  • Page 1 EBC-C413 Intel ® Atom™ E3800 PC/104-Plus Single Board Computer with Digital I/O Product Manual WinSystems, Inc. | 715 Stadium Drive, Arlington, Texas 76011 | 817-274-7553 | info@winsystems.com | www.winsystems.com...

  • Page 2: Revision History

    No part of this document may be copied or reproduced in any form or by any means without the prior written consent of WinSystems, Inc. The information in the document is subject to change without notice. The information furnished by WinSystems, Inc. in this publication is believed to be accurate and reliable.

  • Page 3: Table Of Contents

    EBC-C413 Table of Contents Introduction..........1 Functionality .
  • Page 4 EBC-C413/Table of Contents 7.12.1 PWR - Power Connector ..........18 7.12.2 ATXAUX - ATX/Auxiliary Power Connector .
  • Page 5 EBC-C413/Table of Contents Navigation of the Menus............49 BIOS Splash Screen .

  • Page 6: Introduction

    EBC-C413/Introduction Introduction This manual provides configuration and usage information for the EBC-C413. The EBC- C413 is a full-featured embedded single board computer (SBC) with digital I/O. If you still have questions after reviewing this manual, contact the WinSystems Technical Support at (817) 274-7553, Monday through Friday, between 8 AM and 5 PM Central Standard Time (CST).
  • Page 7 Frequency Effects (LFE), two Microphones, and CD Power • +5 V DC Power Input (main supply to EBC-C413) • If provided, the +12 V DC and -12 V DC supplies the PC104 and PC104PLUS connector. Also, some flat panel displays require +12 V DC.

  • Page 8: Before You Begin

    Practices” on page 64) when using and handling the WinSystems EBC-C413. Adherence to these recommendations provides an optimal user experience and prevents damage. Read this document and become familiar with the EBC-C413 before proceeding. FAILING TO COMPLY WITH THESE BEST PRACTICES MAY DAMAGE THE EBC-C413 AND VOID YOUR WARRANTY.

  • Page 9: General Operation

    EBC-C413/General Operation General Operation The EBC-C413 is a single-board computer (SBC). It is a full-featured embedded system with a variety of onboard I/O options. The following figure is a simplified system block diagram of the EBC-C413. DDR3L SODIMM Display Controller DPØ/Mini DP...

  • Page 10: Specifications

    EBC-C413/Specifications Specifications The EBC-C413 adheres to the following specifications and requirements. EBC-C413 Specifications Electrical +5 V DC ±5%, 1.7 A Typical, 2.2 A Maximum Processor 3815: E3815 single-core 1.46 GHz, 512 K cache (MOQ required) 3825: E3825 dual-core 1.33 GHz, 1 MB cache 3845: E3845 quad-core 1.91 GHz, 2 MB cache...

  • Page 11: Configuration

    This section describes the EBC-C413 components and configuration. Component Layout The EBC-C413 provides components on the top and bottom of the board. 7.1.1 Top View Connectors The following figure illustrates the location of each connector on the top of the EBC- C413.
  • Page 12 EBC-C413/Configuration Top View Components The following table provides connector descriptions and references for the previous figure (“Top View Connectors” on page 6). Item Connector and Description Reference PWR - Power Connector page 18 ATXAUX ATXAUX - ATX/Auxiliary Power Connector page 18...

  • Page 13: Bottom View Components

    EBC-C413/Configuration 7.1.2 Bottom View Components The following figure illustrates the location of each connector on the bottom of the EBC- C413. MiniCard/mSata CFast MiniCard SODIMM0 Memory Bottom View Components The following table provides connector descriptions and references for the above figure (“Bottom View Components”).

  • Page 14: Jumpers

    EBC-C413/Configuration 7.1.3 Jumpers The following figure illustrates the location of each jumper on the EBC-C413. JP104P JP5VSB JPBAT JPFGA JPSATA JPLCDP JPATX JPMC2 JPMC1 JPMSATA Jumpers The following table provides jumper descriptions and references for the above figure (“Jumpers”). Item...

  • Page 15: I/O Port Map

    The EBC-C413 uses plug-and-play (PnP) BIOS resource allocation. Take care to avoid contention with resources allocated by the BIOS. The EBC-C413 utilizes a Low Pin Count to Industry Standard Architecture Bridge (LPC to ISA Bridge) to address the PC/104 bus. Most legacy PC/104 modules are I/O mapped and function as expected.

  • Page 16: Interrupt Map

    Reset Generator Interrupt Map The EBC-C413 supports hardware interrupts (IRQs) for PC/104 (ISA), PCI, and PCIe devices. The user must reserve IRQs in the BIOS CMOS configuration for use by legacy devices. The PCIe/PnP BIOS will use unreserved IRQs when allocating resources during the boot process.
  • Page 17 Bit 6 Bit 7 WinSystems does not provide software support for implementing the Interrupt Status Register to share interrupts. Some operating systems, such as Windows XP and Linux, have support for sharing serial port interrupts (see your specific operating system’s documentation for any available examples). You will need to implement the appropriate software to share interrupts for the other devices.

  • Page 18: Digital I/O

    EBC-C413/Configuration Digital I/O The EBC-C413 uses the WinSystems exclusive application-specific integrated circuit (ASIC), the WS16C48. This device provides 48 lines of digital I/O. There are 16 unique registers within the WS16C48. The following table summarizes the registers. I/O Address Offset...

  • Page 19: Page/Lock

    A write to this register (value ignored) clears ALL of the pending interrupts in this register. Watchdog Timer The EBC-C413 features an advanced watchdog timer that can be used to guard against software lockups. 7.5.1 Enable and Set the Timer The watchdog timer can be enabled in the BIOS Settings by entering a value for Watchdog Timeout on the Advanced/SIO >...

  • Page 20: Real-Time Clock/Calendar

    EBC-C413/Configuration system is loaded, the watchdog can be disabled or reconfigured in the application software. NOTE Use a longer reset interval if the watchdog is enabled and the operating system restarts. The watchdog can also be enabled, disabled, or reset by writing the appropriate values to the configuration registers located at I/O addresses 565h and 566h.

  • Page 21: Activity Light

    16-byte FIFO. The RS-232 has a charge pump to generate the plus and minus voltages so that the EBC-C413 only requires +5 V DC to operate. An independent, software programmable baud-rate generator is selectable from 50 through 115.2 kbps. Individual modem handshake control signals are supported for all ports.

  • Page 22: Power

    (only); 5 V DC stand-by is only required to supply the power connector for ATX mode operation. The EBC-C413 supports AT or ATX type power supplies. Jumper JP1 (see “PWR - Power Connector” on page 18) specifies the type of supply connected to the single board computer.

  • Page 23: Connectors

    7.12 Connectors 7.12.1 PWR - Power Connector Use this connection to supply power to the EBC-C413. If available, the +12 V and -12 V supplies to the PC104 and PC104PLUS connectors. When using an AT power supply, install jumper JP5VSB to short 5 V and 5 V Stand_by (see “JP5VSB - 5V Standby Power Select”...
  • Page 24 Most embedded systems use this type of power supply and it is the default setting. The EBC-C413 power circuit will detect an AT power supply if +5 VSB is not present at startup.

  • Page 25: Com3-4 - Com3 And Com4 Serial Ports

    This connection is a 20-pin Teka SVC210B3580135-0, 2 x 10, 0.1” box header connector (or equivalent). NOTE See “Serial Ports” on page 16 for more information on EBC-C413 serial ports. NOTE Refer to the “MIO - Multi I/O Interface Connector” on page 21 for connection to COM1 and COM2.

  • Page 26: Mio - Multi I/O Interface Connector

    EBC-C413/Configuration 7.12.4 MIO - Multi I/O Interface Connector Connect to the primary serial channels (COM1 and COM2), the printer port, and key board through this connector. Layout and Pin Reference: Name Name COM1_DCD COM1_DSR COM1_RX COM1_RTS COM1_TX COM1_CTS COM1_DTR COM1_RI...

  • Page 27: Rst - Reset Connector

    EBC-C413/Configuration NOTE See “Serial Ports” on page 16 for more information on EBC-C413 serial ports. Matching connector: • 50-pin IDC 0.1 inch TE 1-1658622-2 or equivalent WinSystems cable CBL-247-G-1-1.0 simplifies this connection to the board. 7.12.5 RST - Reset Connector This connector resets the CPU and all peripherals.

  • Page 28: Mouse - Ps/2 Mouse Connector

    This connection is a Molex 22-11-2052 (or equivalent). Matching connector: • Molex 22-01-2057 • Molex 08-55-0102 WinSystems cable CBL-343-G-1-1.375 simplifies this connection to the board. 7.12.7 KBMS - PS/2 Keyboard Connector This connection is for factory use only. v1.0 www.winsystems.com Page 23...

  • Page 29: Usb1 - Usb Connector For Ports 0-3

    7.12.8 USB1 - USB Connector for Ports 0-3 Connect to the USB signals provided at the USB1 connector. NOTE The EBC-C413 provides eight USB2.0 ports with ESD suppression (four ports at USB1 and four at USB2). Layout and Pin Reference:...

  • Page 30: Usb2 - Usb Connector For Ports 4-7

    7.12.9 USB2 - USB Connector for Ports 4-7 Connect to the USB signals provided at the USB2 connector. NOTE The EBC-C413 provides eight USB2.0 ports with ESD suppression (four ports at USB1 and four at USB2). Layout and Pin Reference:...

  • Page 31: Dio1 - Digital I/O Connector With Event Sense

    24 lines capable of event sense interrupt generation). External voltage translators allow the signals to drive or sink up to 5 V DC. NOTE The EBC-C413 provides 48 bi-directional TTL digital I/O lines (24 lines at DIO1 and 24 lines at DIO2).
  • Page 32 Additional Information This connection is a Teka SVC225B3580135-0, 2 x 25, 0.1 inch box header (or equivalent). Matching connector: • 50-pin IDC 0.1 inch TE 1-1658622-2 or equivalent WinSystems cable CBL-129-4 simplifies this connection to the board. v1.0 www.winsystems.com Page 27...

  • Page 33: Dio2 - Digital I/O Connector

    Connect to 24 bi-directional TTL digital I/O lines at the DIO2 connector. External voltage translators allow the signals to drive or sink up to 5 V DC. NOTE The EBC-C413 provides 48 bi-directional TTL digital I/O lines (24 lines at DIO1 and 24 lines at DIO2).
  • Page 34 Additional Information This connection is a Teka SVC225B3580135-0, 2 x 25, 0.1 inch box header (or equivalent). Matching connector: • 50-pin IDC 0.1 inch TE 1-1658622-2 or equivalent. WinSystems cable CBL-129-4 simplifies this connection to the board. v1.0 www.winsystems.com Page 29...

  • Page 35: Pc104Ab - Pc/104 8-Bit Bus Connector Pc104Cd - Pc/104 16-Bit (Includes Pc104Ab) Bus Connector

    PC104CD - PC/104 16-bit (Includes PC104AB) Bus Connector The PC/104 bus is electrically equivalent to the 16-bit ISA bus. Standard PC/104 I/O cards can be populated on EBC-C413’s connectors, located at J2 and J3. The interface does not support hot-swap capability.

  • Page 36: Pc104P - Pc/104-Plus/Pci-104 Bus Connector

    Additional Information The standard EBC-C413 uses a stackable PC104 expansion connector. The standard EBC-C413 is not a "stack-thru" type, meaning PC104 cards must "stackup." A "stack- thru" version may be special ordered (minimum quantities apply). The standard EBC- C413 connectors are: •...
  • Page 37 EBC-C413/Configuration Layout and Pin Reference: RESERVED AD00 VI/O AD02 AD01 AD05 AD04 AD03 C/BE0# AD007 AD06 AD009 AD08 AD11 VI/O AD10 M66EN AD14 AD13 AD12 +3.3V C/BE1# AD15 +3.3V SERR# RESERVED PERR# +3.3V RESERVED STOP# +3.3V LOCK# +3.3V TRDY# DEVSEL#...

  • Page 38: Sata1 - Serial Ata Connector

    EBC-C413/Configuration 7.12.14 SATA1 - Serial ATA Connector The EBC-C413 provides a SATA interface to support connection with a variety of SATA devices. Layout and Pin Reference: Name The SATA interface is an industry standard 7-pin, right angle SATA connector Molex 47080-4005 (WS G650-7007-600).

  • Page 39: Fan - Connector For Optional Fan

    The EBC-C413 supports low-voltage differential signaling (LVDS) for flat-panel displays with resolutions up to 1920x1200 at 24 bpp. NOTE The EBC-C413 has one VGA, one Mini DisplayPort and one Low-Voltage Differential Signaling (LVDS) interface. Only two of the three outputs may be active simultaneously.
  • Page 40 This connection is a Molex 501571-4007, 2 x 20, 1 mm Box Header (or equivalent). Matching connector: • MOLEX 501189-4010 (Housing) • MOLEX 501193-2000 (Crimp) WinSystems LVDS cables are panel specific. Please contact an Application Engineer through technical support for details (see the “Introduction” on page 1 for details). v1.0 www.winsystems.com Page 35...

  • Page 41: Bklt - Backlight Power And Control Connector

    This connection is a Molex 501331-1107, 1 x 11, 1 mm Vertical Box Header (or equivalent). Matching connector: • MOLEX 501330-1100 (Housing) • MOLEX 501334-0000 (Crimp) WinSystems Backlight cables are panel specific. Please contact an Application Engineer through technical support for details (see the “Introduction” on page 1 for details). v1.0 www.winsystems.com Page 36...

  • Page 42: Vga - Analog Vga Display Connector

    7.12.19 VGA - Analog VGA Display Connector The EBC-C413 supports analog VGA. NOTE The EBC-C413 has one VGA, one Mini DisplayPort and one Low-Voltage Differential Signaling (LVDS) interface. Only two of the three outputs may be active simultaneously. Layout and Pin Reference:...

  • Page 43: Dp - Mini Displayport Connector

    EBC-C413/Configuration 7.12.20 DP - Mini DisplayPort Connector NOTE The EBC-C413 has one VGA, one Mini DisplayPort and one Low-Voltage Differential Signaling (LVDS) interface. Only two of the three outputs may be active simultaneously. Layout and Pin Reference: NAME DESCRIPTION PIN...

  • Page 44: Audio - Hd Audio Connector

    EBC-C413/Configuration WinSystems battery BAT-LTC-E-36-16-1 and BAT-LTC-E-36-27-1 (connected to J3) simplify these connections to the board. BAT-LTC-E-36-16-1 BAT-LTC-E-36-27-1 7.12.22 AUDIO - HD Audio Connector Connect to the high-definition audio interface through this connector. Layout and Pin Reference: Name Name OUT_R MIC1_R...

  • Page 45: Lan1/Lan2 - Ethernet Lan Connectors

    EBC-C413/Configuration Matching connector: • Molex 503110-3000 • Molex 501930-1100 WinSystems has four cables for this connector: • CBL-AUDIO7-102-12 HEAD SIDE CENTER LINE 3.5mm JACK PINOUT • CBL-AUDIO7-100-14 PIN 1 • CBL-AUDIO5-102-12 LINE CENTER/ MIC2 MIC1 3.5mm JACK PINOUT • CBL-AUDIO2-102-12...

  • Page 46: Mc1 - Minicard Connector With Pci-Express And Usb

    EBC-C413/Configuration 7.12.24 MC1 - MiniCard Connector with PCI-Express and USB Connect to the MC1 MiniCard socket that supports a variety of peripherals available in this format. Name Name WAKE# 3.3Vaux COEX1 COEX2 1.5V CLKREQ# UIM_PWR UIM_DATA REFCLK- UIM_CLK REFCLK+ UIM_RST...
  • Page 47 To install a MiniCard into the MC1 socket: 1. Insert the MiniCard/mSATA. 2. Push the free end of the card toward the circuit board, and then secure it with two (2 mm) screws (WinSystems P/N: G527-0000-400). v1.0 www.winsystems.com Page 42...

  • Page 48: Mc2 - Minicard/Msata Connector With Pci-Express, Usb, And Sata

    EBC-C413/Configuration 7.12.25 MC2 - MiniCard/mSATA Connector with PCI-Express, USB, and SATA The EBC-C413 provides a second MiniCard socket (also see “MC1 - MiniCard Connector with PCI-Express and USB” on page 41) that supports a variety of peripherals available in this format. The socket alternatively supports an mSATA device in this socket. A sense circuit identifies the type of device present in the socket and auto-switches to handle either type.
  • Page 49 To install a MiniCard/mSATA into the MC2 socket: 1. Insert the MiniCard. 2. Push the free end of the card toward the circuit board, and then secure it with two (2 mm) screws (WinSystems P/N: G527-0000-400). v1.0 www.winsystems.com Page 44...

  • Page 50: Cf1 - Cfast Ssd Connector

    EBC-C413/Configuration 7.12.26 CF1 - CFast SSD Connector CFast is a small form factor SATA SSD standard that encompasses CFast data storage cards. Layout and Pin Reference: Number Segment Name Type Description Sequence SATA SGND Signal GND Ground for signal integrity...

  • Page 51: 204-Pin Sodimm Socket For System Memory

    EBC-C413/Configuration 7.12.27 204-pin SODIMM Socket for System Memory The EBC-C413 supports up to eight GB DDR3 SODIMM system memory through this one on-board socket. 7.13 Jumpers Jumper Part Number SAMTEC 2SN-BK-G applies to all jumpers. These are available in a ten piece kit from WinSystems (Part# KIT-JMP-G-200).

  • Page 52: Jpmc1 - Mc1 Wireless Lan Enable

    EBC-C413/Configuration Jumper Pin Reference Jumper AT / ATX Mode Select 4-6 or Open ATX Mode (Default) AT Mode 7.13.5 JPMC1 - MC1 Wireless LAN Enable Purpose: Enables wireless LAN (turns on) for MC1 Jumper MC1 Wireless LAN Setting Disable wireless LAN (MC1) Enable wireless LAN (MC1) 7.13.6 JPMC2 - MC2 Wireless LAN Enable...

  • Page 53: Jpbat - Rtc Battery Enable

    Purpose: Enable Real Time Clock (RTC) battery backup. Jumper RTC Battery Enable Setting Normal operation Resets RTC time, date, and battery backed 7.14 LED Indicators The EBC-C413 contains four LEDs covered by the heat spreader. Table 7–1: SATA Activity (LED1) LED1 Description LED1 Indicates SATA activity Table 7–2: Power and Standby Status (LED2 and LED3)

  • Page 54: Bios

    EBC-C413/BIOS BIOS General Information The EBC-C413 includes a BIOS from InsideH2O to assure full compatibility with PC operating systems and software. The basic system configuration is stored in battery backed CMOS RAM within the clock/calendar. As an alternative, the CMOS configuration may be stored in EEPROM for operation without a battery.
  • Page 55 EBC-C413/BIOS Main Use this screen to configure the following components: • Language • System Time • System Date Language v1.0 www.winsystems.com Page 50...
  • Page 56 EBC-C413/BIOS Advanced Access the following screens from the Advanced screen. Boot Configuration v1.0 www.winsystems.com Page 51...
  • Page 57 EBC-C413/BIOS PCI Express Configuration PCI Express Root Port Example (Port 1 shown) PCI Port Speed Example (Port 1 shown) v1.0 www.winsystems.com Page 52...

  • Page 58: Usb Configuration

    EBC-C413/BIOS PCI Port ASPM Example (Port 1 shown) USB Configuration Use this screen to enable or disable the following components: • EHCI Controller • USB RMH Mode • USB EHCI Debug • USB Per-Port Control • USB Port #0 •...

  • Page 59: Audio Configuration

    EBC-C413/BIOS Audio Configuration In addition to enabling and configuring LPE Audio Support, use this screen to enable or disable the following components: • Audio Controller • Azalia VCi Enable • Azalia Docking Support Enable • Azalia PME Enable • Azalia HDMI Codec...
  • Page 60 EBC-C413/BIOS VBT Hook Configuration • Configure CRT as: Default, CRT, No Device • CRT EDID Support: Enable, Disable • Configure DD10 as: Default, eDP, DisplayPort, HDMI/DVI, DisplayPort with HDMI/ DVI Compatible, No Device • Configure DD11 as: Default, eDP, DisplayPort, HDMI/DVI, DisplayPort with HDMI/ DVI Compatible, No Device •...

  • Page 61: Sata Configuration

    EBC-C413/BIOS SATA Configuration Use this screen to configure the following components: SATA Controller: Enable, Disable Chipset SATA Mode: IDE, AHCI • SATA PORT: Enable, Disable • SATA PORT 0 Hot Plug Capability: Enable, Disable • SATA PORT 1 Hot Plug Capability: Enable, Disable •...
  • Page 62 EBC-C413/BIOS ACPI Table/Features Control Use this screen to enable and disable the following components: • FACP - RTC S4 Wakeup • APIC - IO APIC Mode • DSDT - ACPI S3 • DSDT - ACPI S4 • DSDT - ACPI BRGT...
  • Page 63 EBC-C413/BIOS • Mode: Loopback, RS232, RS485, RS422 • Slew: Not Limited, Limited • BRG: Normal, High LPT Port: Enable, Disable • Base I/O Interrupt: 278, 378 • Interrupt: IRQ5 through IRQ7 Digital I/O: Enable, Disable • Base I/O Address: [0x120] •...
  • Page 64 EBC-C413/BIOS Power Use this screen to configure, enable, and disable the following components: • Advanced CPU Control: Opens a new screen • Wake on LAN: Enable, Disable • RTC Wake on S5: Enable, Disable Advanced CPU Control Use this screen to configure, enable, and disable the following components: •...
  • Page 65 EBC-C413/BIOS • VTX-2: Enable, Disable • TM1 AND TM2: Enable, Disable • AESNI Feature: Enable, Disable • DTS: Enable, Disable • Active Processor Cores: ALL, 1 • P-Starts (IST): Enable, Disable • Boot Performance Mode: Max Performance, Max Battery •...
  • Page 66 EBC-C413/BIOS • EFI/Legacy Device Order: EFI device first, Legacy device first, Smart Mode • Timeout: Value • Automatic Failover: Enable, Disable • EFI: Internal EFI Shell Exit Use this screen to save or exit the BIOS configuration with specific treatment of any changes made.

  • Page 67: Cables And Accessories

    EBC-C413/Cables and Accessories Cables and Accessories WinSystems cables and batteries simplify connection to the EBC-C413. The following table lists available items. Item Part Number Connection Description CBL-236-G-2-1.5 See “PWR - Power Connector” on PWR Power connection, DC harness page 18 EBC-TX.

  • Page 68: Software Drivers

    EBC-C413/Software Drivers 10. Software Drivers Go to www.winsystems.com for information on available software drivers. v1.0 www.winsystems.com Page 63...

  • Page 69: Appendix A. Best Practices

    If you have a power supply that allows you to adjust the voltage, it is a good idea to set the voltage at the power connector of the EBC-C413 to 5.1 V. The EBC-C413 can tolerate up to 5.25 V, so setting your power supply to provide 5.1 V is safe and allows for a small amount of voltage drop that will occur over time as the power supply ages and the connector contacts oxidize.
  • Page 70 Power Supply OFF—The power supply should always be off before it is connected to the I/O Module. Do not hot-plug the EBC-C413 on a host platform that is already powered. I/O Connections OFF—I/O Connections should also be off before connecting them to the embedded computer modules or any I/O cards.
  • Page 71 Sliding the board around until the standoffs are visible from the top can cause component damage on the bottom of the board. Do Not Bend or Flex the EBC-C413—Bending or flexing can cause irreparable damage. Embedded computer modules are especially sensitive to flexing or bending around Ball Grid Array (BGA) devices.
  • Page 72 I/O board to be damaged beyond repair. Conformal Coating Applying conformal coating to a WinSystems product will not in itself void the product warranty, if it is properly removed prior to return. Coating may change thermal characteristics and impedes our ability to test, diagnose, and repair products. Any coated product sent to WinSystems for repair will be returned at customer expense and no service will be performed.

  • Page 73: Appendix B. Mechanical Drawings

    EBC-C413/Mechanical Drawings Appendix B. Mechanical Drawings EBC-C413 Dimensions 27.30 mm (152.23 mm) 146.05 mm 140.97 mm 130.76 mm 93.35 mm 17.71 mm 7.62 mm 5.08 mm 0 mm DIA 3.20 mm THRU (8X) 9.50 mm 15.24 mm 18.20 mm 0 mm 9.10 mm...

  • Page 74: Appendix C. Power-On Self-Test (Post) Codes

    EBC-C413/Power-on Self-Test (POST) Codes Appendix C. Power-on Self-Test (POST) Codes If the system hangs before the BIOS can process the error, the value displayed at the I/O port address 80h is the code of the last successful operation. In this case, the screen does not display an error code.

  • Page 75: Sec Phase

    EBC-C413/Power-on Self-Test (POST) Codes SEC Phase Table C–1: SEC Phase 8-Bit POST Code Values Value Functionality Name Description SEC_SYSTEM_POWER_ON CPU power on and switch to Protected mode SEC_BEFORE_MICROCODE_PATCH Patching CPU microcode SEC_AFTER_MICROCODE_PATCH Setup Cache as RAM SEC_ACCESS_CSR PCIE MMIO Base Address initial...
  • Page 76 EBC-C413/Power-on Self-Test (POST) Codes Table C–2: PEI Phase 8-Bit POST Code Values (Continued) Value Functionality Name Description PEI_ENTER_DXEIPL Loading BIOS image to RAM PEI_FINDING_DXE_CORE Loading DXE core PEI_GO_TO_DXE_CORE Enter DXE core PEI_IFFS_TRANSITION_START iFFS Transition Start PEI_IFFS_TRANSITION_END iFFS Transition End NOTE The shaded rows in the table indicate the related functions are not from InsydeH2O (platform dependent).
  • Page 77 EBC-C413/Power-on Self-Test (POST) Codes Table C–3: DXE Phase 8-Bit POST Code Values (Continued) Value Functionality Name Description DXE_VARIABLE_RECLAIM Variable store garbage collection and reclaim operation DXE_FLASH_PART_NONSUPPORT Flash part not supported. NOTE The shaded rows in the table indicate the related functions are not from InsydeH2O (platform dependent).
  • Page 78 EBC-C413/Power-on Self-Test (POST) Codes Table C–4: BDS Phase 8-Bit POST Code Values (Continued) Value Functionality Name Description BDS_EXIT_BOOT_SERVICES Send END of POST Message to ME via HECI BDS_LEGACY_BOOT_EVENT Last chipset initialization before boot to Legacy OS. BDS_ENTER_LEGACY_16_BOOT Ready to Boot Legacy OS.
  • Page 79 EBC-C413/Power-on Self-Test (POST) Codes ACPI Table C–7: ACPI 8-Bit POST Code Values Value Functionality Name Description ASL_ENTER_S1 Prepare to enter S1 ASL_ENTER_S3 Prepare to enter S3 ASL_ENTER_S4 Prepare to enter S4 ASL_ENTER_S5 Prepare to enter S5 ASL_WAKEUP_S1 System wakeup from S1...

  • Page 80: Appendix D. Warranty Information

    WinSystems, provided that the warranty, if any, may be assigned. The sole obligation of WinSystems for any breach of warranty contained herein shall be, at its option, either (i) to repair or replace at its expense any materially defective Products or Software, or (ii) to take back such Products and Software and refund the Customer the purchase price and any license fees paid for the same.
