Operating guide Termix AT BTD
Side plates
Fasten the right and left side plates by placing the key holes over
the screws on the sides of the wall bracket.
1 Bottom panel
Slide the slots in the bottom panel onto the 2 bushes in the side
plates, and fasten the panel with the 2 screws in the front.
2 Top plate
Mount the top plate.
3 Front cover
Mount the front cover by lowering the key holes onto the screws
in the side plates.
4 Clock panel
Mount the clock panel by lowering the key holes onto the screws
in the side plates.
