- Page 1 5407384 Issue 1 Oct. 2007 WASHER DRYER Model Comm. Covered Code ARMXXL125EU 47554 Service Information Indesit Company UK Ltd © 2007 Reg. Office: Peterborough PE2 9JB Registered in London: 106725...
-
Page 2: Safety & Servicing Notes
Indesit Company SAFETY NOTES & GENERAL SERVICING ADVICE 1. This manual is NOT intended as a comprehensive repair/maintenance guide to the appliance. 2. It should ONLY be used by suitably qualified persons having technical competence applicable product knowledge and suitable tools and test equipment. 3. -
Page 3: Table Of Contents
Indesit Company INDEX Safety & Servicing Notes ..........2 Manufacturing Serial Number Information . -
Page 4: Specifications
Indesit Company SPECIFICATIONS Model Covered ARMXXL125EU Commercial Code: 47554 Colour White Height 850 mm Width 595 mm Dimensions Depth 580 mm Weight 75.5 kg Country of Origin Great Britain Electrical Supply 220 - 240 Volt AC @ 50 Hz Energy... -
Page 5: Controls, Options, Drying & Drying Process, Valve Operation
Indesit Company CONTROLS Programme Selector Dial Progress Indicator Lights Variable Controls Door Locked Symbol On-Off Option Buttons Start/Pause ON-OFF / SELECTING A PROGRAMME The machine is switched on by pressing the ON-OFF button. All the indicator lights will light up for a few seconds. Turn the programme selector dial to the to the desired programme. - Page 6 Indesit Company DOOR LOCKED INDICATOR LIGHT The 'Door Locked' indicator light will come on when you press the START / PAUSE button and will stay lit throughout the programme. When the programme has finished the indicator light will go out and you can then open the door, a double CLUNK noise will be heard from the door lock Solenoid at this point.
- Page 7 Indesit Company OPTIONS Programme Selector Dial Progress Indicator Lights Variable Controls Door Locked Symbol Mini Extra Start/Pause Easy Time On-Off Load Rinse Iron Delay Options are selected by pressing the button and confirmed by illumination an orange LED sited in the button.
-
Page 8: Option Availability
Indesit Company OPTION AVAILABILITY PROGRAMME PROGRAMME HALF EXTRA EASY TIME NUMBER DESCRIPTION LOAD RINSE IRON DELAY COTTON 60º COTTON COLOURFAST 40º ACRYLICS 60º DELICATE 40º FRESH UP SANITARY 90º NIGHT CYCLE 40º BABY CYCLE 40º SILKS 30º WOOL 40º DRY- COTTON DRY- SYTHETICS DRY- WOOL HIGH RINSE... - Page 9 Indesit Company DRYING SETTING THE DRYING PROGRAMME Independent Drying only Programme: Remove the wet laundry and in the drum the dosing ball (if used) until the correct drying weight load is left in the drum. Close the door until it clicks shut. Turn the programme selector dial to Drying Programmes 11, 12 or 13.
-
Page 10: Controls Information
Indesit Company CONTROLS INFORMATION A single control board located at the back of the machine contains all the circuitry to control the machine and interfaces with the programme selector, option buttons and LEDs located on the console panel. The control board has an access port to the rear of the machine. Programmes are selected by turning the rotary switch to one of the 16 positions. - Page 11 Indesit Company THE CONDENSER TUMBLE DRYING PROCESS The drying process is by means of a closed air system driven by a circulating fan. Air is drawn internally from the rear of the outer drum, passed over a heating element and returned to the front of the drum via an inlet through the door seal.
- Page 12 Indesit Company Flushing Valve Operation During Rinse phase: 2 xs 15 seconds Drying Phase: 1 x before drying phase for 4 seconds End cycle: After drying phase, during cool down phase Valve 118 seconds Valve 2 seconds Beginning of Drying Cycle Wash valve: 1 second to put water into dispenser hose...
-
Page 13: Wiring Connections And Wiring Diagram
Indesit Company WIRING CONNECTION CHART Mains Live & - 7 - Filter - 6 - Neutral - 5 - MAINS FILTER Motor - 4 - - 3 - - 2 - - 1 - - 2 - Pump - 1 - Dryer MOTOR &... -
Page 14: Wiring Diagram
WIRING DIAGRAM Mains Input Filter Pressure Switch Motor Pump Stat. Armature Wash Valves Tacho Flushing Wash Main Valve Thermistor Wash Wash Wash Heater Lav. Feed- back Test Connector Test Feed- back Condenser Valve 1 2 3 4 5 5407376wd.ai Condenser Tumble Dryer ARMXXF145EU... -
Page 15: Wiring Diagram Legend
Indesit Company WIRING DIAGRAM LEGEND Aquastop solenoid valve Neutral or Terminal board Buzzer or Door lock No spin Terminal board contacts, dryer heating Pressure switch element and Door lock Pressure switch 1st level Condenser Pressure switch 2nd level Condenser High speed potentiometer Switch Low speed potentiometer EF/CL... -
Page 16: Error Codes & Possible Causes
Indesit Company ERROR CODES & POSSIBLE CAUSES When an error occurs the following LEDs will flash indicating a fault. Refer to the chart below for the error code definitions. FAULT LED COMBINATION LED 5 LED 5 LED 4 LED 3 LED 2 LED 1 LED 4... -
Page 17: Dismantling Instructions
Indesit Company DISMANTLING INSTRUCTIONS Safety Notes Ensure that the appliance is disconnected from the electrical supply before dismantling. Beware of sharp edges on metal panels, plastic mouldings, and pressed parts. Some fixings (especially those into plastic) must be tightened to the correct specification using a suitable torque wrench. - Page 18 Indesit Company Door Seal & Restraint: Door Seal to Front Panel Fixing The door seal is fixed to the cabinet front panel by a wire clamp and a small spring. The spring is normally at the bottom of the door. Carefully place a small screwdriver into one of the lugs of the spring and by stretching the spring the wire band can be removed.
- Page 19 Indesit Company Door Assembly Top Hinge removal (shown below) - Slide towards lower hinge, twist to the left Open the door through 180° and remove four and slide up to release. screws securing the hinges to the front panel. Ease the hinges from the panel. Lower Hinge removal - Slide upwards, twist to the right and slide down to release.
- Page 20 Indesit Company Motor Remove the lower rear access panel (B) and drive belt (L). Disconnect the motor wiring connection plug and earth wire. Using a 13 mm socket or ratchet ring spanner, remove both motor mount fixing screws. Ease the motor off the drum mountings. Prior to refitting the motor, ensure that the mounting-bush is not worn or damaged., replace if required.
- Page 21 Indesit Company R(a) Suspension Damper Remove two suspension fixing screws from the chassis. Remove the table top (A), dispenser drawer (C) and console panel (D). Remove the door seal restraint (G), door interlock (H) and front panel (J). Remove the lower balance weight (Na) if access is required to the left-hand damper. Remove the plastic peg securing the damper to the outer drum using special tool Part No.
- Page 22 Indesit Company Heater Box / Drum Assembly Disconnect cable connections to motor, heater, thermistor and thermostat / thermal fuse cable. Disconnect tie-wrap fixing heater box assembly to the door seal. Disconnect filter flushing hose (if fitted). Remove five Torx T30 screws fixing heater box assembly to outer drum and lift away. Note: On re-assembly fix screws in front to rear order, torque setting for screws 12 Nm.
- Page 23 Indesit Company 14. Unclip any wiring retained within the integral clip on the spring bearing keeper plates. 15. Unhook springs from the cabinet top rail bearings. 16. Carefully lift the drum assembly out of the cabinet. W(b) Inner Drum & Support Assembly / Drum Seal / Outer Drum Halves Remove the drum assembly (Va).
- Page 24 Indesit Company Power / Control Module ! Remove back panel (B). Ensure the electrical supply is disconnected. See notes on Page 2. Remove screw or screws securing module support to the cabinet. Disconnect wiring. Lift module and support clear. When replacing the board an EEProm will also be required. Note: To remove and fit the EEProm use Insulated Tweezers Part No.
-
Page 25: Service Manual Uk English
Indesit Company Service Manual UK English 25 of 26... - Page 26 Indesit Company Service Manual UK English 26 of 26...
