- Page 1 ITX-N-3900 Industrial Intel Atom ® E3900 Series (Intel Atom ® Processor X Series) NANO-ITX Single Board Computer (SBC) Product Manual WinSystems, Inc. | 715 Stadium Drive, Arlington, Texas 76011 | 817-274-7553 | info@winsystems.com | www.winsystems.com...
- Page 2 No part of this document may be copied or reproduced in any form or by any means without the prior written consent of WinSystems, Inc. The information in the document is subject to change without notice. The information furnished by WinSystems, Inc. in this publication is believed to be accurate and reliable.
-
Page 3: Table Of Contents
8.4.5 USB3 Connector (J6) ............15 v1.0 www.winsystems.com Page ii... - Page 4 Appendix A. Best Practices ........56 v1.0 www.winsystems.com Page iii...
- Page 5 Appendix C. Warranty Information ....... 59 v1.0 www.winsystems.com Page iv...
-
Page 6: Before You Begin
Technical Support at (817) 274-7553, Monday through Friday, between 8 AM and 5 PM Central Standard Time (CST). Refer to the WinSystems website for other accessories (including cable drawings and pinouts) that can be used with your ITX-N-3900. -
Page 7: Features
Product Manual or on our website at www.winsystems.com. NOTE WinSystems can provide custom configurations for Original Equipment Manufacturer (OEM) clients. For details, please contact an Application Engineer through Technical Support (see contact information in the Introduction section on page 1). - Page 8 Two ports on the board (header) General Purpose Input-Output (GPIO) • On-board programmable 8-bit General Purpose Input Output I/O interface SD Interface • One micro SD socket Expansion Interface • One M.2 E key socket for wireless application v1.0 www.winsystems.com Page 3...
- Page 9 Operating temperature: -40 °C to +85 °C (-40 °F to +185 °F) , 10% to 90% relative humidity • Storage temperature: -40 °C to +85 °C (-40 °F to +185 °F), 5% to 90% relative humidity 1. Requires airflow and high temperature grade DRAM. v1.0 www.winsystems.com Page 4...
-
Page 10: General Operation
I2C from EC PCIe x 1 SATA III SDIO SATA USB 2.0 mSATA/mini PCI-E SWITCH PCI-E USB 3.0 + 2.0 I/O x 2 USB 3.0 SMBus LPC BUS Temperature Sensor Front IO ITE8528 EC Flash GPIO SP339 RS232/422/485 v1.0 www.winsystems.com Page 5... -
Page 11: Specifications
HD Graphics LAN Card ® On-board Intel I210-IT Gigabit Network Connection LAN Card ® On-board Intel I210-IT Gigabit Network Connection #2 Audio Card On-board Realtek High Definition Audio 1. Requires airflow and high temperature grade DRAM. v1.0 www.winsystems.com Page 6... -
Page 12: Setup
Apollo Lake-I SOC. An older operating system might not be able to recognize this chip. For compatibility issues with older Windows Operating Systems such as Windows 8, make sure to install the Apollo Lake-I SOC chipset component driver (INF) before any other driver. v1.0 www.winsystems.com Page 7... -
Page 13: Intel Hd Graphics 50X
The timer is programmable from 1 second to 255 minutes (15,300 seconds). NOTE Use a long timeout if the watchdog timer is enabled and booting to an operating system. Use the following example as a guide to program the WDT. v1.0 www.winsystems.com Page 8... -
Page 14: Example Code For Wdt
J18. The signals GPIO[0..3] are configurable as either inputs or outputs. The signals GPIO[4..7] are output only signals. Use of the ITX-N-3900 GPIO signals is supported in the WinSystems, Inc. System Management Libraries and Example Applications. The System Management Libraries contain support for setting the direction of GPIO[0..3] and provides also allows the... -
Page 15: Configuration
J1 SW1 J3 J5 J4 J6 J2 8.1.2 Top View Components The following figure illustrates the location of each connector, jumper, and switch on the ITX-N-3900 top of the Figure 8–2: Top View Components (bottom side of board) v1.0 www.winsystems.com Page 10... - Page 16 BKLTCTRL Signal Source Selection (JP2) page 23 CMOS Clear (JP3) page 23 Power On Mode Selection (JP5) page 24 GPIO4 through GPIO7 Voltage Level Selection (JP6) page 24 Panel Voltage Selection (JP7) page 24 Backlight Power (JP8) page 25 v1.0 www.winsystems.com Page 11...
-
Page 17: Power
This connector provides for a +12 V DC input from a power adapter. Caution Either connect a power supply to this connector (J1) or to the ATX 4-pin connector (J13), but not both. 8.4.2 Audio Jack (Line_out) (J2) This connector provides an audio line out (Line_out) signal. v1.0 www.winsystems.com Page 12... -
Page 18: Displayport (J3)
ML_Lane 3 (n) Lane 3 (negative) CONFIG1 CONFIG1 CONFIG2 CONFIG2 AUX_CH (p) Auxiliary Channel (positive) Ground AUX_CH (n) Auxiliary Channel Hot Plug Hot Plug Detect (negative) RETURN Return for Power DP_PWR Power for connector (3.3 V 500 mA) v1.0 www.winsystems.com Page 13... -
Page 19: Rj45 Connector (J4/J5)
LED (left) and one bi-color green/yellow LED (right). Activity Ethernet Status Left No Link Flashing (green) Linked Right No Link Linked at 10 MB On (yellow) Linked at 100 MB On (green) Linked at 1 GB v1.0 www.winsystems.com Page 14... -
Page 20: Usb3 Connector (J6)
Pin Reference: USB 3.0 USBVCC 8.4.6 External Audio Pin Header (J7) This 4x2-pin header provides pins for Mic + Line_in + Line_out. Layout and Pin Reference: Name Name MIC_L Line_in_L Ground Line_in_R Line_out_L Ground Line_out_R MIC_R v1.0 www.winsystems.com Page 15... -
Page 21: Front Panel Pin Header (J8)
Power On (-) Reset (-) Power On (+) 8.4.8 VGA Pin Header (J9) This 5x2-pin header provides pins for VGA connections. Layout and Pin Reference: Name Name GREEN GND (Ground) BLUE VSYNC GND (Ground) HSYNC +5 V v1.0 www.winsystems.com Page 16... -
Page 22: Rs232/422/485 Pin Header (J10)
RS-485 DCD# RX/TX- RXD# RX/TX+ TXD# DTR# DSR# RTS# CTS# 8.4.10 M.2 key E Socket (J11) The ITX-N-3900 provides a 2230 M.2 key E Socket to support a variety of peripherals as available in this format. v1.0 www.winsystems.com Page 17... -
Page 23: Port Connector (J12)
Voltage (5 V DC) through pin 1 and pin 19 is always available. It is supplied by the 5 V power source (in normal operation mode) or by the 5 V standby power source (in standby mode). v1.0 www.winsystems.com Page 18... -
Page 24: Battery Connector (J15)
The ITX-N-3900 provides a Mini-PCIe socket to support a variety of peripherals as available in this format. The socket alternatively supports a mSATA device in this socket. Select mSATA, or Mini-PCIe in the BIOS to support your specific expansion device. v1.0 www.winsystems.com Page 19... -
Page 25: Ddr3 Sodimm Socket (J17)
GPIO3 GPIO7 (Output Only) Ground +5 V 8.4.18 LVDS Connector (J19) The ITX-N-3900 supports LVDS flat panel displays. Layout and Pin Reference: Name Name VDD_LVDS VDD_LVDS LVDSA_DATA0 LVDSA_DATA#0 LVDSA_DATA1 LVDSA_DATA#1 LVDSA_DATA2 LVDSA_DATA#2 LVDSA_DATA3 LVDSA_DATA#3 LVDSA_CLKP LVDSA_CLKN v1.0 www.winsystems.com Page 20... -
Page 26: Backlight Connector (J20)
LVDSB_DATA#1 LVDSB_DATA2 LVDSB_DATA#2 LVDSB_DATA3 LVDSB_DATA#3 LVDSB_CLKP LVDSB_CLKN Ground Ground 8.4.19 Backlight Connector (J20) Power and control is supplied through the Backlight connector at J20. Layout and Pin Reference: Name +5 V BL_CTRL +12 V Ground BL_Enable v1.0 www.winsystems.com Page 21... -
Page 27: Sata Gen2 Connector (J21)
ITX-N-3900/Configuration 8.4.20 SATA GEN2 Connector (J21) The bootable SATA (3.0) interface is located at J21. WinSystems offers CBL-SATA-701- 20 for this connector. Layout and Pin Reference: Name RX1+ RX1- TX1- TX1+ 8.4.21 SATA Power Connector (J22) Power is supplied to the SATA device via the connector at J22. -
Page 28: Jumpers And Switches
SOC (System on a Chip)(Default) 8.5.3 CMOS Clear (JP3) Clear CMOS using this jumper (JP3). See “Reset CMOS BIOS Configuration” on page 54 for usage of this jumper. JP7/JP8 Function 1-2 Short Normal Operation (Default) 2-3 Short Clear CMOS Contents v1.0 www.winsystems.com Page 23... -
Page 29: Power On Mode Selection (Jp5)
Function 1-2 Short 2-3 Short 3.3 V (Default) 8.5.6 Panel Voltage Selection (JP7) Select the appropriate V setting using this jumper (JP7). Function 1-3 Short 3.3 V 3-5 Short 5 V (Default) 3-4 Short +12 V v1.0 www.winsystems.com Page 24... -
Page 30: Backlight Power (Jp8)
After the initial power up, press SW1 briefly to power the unit on or off, depending on the present state. If the unit accidentally locks up and is unresponsive, press and hold SW1 for four (4) seconds to perform a hard restart. v1.0 www.winsystems.com Page 25... -
Page 31: Bios Settings
F1. The Help screen lists all the possible keys to use and the selections for the highlighted item. Press ESC to exit the Help screen. v1.0 www.winsystems.com Page 26... -
Page 32: Navigation Of The Menus
Enter key until the desired value is highlighted with a square block. Use the +/- keys to change the highlighted value, or enter the time using the number keys. v1.0 www.winsystems.com Page 27... - Page 33 • “Chipset Configuration” on page 30 • “LAN Configuration” on page 31 • “Graphics Configuration” on page 33 • “PCI/PCIE Configuration” on page 35 • “SATA Configuration” on page 38 • “USB Configuration” on page 39 v1.0 www.winsystems.com Page 28...
- Page 34 Use this screen to configure the specific active cores and advanced processor management technologies. Active Processor Cores Number of cores to enable in each processor package. Choices: Disabled (Default), Enabled Active Processor Cores [Enabled] Choices: Core 0: Enabled (Default) Core 1: Enabled (Default), Disabled v1.0 www.winsystems.com Page 29...
- Page 35 Enhanced C-states: Enable/Disable C1E. When enabled, CPU will switch to minimum speed when all cores enter C-State. Choices: Enabled (Default), Disabled Chipset Configuration Use this screen to configure the following features. High Precision Timer: Enable or Disable the High Precision Event Timer. Choices: Enabled (Default), Disabled v1.0 www.winsystems.com Page 30...
- Page 36 PCIe LAN1 Control: Control the PCIe Port 3 LAN function. Choices: Enabled (Default), Disabled PCIe LAN2 Control: Control the PCIe Port 4 LAN function. Choices: Enabled (Default), Disabled Wake on LAN: Enable or disable the Wake on LAN. Choices: Disabled (Default), Enable v1.0 www.winsystems.com Page 31...
- Page 37 PXE boot wait time: Wait time to press ESC key to abort the PXE boot. Choices: 0 (Default), 1, 2, 3, 4, 5 Media detect count: Number of times presence of media will be checked. Choices: 1 (Default), maximum 50 v1.0 www.winsystems.com Page 32...
- Page 38 Primary IGFX Boot Display: Select the Video Device which will be activated during POST. This has no effect if external graphics present. Secondary boot display selection will appear based on your selection. VGA mode will be supported only on primary display. Choices: Auto (Default), VGA, LVDS, DP v1.0 www.winsystems.com Page 33...
- Page 39 Select Color depth and data format. Choices: VESA 24 bpp (Default), JEIDA 24 bpp, VESA and JEIDA 18 bpp, Channel Mode: Select LVDS Channel Mode. Choices: Dual channel (Default), Single channel Clock Mode: Select Clock output for LVDS. Choices: Both Bus (Default), Even Bus, Odd v1.0 www.winsystems.com Page 34...
- Page 40 ITX-N-3900/BIOS Settings PCI/PCIE Configuration Use this screen to select mSATA or Mini-PCIe. Mini-PCIe & mSATA Switch: Choices: mSATA (Default), Mini-PCIe v1.0 www.winsystems.com Page 35...
- Page 41 PCIe Speed: Configure PCIe Speed. Choices Auto (Default), Gen1, Gen2 PCIe Selectable De-emphasis: When the Link is operating at 5.0 GT/s speed, this bit selects the level of de-emphasis for an Upstream component. 1b -3.5 dB, 0b – 6 dB. Choices: Enabled (Default), Disabled v1.0 www.winsystems.com Page 36...
- Page 42 PCIe Speed: Configure PCIe Speed. Choices: Auto (Default), Gen1, Gen2 PCIe Selectable De-emphasis: When the Link is operating at 5.0 GT/s speed, this bit selects the level of de-emphasis for an Upstream component. 1b -3.5 dB, 0b – 6 dB. Choices: Enabled (Default), Disabled v1.0 www.winsystems.com Page 37...
- Page 43 SATA Port 1 Hot Plug Capability: If enabled, SATA port will be reported as hot Plug capable. Choices: Disabled (Default), Enabled SATA Device Type: Identify whether the SATA port is connected to a Solid State Drive. Choices: Hard Disk Drive (Default), Solid State Drive v1.0 www.winsystems.com Page 38...
- Page 44 Legacy USB Support: Enables Legacy USB Support. Auto: Disable legacy Support if no USB devices are connected. Disable: Keep USB device available only for EFI applications. Choices: Enabled (Default), Disabled, Auto USB Mass Storage Driver: Enable/Disable USB Mass Storage Driver Support. Choices: Enabled (Default), Disabled v1.0 www.winsystems.com Page 39...
- Page 45 Use this screen to set the following system power control configuration parameters. Enable Hibernation: Enables or Disables System ability to Hibernate (OS/S4 Sleep State). This option may be not effective with some OS. Choices: Enabled (Default), Disabled v1.0 www.winsystems.com Page 40...
- Page 46 Wake up Time(HH: mm: ss): Use [Enter], [TAB] to select field, HH: 0-23, mm: 0-59, ss: 0-59. Choices: HH: 0-23, mm: 0-59, ss: 0-59 Wake On Ring: Enable or Disable the Wake on Ring. Choices: Disable (Default), Enable TPM Configuration Use this screen to set the trusted computing setting parameter. v1.0 www.winsystems.com Page 41...
- Page 47 Watch Dog Timer: Enable/Disable Watch Dog Timer. Choices: Disabled (Default), Enabled Watch Dog Timer [Enabled] Timer Unit: Select Timer count unit of WDT. Choices: Second (Default), Minute Timer value: Set WDT Timer value seconds/minutes. Choices: 20 (Default), 1-255 (Minute), 10-255 (Second) v1.0 www.winsystems.com Page 42...
- Page 48 ITX-N-3900/BIOS Settings H/W Monitor Configuration (Display only) Use this screen to display the hardware status. v1.0 www.winsystems.com Page 43...
- Page 49 ITX-N-3900/BIOS Settings Serial Port Console Redirection Use this screen to enable and to access serial port console redirection settings. Console Redirection: Choices: Disabled (Default), Enabled v1.0 www.winsystems.com Page 44...
- Page 50 1 stop bit. Choices: 1 (Default), 2 Flow Control: Flow control can prevent data loss from buffer overflow. When sending data, if the receiving buffers are full, a ‘stop’ signal can be sent to stop the data flow. v1.0 www.winsystems.com Page 45...
- Page 51 Legacy Console Redirection is enabled for legacy OS. Default setting for this option is set to Always Enable. Choices: Always Enable (Default), BootLoader Intel(R) I210-IT Gigabit Network Connection-00:90:FB:5D:BC:38 Use this screen to access the I210-IT Gigabit Network connection 00:90:FB:5D:BC:38 device parameters. v1.0 www.winsystems.com Page 46...
- Page 52 Negotiated (Default), 10 Mbps Half, 10 Mbps Full, 100 Mbps Half, 100 Mbps Full Wake On LAN: Enables the server to be powered on using an in-band magic packet. Choices: Disabled (Default), Enabled Blink LEDs: Identify the physical network port by blinking the associated LED. Choices: 0 (Default) v1.0 www.winsystems.com Page 47...
- Page 53 ITX-N-3900/BIOS Settings Intel(R) I210-IT Gigabit Network Connection-00:90:FB:5D:BC:39 Use this screen to access the I210-IT Gigabit Network connection 00:90:FB:5D:BC:38 device parameters (if present). v1.0 www.winsystems.com Page 48...
- Page 54 Negotiated (Default), 10 Mbps Half, 10 Mbps Full, 100 Mbps Half, 100 Mbps Full Wake On LAN: Enables the server to be powered on using an in-band magic packet. Choices: Disabled (Default), Enabled Blink LEDs: Identify the physical network port by blinking the associated LED. Choices: 0 (Default) v1.0 www.winsystems.com Page 49...
- Page 55 BIOS setup program. Password Check Mode: Setup: Check password when entering setup screen. Power on: Check password on every time system is powered on. Choices: Setup (Default), Power Setup Administrator Password: Set Administrator Password. No default setting. v1.0 www.winsystems.com Page 50...
- Page 56 The operating system (OS) may not boot if this setting is changed after the OS is installed. OS Selection: [Default] To Win8/8.1/10; [Other] Android / Linux; [Legacy System] Win7 / DOS; This item setting affects LPSS & XHCI Hand-off item setting. Choices: Default (Win8/8.1/10), Others, Legacy System, Intel Linux v1.0 www.winsystems.com Page 51...
- Page 57 BIOS settings. Save Changes and Reset: Reset the system after saving the changes. Discard Changes and Reset: Reset system setup without saving any changes. Restore Defaults: Restore/Load Default values for all the setup options. v1.0 www.winsystems.com Page 52...
- Page 58 UEFI: Built-in EFI Shell: Boot option filter (UEFI only). Reset the system after saving the changes. Launch EFI Shell from filesystem device: Attempts to Launch EFI Shell application (Shell.efi) from one of the available file system devices. v1.0 www.winsystems.com Page 53...
-
Page 59: Troubleshooting
To reset the BIOS CMOS configuration to the factory default settings: 1. Remove power from the ITX-N-3900. 2. Find JP3. 3. Remove jumpers from pins 1-2. 4. Install jumpers on pins 2-3 and wait five seconds. 5. Replace jumpers back on pins 1-2. v1.0 www.winsystems.com Page 54... -
Page 60: Update Bios
8. Press the DELETE or ESC key to open the BIOS setup menu and select Restore Defaults. 9. To finish the update, select the Save & Exit option. 11. Cables and Software Drivers Go to www.winsystems.com for cable information and software drivers. v1.0 www.winsystems.com Page 55... -
Page 61: Appendix A. Best Practices
Contact Points For maximum reliability, WinSystems boards typically use connectors with gold finish contacts. It is critical that the contact material in the mating connectors is matched properly (gold to gold and tin to tin). Contact areas made with dissimilar metals can cause oxidation/corrosion, resulting in unreliable connections. - Page 62 Conformal Coating Applying conformal coating to a WinSystems product will not in itself void the product warranty, if it is properly removed prior to return. Coating may change thermal characteristics and impedes our ability to test, diagnose, and repair products. Any coated product sent to WinSystems for repair will be returned at customer expense and no service will be performed.
- Page 63 Keep out zone 120.00 117.55 116.76 113.89 107.36 109.44 109.38 104.95 88.83 103.27 86.98 80.69 78.60 68.69 59.92 16.46 MAX HEIGHT=3MM 24.70 5.50 Keep out zone 4.52 14.00 4.27 16.15 5.62 3.54 3.00 MAX HEIGHT=3MM MAX HEIGHT=4MM v1.0 www.winsystems.com Page 58...
- Page 64 WinSystems, provided that the warranty, if any, may be assigned. The sole obligation of WinSystems for any breach of warranty contained herein shall be, at its option, either (i) to repair or replace at its expense any materially defective Products or Software, or (ii) to take back such Products and Software and refund the Customer the purchase price and any license fees paid for the same.
