MODEL
ELECTRICAL
Channels
Input
Range
Resolution
Accuracy
(50/60Hz)
Maximum Input Voltage***
Input Impedance
Sample Rate
Storage Rate
Storage Modes
Recording Length
Memory
Communication
Power Source**
Battery Life
MECHANICAL
Dimensions
Weight (with battery)
Cover/Case
Vibration
Shock
Drop
ENVIRONMENTAL
Operating Temperature
Storage Temperature
Relative Humidity
Altitude
SAFETY & ELECTRO-MAGNETIC COMPATIBILITY
Safety Rating
Protection Degree
Electro-Magnetic
Compatibility
CE Approved
*This unique recording mode provides the opportunity to continuously record over long periods of time by reducing the storage
resolution of the stored data and maintaining matching resolution for the newest data. Each time the memory fills up using
XRM , every other of the oldest stored samples is discarded making room for newer samples. This process continues until the
™
recording is manually stopped.
**A memory backup capacitor provides backup power while batteries are being changed. This backup capacitor will maintain the
instrument for up to 10 sec. without batteries installed. After 10 seconds the date and time will need to be reset (data and configu-
ration will be maintained). If the unit is connected to DataView
***Voltages beyond this range may damage the instrument.
Simple Logger II (Bluetooth Edition) Series
®
Five Recessed Banana Jacks
5 to 50V: ±(0.5% of Reading + 1V)
50 to 600V: ±(0.5% of Reading + 0.5V)
Programmable from 125ms to 1 per day
Start/Stop, FIFO and Extended Recording Mode* (XRM
15 minutes to 8 weeks, programmable using DataView
1,000,000 measurements (2MB).
Recorded data is stored in non-volatile memory and retained
even if battery is low or removed.
4x1.5V C-cell alkaline batteries
>200hrs at 125ms up to 180 days
(dependent on storage rate/recording length)
5.904 x 5.904 x 3.568" (150 x 150 x 91mm) w/o Sensor
Cover: UL94-V0 / Case: UL94-5VB
IEC 68-2-6 (1.5mm, 10 to 55Hz)
14° to 122°F (-10° to 50°C)
-4° to 140°F (-20° to 60°C)
Up to 85% at 95°F (35°C), Non-condensing
EN61010-1; 600V CAT IV, 1000V CAT III; Pollution Degree 2
EN 61326-1; 07/1997 (+A1 10/1998, +A2 09/2001, +A3 05/2004)
via a PC, the battery life is 100 hours regardless of the storage rate.
®
L264
Four
0 to 600V
AC/DC
0.1V
0 to 5V unspecified
1.2 x 600V
16MW
64 samples/cycle
Bluetooth (Class 2)
2.1 lbs (0.95kg)
IEC 68-2-27 (30G)
IEC 68-2-32 (1m)
2000m
IP50 (cover closed)
Pending
), Store on Alarm
™
®
31
