HGI Generators SKD100-I Operation And Maintenance Manual page 44

GB
10.2 AMF PANEL
o
N . DESCRIPTION
MPNano ECO 10 kVA
-
AMF panel
Outline Specification
Height x Width x Depth
Colour
Access
Cabling
Installation of the generator is to be made by qualified
personnel in accordance with appropriate regulations,
for example, Electricity Safety, Quality and Continuity
Regulations 2002 (S.I. 2002/2665), and in observance to
the Directive Machine 98/392/CEE and following changes
91/368/CEE, 93/44/CEE perceived with DPR 459/96, the
electrical panel is considered a component of the the gen
set to realise iin conformity to the norms CEI 60204/1 and
CEI 604439/1.
Possible protections of overload and device of
"emergency arrest" not expressly mounted on the
electrical panel must be installed in observance to the
norm of DL 626/94
44
498-1060
10. OPTIONAL ACCESSORIES
SPARE
PART CODE
760-010
400 x 320 x 180 mm
RAL 7035
Front
Via Fund
CB - Battery Charger
F - Fuses
TG/TR - Contactor
M - Terminal Strip
SKD100
