SYNC
LED RGB - indicates selected clock
SYNC
PTP source and the lock / sync state of
SFP MADI input, PTP-clock or the internal
clock generator.
BNC
SC (OFF)
PTP (100 % green) = signal lock, in sync,
(blinking red)
(blinking green)
Pull-down menu - selection of clock
Clock
master source
Values:
PTP
SFP
BNC
SC
INT 44.1 = internal clock generator 44.1 kHz
INT 48 = internal clock generator 48 kHz
Pull-down menu - selection of scaling
Scaling
Factor* factor of base sample rate
Values: 1 FS, 2 FS, 4 FS
* See „Introduction" on page 27 .
EXBOX.MD Manual - Version 1.0
= no signal lock
selected clock source
= signal lock, not in sync
with selected clock
source
= input selected as
clock source and
no signal lock.
= PTP clock (Master or Slave)
= MADI SFP input
= MADI BNC input
= MADI SC input
