Summary of Contents for Raymarine Ray215e

  • Page 1 Ray215e VHF Radio O w n e r ' s H a n d b o o k...
  • Page 2 RAY215E Modular VHF Radio Owner’s Handbook Document number: R49018_2 Date: April 2002...
  • Page 4 RAY215E The RAY215E is a VHF radiotelephone that, when outfitted with the optional Full Function Handset, includes equipment for Class “D” Digital Selective Calling. It is intended for general communication within the Maritime Mobile Service worldwide and is for use on non-SOLAS vessels.

  • Page 5: Safety Notice

    • connected to the radio before transmitting • properly mounted • located where it will be away from people • located at least three feet (91cm) from the RAY215E and the microphone/ handset Adjustments or Repair Adjustments or Repair...
  • Page 6 United States Raymarine, Inc. 22 Cotton Road, Unit D Nashua, NH 03063-4219 Telephone: Fax: © Raymarine, Inc. 2001 603-881-5200 800-539-5539 603-864-4756...
  • Page 7 Date Certificate No. RT015 Anchorage Park Portsmouth Hampshire England P03 5TD Raymarine RAY 215E VHF Radio with optional Class "D" DSC E43004 Full Function Handset (DSC enabled) E46020 E46022 (includes second station kit) EN 60945 : 1997 EN 60945 : 1997...

  • Page 8: Table Of Contents

    Table of Contents Section 1 General Description 1.1 Introduction ... 1-1 1.2 Equipment Features ... 1-1 1.3 Minimum Function Handset / Full Function Handset Options ... 1-2 Section 2 Installation 2.1 Unpacking and Inspection ... 2-1 2.2 Equipment Supplied... 2-1 2.2.1 Optional Accessories ...
  • Page 9 3.5.10 Priority Channel ...3-11 3.5.11 Channel Memory ... 3-11 3.5.12 Resetting Factory Defaults ... 3-11 3.5.13 Scan Modes ... 3-12 3.5.14 Monitor Mode ... 3-13 3.5.15 Multi-Call Operation ... 3-14 3.5.16 LCD Backlight Function ... 3-14 3.5.17 NMEA Operation ... 3-15 3.5.18 Digital Selective Calling (DSC) ...
  • Page 10 4.7.4.2 Setting MMSI Number ... 4-56 4.7.4.3 ATIS Set Up ... 4-59 Section 5 Maintenance 5.1 How to Contact Raymarine... 5-1 5.2 Preventive Maintenance... 5-3 5.3 Specifications... 5-3 5.4 Drawings ... 5-7 Section 6 Appendix 6.1 International Channel Frequency Tables ... 6-1 6.2 US Channel Frequency Tables (Optional) ...

  • Page 11: Glossary Of Terms

    viii GLOSSARY OF TERMS All Scan ... Scans all channels ATIS ... Automatic Transmission Identification Canadian Channels ... Channel designator as defined by Industry DSC ... Digital Selective Calling Dual Watch ... Monitor the Priority Channel (9 or 16) while Duplex ...

  • Page 12: Section 1 General Description

    The RAY215E can transmit and receive on all available International marine VHF radiotelephone channels. With a software upgrade, the RAY215E can also communicate on the US channel set. Refer to the of Frequency Tables in Section 6, which list all marine VHF channels available in your RAY215E.
  • Page 13 Minimum Function Handset to enable intercom communications between the two stations. Note: The RAY215E is designed to have the base station as the priority unit. Therefore, Raymarine recommends installing the base station in the radio operating room or the location from which the ship is normally navigated.

  • Page 14: Optional Accessories

    It is also good practice to save the carton and the interior packing material in the event you must return the unit to the factory. Equipment Supplied The following is a list of materials supplied with the RAY215E: Description Description...

  • Page 15: Planning The Installation

    Mount the base station transceiver to allow easy access from the location where the ship is normally navigated. 2.3.1 Typical Mounting Methods The RAY215E can be conveniently mounted on a chart table, bulkhead, overhead, or any other desired location. Refer to Figure 2-1 for typical mounting methods.

  • Page 16: Flush Mounting

    Figure 2-1 Typical Mounting Methods 2.3.2 Flush Mounting In addition to the typical Mounting Methods, the RAY215E may also be flush mounted using the optional Flush Mount Kit. These kits are available from your Raymarine dealer or our Customer Service Department.
  • Page 17 8. Continue to push the bracket onto the transceiver until it is flush with the front bezel. 9. On each side of the transceiver, insert a screw through the bracket tab and into the threaded holes from which you removed the yoke knobs. 10.
  • Page 18 Installation 25 (1) 9 (0.35) 139 (5.47) 170 (6.69) Figure 2-2 Outline and Mounting Dimensions All dimensions are shown in millimeters and (inches)

  • Page 19: Dc Power And External Speaker Connections

    15 feet, larger wire diameter size should be used to prevent voltage line loss. Your RAY215E should be connected to the nearest primary source of ship's DC power. A typical source may be a circuit breaker on the power panel or a fuse block near the unit.

  • Page 20: External Speaker Connections

    2.4.2 External Speaker Connections The yellow (+) wire and green (-) wire are used for connecting the RAY215E to an external speaker (see Figure 2-3), such as Raymarine’s 10W External Speaker (part number E46006). Four watts of audio output power are provided for an external 4-ohm speaker.

  • Page 21: Antenna Connections

    When an optional Full Function Handset is installed enabling Class “D” DSC functionality, inputting NMEA data will provide position information to the radio. The RAY215E accepts NMEA 0183 data from a position determining device (GPS, etc.) to provide the Latitude and Longitude position information that is transmitted during a DSC Distress Call.

  • Page 22: Grounding

    While special grounding is not generally required for VHF radiotelephone installations, it is good marine practice to properly ground all electronic equipment to the ship's earth ground system. The RAY215E can be connected to ground by attaching a wire to one of the screws on the unit's rear panel and then to the nearest ship's earth ground connection point.
  • Page 23 2-10 Installation Figure 2-6 Typical Grounding Method...

  • Page 24: Minimum / Full Function Handset Priority

    Operation with Minimum Function Handset Introduction The RAY215E can be operated with the standard Minimum Function Handset, or an optional Full Function Handset that enables additional features, or both handsets to enable intercom capabilities. This section describes using the RAY215E with the Minimum Function Handset. See Section 4 for a full discussion of operation using the Full Function Handset.

  • Page 25: Handset Connections

    Note: The RAY215E is designed to have the base station as the priority unit. You should install the base station and Minimum Function Handset in the radio operation room or the location from which the ship is normally navigated. If an optional second station Full Function Handset is also installed, that handset is the one that should be installed in the remote location.

  • Page 26: Controls

    Operation with Minimum Function Handset Control and LCD Display 3.4.1 Controls Several of the keys on the front panel of the base station serve multiple purposes. For the most part, the function indicated on the first line of the key is accessed by pressing and releasing that key. The function indicated on the second line of the key is accessed by pressing and holding the key for two seconds.
  • Page 27 Operation with Minimum Function Handset SQUELCH Knob This knob controls the squelch sensitivity level. Rotating the knob clockwise increases the squelch level. Rotating the knob counterclockwise decreases the squelch. The lower bar graph on the LCD displays the squelch level. SCAN/ MEM Key This key starts or stops All Scan and Memory Scan Modes.
  • Page 28 Operation with Minimum Function Handset MON/ 1/25 Key Pressing and releasing MON/1/25 initiates the Dual-Watch Monitor mode. Pressing and holding MON/1/25 for 2 seconds toggles the output power between 1 and 25 watts. While in the 1 Watt mode, the 1W indicator illuminates on the LCD.

  • Page 29: Lcd Display

    16 Key Has the same function as the 16 key on the front panel controls. 3.4.2 LCD Display The following describes the functional characters on the RAY215E’s LCD. Figure 3-3 LCD Display Layout Operation with Minimum Function Handset 15 9...
  • Page 30 Operation with Minimum Function Handset NMEA indicator Appears in every operation mode when valid NMEA data is being received (available only with optional Full Function Handset). DSC indicator Appears when the radio is in the DSC mode, when an optional Full Function Handset is installed enabling the Class “D”...

  • Page 31: Operating Procedures

    REMOTE indicator Appears when a remote Second Station Full Functional Handset (optional) has the priority operation. Channel display (Large) Displays the current channel number. Channel display (Small) Displays the Priority Channel number while the radio is in the Monitor mode and function indicators during DSC mode. VOL indicator (in bar graph) Represents the current sound volume level.

  • Page 32: Setting The Channel

    Finland, Norway & Sweden You must have the appropriate license and your RAY215E must be programmed to use the private channel(s) that are approved for your country. Note: A license is required to operate the radio on the private channels.

  • Page 33: Setting The Frequency Mode

    16 key to switch to the Priority Channel 16 . 3.5.7 Setting the Frequency Mode The RAY215E can transmit and receive on all available International marine VHF radiotelephone channels. With a software upgrade, the RAY215E can also communicate on the US channel set.

  • Page 34: Selecting A Weather Channel

    The US National Oceanic and Atmospheric Administration (NOAA) broadcasts continuous weather reports and severe weather alerts, as needed. The RAY215E can be set to receive these broadcasts if the unit has been upgraded to use the US channel set, and US mode is selected. Weather broadcasts can only be heard in the US and Canada.

  • Page 35: Scan Modes

    The LCD remains blank for 2 seconds, CL appears momentarily, then the unit switches to channel 16. 3.5.13 Scan Modes The RAY215E is equipped with two types of scan options: All Scan and Memory Scan. How these options are initiated depends upon whether there are any channels stored in memory.

  • Page 36: Monitor Mode

    MULTI key. The MULTI indicator illuminates on the LCD to indicate the Multi-Call channel is also being monitored. If the RAY215E has received an upgrade to use the US channel set, and US mode is selected, Tri-Watch monitors the selected working channel, Channel 16, and the last used Weather Channel for the Weather Alert Tone.

  • Page 37: Multi-Call Operation

    3-14 When the Private Channel is the active channel in International mode, Tri-Watch monitors the selected Private Channel, Channel 16, and the Working Channel last used before entering Private Channel mode. To initiate Tri-Watch, press the MULTI key once. You cannot enter Tri-Watch from Dual Watch mode, as you do when the working channel is selected.

  • Page 38: Nmea Operation

    NMEA Operation When an Optional Full Function Handset is installed enabling the Class “D” DSC functionality, the RAY215E can receive valid position and time information, which are transmitted during a DSC Distress call. This data can be communicated via NMEA 0183 from a GPS, fishfinder, radar, or any device that outputs GPS sentences.

  • Page 39: Digital Selective Calling (Dsc)

    DSC equipment know where you are and that you are in a Distress situation. In the RAY215E, Class “D” DSC functionality is enabled by installing an optional Full Function Handset. This can be in the form of Single Station...

  • Page 40: Mmsi Number Setup

    3.5.18.1 MMSI Number Setup on Base Station You must enter your Maritime Mobile Service Identity (MMSI) number in the RAY215E before the DSC system will be operational. You can request an MMSI number when you apply for a radio license, if your country allows you to enter an MMSI number yourself.
  • Page 41 6. Press the DSC/PRI key once to accept. 7. Enter all 9 digits of the MMSI number in the same way. Once the 9th digit has been entered and accepted, the RAY215E plays back the 9 digits (one digit at a time) to verify proper entry.

  • Page 42: Individual Ship's Call

    SAFETY for advisory alerts, and URGENCY for assistance when life is not in immediate danger. The RAY215E can receive all three types of Individual calls but can only transmit ROUTINE Individual calls. As with any DSC operation, the call is made on channel 70.
  • Page 43 6. Press the DSC/PRI key once to accept. 7. Enter all 9 digits of the MMSI number in the same way. 8. Once the 9th digit has been entered and accepted, the RAY215E plays back the 9 digits to verify the entry.
  • Page 44 13. If the target station acknowledges, a tone sounds and “ACK” illuminates on the LCD. After 2 seconds, the RAY215E switches to the previously selected working channel. If the call is not acknowledged, exit the DSC mode by pressing the 16 key.
  • Page 45 6. Using the Channel Select (CH) knob on the front panel, select the desired channel, and press the DSC/PRI key once. The TX indicator on the LCD flashes, indicating the RAY215E is ready to transmit. 7. Press the PTT key to send the Individual Ship’s Call. After the digital “packet”...
  • Page 46 Operation with Minimum Function Handset ROTATE Select letter assigned to desired MMSI PRESS [TX] Flashing 2 seconds after receiving ACK, switches to selected channel To store an MMSI number in phonebook: 1. Press and release the DSC/PRI and D/L / I.C. keys simultaneously to place the unit in DSC mode.
  • Page 47 Note: The operation is cancelled if the 16 key is pressed or if no keys are pressed for 60 seconds during any part of this process. 8. Once the 9th digit has been entered and accepted, the RAY215E plays back the 9 digits just entered for proper entry verification.
  • Page 48 “IU” for URGENCY Individual Ship’s Call 2. To acknowledge the incoming Individual Ship’s Call, press the PTT key. The acknowledge is transmitted and your RAY215E automatically selects the working channel specified by the originating ship or station. 3. If you do not wish to acknowledge the call, press the 16 key to exit the DSC mode.

  • Page 49: Receiving An All Ships Call

    There are three types of All Ships Calls: ROUTINE for normal calls, SAFETY for advisory alerts, and URGENCY for assistance when life is not in immediate danger. The RAY215E can receive all three types of these calls but can transmit only SAFETY and URGENCY. As with any DSC operation, the call is made on channel 70.

  • Page 50: Group Call

    The Group Call feature sends transmissions that are only received by radios that share a common Group MMSI number. The RAY215E requires a Full Function Handset to program in the Group MMSI number. For this reason, the Minimum Function Handset can only receive Group Calls.

  • Page 51: Sending A Distress Call

    Note: When a Distress Call is sent, the unit emits a VERY LOUD distress alarm tone. To mute the alarm without interrupting the Distress Call, press the DSC/PRI key on the RAY215E base station. The radio will remain in DSC mode.

  • Page 52: Receiving A Distress Call

    Pressing the DSC/PRI key mutes this alarm but does NOT cancel the Distress Call. 3. Because it is Class “D” DSC compliant, the RAY215E can receive a DSC Distress Call but cannot acknowledge or relay the call. After the Distress Call is received, attempt to contact the vessel in distress on channel 16 and render assistance.

  • Page 53: Distress Relay Call

    PTT key is released following a transmission, the vessel’s ATIS ID number is also transmitted. You must enter your ATIS ID number into the RAY215E before the ATIS system will be operational. You can request an ATIS number when you apply for a radio license.
  • Page 54 DSC radio. However, if you have installed a Full Function Handset, which enables full Class “D” DSC functionality, the regulation allows for the disabling of ATIS. In the RAY215E you can toggle ATIS on and off by simultaneously pressing and releasing the SCAN/MEM and D/L/I.C.
  • Page 55 Note: Ensure the ATIS ID number entered is correct with the verification playback. Once the number is accepted as outlined in the next step, it can not be changed except by Raymarine representatives. 8. If the number is verified as correct, press and hold the DSC key for 2 seconds and a tone sounds.

  • Page 56: Operation With Optional Full Function Handset

    Handset, or an optional Full Function Handset that upgrades the radio to full Class “D” DSC status, or both handsets to enable intercom capabilities. This section describes using the RAY215E with the optional Full Function Handset. See section 3 for operation using the standard Minimum Function Handset.

  • Page 57: Handset Connections

    DISTRESS. The base station retains control until the DSC/PRI key is again pressed and held. Note: The RAY215E is designed to have the base station as the priority unit. You should install the base station in the radio operation room or the location from which the ship is normally navigated.

  • Page 58: Control And Lcd Display

    This section describes the control keys and display messages that appear on the Full Function Handset. Note: This Full Function Handset is also used with Raymarine radios that have additional features. As a result, the yellow Function labels POWER (16 key), CELL (3 key), HAIL (* key), and FOG (# key) represent features that are not available on the RAY215E.
  • Page 59 You can program the MMSI number yourself using the operation described in Section 4.7.4.2 (if regulations in your country permit MMSI number programming by the radio owner) or you can have your authorized Raymarine dealer/distributor program the number for you. ALL SHIP key Switches to the All Ships Call mode for Safety and Urgency transmissions.
  • Page 60 3, D, E, then F. Note: The CELL label over this key does not pertain to the RAY215E. 4/US key This key inputs the number 4. When an alphanumeric response is appropriate, each press of this key alternately inputs the characters 4, G, H, then I.
  • Page 61 25 key alternates the transmission power between 1W and 25W. * key This key inputs an asterisk (*). Note: The HAIL label over this key does not pertain to the RAY215E. 0/IC key This key inputs the number 0. Pressing the FUNC key followed by...

  • Page 62: Lcd Display

    Pressing and holding this key for 5 seconds selects Distress Signal Call mode. Subsequent operations are described in Section 4.6.18.8. 4.4.2 LCD Display The following describes the functional characters on the RAY215E Handset’s LCD. Figure 4-3 LCD Display Layout...
  • Page 63 Operation with Full Function Handset NMEA indicator Displayed when the radio receives valid NMEA position data. If the data is invalid or no data is received for a period of time, the indicator disappears. FUNC indicator Displayed when the FUNC key is pressed. Disappears when another key is pressed, or after no other key is pressed for a period of time.

  • Page 64: Radio Functions

    International and US (available only with a software upgrade). Receiving the Weather Channels (Optional) The RAY215E can programmed to receive 10 NOAA weather channels and will sound an alarm if a Weather Alert is received. This operation is available only in US frequency mode, if this option has been activated in your unit.

  • Page 65: Operating Procedures

    You can program the MMSI number yourself one time only, if permitted in your region, using the Menu Operation described in Section 4.7.4.2 or you can have your Raymarine dealer program the number for you. NMEA Positional Data Reception Positional information from external equipment is obtained using the NMEA 0183 interface.

  • Page 66: Setting The Volume

    4-11 Operation with Full Function Handset 4.6.1 Setting the Volume The sound volume adjustment for the handset has 11 settings. Pressing and releasing the VOL UP ( ) key increases the volume by one level; pressing and releasing the VOL DOWN ( ) key reduces the volume by one level.

  • Page 67: Setting The Frequency Mode

    4-12 Operation with Full Function Handset 4.6.4 Setting the Frequency Mode The RAY215E can transmit and receive on all available International marine VHF radiotelephone channels. With a software upgrade, the RAY215E can also communicate on the US channel set. Indicators displayed in the LCD identify the active frequency group: US for the US frequency group, or INT for the International group.

  • Page 68: Receiving On The Weather Channels

    The US National Oceanic and Atmospheric Administration (NOAA) broadcasts continuous weather reports and severe weather alerts, as needed, that can be received in the US and Canada. If your RAY215E has been programmed to use the US channel set and the US mode is selected, you will be able to receive these reports while your vessel is traveling in the waters of the US or Canada.

  • Page 69: Selecting The Private Channel

    The following table lists the Private Channel designations in each country and the corresponding RAY215E Private Channel numbers P1–P10. You must have the appropriate license and your RAY215E must be programmed to use the private channel(s) that are approved for your country.

  • Page 70: Priority Channel

    Operation with Full Function Handset Note: A license is required to operate the radio on the private channels. It is your responsibility to obtain the proper license to operate the radio on these frequencies. To select the Private Channel: 1. Press the FUNC key, followed by the 5/PRIV key. The assigned private channel number appears in the large channel display, preceded by a “P”.

  • Page 71: Multi-Call Operation

    4-16 Operation with Full Function Handset 4.6.9 Multi-Call Operation The Multi-Call function stores as many channels as desired in memory for quick access to frequently used channels. Using Multi-Call To start the Multi-Call operation, press the FUNC key followed by the 8/ M-CALL key.

  • Page 72: Setting The Transmission Power Output

    4.6.12 Desensitized Reception (Local Mode) You can set the RAY215E to reduce the receiving sensitivity in high traffic areas to decrease unwanted reception. This is also known as local mode. To select this mode, press the FUNC key followed by the 7/D/L key. While the desensitize function (local mode) is active, the DESENS indicator appears in the LCD display.

  • Page 73: Intercom Mode

    4-18 4.6.14 Intercom Mode Intercom mode enables conversation between a Minimum Function Handset connected to the port on the front of the base station and a Full Function Handset connected to the port on the rear of the base station. Note: Using the Intercom is a simplex operation.

  • Page 74: Scan Mode

    4. To exit Intercom mode, again press and hold the D/L/I.C. key. 4.6.15 Scan Mode During Scan mode, the RAY215E searches through the channels (including Private Channels), stops when radio traffic is detected, then resumes scanning after the traffic ceases. Two scan functions are available: All Channel Scan and Memory Channel Scan.

  • Page 75: Monitor Mode

    Note: Monitor modes are disabled when the ATIS operation is active. Dual-Watch In Dual-Watch Mode, the RAY215E operates on the Working Channel or Private Channel while constantly monitoring the Priority Channel 16. The radio locks onto the Priority, Working, or Private Channel whenever it becomes active, then returns to Dual-Watch when there is no activity.

  • Page 76: Nmea Operation

    When there is no longer any activity on the channel, the RAY215E returns to Tri-Watch. If the RAY215E has received an upgrade to use the US channel set and US mode is selected, Tri-Watch monitors the Working Channel, the Priority Channel 16, and the previously selected Weather Channel for severe weather alert broadcasts.
  • Page 77 4-22 Operation with Full Function Handset If a GPS device is not connected via NMEA, the radio emits a 5-second- long staccato alert tone and flashes the NMEA indicator 2 minutes after power up. This occurs every time the unit is turned on. The alarm is required by safety regulations and cannot be disabled.

  • Page 78: Digital Selective Calling (Dsc)

    Distress calls as well as Individual and All Ships calls on channel 70, the dedicated DSC channel for Marine VHF. For a Distress call transmission, the RAY215E with a Full Function Handset takes the position and time information from the input NMEA data along with your Maritime Mobile Station Identifier (MMSI) and converts it into a digital “packet”.

  • Page 79: Transmitting An Individual Call

    4-24 Transmitting an Individual Call To call another ship, you must select the Working Channel and a specific MMSI number. The MMSI number is selected either manually or from a Phonebook list of preprogrammed numbers specified using the MENU function. To cancel the call, press and hold the CLR key for 3 seconds. Press the INDV key to initiate the call data setup operation.
  • Page 80 Operation with Full Function Handset Note: The Full Function Handset provides you with a phonebook that holds entries for up to 20 Ship stations and 20 Shore stations. These are separate from the 10 phonebook entries stored in the base station using the Minimum Function Handset (see Section 3.5.18.2).

  • Page 81: Individual Call To Shore Station (Ship-To-Shore)

    4-26 Note: Only simplex channels (those channels that transmit and receive on the same frequency) can be selected for ship to ship Individual Calls. Pressing the SQ UP/DOWN key will scroll you through the simplex channels usable for this operation. Response If a response is received after pressing the PTT key, a receive-confirmation message is displayed.
  • Page 82 Operation with Full Function Handset INDV 3. Select SHORE and press the ENT key. 4. Scroll with the SQ UP/DOWN keys to select the method for inputting the MMSI number, either from the phonebook or manually. Press ENT to input your selection. 5.
  • Page 83 4-28 6. Press ENT again. A prompt appears on the display instructing you to press the PTT key. 7. Press PTT to transmit. With manual input, MMSI number would be displayed Response If a response is received after pressing the PTT key, a receive-confirmation message is displayed.

  • Page 84: Receiving An Individual Call

    Operation with Full Function Handset 4.6.18.3 Receiving an Individual Call When an Individual Call is received, the DSC indicator flashes, Ind appears on the 7-segment display, and the DSC Received Alert is sounded. On the dot matrix display appears the message RECEIVED IND CALL along with the type of call: ROUTINE, SAFETY, or URGENCY.

  • Page 85: Transmitting A Group Call

    You can send and receive DSC calls from groups of stations that share the same Group MMSI number. The RAY215E can only transmit ROUTINE Group calls. As with any DSC operation, the call is made on channel 70. To make a Group Call: 1.

  • Page 86: Receiving A Group Call

    Operation with Full Function Handset 9. Press PTT. The radio changes over to the selected Working Channel without waiting for acknowledgment. MMSI number Select Working Chanel with SQ UP/DOWN key 4.6.18.5 Receiving a Group Call When a Group Call is received, the DSC indicator flashes, Grp appears on the 7-segment display, and the DSC Received Alert is sounded.

  • Page 87: Transmitting An All Ships Call

    Distress Call. This call should only be used if hailing for assistance on 16 fails. The RAY215E can transmit and receive all three types of All Ships Calls: ROUTINE, SAFETY, and URGENCY. The RAY215E can transmit only SAFETY and URGENCY.

  • Page 88: Receiving An All Ships Call

    Operation with Full Function Handset Alternate by pressing the SQ UP/DOWN key 4.6.18.7 Receiving an All Ships Call When an All Ships Call is received, an alert is sounded. The LCD displays the type of All Ships call being received, along with the sender’s MMSI number, and a prompt to press ENT to accept or CLR to log the call.
  • Page 89 4-34 Unspecified Distress Call To make a Distress Call without specifying type of distress: 1. Open the door labeled DISTRESS on the back of the handset and press and hold the DISTRESS key. After one second, dSr flashes on the 7-segment display and the DSC indicator appears. On the dot matrix display, countdown message appears prompting you to hold the DISTRESS key for 4 more seconds.
  • Page 90 Operation with Full Function Handset When a response is received, the DSC indicator flashes and the DSC Distress alert is sounded. The LCD scrolls a message that the DISTRESS has been acknowledged, along with the sending station’s MMSI number or nickname. The message and alert are repeated until the CLR key is pressed.
  • Page 91 4-36 To make a Distress Call specifying the type of distress: 1. Open the door labeled DISTRESS on the back of the handset and press and release the DISTRESS key on the back of the handset. dSr appears on the 7-segment display and the DSC indicator illuminates. On the dot matrix display, the message FIRE appears.

  • Page 92: Receiving A Distress Call

    Operation with Full Function Handset 5. When this prompt appears, release the DISTRESS key. The unit is switched to Channel 16, displays the message AWAIT ACK, and monitors channel 70 for an acknowledgment. release DISTRESS dSr stops flashing and the distress alarm sounds continuously. The unit retransmits the DISTRESS call at random intervals of 3.5 to 4.5 minutes, until a response is received or the call is manually cancelled.

  • Page 93: Receiving A Distress Relay Call

    4.6.18.10 Receiving a Distress Relay Call Sometimes a ship’s distress call can be relayed from another ship or a shore station. The RAY215E can only receive a Relayed Distress call that has been addressed to All Ships. When a Relayed Distress call is received, the DSC indicator flashes, dSr appears on the 7-segment display, and the DSC Distress alert is sounded.

  • Page 94: Using The Dsc Log

    Operation with Full Function Handset 4.6.18.11 Using the DSC Log The RAY215E maintains 3 separate logs for storing information about sent and received DSC calls. The logs are divided by type: • Individual, All Ships, and Group Calls • Distress Calls •...

  • Page 95: Atis Operation

    ID number, program it into the RAY215E’s system Menu, and activate the ATIS feature. Once activated, ATIS can be enabled or disabled in the system Menu so that the RAY215E can be used in open water or inland waterways.

  • Page 96: Navstat Operation

    Operation with Full Function Handset FUNC + MENU 4.7.2 NAVSTAT Operation This operation indicates on the LCD display the position information that has been input via NMEA or has been manually input using the LL/ENT function as outlined in Section 4.7.3.2. To view current position information: 1.

  • Page 97: Dsc Operation

    4-42 4.7.3 DSC Operation DSC operation includes the manual entry of latitude/longitude, listing of other ship’s MMSI numbers for ship-to-ship and ship-to-shore communications, and listing of Group MMSI number. To initiate the DSC operation: 1. Press the FUNC key followed by the MENU key to initiate the Menu operation.

  • Page 98: Selecting Distress Call Type (Nature)

    Operation with Full Function Handset 4.7.3.1 Selecting Distress Call Type (NATURE) This menu item is used to select the nature of a distress call before the call is sent. The selected information will be sent along with the distress call. To select the nature of the distress that will be included with the call: 1.

  • Page 99: Manual Entry Of Latitude/Longitude (L/L Ent)

    4-44 4.7.3.2 Manual Entry of Latitude/Longitude (L/L ENT) This operation is used to manually enter the latitude/longitude and UTC time when normal NMEA input of the position information is not available. The radio will sound a 5-second-long alert tone every four hours to remind you to update your position.
  • Page 100 Operation with Full Function Handset press ENT press ENT Flashing press ENT Flashing press ENT Flashing press 2 Flashing press ENT Flashing press ENT press 5 Flashing Flashing press 7 Flashing press 0 Flashing Flashing press 7 Flashing press 0 Flashing Flashing press ENT...

  • Page 101: Modifying The Mmsi Number List (Phnbook)

    4-46 4.7.3.3 Modifying the MMSI Number List (PHNBOOK) This operation is used to modify the “phonebook” lists of MMSI numbers used for DSC Individual Calls. Two lists are available: one for Ship stations and one for Shore stations. Each list allows you to register the MMSI number and nickname for up to 20 Ship and 20 Shore stations.
  • Page 102 Operation with Full Function Handset Note: Pressing and holding the CLR key for 3 seconds during either ENTRY or DELETE returns operation to the mode before the Menu operation began. Adding Ship Stations to the List To add to the phonebook list for ship stations, input the MMSI number and nickname of the station.
  • Page 103 4-48 This display is shown only if the list already has the maximum 20 stations registered 2/ABC Flashing Deleting Ship Stations from the List When the ship station phonebook is selected, the oldest MMSI number or nickname flashes on the dot matrix display. 1.
  • Page 104 Operation with Full Function Handset To exit without deleting, press the SQ UP/DOWN key until DEL? N is displayed. If the list has no stations entered, the message PHNBOOK IS EMPTY HOLD DOWN CLR KEY is displayed. Press and hold the CLR key for 3 seconds to exit Menu mode.
  • Page 105 4-50 Adding Shore Stations to the List To add to the phonebook list for shore stations, input the MMSI number and nickname of the station. 1. To enter the MMSI number, press the corresponding numeric keys (0 through 9). The currently selected location is indicated by a flashing “–”...

  • Page 106: Modifying The Mmsi Group Number (Group)

    Operation with Full Function Handset Note: The 0 key will enter only the numeral “0”, while the 1 key will alternately enter “1” and “space”. The 0 and 1 keys do not have associated alpha characters. Deleting Shore Stations from the List When the shore station phonebook is selected, the oldest MMSI number or nickname flashes on the dot matrix display.
  • Page 107 4-52 Operation with Full Function Handset Entering a Group MMSI Number To add a Group MMSI number, select ENTRY then press the ENT key. Use the numeric keys (0 through 9) to input desired group number. The currently selected location is indicated by a flashing “–” character. Pressing a numeric key enters that value then advances to the next place.

  • Page 108: Setting Operation

    Operation with Full Function Handset 4.7.4 Setting Operation This operation sets the function features of the RAY215E: the ATIS ID number and on/off state, and the MMSI number. 1. Press the FUNC key followed by the MENU key to initiate the Menu mode.
  • Page 109 4-54 • The ATIS ID number is a ten digit number, beginning with a “9”. The MY ATIS set up process has you input only the last 9 digits. The leading “9” is automatically input for you. To register the ATIS Number into memory: 1.
  • Page 110 Operation with Full Function Handset Note: If the two ATIS numbers don’t match, the message ATIS ID NOT MATCH PRESS ENT scrolls across the display. Press ENT to exit the Menu mode and try again from step 1. 10. Press ENT to verify. The message ENT - STORE, CLR - EXIT is displayed.

  • Page 111: Setting Mmsi Number

    MMSI number. If this unit was purchased to be used in such a region, this function will e disabled and the programming must be done by your Raymarine distributor. • This is a one time operation. Once the MMSI number has been programmed, you will not be able to change it.
  • Page 112 Operation with Full Function Handset Pressing the following keys initiate the corresponding operation: K K K K K eys Action Action Action Action Action 0 - 9 keys Changes the flashing numeric value, then advances to the next digit’s place. ENT key Advances the (flashing) subject item to the next one without changing the numeric value.
  • Page 113 4-58 Operation with Full Function Handset Flashing Input MMSI number using numeric keypad Flashing re-enter MMSI No. Flashing...

  • Page 114: Atis Set Up

    Operation with Full Function Handset 4.7.4.3 ATIS Set Up This operation determines whether the ATIS ID number is transmitted after the PTT key is released. To set the ATIS function: 1. Per the description in Section 4.7.4 Setting Operation above, select ATIS.
  • Page 115 4-60 Operation with Full Function Handset...

  • Page 116: Section 5 Maintenance

    Accessories and Parts Raymarine accessory items and parts are available through your authorized Raymarine dealer. Please refer to the lists of component part numbers and optional accessories in Section 2.2.1 of this handbook and have the Raymarine part number ready when speaking with your dealer. If you are uncertain about what item to choose for your Raymarine unit, please contact our Customer Services Department prior to placing your order.

  • Page 117: On The Internet

    Many Raymarine accessory items and parts are available through your authorized Raymarine dealer. However if you are in need of an item not available through your retailer feel free to contact our Customer Service department Monday to Friday 8:15 AM to 5:00 PM Eastern Standard Time.

  • Page 118: Preventive Maintenance

    Maintenance Preventative Maintenance The RAY215E has been constructed to be virtually maintenance free. Your attention to a few basic points should assure many years of service. 1. Although the unit is waterproof, always keep the unit as dry as possible.

  • Page 119: Operating Requirement

    5.3.2 Receiver Channels Frequency Range Frequency Stability Usable Sensitivity Threshold Adjacent Channel Rejection 70dB Spurious Image Rejection Intermodulation Rejection 70dB Audio Output Hum & Noise in Audio 5.3.3 Operating Requirement Input Voltage Current Required Transmit Operating Temperature -20 °C to +50 °C Duty Cycle Humidity 5.3.4...
  • Page 120 Maintenance Optional Full Function Handset (FFHS) Height Width Depth Weight Optional FFHS Cradle Height Width Length Weight Optional FFHS External Speaker Height Width Depth Weight 173 mm (6.81 inches) 57 mm (2.25 inches) 28 mm (1.1 inches ) Approx. 138 g (0.30 lbs) 50 mm (1.97 inches ) 64 mm (2.52 inches) 102.1 mm (4.02 inches)
  • Page 121 Maintenance This page intentionally left blank...

  • Page 122: Drawings

    Maintenance Drawings Assembly Drawing...
  • Page 123 Maintenance Block Diagram RF PCB...
  • Page 124 Maintenance Control PCB...
  • Page 125 5-10 Maintenance Front PCB Microphone PCB...

  • Page 126: Frequency Tables

    Appendix Section 6 Frequency Tables International Mode Note: International VHF frequency usage varies from country to country. Ensure you are familiar with the channel requirements of the country where you are boating before using any VHF transceiver. Channel Frequency (MHz) Number 156.050 160.650...
  • Page 127 Channel Frequency (MHz) Number 157.150 161.750 157.200 161.800 157.250 161.850 157.300 161.900 157.350 161.950 157.400 162.000 156.025 160.625 156.075 160.675 156.125 160.725 156.175 160.775 156.225 160.825 156.275 160.875 156.325 160.925 156.375 156.375 156.425 156.425 156.475 156.475 156.575 156.575 156.625 156.625 156.675 156.675 156.725...
  • Page 128 Appendix Channel Frequency (MHz) Number 157.375 157.375 157.425 157.425 Notes: 1. For channels 15 and 17, output power is fixed at 1 watt only. Transmission at high power is not permitted. 2. Channel 70 is used for Digital Selective Calling (DSC) only and is not available for voice transmissions.
  • Page 129 US Mode Frequency Table (optional) Channel Frequency (MHz) Number 156.050 156.050 156.150 156.150 156.250 156.250 156.300 156.300 156.350 156.350 156.400 156.400 156.450 156.450 156.500 156.500 156.550 156.550 156.600 156.600 1 1 1 1 1 156.650 156.650 156.700 156.700 2 2 2 2 2 —...
  • Page 130 Appendix Channel Frequency (MHz) Number 156.325 156.325 1 1 1 1 1 156.375 156.375 156.425 156.425 156.475 156.475 156.575 156.575 156.625 156.625 156.675 156.675 156.725 156.725 3 3 3 3 3 156.875 156.875 156.925 156.925 156.975 156.975 157.025 157.025 157.075 157.075 157.125 157.125...

  • Page 131: Weather Channels And Frequencies (Optional)

    Important Notice The US National Oceanic and Atmospheric Administration (NOAA) broadcasts continuous weather reports and severe weather alerts, as needed. The RAY215E can be programmed to receive 10 NOAA weather channels and sound an alarm if a weather alert is received.
  • Page 132 Ray215e Document Number: R49018 Raymarine Ltd. Raymarine Inc. Anchorage Park 22 Cotton Road, Unit D Portsmouth, Hampshire Nashua, NH 03063-4219 England PO3 5TD +44 (0)23 9269 3611 603-881-5200 +44 (0)23 9269 4642 fax 603-864-4756 fax www.raymarine.com www.raymarine.com...

Table of Contents
