Wiring the SENSOR to Mighty Mule Gate Openers:
IMPORTANT:
TURN OFF the
connect the battery wires b
the SENSOR wires to any gate opener.
Step 5: Run the cable from the SENSOR through a
WIRE CLAMP into the control box. Pull about 8 - 10
inches of cable into the control box to reach the AC-
CESSORY TERMINAL BLOCK and BATTERY TER-
MINALS in the control box. Now tighten the WIRE
CLAMP nut to secure the cable in the WIRE CLAMP.
Step 6: Strip about 3/8 of an inch of insulation from the
YELLOW, BLACK, RED and BLUE wires in the SEN-
SOR CABLE.
NOTE:
The SHIELD is the braided metal
wire wrapped around the insulated leads
inside the SENSOR CABLE.
PRO-1000, PRO-SL1000 and Old Mighty Mule
Control Boards
ALARM
Connect the BLACK wire
from the SENSOR CABLE to
the GRN terminal on the
opener control board.
BLACK
BLUE
Mighty Mule 500 & 502
Control Boards
COM COM
Connect the BLACK
wire from the SENSOR
CABLE to one of the
COMMON terminals on
the opener control board.
GTO/PRO DC Powered PRO-SW3000
and PRO-SW4000 Control Boards
J11 J11
COM COM
Connect the BLACK
wire from the SENSOR
CABLE to one of the
COMMON terminals on
the opener control board.
power and dis-
efore you begin to connect
SEQ1
SEQ2
LEARN
R B G
ACCESSORY RCVR
Connect BLUE wire from the
SENSOR CABLE to the
BLU terminal on the opener
control board.
GRN BLK RED
RECEIVER
Connect the BLUE wire from
the SENSOR CABLE to the
EXIT/OPEN terminal on the
opener control board.
BLUE
BLACK
J8
J12
GRN BLK RED
RECEIVER
Connect the BLUE wire from
the SENSOR CABLE to the
EXIT/OPEN terminal on the
opener control board.
BLUE
BLACK
Bottom of Control Box
Mighty Mule 350 Control Board
Connect the BLUE wire from
the SENSOR CABLE to the
EXIT terminal on the opener
control board.
GEN-3 (Blue) Control Boards
Connect the BLACK wire from
the SENSOR CABLE to one
of the COMMON terminals on
the opener control board.
GTO/PRO GP-SL100 and GP-SW100
Control Boards
Connect the BLUE wire
from the SENSOR CABLE
to the OPEN terminal on
the opener control board.
4
WIRE CLAMP in Knockout
CABLE from
the Opening Sensor
PVC Conduit
LINK
RECR
Connect the BLACK wire from
the SENSOR CABLE to one of
the COMMON terminals on the
opener control board.
BLUE
RECEIVER
CONTROL INPUTS
GTO RCVR.
Connect the BLUE wire from
the SENSOR CABLE to the
EXIT terminal on the opener
control board.
BLUE
BLACK
Connect the BLACK wire from
the SENSOR CABLE to one
of the COMMON terminals on
the opener control board.
BLUE
BLACK
ALM
BLACK
