NOTE: The native measurement of the Model L104 is voltage. This voltage is scaled to
displace current by a factor that corresponds to the users probe selection. This accuracy
specification does not account for probe errors.
MODEL
ELECTRICAL
Channels
Input
Range
Resolution
Accuracy
(50/60Hz)
Maximum Input Voltage***
Input Impedance
Sample Rate
Storage Rate
Storage Modes
Recording Length
Memory
Communication
Power Source**
Battery Life
MECHANICAL
Dimensions
Weight (with battery)
Cover/Case
Vibration
Shock
Drop
ENVIRONMENTAL
Operating Temperature
Storage Temperature
Relative Humidity
Altitude
SAFETY & ELECTRO-MAGNETIC COMPATIBILITY
Safety Rating
Protection Degree
Electro-Magnetic
Compatibility
CE Approved
Simple Logger II (Bluetooth Edition) Series
®
One connector per channel
10 to 50mV: ±(0.5% of Reading + 1mV)
50 to 1000mV: ±(0.5% of Reading + 0.5mV)
5Vrms (-7.07Vpeak to +7.07Vpeak)
Programmable from 125ms to 1 per day
Start/Stop, FIFO and Extended Recording Mode* (XRM
15 minutes to 8 weeks, programmable using DataView
1,000,000 measurements (2MB).
Recorded data is stored in non-volatile memory and retained
even if battery is low or removed.
4x1.5V C-cell alkaline batteries
>200hrs at 125ms up to 180 days
(dependent on storage rate/recording length)
5.904 x 5.904 x 3.568" (150 x 150 x 91mm) w/o Sensor
Cover: UL94-V0 / Case: UL94-5VB
IEC 68-2-6 (1.5mm, 10 to 55Hz)
14° to 122°F (-10° to 50°C)
-4° to 140°F (-20° to 60°C)
Up to 85% at 95°F (35°C), Non-condensing
EN61010-1; 600V CAT IV, 1000V CAT III; Pollution Degree 2
EN 61326-1; 07/1997 (+A1 10/1998, +A2 09/2001, +A3 05/2004)
L104
Four
0 to 1V
AC
0.1A (1mV/A scale)
0 to 10mV unspecified
100KW
64 samples/cycle
Bluetooth (Class 2)
2.1 lbs (0.95kg)
IEC 68-2-27 (30G)
IEC 68-2-32 (1m)
2000m
IP50 (cover closed)
Pending
), Store on Alarm
™
®
