Table 15 - imagePROGRAF iPF8400S Estimated Installation Times
imagePROGRAF iPF8400S Main Unit (with Stand)
Printhead PF-05 (x2)
Ink Tanks (time includes installation of all eight (8) ink tanks)
Starting from an unpacked condition, installation times shown are the
estimated times required for installation. They are calculated based on
man-hours.
F.

Installation / Service Support Tools

The tools necessary to install these printers are in the Table below.
Table 6 - imagePROGRAF iPF8400S Installation Tools
Hexagonal wrench (Provided with the printer
stand)
Cut sheet paper A3 size or larger, or roll
paper
Cutter or Scissor
In addition to the standard tools used to service this device, the following
special tools, solvents, & oils should also be carried when servicing the
imagePROGRAF iPF8400S.
Table 7 - imagePROGRAF iPF8400S Special Tools, Solvents, & Oils List
Description
Cover Switch Tool
Syringe
Tube
Grease PG-5000H
Silbon paper
Rubber Gloves
Pen Flashlight
1
Item Numbers and Part Numbers are subject to change due to engineering changes, etc.
imagePROGRAF iPF8400S Service Guide
Description
Tool
For assembling stand and removing the fixed
parts
For test print after confirming printer operation
For unpacking
1
Parts Number
QY9-0103-000
For pressing down cover switch
CK-0541-000
For draining ink manually
QA2-6161-000
For draining ink manually
For applying to the places specified in the Service
FY9-6022-000
Manual
CK-0336-000
Use for cleaning
Use for cleaning and to prevent from dirtying the
QC1-5547-000
hands
CK-0327-000
For locking and unlocking the carriage.
imagePROGRAF iPF8400S Service Guide
Use
Use
Estimated Time
25 minutes
5 minutes
25 minutes
September 2013
Page 12
