AEMC Simple Logger II L104 User Manual page 30

MODEL
ELECTRICAL
Channels
Input
Range
Accuracy
(50/60Hz)
Resolution
Sample Rate
Storage Rate
Storage Modes
Recording Length
Memory
Communication
Power Source**
Battery Life
MECHANICAL
Dimensions
Weight (with battery)
Sensor/Cable Length
Maximum Conductor
Cover/Case
Vibration
Shock
Drop
ENVIRONMENTAL
Operating Temperature
Storage Temperature
Relative Humidity
Altitude
SAFETY & ELECTRO-MAGNETIC COMPATIBILITY
Safety Rating
Protection Degree
Electro-Magnetic
Compatibility
CE Approved
28
Captive AmpFlex
300A
AC
0 to 5A unspecified
5 to 300A:
±(1% of Reading + 0.5A)
0.1A
AC
Programmable from 125ms to 1 per day
Start/Stop, FIFO and Extended Recording Mode* (XRM
15 minutes to 8 weeks, programmable using DataView
Recorded data is stored in non-volatile memory and retained
>200hrs at 125ms up to 180 days (dependent on storage rate/recording length)
5.904 x 5.904 x 3.568" (150 x 150 x 91mm) w/o Sensor
Sensor: 24" (610mm) / Cable: 6.5 ft (2m)
Up to 85% at 95°F (35°C), Non-condensing
EN61010-1; EN61010-2-32; 600V CAT IV, 1000V CAT III; Pollution Degree 2
EN 61326-1; 07/1997 (+A1 10/1998, +A2 09/2001, +A3 05/2004)
AL834
Four
AC Current Flexible Sensors
®
64 samples/cycle
1,000,000 measurements (2MB).
even if battery is low or removed.
Bluetooth (Class 2)
4x1.5V C-cell alkaline batteries
3.9lbs (1.77kg)
Ø 8" (203mm)
Cover: UL94-V0 / Case: UL94-5VB
IEC 68-2-6 (1.5mm, 10 to 55Hz)
IEC 68-2-27 (30G)
IEC 68-2-32 (1m)
14° to 122°F (-10° to 50°C)
-4° to 140°F (-20° to 60°C)
2000m
IP65 (cover closed)
Yes
Simple Logger
3000A
AC
0 to 15A unspecified
15 to 3000A:
±(1% of Reading + 1A)
0.5A
AC
), Store on Alarm
™
®
II (Bluetooth Edition) Series
®
