- Page 1 7i AND 3i OWNER’S MANUAL 1-800-348-0998 | www.StreetStrider.com...
-
Page 2: Table Of Contents
Riding a StreetStrider can be a hazardous activity even under the best of circumstances. It is highly recommended that your first stride on your new StreetStrider be taken in a controlled environment, away from cars, obstacles and other cyclists, and wearing your helmet. - Page 3 Figure 2.1. StreetStrider 3i and 7i Parts. Refer to Table 2.1 for part numbers and descriptions. Figure 2.2. StreetStrider 3i and 7i Parts. Refer to Table 2.1 for part numbers and descriptions. Brake unlocked Brake locked Figure 2.2. StreetStrider 3i and 7i Parts. Refer to Table 2.1 for part numbers and descriptions.
-
Page 4: Parts Identification
Inboard and outboard M8 x P1.25 x L20 x W14 flats on stud Lubricate balls Table 2.1 StreetStrider Parts List with Hardware Specifications, Quantity, and Maintenance State. rod ends M8 x P1.25 x L10 x W13 nylon lock nut Tighten Parts are numbered in previous figures. -
Page 5: Assembling The Streetstrider 3I And 7I
19 mm socket, 17 x 14, 15 x 13, 14 x 12, and 13 x 10 mm open end wrenches, 2, 2.5, 3, 4, 5, 6 and 8 mm hex wrenches, and 2 tire levers. Parts include: a front beam bearing assembly, 8 mm crank arm screws, a shifter push rod for the 3i, and a cassette pulley for the 7i. -
Page 6: Poles And Skis
FIGURE 3.2.10 Route the front brake cables from the cable doubler on either side of the head tube, under the steering linkage and over the front beam. If the cable housing is off of the cables, slide it back on. Insert the left and right cable and housing into the barrel adjuster on the left and right brakes, respectively. -
Page 7: Rear Hub, Chain And Shifter
FIGURE 3.3.14 With the 4 mm hex wrench, carefully tighten the Joint #1 clamp in an X pattern so that all the screws are tightened evenly and the space between the clamp base and cap on the front side of the pole is equal to the space on the rear side. Finally, position the brake levers forward, in front of the grips, and tighten the brake clamp with a 5 mm hex wrench. -
Page 8: Brakes
3.5| BRAKES (SEE VIDEO) FIGURE 3.4.7 For the 7i, set the 7-speed shifter to FIGURE 3.4.8 Insert the 2 mm hex wrench (or short FIGURE 3.4.9 Rotate the wrench to the 6 o’clock gear 1. spoke) into the hole of the cassette pulley tab located position so the cable fixing screw can be inserted into at the 9 o’clock position. -
Page 9: Front Wheel Alignment
FIGURE 3.7.1 Stabilize the StreetStrider by engaging the right parking brake pin to lock the rear brake. From locate and press the brass button that releases the the left side of the StreetStrider, rotate the left crank arm to the 3 o’clock position and open the quick release telescopic inner tube of the left ski. -
Page 10: Safety Equipment
Use your legs to move the platforms in the Lights. If you ride your StreetStrider after dusk, it must be equipped with lights so that you can see the road and avoid road hazards, and so forward elliptical path and focus on using your arms to striding on a flat place, rotate the shifter to a middle gear. -
Page 11: Mechanical Safety Check
StreetStrider occupant that may arise from the use of the StreetStrider. The user assumes the risk of any personal injury, damage to or failure of the StreetStrider and any other losses if the StreetStrider is used in any competitive event, including racing, ramp jumping, stunt riding or similar activities or training for such competitive activities or events. -
Page 12: Return Policy
SHIPPING WILL RESULT IN AN ADDITIONAL REPAIR FEE. To avoid an additional repair fee and to make sure the StreetStrider is returned properly, we encourage you to repack it exactly as it was packed when it arrived. At the bottom of the StreetStrider Support page WATCH THIS 3-PART VIDEO TO REPACK THE 3i AND 7i. - Page 13 1-800-348-0998 | www.StreetStrider.com...
