Wild Wash 132 LED RGB DMX,
Wild Wash 132 LED White DMX,
Wild Wash 648 LED RGB DMX,
Wild Wash 648 LED White DMX
LED floodlight
user manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Wild Wash 132 LED RGB DMX and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for thomann Wild Wash 132 LED RGB DMX

Summary of Contents for thomann Wild Wash 132 LED RGB DMX

  • Page 1 Wild Wash 132 LED RGB DMX, Wild Wash 132 LED White DMX, Wild Wash 648 LED RGB DMX, Wild Wash 648 LED White DMX LED floodlight user manual...
  • Page 2 Musikhaus Thomann Thomann GmbH Hans-Thomann-Straße 1 96138 Burgebrach Germany Telephone: +49 (0) 9546 9223-0 E-mail: info@thomann.de Internet: www.thomann.de 27.10.2016, ID: 399664, 399663, 399658, 399662...

  • Page 3: Table Of Contents

    7.4 Functions in DMX mode 1ch......................41 7.5 Functions in DMX mode 2Ch (model versions with white LEDs)........41 Wild Wash 132 LED RGB DMX, Wild Wash 132 LED White DMX, Wild Wash 648 LED RGB DMX, Wild Wash 648 LED White DMX...
  • Page 4 Table of contents 7.6 Functions in DMX mode 2Ch1 (model versions with RGB LEDs)........42 7.7 Functions in DMX mode 2Ch2 (model versions with white LEDs)......... 44 7.8 Functions in DMX mode 3Ch1 ....................45 7.9 Functions in DMX mode 3Ch2 (model versions with RGB LEDs)........46 7.10 Functions in DMX mode 3Ch2 (model versions with white LEDs).......

  • Page 5: General Notes

    Our products are subject to a process of continuous development. Thus, they are subject to change. Wild Wash 132 LED RGB DMX, Wild Wash 132 LED White DMX, Wild Wash 648 LED RGB DMX, Wild Wash 648 LED White DMX...

  • Page 6: Further Information

    General notes 1.1 Further information On our website (www.thomann.de) you will find lots of further information and details on the following points: Download This manual is also available as PDF file for you to download. Use the search function in the electronic version to find the topics of Keyword search interest for you quickly.

  • Page 7: Notational Conventions

    In the electronic version of the manual, you can click the cross-reference to jump to the specified location. Example: See Ä ‘Cross-references’ on page 7. Wild Wash 132 LED RGB DMX, Wild Wash 132 LED White DMX, Wild Wash 648 LED RGB DMX, Wild Wash 648 LED White DMX...

  • Page 8: Symbols And Signal Words

    General notes 1.3 Symbols and signal words In this section you will find an overview of the meaning of symbols and signal words that are used in this manual. Signal word Meaning DANGER! This combination of symbol and signal word indicates an immediate dangerous situation that will result in death or serious injury if it is not avoided.
  • Page 9 Warning signs Type of danger Warning – high-voltage. Warning – suspended load. Warning – danger zone. Wild Wash 132 LED RGB DMX, Wild Wash 132 LED White DMX, Wild Wash 648 LED RGB DMX, Wild Wash 648 LED White DMX...

  • Page 10: Safety Instructions

    Safety instructions Safety instructions Intended use This device is intended to be used as an electronic illumination effect using LED technics. The device is designed for professional use and is not suitable for use in households. Use the device only as described in this user manual. Any other use or use under other operating con‐ ditions is considered to be improper and may result in personal injury or property damage.
  • Page 11 There are no user-serviceable parts inside. Do not use the device if covers, protectors or optical components are missing or damaged. Wild Wash 132 LED RGB DMX, Wild Wash 132 LED White DMX, Wild Wash 648 LED RGB DMX, Wild Wash 648 LED White DMX...
  • Page 12 Safety instructions DANGER! Electric shock caused by short-circuit Always use proper ready-made insulated mains cabling (power cord) with a pro‐ tective contact plug. Do not modify the mains cable or the plug. Failure to do so could result in electric shock/death or fire. If in doubt, seek advice from a regis‐ tered electrician.
  • Page 13 Avoid direct sunlight, heavy dirt, and strong vibrations. Wild Wash 132 LED RGB DMX, Wild Wash 132 LED White DMX, Wild Wash 648 LED RGB DMX, Wild Wash 648 LED White DMX...
  • Page 14 Safety instructions NOTICE! Power supply Before connecting the device, ensure that the input voltage (AC outlet) matches the voltage rating of the device and that the AC outlet is protected by a residual current circuit breaker. Failure to do so could result in damage to the device and possibly injure the user.

  • Page 15: Features

    Equipped with SMD LEDs with 0.2 W power consumption each, depending on the model version: – Stairville Wild Wash 132 LED RGB DMX (item no. 399664): 132 tricolour LEDs (RGB) – Stairville Wild Wash 132 LED White DMX (item no. 399663): 132 cold white LEDs –...

  • Page 16: Installation

    Installation Installation Unpack and carefully check that there is no transportation damage before using the unit. Keep the equipment packaging. To fully protect the device against vibration, dust and moisture during transportation or storage use the original packaging or your own packaging material suitable for transport or storage, respectively.
  • Page 17 Never connect the DMX input or output to audio devices such as mixers or ampli‐ fiers. Wild Wash 132 LED RGB DMX, Wild Wash 132 LED White DMX, Wild Wash 648 LED RGB DMX, Wild Wash 648 LED White DMX...
  • Page 18 Installation Please note that this device must not be connected to a dimmer. LED floodlight...

  • Page 19: Starting Up

    Create all connections while the device is off. Use the shortest possible high-quality cables for all connections. Take care when running the cables to prevent tripping hazards. Wild Wash 132 LED RGB DMX, Wild Wash 132 LED White DMX, Wild Wash 648 LED RGB DMX, Wild Wash 648 LED White DMX...
  • Page 20 Starting up Connections in DMX mode Connect the DMX input of the device to the DMX output of a DMX controller or another DMX device. Connect the output of the first DMX device to the input of the second one, and so on to form a daisy chain.
  • Page 21 DMX input of the first slave device. Then connect the DMX output of the first slave device to the DMX input of the second slave device and so on. Wild Wash 132 LED RGB DMX, Wild Wash 132 LED White DMX, Wild Wash 648 LED RGB DMX, Wild Wash 648 LED White DMX...

  • Page 22: Connections And Controls

    Connections and controls Connections and controls Stairville Wild Wash 132 LED RGB DMX (item no. 399664) LED floodlight...
  • Page 23 Connections and controls Stairville Wild Wash 132 LED White DMX (item no. 399663) Wild Wash 132 LED RGB DMX, Wild Wash 132 LED White DMX, Wild Wash 648 LED RGB DMX, Wild Wash 648 LED White DMX...
  • Page 24 Connections and controls Stairville Wild Wash 648 LED RGB DMX (item no. 399658) LED floodlight...
  • Page 25 Connections and controls Stairville Wild Wash 648 LED White DMX (item no. 399662) Wild Wash 132 LED RGB DMX, Wild Wash 132 LED White DMX, Wild Wash 648 LED RGB DMX, Wild Wash 648 LED White DMX...
  • Page 26 Connections and controls 1 Display and control buttons: [MENU]: Activates the main menu and toggles between menu items. [UP]: Increases the displayed value by one. [DOWN]: Decreases the displayed value by one. [ENTER]: Selects an option of the respective operating mode. 2 [DMX IN]: DMX input socket.

  • Page 27: Operating

    The device is then ready for use. The display shows the operating mode that was selected when the unit was last powered off. Wild Wash 132 LED RGB DMX, Wild Wash 132 LED White DMX, Wild Wash 648 LED RGB DMX, Wild Wash 648 LED White DMX...

  • Page 28: Main Menu

    Operating 7.2 Main menu Operating mode ‘DMX’ This setting is only relevant if the device is controlled via a DMX controller. Press [MODE] repeatedly until one of the available DMX modes appears in the display and press [ENTER]. Use [UP] and [DOWN] to select the desired DMX mode and press [ENTER]. The following table shows the DMX modes available depending on the version.
  • Page 29 1 Hz) and ‘CF99’ (Strobe frequency approx. 30 Hz) or ‘CF00’ (continuous light, no Strobe effect) and press [ENTER]. Wild Wash 132 LED RGB DMX, Wild Wash 132 LED White DMX, Wild Wash 648 LED RGB DMX, Wild Wash 648 LED White DMX...
  • Page 30 Operating Operating mode ‘Manual con‐ This setting is only relevant if the device is not controlled via a DMX controller and not working trol’ (RGB LED model versions) as slave in a master / slave configuration. In this mode, the intensity of the LEDs can be adjusted per colour and a Strobe effect can be engaged.
  • Page 31 CM01 CM02 Amber CM03 Warm yellow CM04 Yellow CM05 Green CM06 Cyan CM07 Cyan CM08 Blue Wild Wash 132 LED RGB DMX, Wild Wash 132 LED White DMX, Wild Wash 648 LED RGB DMX, Wild Wash 648 LED White DMX...
  • Page 32 Operating Setting Colour CM09 Lavender CM10 Mauve CM11 Magenta CM12 Pink CM13 Warm white CM14 White CM15 Cold white LED floodlight...
  • Page 33 1 Hz) and ‘CF99’ (flash frequency approx. 30 Hz) or ‘CF00’ (continuous light, no Strobe effect) and press [ENTER]. Wild Wash 132 LED RGB DMX, Wild Wash 132 LED White DMX, Wild Wash 648 LED RGB DMX, Wild Wash 648 LED White DMX...
  • Page 34 Operating Operating mode ‘Fading’ (white This setting is only relevant if the device is not controlled via a DMX controller and not working LED model versions) as slave in a master / slave configuration. In this mode, the LEDs will gradually fade in with a freely selectable speed from blackout to maximum brightness and reverse, a Strobe effect can be engaged.
  • Page 35 [UP] and [DOWN] to select a value between ‘AU01’ (minimum speed) and ‘AU99’ (maximum speed) and press [ENTER]. Wild Wash 132 LED RGB DMX, Wild Wash 132 LED White DMX, Wild Wash 648 LED RGB DMX, Wild Wash 648 LED White DMX...
  • Page 36 Operating Operating mode ‘Automatic This setting is only relevant if the device is not controlled via a DMX controller and not working show’ (RGB LED model versions) as slave in a master / slave configuration. In this mode, the LEDs gradually change at freely selectable speed between the available colours, the Strobe effect is automatically engaged in regular intervals.
  • Page 37 Press [MODE] repeatedly until ‘SLAV’ appears in the display and press [ENTER]. The slave device now copies exactly the actions of the master device. Wild Wash 132 LED RGB DMX, Wild Wash 132 LED White DMX, Wild Wash 648 LED RGB DMX, Wild Wash 648 LED White DMX...

  • Page 38: Menu Overview

    Operating 7.3 Menu overview Model version with 132 white LEDs. LED floodlight...
  • Page 39 Operating Model version with 648 white LEDs. Wild Wash 132 LED RGB DMX, Wild Wash 132 LED White DMX, Wild Wash 648 LED RGB DMX, Wild Wash 648 LED White DMX...
  • Page 40 Operating Model versions with RGB LEDs LED floodlight...

  • Page 41: Functions In Dmx Mode 1Ch

    Dimmer (0 % to 100 %) Strobe 0 … 5 LEDs on 6 … 10 LEDs off (blackout) Wild Wash 132 LED RGB DMX, Wild Wash 132 LED White DMX, Wild Wash 648 LED RGB DMX, Wild Wash 648 LED White DMX...

  • Page 42: Functions In Dmx Mode 2Ch1 (Model Versions With Rgb Leds)

    Operating Channel Value Function 11 … 250 Strobe effect, speed increasing from approx. 0 Hz to 30 Hz 251 … 255 LEDs on 7.6 Functions in DMX mode 2Ch1 (model versions with RGB LEDs) Channel Value Function 0 … 255 Dimmer (0 % to 100 %) Colour macro 0 …...
  • Page 43 Warm white 110 … 117 White 118 … 125 Cold white 126 … 128 Ending colour change Wild Wash 132 LED RGB DMX, Wild Wash 132 LED White DMX, Wild Wash 648 LED RGB DMX, Wild Wash 648 LED White DMX...

  • Page 44: Functions In Dmx Mode 2Ch2 (Model Versions With White Leds)

    Operating Channel Value Function 129 … 192 Colour change, increasing speed 193 … 255 Gradual colour change, increasing speed 7.7 Functions in DMX mode 2Ch2 (model versions with white LEDs) Channel Value Function 0 … 255 Dimmer (0 % to 100 %) Strobe 0 …...

  • Page 45: Functions In Dmx Mode 3Ch1

    LEDs on Flash impulse 0 … 255 Flash impulse duration, increasing from 0 ms to 510 ms Wild Wash 132 LED RGB DMX, Wild Wash 132 LED White DMX, Wild Wash 648 LED RGB DMX, Wild Wash 648 LED White DMX...

  • Page 46: Functions In Dmx Mode 3Ch2 (Model Versions With Rgb Leds)

    Operating 7.9 Functions in DMX mode 3Ch2 (model versions with RGB LEDs) Channel Value Function 0 … 255 Dimmer (0 % to 100 %) Strobe 0 … 5 LEDs on 6 … 10 LEDs off (blackout) 11 … 250 Strobe effect, speed increasing from approx. 0 Hz to 30 Hz 251 …...
  • Page 47 Warm white 110 … 117 White 118 … 125 Cold white 126 … 128 Ending colour change Wild Wash 132 LED RGB DMX, Wild Wash 132 LED White DMX, Wild Wash 648 LED RGB DMX, Wild Wash 648 LED White DMX...

  • Page 48: Functions In Dmx Mode 3Ch2 (Model Versions With White Leds)

    Operating Channel Value Function 129 … 192 Colour change, increasing speed 193 … 255 Gradual colour change, increasing speed 7.10 Functions in DMX mode 3Ch2 (model versions with white LEDs) Channel Value Function 0 … 255 Dimmer (0 % to 100 %) Strobe 0 …...
  • Page 49 Sound control 0 … 5 Sound control off 6 … 255 Sound control on, increasing sensitivity Wild Wash 132 LED RGB DMX, Wild Wash 132 LED White DMX, Wild Wash 648 LED RGB DMX, Wild Wash 648 LED White DMX...

  • Page 50: Functions In Dmx Mode 3Ch3 (Model Versions With Rgb Leds)

    Operating 7.11 Functions in DMX mode 3Ch3 (model versions with RGB LEDs) Channel Value Function 0 … 255 Intensity red (0 % to 100 %) 0 … 255 Intensity green (0 % to 100 %) 0 … 255 Intensity blue (0 % to 100 %) 7.12 Functions in DMX mode 4Ch (model versions with RGB LEDs) Channel...
  • Page 51 6 … 13 14 … 21 Amber 22 … 29 Warm yellow 30 … 37 Yellow Wild Wash 132 LED RGB DMX, Wild Wash 132 LED White DMX, Wild Wash 648 LED RGB DMX, Wild Wash 648 LED White DMX...
  • Page 52 Operating Channel Value Function 38 … 45 Green 46 … 53 Cyan 54 … 61 Cyan 62 … 69 Blue 70 … 77 Lavender 78 … 85 Mauve 86 … 93 Magenta 94 … 101 Pink 102 … 109 Warm white 110 …...

  • Page 53: Functions In Dmx Mode 5Ch (Model Versions With White Leds)

    0 … 5 LEDs on, brightness controlled by channel 1 6 … 10 LEDs off (blackout) Wild Wash 132 LED RGB DMX, Wild Wash 132 LED White DMX, Wild Wash 648 LED RGB DMX, Wild Wash 648 LED White DMX...
  • Page 54 Operating Channel Value Function 11 … 33 Random impulses, increasing speed 34 … 56 Randomly increasing brightness, increasing speed 57 … 79 Randomly decreasing brightness, increasing speed 80 … 102 Random Strobe effect, increasing speed 103 … 127 Interrupt effect, 5 s to 1 s 128 …...

  • Page 55: Functions In Dmx Mode 6Ch (Model Versions With Rgb Leds)

    LEDs off (blackout) 11 … 33 Random impulses, increasing speed 34 … 56 Randomly increasing brightness, increasing speed Wild Wash 132 LED RGB DMX, Wild Wash 132 LED White DMX, Wild Wash 648 LED RGB DMX, Wild Wash 648 LED White DMX...
  • Page 56 Operating Channel Value Function 57 … 79 Randomly decreasing brightness, increasing speed 80 … 102 Random Strobe effect, increasing speed 103 … 127 Interrupt effect, 5 s to 1 s 128 … 250 Strobe effect, speed increasing from approx. 0 Hz to 30 Hz 251 …...

  • Page 57: Functions In Dmx Mode 7Ch (Model Version With 648 White Leds)

    Brightness of LED segment 1 (0 % to 100 %) 0 … 255 Brightness of LED segment 2 (0 % to 100 %) Wild Wash 132 LED RGB DMX, Wild Wash 132 LED White DMX, Wild Wash 648 LED RGB DMX, Wild Wash 648 LED White DMX...
  • Page 58 Operating Channel Value Function 0 … 255 Brightness of LED segment 3 (0 % to 100 %) 0 … 255 Brightness of LED segment 4 (0 % to 100 %) LED floodlight...

  • Page 59: Technical Specifications

    5 mm × 20 mm, 2 A, 250 V, slow-blow Dimensions (W × H × D) 310 mm× 70 mm× 70 mm Weight 1.05 kg Wild Wash 132 LED RGB DMX, Wild Wash 132 LED White DMX, Wild Wash 648 LED RGB DMX, Wild Wash 648 LED White DMX...
  • Page 60 Technical specifications Stairville Wild Wash 132 LED White DMX (item no. 399663) Number of DMX channels 1, 2 or 3 channels, depending on operating mode Illuminant 132 SMD LEDs, cold white, 0.2 W each Beam angle approx. 75° Operating supply voltage 100 - 240 V 50/60 Hz Power consumption...
  • Page 61 5 mm × 20 mm, 2 A, 250 V, slow-blow Dimensions (W × H × D) 335 mm× 182 mm× 93 mm Weight 3.25 kg Wild Wash 132 LED RGB DMX, Wild Wash 132 LED White DMX, Wild Wash 648 LED RGB DMX, Wild Wash 648 LED White DMX...
  • Page 62 Technical specifications Stairville Wild Wash 648 LED White DMX (item no. 399662) Number of DMX channels 1, 2, 3, 4, or 6 channels, depending on operating mode Illuminant 648 SMD LEDs, cold white, 0.2 W each Beam angle approx. 75° Operating supply voltage 100 - 240 V 50/60 Hz...

  • Page 63: Plug And Connection Assignments

    XLR plug. Configuration Ground, shielding Signal inverted (DMX–, ‘cold signal’) Signal (DMX+, ‘hot signal’) Wild Wash 132 LED RGB DMX, Wild Wash 132 LED White DMX, Wild Wash 648 LED RGB DMX, Wild Wash 648 LED White DMX...

  • Page 64: Troubleshooting

    Troubleshooting Troubleshooting NOTICE! Possible data transmission errors For error-free operation make use of dedicated DMX cables and do not use ordi‐ nary microphone cables. Never connect the DMX input or output to audio devices such as mixers or ampli‐ fiers. In the following we list a few common problems that may occur during operation.
  • Page 65 If the procedures recommended above do not succeed, please contact our Service Center. You can find the contact information at www.thomann.de. Wild Wash 132 LED RGB DMX, Wild Wash 132 LED White DMX, Wild Wash 648 LED RGB DMX, Wild Wash 648 LED White DMX...

  • Page 66: Cleaning

    Cleaning Cleaning Optical lenses Clean the optical lenses, that are accessible from the outside, regularly in order to optimize the light output. The frequency of cleaning depends on the operating environment: wet, smoky or particularly dirty surroundings can cause more accumulation of dirt on the optics of the device.

  • Page 67: Protecting The Environment

    When discarding the device, comply with the rules and regulations that apply in your country. If in doubt, consult your local waste disposal facility. Wild Wash 132 LED RGB DMX, Wild Wash 132 LED White DMX, Wild Wash 648 LED RGB DMX, Wild Wash 648 LED White DMX...
  • Page 68 Notes LED floodlight...
  • Page 69 Notes Wild Wash 132 LED RGB DMX, Wild Wash 132 LED White DMX, Wild Wash 648 LED RGB DMX, Wild Wash 648 LED White DMX...
  • Page 70 Notes LED floodlight...
  • Page 72 Musikhaus Thomann · Hans-Thomann-Straße 1 · 96138 Burgebrach · Germany · www.thomann.de...
