06. INSTALLING AND STARTING THE POWER GENERATOR
BATTERY (picture. 4)
The unit is delivered with a fully charged
battery (disconnected).
The battery is factory filled with acid at density of 1.28 g/
ml and is ready for operation.
If the starting power is not enough, it is advisable to fur-
ther charge the battery as follows. For this operation it is
advisable to wear protective gloves and acid resistant
overalls.
• Open the canopy.
• Disconnect battery cables starting from the negative
terminal and remove the battery from the unit.
• Remove battery caps.
• Make sure that the room where the recharging will
takeplace is properly ventilated.
• Use only a DC battery charger with output voltage of
14.4 V.
• Connect to the battery charger the positive terminal
first and then the negative terminal.
• Operate the battery charger. It is advised that the
charging current be about 1/10 of the value of battery
capacity (e.g. for a 44 Ah battery it is advised that the
charging current be about 4,4 A).
• If the acid temperature exceeds 55°C cut off the
charging.
• The battery is deemed fully charged if the charging
voltage has no increased within the two hours.
In case of accidental contact with the
battery acid it is advised to:
• Wash immediately with clean water
any splash of acid into the eyes.
Seek medical advice as soon as
possible.
• Wash immediately with clean water
any splash of acid onto the skin or
clothing.
• In case of ingestion of acid: seek
medical advice immediately.
pic.4
SKD100

06.2 MAXIMUM OPERATING ANGLES

(picture 5)
Do not exceed the operating angles
shown in the figure while running the
power generator unit, or engine damage
will occur.

06.3 LOCATION

A proper installation site should be selected for the power
generator if the unit is to provide dependable service.
Operate in open, well-ventilated areas; if
operated indoors, vent the engine
exhaust outside the building and make
sure that the room has good air turnover.
Keep the engine exhaust outlet away
from building exterior
and interior walls and air intakes.
pic.5
