11. After a few moments, a screen appears informing you that instal-
lation is complete. Click Finish to leave the InstallShield Wizard. You
are now asked whether or not you would like to view instructions
about how to connect the AEMC instrument or cable to the USB
port on the computer. Click Yes to view these instructions, or No to
proceed.
12. Close the DataView Setup screen. The DataView folder now
appears on your computer desktop. This folder contains the Data-
View and Simple Logger II Control Panel icons, along with the
icon(s) for any other Control Panel(s) you have installed.

4.2 Simple Logger II Control Panel

After you install DataView, the DataView folder appears on your desk-
top. This contains the DataView icon, which opens the core DataView
program. The folder also contains the Simple Logger II Control Panel
icon. Clicking this icon opens the Simple Logger II Control Panel.
In general, core DataView features are for creating, viewing, editing,
and storing DataView reports; while the Control Panel is for connecting
to, configuring, viewing real-time measurements, and downloading data
from the instrument. You can access all DataView features through
either the DataView icon or the Control Panel icon. For users who
interact with a single type of AEMC instrument, we recommend primarily
using the Control Panel. However, there are situations where using the
core DataView icon may be more convenient for some users, such as
when viewing multiple archived reports from different AEMC product
families.
NOTE: For further information about DataView and its
capabilities, or for information about using the Simple
Logger II Control Panel, consult the Help system that
comes with the product. Access this Help by clicking the
option Help in the Control Panel's menu bar at the top of
the screen.
Simple Logger II Series
®
25
