  • Page 1 LED EXPO 310 6300 K, LED EXPO 310 2700 K LED spotlight...
  • Page 2 Musikhaus Thomann Thomann GmbH Hans-Thomann-Straße 1 96138 Burgebrach Germany Telephone: +49 (0) 9546 9223-0 E-mail: info@thomann.de Internet: www.thomann.de 08.12.2017, ID: 390807, 420506...

  • Page 3: Table Of Contents

    Table of contents Table of contents General notes............................... 6 1.1 Further information........................... 7 1.2 Notational conventions........................8 1.3 Symbols and signal words....................... 8 Safety instructions..........................11 Features............................... 16 Installation..............................17 Starting up..............................21 Connections and controls........................24 Operating..............................27 7.1 Main menu............................27 7.2 Menu overview..........................
  • Page 4 Table of contents Plug and connection assignments....................37 Troubleshooting............................38 Cleaning............................... 40 Protecting the environment......................41 LED EXPO 310 6300 K, LED EXPO 310 2700 K LED spotlight...
  • Page 5 LED EXPO 310 6300 K, LED EXPO 310 2700 K LED spotlight...

  • Page 6: General Notes

    General notes General notes This manual contains important instructions for the safe operation of the unit. Read and follow the safety instructions and all other instructions. Keep the manual for future reference. Make sure that it is available to all those using the device. If you sell the unit please make sure that the buyer also receives this manual.

  • Page 7: Further Information

    General notes 1.1 Further information On our website (www.thomann.de) you will find lots of further information and details on the following points: Download This manual is also available as PDF file for you to download. Use the search function in the electronic version to find the topics of Keyword search interest for you quickly.

  • Page 8: Notational Conventions

    General notes 1.2 Notational conventions This manual uses the following notational conventions: Letterings The letterings for connectors and controls are marked by square brackets and italics. Examples: [VOLUME] control, [Mono] button. Displays Texts and values displayed on the device are marked by quotation marks and italics. Examples: ‘24ch’...
  • Page 9 General notes Signal word Meaning DANGER! This combination of symbol and signal word indicates an immediate dangerous situation that will result in death or serious injury if it is not avoided. WARNING! This combination of symbol and signal word indicates a pos- sible dangerous situation that can result in death or serious injury if it is not avoided.
  • Page 10 General notes Warning signs Type of danger Warning – danger zone. LED EXPO 310 6300 K, LED EXPO 310 2700 K LED spotlight...

  • Page 11: Safety Instructions

    Safety instructions Safety instructions Intended use This device is intended to be used as an electronic illumination effect using LED technics. The device is designed for professional use and is not suitable for use in households. Use the device only as described in this user manual. Any other use or use under other operating con- ditions is considered to be improper and may result in personal injury or property damage.
  • Page 12 Safety instructions Safety DANGER! Danger for children Ensure that plastic bags, packaging, etc. are disposed of properly and are not within reach of babies and young children. Choking hazard! Ensure that children do not detach any small parts (e.g. knobs or the like) from the unit.
  • Page 13 Safety instructions DANGER! Electric shock caused by short-circuit Always use proper ready-made insulated mains cabling (power cord) with a pro- tective contact plug. Do not modify the mains cable or the plug. Failure to do so could result in electric shock/death or fire. If in doubt, seek advice from a regis- tered electrician.
  • Page 14 Safety instructions NOTICE! Risk of fire Do not block areas of ventilation. Do not install the device near any direct heat source. Keep the device away from naked flames. NOTICE! Operating conditions This device has been designed for indoor use only. To prevent damage, never expose the device to any liquid or moisture.
  • Page 15 Safety instructions NOTICE! Power supply Before connecting the device, ensure that the input voltage (AC outlet) matches the voltage rating of the device and that the AC outlet is protected by a residual current circuit breaker. Failure to do so could result in damage to the device and possibly injure the user.

  • Page 16: Features

    Features Features Powerful and flexible LED spotlight for showrooms, studios, exhibition booths, etc. LED configuration: LED EXPO 310 – 6300 K: 31 cold white LEDs – LED EXPO 310 – 2700 K: 31 warm white LEDs – Replacement for 575 W daylight lamps Control via DMX (2 channels) as well as via buttons and display on the unit Lockable connections (Power Twist) for self-supply and to supply additional devices sturdy bracket for secure attachment to trusses or firm footing on the ground...

  • Page 17: Installation

    Installation Installation Unpack and carefully check that there is no transportation damage before using the unit. Keep the equipment packaging. To fully protect the device against vibration, dust and moisture during transportation or storage use the original packaging or your own packaging material suitable for transport or storage, respectively.
  • Page 18 Installation NOTICE! Risk of overheating Always ensure sufficient ventilation. The ambient temperature must always be below 40 °C (104 °F). NOTICE! Use of stands When mounting the device onto a stand, ensure that the stand is in a safe and stable position and that the weight of the device does not exceed the maximum permissible load capacity of the stand.
  • Page 19 Installation NOTICE! Possible data transmission errors For error-free operation make use of dedicated DMX cables and do not use ordi- nary microphone cables. Never connect the DMX input or output to audio devices such as mixers or ampli- fiers. Mounting options You can install the unit in hanging or standing position.
  • Page 20 Installation Please note that this device must not be connected to a dimmer. LED EXPO 310 6300 K, LED EXPO 310 2700 K LED spotlight...

  • Page 21: Starting Up

    Starting up Starting up Create all connections while the device is off. Use the shortest possible high-quality cables for all connections. Take care when running the cables to prevent tripping hazards. LED EXPO 310 6300 K, LED EXPO 310 2700 K LED spotlight...
  • Page 22 Starting up Connections in DMX mode Connect the DMX input of the device to the DMX output of a DMX controller or another DMX device. Connect the output of the first DMX device to the input of the second one, and so on to form a daisy chain.
  • Page 23 Starting up Connections in master/slave When you configure a group of devices in master/slave mode, the first unit will control the mode other units for an automatic, sound-activated, synchronized show. This function is ideal when you want to start a show immediately. Connect the DMX output of the master device to the DMX input of the first slave device.

  • Page 24: Connections And Controls

    Connections and controls Connections and controls LED EXPO 310 6300 K, LED EXPO 310 2700 K LED spotlight...
  • Page 25 Connections and controls 1 Barn doors for directing the light beam. 2 LEDs 3 Bracket for hanging or installation and for securing the safety rope. 4 [FUSE]: Fuse holder 5 Display and control buttons: [MENU]: Activates the main menu and toggles between menu items. [UP]: Increases the displayed value by one.
  • Page 26 Connections and controls 9 [IN]: DMX input socket 10 Locking screw for fixing the spotlight. LED EXPO 310 6300 K, LED EXPO 310 2700 K LED spotlight...

  • Page 27: Operating

    Operating Operating 7.1 Main menu Press [MODE] to open the main menu. Use [UP] or [DOWN] to select the desired parameter or to change the respectively displayed value. When the display shows the desired parameter or value press [ENTER] to enter the respective submenu or to confirm a new value. To return to the previous menu level without changes, press [MENU].
  • Page 28 Operating Selecting DMX mode Press [MODE]. Press [UP] or [DOWN] repeatedly until the display shows ‘Personal’ . Press [ENTER]. Use [UP] or [DOWN] to select the submenu ‘Status’ . Press [ENTER]. Use [UP] or [DOWN] to select the submenu ‘DMX Mod’ . Press [ENTER]. Use [UP] or [DOWN] to select between ‘Mod 1’...
  • Page 29 Operating Selecting the behaviour on Press [MODE]. Press [UP] or [DOWN] repeatedly until the display shows ‘Personal’ . Press missing DMX signal. [ENTER]. Use [UP] or [DOWN] to select the submenu ‘Status’ . Press [ENTER]. Use [UP] or [DOWN] to select the submenu ‘No DMX’ . Press [ENTER]. Use [UP] or [DOWN] to select between ‘Hold’ (the last received DMX value will be retained if the DMX signal is missing), ‘Open’...
  • Page 30 Operating Setting the display off time Press [MODE]. Press [UP] or [DOWN] repeatedly until the display shows ‘Personal’ . Press [ENTER]. Use [UP] or [DOWN] to select the submenu ‘Display’ . Press [ENTER]. Use [UP] or [DOWN] to select the submenu ‘ClosT’ . Press [ENTER]. Use [UP] or [DOWN] to select switch-off time of the display in a range from ‘02m’...
  • Page 31 Operating Showing software version Press [MODE]. Press [UP] or [DOWN] repeatedly until the display shows ‘Info’ . Press [ENTER]. Use [UP] or [DOWN] to select the submenu ‘Product’ . Press [ENTER]. The software version of the device will now appear on the display. LED EXPO 310 6300 K, LED EXPO 310 2700 K LED spotlight...

  • Page 32: Menu Overview

    Operating 7.2 Menu overview LED EXPO 310 6300 K, LED EXPO 310 2700 K LED spotlight...

  • Page 33: Functions In 2-Channel Dmx Mode (Mod 1)

    Operating 7.3 Functions in 2-channel DMX mode (Mod 1) Channel Value Function 0…255 Brightness (0 % to 100 %) Open shutter 1…95 Stroboscope effect, increasing speed 96…127 Open shutter 128…159 Pulse effect 160…191 Open shutter 192…223 Random stroboscope effect, increasing speed 224…255 Open shutter LED EXPO 310 6300 K, LED EXPO 310 2700 K...

  • Page 34: Functions In 1-Channel Dmx Mode (Mod 2)

    Operating 7.4 Functions in 1-channel DMX mode (Mod 2) Channel Value Function 0…255 Brightness (0 % to 100 %) LED EXPO 310 6300 K, LED EXPO 310 2700 K LED spotlight...

  • Page 35: Technical Specifications

    Technical specifications Technical specifications LED EXPO 310 – 6900 K LED EXPO 310 – 2700 K Item no. 390807 420506 LED configuration: 31 × 10 W, cold white 31 × 10 W, warm white Colour temperature 6900 K 2700 K Number of DMX channels: Beam angle 20 °...
  • Page 36 Technical specifications LED EXPO 310 – 6900 K LED EXPO 310 – 2700 K Dimensions (W × H × D) 270 mm × 270 mm × 490 mm Weight 6.6 kg LED EXPO 310 6300 K, LED EXPO 310 2700 K LED spotlight...

  • Page 37: Plug And Connection Assignments

    Plug and connection assignments Plug and connection assignments Introduction This chapter will help you select the right cables and plugs to connect your valuable equip- ment so that a perfect light experience is guaranteed. Please take our tips, because especially in ‘Sound & Light’ caution is indicated: Even if a plug fits into a socket, the result of an incorrect connection may be a destroyed DMX controller, a short circuit or ‘just’...

  • Page 38: Troubleshooting

    Troubleshooting Troubleshooting NOTICE! Possible data transmission errors For error-free operation make use of dedicated DMX cables and do not use ordi- nary microphone cables. Never connect the DMX input or output to audio devices such as mixers or ampli- fiers. In the following we list a few common problems that may occur during operation.
  • Page 39 DMX interface circuits. If the procedures recommended above do not succeed, please contact our Service Center. You can find the contact information at www.thomann.de. LED EXPO 310 6300 K, LED EXPO 310 2700 K LED spotlight...

  • Page 40: Cleaning

    Cleaning Cleaning Optical lenses Clean the optical lenses, that are accessible from the outside, regularly in order to optimize the light output. The frequency of cleaning depends on the operating environment: wet, smoky or particularly dirty surroundings can cause more accumulation of dirt on the optics of the device.

  • Page 41: Protecting The Environment

    Protecting the environment Protecting the environment Disposal of the packaging mate- rial For the transport and protective packaging, environmentally friendly materials have been chosen that can be supplied to normal recycling. Ensure that plastic bags, packaging, etc. are properly disposed of. Do not just dispose of these materials with your normal household waste, but make sure that they are collected for recycling.
  • Page 42 Notes LED EXPO 310 6300 K, LED EXPO 310 2700 K LED spotlight...
  • Page 44 Musikhaus Thomann · Hans-Thomann-Straße 1 · 96138 Burgebrach · Germany · www.thomann.de...
