List of spare part codes
No. DESCRIPTION
1 Control panel box
2 Electronic panel support
3 N.C. contact
4 N.O. contact
5 4 poles switch *
6 Stop button base
7 30A circuit breaker
8 15A circuit breaker
9 Tie rod
10 Circuit breaker cover
11 16 poles connector *
12 Connector cover *
13 Stop button rating plate
14 Stop button
15 Fuel level gauge
16 110V 32A current socket
17 110V 32A current plug
18 Selector
19 110V 16A current socket
20 110V lamp
21 110V 16A current plug
22 230V 16A current socket
23 230V 16A current plug
SKD100
11. SPARE PARTS
SPARE
No.
PART CODE
A1032-009 24
A1032-010 25
A1032-012 26
A1032-013 27
A1033-059 28
A1032-014 29
A1032-015 30
A1032-016 31
A1032-018 32
A1032-017 33
A1032-122 34
A1032-123 35
A1032-020 36
A1032-021 37
A1032-022 38
A1032-019 39
A1032-024 40
A1032-030 41
A1032-023 42
A1032-028 43
A1032-026 44
A1032-025 45
A1032-027 46
* SKD100-IR Only
DESCRIPTION
Glow plug lamp
230V 32A current plug
230V 32A current socket
230V lamp
Oil lamp
Transparent cover
Water lamp
Battery lamp
Hourmeter
Instruments support
Circuit breakers spacer
40A 2 poles ELCB
80A 2 poles circuit breaker
L.125 omega profile
Fuse holder
2A fuse
Terminal board
Electronic panel
Relay plate
110V relay
Rear cover
12V relay
Relays support *
GB
SPARE
PART CODE
A1032-029
A1032-031
A1032-032
A1032-033
A1032-034
A1032-035
A1032-036
A1032-037
A1032-038
A1032-039
A1032-040
A1032-041
A1032-042
A1032-043
A1032-044
A1032-045
A1032-046
A1032-047
A1032-048
A1032-049
A1032-050
A1032-011
A1032-124
