AEMC Simple Logger II L104 User Manual page 34

NOTE: When installing probes, face the arrow on the probe in the direc-
tion of the load.
Nominal Range
Measurement Range
Probe Output Signal
Maximum Clamping Diameter
Safety
Nominal Range
Measurement Range
Probe Output Signal
Maximum Clamping Diameter
Safety
NOTE: Currents <0.5A will be displayed as zero. Neutral current measures down to 0A.
Nominal Range
Measurement Range
Probe Output Signal
Maximum Clamping Diameter
Safety
The 5A range of the MN193 is designed to work with secondary current transformers.
Best accuracy is available when entering the transformer ratio (e.g. 1000/5A). When used to
measure 5A direct, the resolution will be limited to 0.1A max.
Specifications are subject to change without notice.
32
Model SR193
1000A
1A to 1000A
AC
EN 61010-2-032, Pollution Degree 2, 600V CAT IV, 1000V CAT III
Model MN93
2A to 200A
AC
EN 61010-2-032, Pollution Degree 2, 300V CAT IV, 600V CAT III
Model MN193
5A: 0.005A to 6A max (1A to 1000A with ratio 1000/5 selected)
AC
100A: 0.1A to 100A
5A: 200mV/A
EN 61010-2-032, Pollution Degree 2, 300V CAT IV, 600V CAT III
for f ≤1kHz
AC
max (I >1000A not continuously)
1mV /A
AC AC
2" (52mm)
for f ≤1kHz
200A
AC
max (I >200A not permanent)
5mV / A
AC AC
0.8" (20mm)
5A and 100A
AC
max
AC
; 100A: 10mV/A
AC
0.8" (20mm)
Simple Logger II (Bluetooth Edition) Series
®
AC
