  • Page 1 OPERATING INSTRUCTIONS Humidity Chambers HCP 108 HCP 153 HCP 246...
  • Page 2 page 2...

  • Page 3: Table Of Contents

    1 General notes and safety notes ......................5 1.1 Transport ..........................5 2 Installation ............................6 2.1 Subframe (accessory) ....................... 6 2.2 Stackable version (accessory) ....................6 2.3 Initial start-up .......................... 7 2.4 Oven load ..........................7 3 Technical data .............................8 3.1 Working range of the HCP units ....................9 3.2 Standard equipment of HCP units ..................
  • Page 4 18 Communication interface for the PC ....................38 18.1 Communication interface RS232C ..................38 18.2 Bus interface RS485 ......................39 19 Report memory ..........................40 19.1 Reading the report memory ....................40 19.2 Reading the report memory into the PC via RS232C ............. 40 19.3 Printing the report memory from the oven ................

  • Page 5: General Notes And Safety Notes

    1 General notes and safety notes 1 General notes and safety notes You have purchased a technically fully proven product which has been produced in Germany with the use of high-grade materials and the application of the latest manufacturing techniques; it has been factory tested for many hours.

  • Page 6: Installation

    2 Installation The oven can be placed on the floor or on a bench (working surface). It is important that the oven is set up accurately horizontally; the door may have to be adjusted (see section 21) min. 15 min. 8 min.

  • Page 7: Initial Start-Up

    Please note that the MEMMERT ovens described here are not explosionproof (they do not conform to the Industrial Association Specification VBG 24) and are therefore not suitable for drying, evaporating and burning-in of paints, enamels or similar materials whose solvents may produce an inflammable mixture with air.

  • Page 8: Technical Data

    3 Technical data supply cable serial and parallel interface inner glas door adjusting screw Model HCP 108 HCP 153 HCP 246 Chamber width A [mm] Chamber height B [mm] Chamber depth C [mm] Housing width D [mm] Housing height E (variable through adjustable feet) [mm]...

  • Page 9: Working Range Of The Hcp Units

    3.1 Working range of the HCP units 3.1 Working range of the HCP units The temperature-humidity diagram of the humidity chamber HCP indicates the range of temperature and humidity within which continuous condensation-free operation is possible (at an ambient temperature of 22 °C ±...

  • Page 10: Standard Equipment Of Hcp Units

    Serial RS-232C interface for computer-supported temperature programmes and for reading the internal report memory • MEMMERT software “Celsius 2007“ for control and documentation of temperature and relative humidity via a PC • A pre-formatted blank MEMoryCard XL with 32 kB storage capacity, reprogrammable for up to 40...

  • Page 11: Material Quality

    3.3 Material quality 3.3 Material quality For the external housing MEMMERT employs stainless steel (Mat.Ref. 1.4016). The chamber is made from stainless steel (Mat.Ref. 1.4301) which exhibits high stability, optimal hygienic properties and corrosion resistance against many (not all) chemical compounds (care required e.g. with chlorine compounds).

  • Page 12: Oven Construction And Operation

    4 Oven construction and operation 4 Oven construction and operation The special feature of the HCP is the particularly uniform conditions inside the chamber. The air is heated by large-area allround heating (1). Humidity is provided by a dry steam generator which produces controlled evaporation of the water.

  • Page 13: Switching On

    4.3 Switching on 4.3 Switching on The oven is switched on by pressing the push/turn control. Oven switched off. The push/turn control is Oven switched on and can be operated using pushed in and protected against damage. the push/turn control and the SET key. 4.4 Setting the temperature (quick setting) 4.4 Setting the temperature (quick setting) Hold down the SET key and set the temperature setpoint with the push/turn control.

  • Page 14: Normal Operation

    7 Normal operation 7 Normal operation SETUP PRINT In this operating mode the oven operates continuously. The settings for operating the oven can be selected. The settings act directly on the operation of the oven. IN 1 IN 2 °C °C AUTO By rotating the push/turn control the following parameters can be selected and can be altered as described...
  • Page 15 Setting example Normal operation Setting example Normal operation The unit has to heat up to 50°C at a humidity of 95%rh. The monitor function has to be activated at 51°C. relative humidity temperature °C (rh) % temperature monitor time time 1.

  • Page 16: Weekly Programmer

    8 Weekly programmer 8 Weekly programmer SETUP PRINT In this operating mode the weekly programmer is activated and the oven switches on and off automatically at the programmed times. While the weekly programmer is in the OFF phase the unit is in stand-by mode. Heating and the supply of humidity are switched off, the controller display is dimmed and shows the clock time.
  • Page 17 Programming example Weekly programmer Programming example Weekly programmer The unit has to switch on at 9.30 hrs from Mo to Fr (workday group) and switch off at 19.00 hrs. In addition it has to operate on Saturday from 10.00 to 14.00 hrs. 1.

  • Page 18: Programme Operation

    9 Programme operation 9 Programme operation PRINT SETUP In this operating mode it is possible to set up to 40 freely programmable ramps for temperature and humidity. Rotating the press/turn control while holding down the SET key selects the following parameters in sequence after released the SET key: - a new programme can be programmed or an existing programme can be edited...
  • Page 19 STERI DEFRO IN 1 IN 2 °C °C loop AUTO PRINT SETUP Duration of first ramp segment Duration of first ramp segment Range: 1 minute to 999 hours. STERI DEFRO IN 1 IN 2 °C °C loop AUTO SETUP PRINT Setpoint temperature / temperature at the end of the ramp segment Setpoint temperature / temperature at the end of the ramp segment Range with humidity: 20 to 90 °C...

  • Page 20: Closure Commands For Ramp Segments

    9.1 Closure commands for ramp segments 9.1 Closure commands for ramp segments NEXT Follow-on with next programme segment. SPWT (T) Wait until the setpoint temperature is reached. The unit only starts the next programme segment when the programmed setpoint temperature has been reached, even if the programmed SET-POINT WAIT (temperature) heating time has already elapsed.
  • Page 21 Programming example programme operation Programming example programme operation On Monday at 08.00 hrs the unit has to heat up as quickly as possible to 50°C and reach a relative humidity of 95%rh. Once the temperature and humidity have been reached, the unit has to hold the setpoints for 45 minutes and then cool down to 37°C at a humidity of 50%rh.
  • Page 22 6. Select temperature of first ramp segment 6. Select temperature of first ramp segment °C Turn the push/turn control clockwise until the temperature display is flashing. Hold down the SET key and set the required temperature setpoint of 50.0 °C using the push/turn control. 7.
  • Page 23 14. Select temperature of third ramp segment 14. Select temperature of third ramp segment °C Turn the push/turn control clockwise until the temperature display is flashing. Hold down the SET key and set the required temperature setpoint of 37.0 °C using the push/turn control. 15.

  • Page 24: Printer

    10 Printer SETUP PRINT All HCP ovens are fitted as standard with a parallel printer interface, as used on personal computers. This parallel printer interface on the back of the oven is suitable for connecting conventional PCL3- compatible printers which are provided with a parallel printer interface (e.g. HP Deskjet 5550 or HP Deskjet 9xx).

  • Page 25: Basic Oven Settings (Setup)

    11 Basic oven settings (Setup) 11 Basic oven settings (Setup) PRINT SETUP In this operating mode it is possible to make the basic settings of the oven. Clock time, date, day, year, and settings of sounder, of address assignment, monitoring units, heater power and calibration are set here. The following parameters can be selected by turning the push/turn control, and altered as described in the section 6: Clock time in 24-hour format...

  • Page 26: Real-Time Clock

    Calibration correction for user-calibration (see section 17) Exit setup mode Exit setup mode = store all settings and exit SETUP mode 11.1 Real-time clock The real-time clock is set in SETUP and includes date and clock time. The real-time clock serves for documentation according to GLP. Date and clock time are marked in the report print.

  • Page 27: Electronic Temperature Monitor

    12.2 Electronic temperature monitor 12.2 Electronic temperature monitor 12.2.1 Overtemperature protection 12.2.1 Overtemperature protection Adjustment range: up to 10°C max Using the push/turn control °C above nominal temperature (for nominal select the symbol temperature see label) Hold down the SET key and set the protection temperature using the push/turn control.

  • Page 28: Automatic Temperature Monitor (Asf)

    12.2.4 Automatic temperature monitor (ASF) 12.2.4 Automatic temperature monitor (ASF) A monitoring device which automatically follows the selected temperature setpoint. Automatic temperature monitor Using the push/turn control select the symbol AUTO °C Hold down the SET key and select (ASF OFF) off using the push/turn control.
  • Page 29 Going outside tolerance margin = ASF alarm Going outside tolerance margin = ASF alarm Going outside the selected tolerance margin of the setpoint (in the example 37°C, +/-3°C), for example through opening the oven door during operation, triggers the alarm. Triggering the ASF alarm is indicated by flashing symbol AUTO If the sounder is switched on in SETUP, the ASF alarm is additionally signalled by an interrupted tone.

  • Page 30: Active Humidity Control (%Rh)

    Setpoint changed = ASF de-activated automatically Setpoint changed = ASF de-activated automatically If the temperature setpoint is altered, the automatic temperature monitor is automatically de-activated temporarily (see in the example the setpoint is changed from 37°C to 30°C) until the tolerance margin of the new temperature setpoint is reached (see in the example below: the ASF is re-activated at 30°C, +/- 3°C).

  • Page 31: Audible Alert Signals

    14 Audible alert signals 14 Audible alert signals The interval sound indicates a fault in the temperature control system or the humidifying system. It is triggered in the following cases: Fault in the temperature control system: Fault in the temperature control system: Tb activ - temperature limiter activated if the temperature limiter operates (see section 12.1) hi-alarm - overtemperature alarm activated if the overtemperature...

  • Page 32: Sterilisation Chip Card

    15 Sterilisation chip card 15 Sterilisation chip card Sterilisation Parameter: 160 °C / 4:00 h Sterilisation Process Control Unit-ID: Card ________________________ As protection against contamination the HCP is equipped as standard with a STERICard. The STERICard starts an automatic and pre-set sterilisation procedure. To activate, insert the STERICard into the slit in the control field, select the Start symbol with the push/ turn control and the depressed SET key.

  • Page 33: User-Id-Card (Available As Optional Extra)

    16 User-ID-Card (available as optional extra) 16 User-ID-Card (available as optional extra) Name: _____________________ access authority card _____________________ The User-ID-Card stores the serial number of the oven and a unique user number in encrypted format. The User-ID-Card therefore functions only in the oven with the corresponding serial number. Each log-on via the User-ID-Card is documented in the internal flash memory.

  • Page 34: Calibration

    17 Calibration 17.1 Temperature 17.1 Temperature User-calibration of oven at the controller, with three calibration temperatures selected by the user. CAL.1 Temperature calibration at low temperature CAL.2 Temperature calibration at medium temperature CAL.3 Temperature calibration at high temperature Either a positive or a negative calibration correction can be applied to each selected calibration point. General calibration instructions: Select the required calibration temperature in SETUP and set the corresponding calibration correction to 0.0 °C.
  • Page 35 calibration correction calibration point1 calibration temperature adjustment range -4.9 °C to +4.9 °C °C °C calibration correction calibration point 2 calibration temperature adjustment range -4.9 °C to +4.9 °C °C °C calibration correction calibration point 3 calibration temperature adjustment range -4.9 °C to +4.9 °C °C °C...

  • Page 36: Humidity

    17.2 Humidity 17.2 Humidity User-calibration of the unit at the controller, using two humidity points: RH 20 Humidity calibration at 20% relative humidity RH 90 Humidity calibration at 90% relative humidity Either a positive or a negative calibration correction can be applied to each selected calibration point. General calibration instructions: Select the required calibration humidity in SETUP and set the corresponding calibration correction to 0.0 °C.
  • Page 37 calibration humidity calibration correction 20%rh adjustment range -5.0 % to +5.0 % IN 1 IN 1 STERI DEFRO IN 2 IN 2 °C °C loop AUTO PRINT SETUP calibration humidity calibration correction 90%rh adjustment range -5.0 % to +5.0 % STERI DEFRO IN 1...

  • Page 38: Communication Interface For The Pc

    18 Communication interface for the PC 18.1 Communication interface RS232C The oven is provided as standard with a serial communication interface RS232C according to DIN 12 900- 1. Using this interface it is possible to control the oven from the PC and to produce reports. This is done using the “Celsius 2007“...

  • Page 39: Bus Interface Rs485

    18.2 Bus interface RS485 When so ordered, the oven can be equipped at the factory with an RS485 interface instead of the RS232C interface. This permits networking of several ovens (up to 16) with a single PC using a common 2-wire circuit. The system is operated using the “Celsius 2007”...

  • Page 40: Report Memory

    19 Report memory 19 Report memory The controller continuously records all relevant measurements, settings and error messages at 1-minute intervals. The internal report memory is arranged as a ring memory, i.e. the new data always overwrite the oldest report data. The report function can not be switched off but remains active at all times.
  • Page 41 By regular cleaning of the (easy to clean) interior, residues are avoided which may impair the outfit and function of the incubator. The unit can be cleaned with commercial stainless steel cleaning agent. Please note that objects liable to rust must not be placed into the interior. Rust sediments lead to contamination of the interior or the external casing.

  • Page 42: Maintenance

    Silicone grease, and to check that the hinge screws are tight. A well-closing door is essential on an oven. On MEMMERT ovens, tight closure of the door is ensured by a seal on the oven and another one on the door. In continuous operation the flexible sealing material may take a permanent set.

  • Page 43: Check List For Fault Rectification

    In case there is a fault on the oven, please get in touch with an authorised service organisation or contact the MEMMERT customer service department. (see section 25) In case of queries always specify model and serial number (on the rating label)

  • Page 44: Supply Failure

    Supply failure in operating mode “Normal operation“ Supply failure in operating mode “Normal operation“ After a supply failure the operation is continued with the set parameters. The instant and duration of the supply failure are documented in the record memory. Supply failure in operating mode “Weekly programmer“...

  • Page 45: Ce Conformity Declaration

    24 CE Conformity Declaration 24 CE Conformity Declaration EC Declaration of Conformity Manufacturer´s name and address: MEMMERT GmbH + Co. KG Äußere Rittersbacher Straße 38 D-91126 Schwabach Product: Humidity Chambers Type: Sizes: 108 l / 153 l / 246 l...

  • Page 46: Address And Customer Service

    E-mail: sales@memmert.com Internet: www.memmert.com Customer service: Phone: 00 49 9122 / 925-143 or 00 49 9122 / 925-126 E-mail: service@memmert.com In case of queries always specify model and serial number (on the rating label) © by MEMMERT GmbH+Co.KG page 46...
  • Page 47 page 47...
