MADI Ports SC optical
• SC socket FDDI (input / output)
• ISO/IEC 9314-3
• Wave length 1310 nm
• Multi-Mode 62.5/125 or 50/125
MADI Ports BNC coaxial
• BNC socket (input / output)
• Impedance: 75 Ω
• 0.3 V up to 0.6 V (peak to peak)
MADI Ports SFP
• empty cage without module
Sample Rate
• 30 - 50 kHz
• 60 - 100 kHz @ 2 FS
• 120 - 200 kHz @ 4 FS
MADI Format (I/O)
• 48k Frame, 96k Frame
• 56 channel, 64 channel
EXBOX.MD Manual - Version 1.0
@ 1 FS
