04.2 SKD100-I CONTROL PANEL DESCRIPTION

15
16
Item Description
1 Hour meter
2 Battery charger failure alarm lamp
3 High coolant temperature alarm lamp
Low oil pressure alarm lamp
4
Glow plug signal lamp
5
6 Starting key
Fuel level gauge (option on request)
7
Machine serial number
8
Emergency stop button (option on request)
9
10 110 V signal lamp
11 230 V signal lamp
SKD100
04. THE POWER GENERATOR
1
2
13
14
17 17
18
18
3 4
5
11 10
12
17
20
19
Item Description
Voltage selector
12
13 80 A 2 poles circuit breaker
14 40 A 2 poles earth leakage circuit breaker
(option on request)
30 A circuit breakers (push to reset)
15
230 V 32 A single-phase current socket
16
17 15 A circuit breakers (push to reset)
18 230 V 16 A single-phase current sockets
110 V 16 A single-phase current socket
19
110 V 32 A single-phase current sockets
20
21 Grounding clamp
7
6
8
9
15
15
20
