-3651A External Dimensions Unit: mm [in.] 301[11.85] 60[2.36] 5[0.20] 313[12.32] side Front Dimensions with installation fasteners 130[5.12] 130[5.12] side side Front 130[5.12] 130[5.12] Bottom 2-10...

  • Page 32: Panel Cut Dimensions

    Chapter 2 Specifications 2.4.3 Panel Cut Dimensions Panel cut dimensions for both PS-3650A and PS-3651A are the same. Unit: mm [in.] +0.04 301.5 [11.87 under 4-R3 2.4.4 Installation Fasteners Unit: mm [in.] 16 [0.63] 16.6 [0.65] 31 [1.22] 2-11...

  • Page 33: Dimensions Attached Rs-232C/Rs-485 Exchangeable Unit

    PS-3650A / PS-3651A User Manual 2.4.5 Dimensions attached RS-232C/RS-485 exchangeable unit PS-3650A Unit: mm [in.] (Except for protrudent objects and cable parts) 55[2.17] 50.5[1.99] PS-3651A Unit: mm [in.] (Except for protrudent objects and cable parts) 55[2.17] 50.5[1.99] 15.5[0.61] 2-12...

  • Page 34: Installation

    Hardware Installation 1. Installation 2. Wiring Precautions 3. Peripheral Devices Installation...

  • Page 35: Installation Procedures

    PS-3650A / PS-3651A User Manual 3.1 Installation This section describes the procedures and precautions for installing the PS-A unit. 3.1.1 Installation Procedures Follow the steps given below when installing the PS-A. Check the Installation Gasket’s Seating It is strongly recommended that you use the installation gasket, since it absorbs vibration in addition to repelling water.
  • Page 36 Chapter 3 Hardware Installation Creating a Panel Cut Create the correct sized opening required to install the PS-A, using the installation dimensions given. The installation gasket and the installation fasteners are required when installing the PS-A. 2.4.3 Panel Cut Dimensions (page2-11) Panel Panel Cut Area...
  • Page 37 PS-3650A / PS-3651A User Manual • Be sure that the ambient operation temperature and the ambient humidity are within their designated ranges. When installing the PS-A on the panel of a cabinet or enclosure, “Ambient operation temperature” indicates both the panel face and cabinet or enclosure’s internal temperature.
  • Page 38 Chapter 3 Hardware Installation Installing the PS-A (1) Insert the PS-A into the panel cut, as shown. (2) Insert the installation fasteners into the PS-A insertion slots, at the top and bottom of the unit. (total: 4 slots) • Insert each installation fastener securely into the Slots slot’s recess (shaded area).
  • Page 39 PS-3650A / PS-3651A User Manual (4) Use a Phillips screwdriver to tighten each fastener screw and secure the PS-A in place. • Tightening the screws with too much force can damage the PS-A unit’s plastic case. • For the moisture resistance effect, the torque required to tighten these screws is 0.5...

  • Page 40: Wiring Precautions

    Chapter 3 Hardware Installation 3.2 Wiring Precautions This section describes the procedures and precautions to install the PS-A unit. 3.2.1 Connecting the Power Cord To avoid an electric shock, prior to connecting the PS-A unit’s power cord terminals to the power terminal block, confirm that the PS-A unit’s power supply is completely turned OFF, via a breaker, or similar unit.
  • Page 41 PS-3650A / PS-3651A User Manual Power Cable specifications 0.75 to 2.5mm² [0.0009 to 0.0097inch Power Cable Size (18 to12AWG) Type of Cable Core Single or Strand Wire 10mm [0.39in.] Cable Core Length • Use copper conductors only. • When using the Strand Wire, if the Conductor's end (individual) wires are not twisted correctly, the end wires may either short against each other, or against an electrode.

  • Page 42: Connecting The Power Cord

    Chapter 3 Hardware Installation Connecting the Power Cord • To prevent the possibility of a terminal short, use a pin terminal that has an insulating sleeve. • The temperature rating of field installed conductors : 75°C only. (1) Confirm that the power cord is unplugged from the power supply. (2) Open the cable attachment holes of the Power Plug.

  • Page 43: Connecting The Power Supply

    PS-3650A / PS-3651A User Manual 3.2.2 Connecting the Power Supply This section describes the precautions for supplying a power voltage. • If the supplied voltage exceeds the PS-A unit's range, Twisted-pair cord Constant PS-A Unit Voltage connect a constant voltage transformer.

  • Page 44: Grounding

    Chapter 3 Hardware Installation 3.2.3 Grounding This section describes the precautions for grounding the PS-A unit. Do not use common grounding, since it can lead to an accident or machine breakdown. • When supplying power to the PS-A unit, be sure to (a) Exclusive Grounding (BEST) separate the input/output and power lines, as shown.

  • Page 45: Peripheral Devices Installation

    PS-3650A / PS-3651A User Manual 3.3 Peripheral Devices Installation A wide variety of optional units, DIM module, CF cards, manufactured by Pro-face and commercial Expansion boards (PCI bus compatible board), PCMCIA (PC cards) can be used with the PS-A. (Expansion boards are used only for PS-3650A.)
  • Page 46 Chapter 3 Hardware Installation (3) Install the main memory where the following figure shows. Insert the DIM module, which is an optional product, into the connector completely in an oblique direction, then press it downward until it is locked into the stopper. Connector Main Memory Main Memory (DIM Module)

  • Page 47: Pci Board Installation

    3.3.2 PCI Board Installation A PCI board, which is sold on the market, can be installed on PS-3650A. • The maximum size allowed for a PCI board is 174.63mm [6.88in.] × 106.68mm [4.2in.]. (1) Turn OFF the power switch of the PS-A and remove the power cable. Place the PS-A on a flat, level sur- face facing the display face downwards (2) Unscrew a screw of the expansion board support and remove the expansion board support.
  • Page 48 Chapter 3 Hardware Installation (3) Unscrew the expansion board cover’s screws (2) and remove the expansion board cover. (4) Unscrew a screw of the blank panel and take out the blank panel. (5) Insert the PCI board into the expansion board connector and place back the screw to fix the PCI board. The torque required to tighten a screw is 0.5 to 0.6N•m.

  • Page 49: Pcmcia (Pc Card) Installation/Removal

    (3) Place back the PCMCIA slot cover and tighten a screw. • When using a PC Card with a cable attached, Pro-face recommends you use a clamp or other type of device to prevent vibration from possibly dislodging the cable.

  • Page 50: Cf Card Insertion/Removal

    Multi Unit, the CF Card’s internal data, CF Card and the PS-A unit may be damaged or broken. Be sure to use only CF Cards manufactured by the Pro-face. The CF Card’s internal data may be damaged when using another manufacturer’s CF Card.
  • Page 51 PS-3650A / PS-3651A User Manual Inserting the CF Card Use the following steps to insert the CF Card in the PS-A. (1) Confirm that the PS-A is turned OFF. (2) Slacken a screw of the CF card cover and remove the CF card cover.

  • Page 52: Usb Holder Attachment/Removal

    Chapter 3 Hardware Installation 3.3.5 USB Holder Attachment/Removal When using a USB device, attaching the USB holder to the USB Interface located on the side of the PS-A unit prevents the USB cable Interface from becoming disconnected. Attachment (1) Attach the USB holder to the USB Interface on the side of the PS-A unit. Hook the upper pick of the USB holder to the attachment hole of the PS-A unit and then insert the lower pick as shown below to fix the USB holder.
  • Page 53 PS-3650A / PS-3651A User Manual Removal Remove USB Holder by the reverse procedures to the attachment procedures. (1) Lift up the tab of the USB holder and then remove the USB cover. USB Caver (2) Remove the USB cable. (3) Remove the picks pushing the USB holder from both top and bottom and then remove the USB holder from PS-A unit.

  • Page 54: Chapter 4 System Setup

    System Setup 1. Setup Procedures 2. System Parameters This chapter explains how to enter the PS-A system settings, as well as the cautions required both before and during set up.
  • Page 55 PS-3650A / PS-3651A User Manual 4.1 Setup Procedures The BIOS setting up procedures are the following. • Normally, use only the factory (default) settings. (1) Connect a USB keyboard to the PS-A. (2) Turn the PS-A’s power ON. (3) After the boot-up screen comes up, press the [F2] key until the following screen appears.

  • Page 56: System Parameters

    Chapter 4 System Setup 4.2 System Parameters Select the items to set up the system information. Here, we introduce the system parameters of each item. • Normally, use only the factory (default) settings. 4.2.1 Main System Time Shows the time which the PS-A currently recognizes. Move the cursor by the [Tab] key and set a proper time for the PS-A by the [Tab], [+] and [-] keys because the factory default setting is the Japan’s Standard Time (GMT+09:00).
  • Page 57 PS-3650A / PS-3651A User Manual Primary Master / Primary Slave Point out the cursor at the [Primary Master] or [Primary Slave] on the “Main screen”, and then press the [Enter] key, so that the following screen is shown. Type Specifies a type of drive which you use. Select from [Auto], [None], [ATAPI Removable], [CD-ROM], [IDE- Removable], [Other ATAPI], or [User].

  • Page 58: Advanced

    Chapter 4 System Setup Transfer Mode Specifies a method of transferring data. When the [type] is [None], nothing is displayed. In other cases, select from [Standard], [Fast PIO 1], [Fast PIO 2], [Fast PIO 3], [Fast PIO 4], [FPIO 3/DMA 1], or [FPIO 4/DMA 2] Ultra DMA Mode Specifies a Ultra DMA mode for the Hard drive.
  • Page 59 PS-3650A / PS-3651A User Manual Advanced Chipset Control Point the cursor to the [Advanced Chipset Control] and press the [Enter] Key, so that you can set up details. Advanced Chipset Control (page4-7) I/O Device Configuration Point the cursor to the [I/O Device Configuration] and press the [Enter] Key, so that you can go to the Serial...
  • Page 60 Chapter 4 System Setup Extended Memory Testing Specifies whether a test for the Extended Memory needs to be executed at the system starting-up. The test types are listed below. The factory default setting is [Just Zero it]. [Normal] Normal test [Just Zero it] Simple test [None] No test...
  • Page 61 PS-3650A / PS-3651A User Manual ECC Error Type Specifies the interruption setting when an ECC error occurs. Select from [None], [NMI], [SMI], or [SCI]. The factory default setting is [SMI]. SERR signal condition Specifies error bit(s) for ECC. Select from [None], [Single bit], [Multiple bit], or [Both]. The factory default setting is [Both].
  • Page 62 Chapter 4 System Setup RAS# Precharge Specifies the number of cycles of RAS precharge. Select from [Auto], [4DDR SDRAM Clocks (DDR333 SDRAM)], [3DDR SDRAM Clocks], or [2DDR SDRAM Clocks]. The factory default setting is [Auto]. I/O Device Configuration Point the cursor to the [I/O Device Configuration] on the [Advanced] screen and press the [Enter] Key, so that the following screen will be displayed.
  • Page 63 PS-3650A / PS-3651A User Manual Keyboard Features Point the cursor to the [Keyboard Features] on the [Advanced Chipset Control] and press the [Enter] Key, so that the following screen will be displayed. NumLock Specifies the NumLock status. Select from [Auto], [On], or [Off]. The factory default setting is [On].
  • Page 64 Chapter 4 System Setup Cache Memory Point the cursor to the [Cache Memory] on the [Advanced] screen and press the [Enter] Key, so that the following screen will be displayed. Memory Cache Specifies an enabled/disabled state for the Memory Cache. The choice is [Enabled] or [Disabled]. The factory default setting is [Enabled].
  • Page 65 PS-3650A / PS-3651A User Manual Cache xxxx-xxxx Specifies the cache setting for each address. Select from [Disabled], [USWC Caching] (The address A000 - AFFF and B000 - BFFF are only available.), [Write Through], [Write Protect], or [Write Back]. The factory default setting is as follows.
  • Page 66 Chapter 4 System Setup PCI IRQ line 1 ~ 8 Specifies the Interrupt Request Lines (IRQ) for PCI. Select from [Disabled], [Auto Select], [3], [4], [5], [7], [9], [10], [11], [12], [14], or [15]. The factory default setting is [Auto Select]. PCI/PNP ISA IRQ Resource Exclusion Point the cursor to the [PCI/PNP ISA IRQ Resource Exclusion] on the [PCI Configuration] screen and press the [Enter] Key, so that the following screen will be displayed.

  • Page 67: Intell

    PS-3650A / PS-3651A User Manual 4.2.3 Intell CPU Control Sub-Menu Point the cursor to the [CPU Control Sub-Menu] on the [Intel] screen and press the [Enter] Key, so that you can go to the [CPU] set-up screen. CPU Control Sub-Menu (page4-15)
  • Page 68 Chapter 4 System Setup ACPI Control Sub-Menu Point the cursor to the [ACPI Control Sub-Menu] on the [Intel] screen and press the [Enter] Key, so that you can go to the [ACPI] set-up screen. ACPI Control Sub-Menu (page4-21) APM Control Sub-Menu Point the cursor to the [APM Control Sub-Menu] on the [Intel] screen and press the [Enter] Key, so that you can go to the [APM] set-up screen.
  • Page 69 PS-3650A / PS-3651A User Manual Thermal Control Circuit This is a function that protects the CPU’s temperature, and its setting is a situation that if it exceeds the limit that CPU is able to work properly. Select from [Disabled], [TM1], or [TM2]. The factory default setting is [TM2].
  • Page 70 Chapter 4 System Setup MCH Power Management Sub-Menu Point the cursor to the [MCH Power Management Sub-Menu] on the [Intel] screen and press the [Enter] Key, so that the following screen will be displayed. Chipset Thermal Throttling Specifies a thermal throttle, a system to prevent a themorunway, for chipset. The choice is [Enabled] or [Disabled].
  • Page 71 PS-3650A / PS-3651A User Manual Video (Intel IGD) Control Sub-Menu Point the cursor to the [Video (Intel IGD) Control Sub-Menu] on the [Intel] screen and press the [Enter] Key, so that the following screen will be displayed. Default Primary Video Adapter Selects a priority of the [PCI] or [AGP] which should take for displaying.
  • Page 72 Chapter 4 System Setup ICH Control Sub-Menu Point the cursor to the [ICH Control Sub-Menu] on the [Intel] screen and press the [Enter] Key, so that the following screen will be displayed. Integrated Device Control Sub-Menu Goes to the setting screen where an enabled/disabled state for the USB, LAN and PCMCIA is specified. Integrated Device Control Sub-Menu (page4-20) CPU Sleep Specifies whether the CPU needs power saving.
  • Page 73 PS-3650A / PS-3651A User Manual Integrated Device Control Sub-Menu Point the cursor to the [Integrated Device Control Sub-Menu] from the [ICH Control Sub-Menu] on the [Intel] screen and press the [Enter] Key, so that the following screen will be displayed.
  • Page 74 Chapter 4 System Setup ACPI Control Sub-Menu Point the cursor to the [ACPI Control Sub-Menu] on the [Intel] screen and press the [Enter] Key, so that the following screen will be displayed. ACPI-IO APIC Mode Specifies an enabled/disabled state for the APIC. The choice is [Enabled] or [Disabled]. The factory default setting is [Enabled].
  • Page 75 PS-3650A / PS-3651A User Manual APM Control Sub-Menu Point the cursor to the [APM Control Sub-Menu] on the [Intel] screen and press the [Enter] Key, so that the following screen will be displayed. CX Status Specifies whether you use a power saving state when using APM OS. The choice is [Enabled] or [Disabled].
  • Page 76 Chapter 4 System Setup Workaround Control Sub-Menu Point the cursor to the [Workaround Control Sub-Menu] on the [Intel] screen and press the [Enter] Key, so that the following screen will be displayed. C3-APIC Workaround Select from [Enabled], [Auto], or [Disabled]. The factory default setting is [Enabled]. 4-23...

  • Page 77: Security

    PS-3650A / PS-3651A User Manual 4.2.4 Security Supervisor Password Is Displayed as “Set“ when the password is set. Since no password has been set at factories, the factory default setting is [Clear]. User Password Is Displayed as “Set“ when the password is set. Since no password has been set at factory, the factory default setting is [Clear].

  • Page 78: Boot

    Chapter 4 System Setup 4.2.5 Boot Specifies an order for boot-up devices. It searches from the top in sequence. By using the [+] or [-] keys, change its order. • Be sure to set and confirm the Boot menu each time when you install new hard disk or commer- cial USB memory.

  • Page 79: Exit

    PS-3650A / PS-3651A User Manual 4.2.6 Exit Exit Saving Changes Point the cursor to the [Exit Saving Changes] on the [Exit] screen and press the [Enter] Key, the current configuration is saved and the setting procedure is ended. Exit Discarding Changes Point the cursor to the [Exit Discarding Changes] on the [Exit] screen and press the [Enter] Key, the current configuration is NOT saved but the setting procedure is ended.

  • Page 80: Chapter 5 Setting Up Software

    Setting up Software 1. CD-ROM Contents 2. Setting Up Your PS-A Unit 3. Installing Drivers 4. Special Application Program Features 5. Cautions When Using Windows®2000/Windows®XP An accessory CD-ROM disk is included with the PS-A unit. This CD-ROM contains special programs ®...

  • Page 81: Software Configuration

    PS-3650A / PS-3651A User Manual 5.1 CD-ROM Contents 5.1.1 Software Configuration This section explains the organization of the software included in the accessory CD-ROM by the folder com- position diagram. PS-3650A/PS-3651A User Manual & Driver CD [Driver] [Audio] Audio Driver <Supported OS types> ®...

  • Page 82: Setting Up Your Ps-A Unit

    PS-A Utility Setup Install the necessary drivers and utility software from the “PS-3650A/PS-3651A User Manual & Driver CD” supplied with the PS-A unit. • To install the software on the PS-A, the USB CD-ROM drive is required.
  • Page 83 PS-3650A / PS-3651A User Manual Installing Software from the provided CD-ROM Install the software from the provided CD-ROM “PS-3650A/PS-3651A User Manual & Driver CD”. To begin the installation, click on the “Setup.exe” file in the following folder. ® Example) With Windows D:\Utility\WinXP\Setup.exe (When the CD-ROM drive is “D”)

  • Page 84: Setting Up An Hdd With Pre-Installed Os

    XP, related drivers and utility software. • Each pre-installed operating system on the hard disk in the PS-A unit is designed specially for PS-3650A/PS-3651A. Installing the HDD Unit After opening the PS-A unit’s packing box, check that a hard disk unit is installed. If it is not, install an HDD unit with the pre-installed OS.
  • Page 85 PS-3650A / PS-3651A User Manual Setting Up OS Set up the Pre-installed OS in the PS-A unit. For the setup procedures about the OS, refer to the Installation Guide that comes with the HDD unit with the pre-installed OS. PS-A Hard Disk Data A [Proface] folder is prepared on the C drive.

  • Page 86: Installing Drivers

    Chapter 5 Setting up Software 5.3 Installing Drivers Four types of dedicated PS-A drivers (Audio, Chipset, Graphic Accelerator and Mouse Emulation Software) are available. Install the required drivers when using a PS-A with no pre-installed OS (A PS-A unit that has been recovered using the Recovery CD-ROM will have all the required drivers installed).
  • Page 87 PS-3650A / PS-3651A User Manual Installing the Mouse Emulation Software Install the Touch Panel Driver in the PS-A unit. It’s necessary to agree to D.M.C’s Mouse Emulation Soft- ware (TSC-1310D/DD) License in advance. Appendices 4 License Agreement (pageA-5) (1) Start “C:\Proface\UPDD\Setup.exe” file.

  • Page 88: Special Application Program Features

    Chapter 5 Setting up Software 5.4 Special Application Program Features The special programs designed for the PS-A unit are located in the following folders. Here, it is assumed that the [Proface] folder has already existed on the hard disk of the PS-A unit. ®...
  • Page 89 PS-3650A / PS-3651A User Manual System Monitoring/RAS Application: SystemMonitor.exe The RAS and System Monitoring features allow users to monitor temperature, voltage, and fan operation ® alarms. This program runs on Windows System Monitoring Program: SystemMonitor.exe When an Error is Detected (page6-13) Watchdog Parameter Setup Program: System Monitor Property 6.2.1 Setup Procedures (page6-9)

  • Page 90: Uninstalling Utility Software

    Chapter 5 Setting up Software Keyboard Emulator (Keyclick.exe) This program allows the User’s mouse operation to perform keyboard-like data input. When this program is ® executed on Windows , a keyboard is displayed on the screen of the PS-A unit. It is required to agree to “IN-fINITY soft Keyclick32 License Agreement Appendices 4 License Agreement (pageA-5) •...

  • Page 91: Cautions When Using Windows®2000/Windows®Xp

    PS-3650A / PS-3651A User Manual ® ® 5.5 Cautions When Using Windows 2000/Windows Do the following process if necessary. 5.5.1 Automatic System Log-on Setup This setting allows users to simplify password entry at startup. ® Windows 2000 (1) Double-click on the [Control Panel]’s [User and Password] icon.

  • Page 92: Changing System Settings

    Chapter 5 Setting up Software 5.5.3 Changing System Settings ® Your Windows system’s configuration settings will need to be changed when the PS-A unit is connected to a LAN network or printer. Changing the System Configuration Settings ® When the Windows system configuration settings are changed, the following message appears.
  • Page 93 PS-3650A / PS-3651A User Manual Memo 5-14...

  • Page 94: Ras Features

    Monitoring Features 1. RAS Features 2. Monitoring the PS-A Status 3. Checking the Error Log List 4. Monitoring the PS-A Status from the Server 5. Restarting/shutting down the PS-A from the Server...

  • Page 95: Ps-A Ras Features

    Though the standard set of RAS features used will vary depending on the devices used, the following features are used to provide Alarm Monitoring and External Input Signal support. Power Voltage Alarm Cooling Fan RPM Alarm (PS-3650A only) Internal Temperature Alarm Alarm Monitoring...

  • Page 96: Ras Feature Details

    • An administrator Authentication is required for executing SMART Monitoring. • A CF card doesn't support SMART and therefore the status of the CF card cannot be monitored. • When a hard disk except options made by Pro-face is used, the operation of SMART Monitoring cannot be guaranteed.
  • Page 97 PS-3650A / PS-3651A User Manual External Input Signals The RAS interface connector of the PS-A unit accepts the following input signals. General Purpose Signal Input (DIN 2-bit) This general digital input is used for alarm detection in external devices. The input signal uses two bits. The System Monitor Property or an API-DLL can be used to enable or disable this feature, as well as designate what type of processing is to be performed once a signal is received.
  • Page 98 Chapter 6 Monitoring Features (Interface circuit) No polar character for sink source input Internal circuit Input part circuit DC12V to DC24V DIN 0(+) Input port PC357 DIN 0(-) DIN 1(+) Input port PC357 DIN 1(-) • For information concerning the RAS Connector Pin Configuration, refer to the following. 2.3.2 RAS Interface (page2-8)
  • Page 99 PS-3650A / PS-3651A User Manual External Output Signals The RAS interface connector on the PS-A unit is prepared for the following output signals. General Purpose Signal Output (DOUT 2-bit) This is a digital output signal for reporting system conditions to external devices. It can be controlled from applications via either the System Monitor Property, or an API-DLL.
  • Page 100 Chapter 6 Monitoring Features Types of Processing The PS-A unit can send the following system status information to an external device. LED Indicator The three-color LED is used to indicate the PS-A system conditions. It is also used as a power ON/OFF indi- cator.

  • Page 101: Ras Feature Overview

    PS-3650A / PS-3651A User Manual 6.1.3 RAS Feature Overview System Monitor System Properties Voltage, Fan RPM* , Temperature Alarm Detection Level Settings Enable/Disable Settings SMART Alarm, Power Alarm, Fan Alarm* 3 , Internal Temperature Alarm, Output Settings, Popup User OS Shutdown...

  • Page 102: Monitoring The Ps-A Status

    Chapter 6 Monitoring Features 6.2 Monitoring the PS-A Status 6.2.1 Setup Procedures Double-click [System Monitor Property] in [Control Panel] to display the System Monitor Property screen. • You can also display the System Monitor Property screen by selecting [Start] -> [Program] -> [System Monitor].
  • Page 103 PS-3650A / PS-3651A User Manual The following table lists the operating settings that can be configured for each feature. O: Setting available X: Setting not available Operation Feature Popup DOUT0- Buzzer Reset Message Shutdown Watchdog Timer Voltage Temperature Backlight SMART DIN0-1 •...

  • Page 104: Monitoring Operation

    Chapter 6 Monitoring Features 6.2.2 Monitoring Operation When you start monitoring, you can check the operating status of the PS-A on the System Monitor screen. System Monitor Screen When you start up the System Monitor, the System Monitor screen is not displayed immediately but its icon appears in the System Tray in the taskbar.
  • Page 105 PS-3650A / PS-3651A User Manual There are buttons: [Buzzer Off], [Reset], [Minimize], and [Close], located at the bottom of the System Moni- tor screen. Button Operation Buzzer Off Stops the buzzer sound at normal operations. Clears the error condition held at normal operations and inside the Reset System Monitor.

  • Page 106: Error Messages

    "Watchdog Timer Error" Backlight "Backlight Blowout Error" SMART "SMART Error" *1: PS-3650A Only • The messages displayed on the pop-up message output screen can be modified on the System Monitor Property screen. 6.2.1 Setup Procedures (page6-9) Shutdown Confirmation Message 6-13...
  • Page 107 PS-3650A / PS-3651A User Manual System Monitor Property Screen Shutdown Confirmation Message 6-14...

  • Page 108: Checking The Error Log List

    Chapter 6 Monitoring Features 6.3 Checking the Error Log List Error type/location and error actions are recorded as error events in the System Log. Error event information can be checked using the Event Viewer. ® ® • This feature can be used with Windows 2000 and Windows 6.3.1 Error Message Display...

  • Page 109: Error Type/Location And Error Action

    PS-3650A / PS-3651A User Manual 6.3.2 Error Type/Location and Error Action Error Type/Location The error types/locations shown by the Event Viewer are as follows. Error Type/Loca- Error Message tion Vcore A VOLT Vcore A Error has occurred. Vcore B VOLT Vcore B Error has occurred.
  • Page 110 Chapter 6 Monitoring Features Error Action Error Message Buzzer Buzzer has sounded because of error. Popup Message Popup Message has been shown because of error. OS Shutdown Window has been shut down because of error. LED has output because of error.

  • Page 111: Monitoring The Ps-A Status From The Server

    PS-3650A / PS-3651A User Manual 6.4 Monitoring the PS-A Status from the Server The Remote RAS feature uses the Pro-face’s Pro-Server with Pro-Studio (optional) installed in the host PC to monitor and control the System Monitor/RAS feature of the PS-A.

  • Page 112: Installation Procedures

    Chapter 6 Monitoring Features 6.4.2 Installation Procedures On the server PC, start up the “Setup.exe” file in the [RASSvr] folder on the accessory CD-ROM, and then install the program by following the instructions on the screen. 6.4.3 Setup and Preparation of the Remote RAS Feature In order to monitor the System Monitor/RAS features from the server PC, you are required to set up the Remote RAS feature and start up the System Monitor (SystemMonitor.exe).
  • Page 113 PS-3650A / PS-3651A User Manual When 2 or more IP Addresses are allocated to the PS-A unit, the [Auto] cannot be selected. Enter set- tings that allow the reading of a fixed IP Address from a DHCP server. For details, contact your com- pany’s network administrator for getting the detailed information.

  • Page 114: Read And Write Of The System Monitor/Ras Feature

    Chapter 6 Monitoring Features 6.4.4 Read and Write of the System Monitor/RAS Feature The read/write operation of the operating conditions of the client PS-A and System Monitor/RAS feature can be performed from the server PC via the Pro-Server. User Application Server PC Pro-Server with Pro-Studio (Optional) Pro-Easy.dll...
  • Page 115 PS-3650A / PS-3651A User Manual List of Device Addresses Device Device Read/ 16-bit 32-bit Device Bit Access Type Symbol Write Access Access VcoreA Voltage* WORD VLT0 VcoreB Voltage* WORD VLT1 +3.3V Voltage* WORD VLT2 +5V Voltage* WORD VLT3 +12V Voltage*...
  • Page 116 Chapter 6 Monitoring Features • When “Forced Shutdown” or “Forced Reboot” is written to the device address, the system automatically shuts down/restarts the operation system without prompting the confirmation for saving the data on current applications. Take extra cautions when performing write operation in order to avoid accidental data loss.
  • Page 117 PS-3650A / PS-3651A User Manual Bit Assign of Error Event, and Error Mask Device Name Item VcoreA Voltage Error ERR00 VcoreB Voltage Error ERR01 +3.3V Voltage Error ERR02 +5V Voltage Error ERR03 +12V Voltage Error ERR04 +2.5V Voltage Error ERR05...

  • Page 118: Restrictions

    Chapter 6 Monitoring Features Error Messages This section describes the error messages of the Pro-Server that are displayed for the errors caused during device read/write operations. The following table lists the error codes for the RAS feature. Error Code Error Message Decimal Hexadecimal Number...
  • Page 119 PS-3650A / PS-3651A User Manual Available Simplified DLL Features • Direct Read Function • Direct Write Function • Cache Read Function • Retrieval of Multithreading Handle • Release of Multithreading Handle • Loading of Network Project File • Error Code String Conversion.

  • Page 120: Restarting/Shutting Down The Ps-A From The Server

    Chapter 6 Monitoring Features 6.5 Restarting/shutting down the PS-A from the Server The Remote Shutdown feature allows the user to shut down and/or restart the PS-A from the server PC via the network when the Pro-Server is not installed to the system. The installer of this application is included on the accessory CD-ROM (\Utility\Shutdown).
  • Page 121 PS-3650A / PS-3651A User Manual 6-28...

  • Page 122: Chapter 7 Maintenance

    Maintenance 1. Cleaning the Display 2. Cleaning the Fan Filter 3. Periodic Inspection Items 4. Replacing the Installation Gasket 5. Replacing the Backlight 6. Replacing the Internal Battery This chapter explains cautions and inspection criteria that will ensure trouble-free use of the PS-A.
  • Page 123 PS-3650A / PS-3651A User Manual 7.1 Cleaning the Display When the surface or frame of the display become dirty, soak a soft cloth in water with a neutral detergent, wring the cloth tightly, and wipe the display. • Do not use paint thinner, organic solvents, or a strong acid compound to clean the unit.
  • Page 124 7.2 Cleaning the Fan Filter In PS-3650A, the fan is used for cooling the CPU and the memory. Since excessive dirt and dust in the filter of the fan can potentially affect the performance of the unit, regular cleaning of the filter is strongly recom- mended.
  • Page 125 PS-3650A / PS-3651A User Manual (4) Remove dust on the filter using a cleaner etc. If stubborn dirt or stains are present, wash the filter with a neutral detergent. • Do not wring the filter to dry it. Filter Filter •...
  • Page 126 Be sure to inspect the PS-A periodically to ensure it is in good working condition. Ambient environment check • Is the ambient temperature within the specified range? (PS-3650A) When using HDD When not using HDD 5 to 50°C 0 to 50°C...
  • Page 127 PS-3650A / PS-3651A User Manual 7.4 Replacing the Installation Gasket The installation gasket provides protection against dust and moisture. • A gasket which has been used for a long period of time may have scratches or dirt on it, and could have lost the moisture resistance to be equivalent to IP65f. when installing the PS-A removed from the enclosure again, the moisture resistance to be equivalent to IP65f may go down.
  • Page 128 Chapter 7 Maintenance • Be sure to confirm the condition of installation of the gasket when you install the unit in the panel. The gasket must be inserted correctly into the groove for the PS-A’s moisture resistance to be equivalent to IP65f. •...
  • Page 129 PS-3650A / PS-3651A User Manual 7.5 Replacing the Backlight PS-A units use a CFL, long-life type backlight. The actual life of the backlight however, will vary depending on the PS-A’s operating conditions, and replacement may be required. A PS-A backlight has a life of 50,000 hours (approx.

  • Page 130: Procedure For Replacing The Backlight Of Ps-3650A

    Chapter 7 Maintenance 7.5.1 Procedure for replacing the backlight of PS-3650A Be sure to wear gloves when exchanging the backlight, and follow the following procedures. (1) Turn OFF the power switch of the PS-A and remove the power cable. (2) Remove the PS-A unit from the equipment (panel etc.) to which the unit has been incorporated, and place the PS-A unit on a flat, level surface facing the display face downwards.
  • Page 131 PS-3650A / PS-3651A User Manual (5) Unscrew the screws (6) (See the figure below). (6) Open the PS-A unit as the figure below indicates. Backlight Unit (7) Disconnect the Backlight Unit cable from the connector on the inverter board, and then remove the cable from the cable clamp.
  • Page 132 The necessary torque is 0.5N•m to 0.6N•m. • After backlight replacement is completed, turn the PS-A unit’s power ON and check if the screen’s display is normal. If the display is not correct, please contact the Pro-face distributor from whom you purchased the backlight unit.

  • Page 133: Procedure For Replacing The Backlight Of Ps-3651A

    PS-3650A / PS-3651A User Manual 7.5.2 Procedure for replacing the backlight of PS-3651A Be sure to wear gloves when exchanging the backlight, and follow the following procedures. (1) Turn OFF the power switch of the PS-A and remove the power cable.
  • Page 134 Chapter 7 Maintenance (5) Open the PS-A unit as the figure below indicates. Backlight Unit (6) Disconnect the Backlight Unit cable from the connector on the inverter board, and then remove the cable from the cable clamp. Cable Clamp Connector Cable (7) Loose the Backlight Unit setscrew (1), and lift the edge of the Backlight Unit, and remove the unit while sliding it along the groove.
  • Page 135 (11) Put the Mask Cover back in place and tighten the screws (3).The necessary torque is 0.5N•m to 0.6N•m. • After backlight replacement is completed, turn the PS-A unit’s power ON and check if the screen’s display is normal. If the display is not correct, please contact the Pro-face distributor from whom you purchased the backlight unit.

  • Page 136: Replacing The Internal Battery

    BIOS settings again after replacing the battery. There is a danger of explosion if the PS-A unit’s battery is incorrectly replaced. This battery should be replaced with equivalent type recommended by Pro-face. Prior to replacing the battery, be sure to turn OFF the PS-A unit’s power.
  • Page 137 The battery is on the PC board inside the PS-A unit. Refer to “7.5 Replacing the Backlight” for how to open the PS-A unit. 7.5.1 Procedure for replacing the backlight of PS-3650A (page7-9) 7.5.2 Procedure for replacing the backlight of PS-3651A (page7-12) (1) Be sure to confirm that power is not supplied to the PS-A unit and open the unit.

  • Page 138: Appendices

    Appendices 1. I/O Map 2. Memory Map 3. Interrupt Map 4. License Agreement This section describes the hardware configuration including the I/O map, memory map and interrupt map.

  • Page 139: O Map

    PS-3650A / PS-3651A User Manual I/O Map Address AT System Device System Device 0000H-001FH DMA controller (8237) 0020H-003FH Interrupt controller (8259A) 0040H-005FH System timer (8254) 0060H-006FH Keyboard controller 0070H-007FH Real time clock, NMI mask 0080H-009FH DMA page register 00A0H-00BFH Interrupt controller 2 (8259A)

  • Page 140: Memory Map

    Appendices Memory Map MAXMEM SMRAM MAXMEM-1MB FrameBuffer Ŷ1 MAXMEM-2MB to 8MB Expanded Memory System BIOS F000:0000 Expanded ROM Area D000:0000 PXE BIOS, VGA BIOS C000:0000 Video RAM A000:0000 Conventional Memory 0000:0000 The capacity allocated by “IGD-Memory Size“ of the “Video (Intel IGD) Control Sub-Menu“ screen of the BIOS setting is 1MB.

  • Page 141: Interrupt Map

    PS-3650A / PS-3651A User Manual Interrupt Map • The interrupts and DMA channel will change depending on the PnP features of PCI available. Hardware Interrupt List Description Parity Error or I/O Channel Check IRQ 0 Timer (in the Chipset) Keyboard...

  • Page 142: License Agreement

    Appendices License Agreement DMC Corporation Mouse Emulation Software (TSC-1310D/DD) Software License Agreement Before unsealing and using this product, please read the following license agreement carefully: This license agreement regarding the following software product (hereinafter called “product”) is concluded between you the individual or entity licensing the product (hereinafter called (“licensee”) and DMC Co., Ltd. (hereinafter called “DMC”).
  • Page 143 PS-3650A / PS-3651A User Manual 4. Termination of the right of use (1) The licensee can at any time terminate the right to use the product by expunging or destroying the product and all the copied contents. (2) When a licensee contravenes these license contents, DMC can notify the licensee of termination of the right to use the product.
  • Page 144 Appendices 7. Restrictions on Export When the product is subjected to the regulation of the Foreign Exchange and Foreign Trade Control Act and the laws and regulations accompanying it and the Export, the licensee shall observe the corresponding laws and regulations and rules. http://www.dmccoltd.com Hironokougyoudanchi, Hirono-machi, Futaba-gun, Fukushima 979-0401, Japan...
  • Page 145 PS-3650A / PS-3651A User Manual Memo...
