Programming the ICAD
Valve size setup (mandatory)
When powering up the ICAD, A1 will flash in the display
; 01
Hold down for
2 seconds to enter
programming mode.
0
Press or
to select ICM size.
Press
Changing analogue input signal (optional)
; 01
Hold down for
2 seconds to enter
programming mode.
; 03
Hold down for
2 seconds to exit
programming mode.
24 Volt d.c. ONLY
2
; 10
Press and
go to parameter 10.
Press
1: ICM 20 with ICAD 600 6: ICM 65 with ICAD 900/1200
2: ICM 25 with ICAD 600 7: ICM 100 with ICAD 1200
3: ICM 32 with ICAD 600 8: ICM 125 with ICAD 1200
4: ICM 40 with ICAD 900/1200 9: ICM 150 with ICAD 1200
5: ICM 50 with ICAD 900/1200
Valve label ID:
ICM 20 ICM 25-65
; 03
Press until you
reach parameter 03.
Press
A3
If A3 alarm occurs
the analogue input
signal is out of range.
For further functions,
programming possibilities
and factory settings;
please see ICAD instruction.
DKRCI.PI.HV0.J2.02 / 520H4887 / 027R9801
11
Press until
you reach 11 (pass-
word). Press
ICM 100-150
ICM / ICAD is now
calibrating.
2
Press or
to select analogue
input signal.
Factory reset of ICAD
Disconnect power 
Press down and
simultaneously while
reconnecting power 
Release and

Note:
If factory reset has been performed the
ICAD will start flashing A1 in the display.
Decrease
value
Note:
If the keypad is not operated within 20 seconds;
time out will automatically exit programming mode.
; 26
Press until
you reach parameter 26
Press
; 26
Hold down
2 seconds to exit
programming mode.
1: 0-20 mA
2: 4-20 mA*
3: 0-10 V
4: 2-10 V
* default factory setting
Press

© Danfoss A/S (AC-SMC/MWA), 05 - 2011
Edit / Increase
Enter value
4
CA
for
5
; 03
