26
Table 2-1: Common Sounder Problems
Problem
Sounder temperature
readings are wrong
Sonar display is unreli-
able at high boat speeds

Status LED

The LED on the connector panel provides valuable information on the status of
your sounder module. The LED blinks green while the module is operating
normally. If the unit detects a problem, the LED blinks amber to indicate a warning
or red for an error. The number of times the LED blinks is a code representing the
nature of the problem. For multiple warnings/errors, the codes are given in
sequence with a 1.5 second pause between strings.
The following table shows the various LED status codes and their meanings.
Table 2-2: Status LED Warning Indications
W
A
R
N
I
N
G
S
1
After 30 seconds of no network activity, the sounder enters Standby mode: No sonar pings
are emitted and no warnings are output on the LED. Instead, the LED blinks green once
every 10 seconds.
For example, if the Transducer Sense fails and the network is not detected, the LED blinks
amber once, pauses 1.5 secs, blinks amber twice 0.5 secs apart, pauses 1.5 secs, and then
repeats the sequence until the problems are resolved or up to 10 minutes elapse.
Correction
1. If necessary, adjust the TEMP CALIBRATE parameter.
2. If receiving SeaTalk temperature, unplug the SeaTalk con-
nector from the display.
1. Turbulence around the transducer may be confusing the
unit.
No of
Color blinks
Amber 1
2
3
4
5
6
7
8
DSM300 and DSM30 Installation Manual
Meaning
Transducer Sense Failure
Network not detected
High Temperature Warning
Reserved
Reserved
Reserved
Reserved
Watchdog Timeout Reboot
Cleared
every 10 min
1
