Product Features; Description - AEMC Simple Logger II L104 User Manual

Throughout the content of this user manual, the Simple Logger
referred to as the "SLII".
2.1

Description

The Simple Logger
recording devices powered by alkaline batteries.
Frequency tracking is performed such that 64 samples over one line cycle
are taken. Frequency tracking is performed around the nominal frequency
of 50/60Hz. Harmonic measurements are calculated from these 64 sam-
ples (harmonics are only available from the Simple Logger II Control
Panel within the DataView
The Simple Logger
Samples are taken at a user defined storage rate. This means that the
input(s) are ignored between measurement intervals.
The SLII's battery operation allows operation without the need for external
power. A series of front panel LEDs provide a quick status of the logger's
state, memory usage and low battery indication.
The main advantage of the logger is its ability to perform a variety of
recording tasks with easy and intuitive setup from a computer using
DataView software, Bluetooth communication and long battery life.
®
Analog information on the input is sampled and converted to a digital
value. This digital signal is processed and stored along with scale and
time information. An integrated Bluetooth module provides for the transfer
of data from the instrument's internal memory to the computer for analysis.
8
CHAPTER 2

PRODUCT FEATURES

II Bluetooth Series of loggers are four channel
®
software).
®
II records at a rate of up to eight times per second.
®
Simple Logger II (Bluetooth Edition) Series
®
II may be
®
