- Page 1 Thermal Network Bullet Camera Quick Start Guide Version 1.0.0...
-
Page 2: Table Of Contents
Table of Contents CYBERSECURITY RECOMMENDATIONS ................3 PACKING LIST ........................8 DEVICE STRUCTURE ......................9 Device External Cable ............................... 9 Dimension .................................. 10 DEVICE INSTALLATION ....................11 Preparation before Installation ........................... 11 3.1.1 Check Installation Space and Intensity ......................11 3.1.2 Cable Preparation .............................. - Page 3 Welcome Thank you for purchasing our product! This quick start guide is designed to be a reference tool for the operation of your system. Here you can find information about this speed dome features and functions, as well as a detailed menu tree. Please keep it well for future reference! Before installation and operation, please read the following safeguards and warnings carefully!
-
Page 4: Cybersecurity Recommendations
Cybersecurity Recommendations Mandatory actions to be taken towards cybersecurity 1. Change Passwords and Use Strong Passwords: The number one reason systems get “hacked” is due to having weak or default passwords. It is recommended to change default passwords immediately and choose a strong password whenever possible. A strong password should be made up of at least 8 characters and a combination of special characters, numbers, and upper and lower case letters. - Page 5 7. Disable Auto-Login on SmartPSS: Those using SmartPSS to view their system and on a computer that is used by multiple people should disable auto-login. This adds a layer of security to prevent users without the appropriate credentials from accessing the system. 8.
- Page 6 16. Isolate NVR and IP Camera Network The network your NVR and IP camera resides on should not be the same network as your public computer network. This will prevent any visitors or unwanted guests from getting access to the same network the security system needs in order to function properly.
-
Page 7: Important Safeguards And Warnings
Important Safeguards and Warnings 1. Installation and Maintenance Professionals Requirements All the installation and maintenance professionals must have qualification certificate or experiences of installing and maintaining CCTV system, electric apparatus in the explosive gas environment and working high above the ground. Besides, they have to acquire the following knowledge and operation skills. ... - Page 8 It is recommended to use the device together with a lightning arrester, which is to improve the effect of lightning protection, it needs to conform to the lightning protection regulation for outdoor application. 5. Warning Please modify the default password after login, in case it is stolen. ...
-
Page 9: Packing List
1 Packing List Please check if there is any obvious damage to the device appearance when opening the packing box, and confirm if the accessories in the box are in accordance with those on the list. Please refer to Table 1-1 for more details about the list. -
Page 10: Device Structure
2 Device Structure 2.1 Device External Cable Note The following figure is for reference only, which is only used to know the function of cable ports. The cable structure may be different according to different devices, please refer to the actual device for more details. -
Page 11: Dimension
Port Port name Connector Function description Generally it outputs analog video signal, it can connect to TV monitor to check image. Video output Plug the connector into the network port VIDEO OUT port before powering up the device, then the device is powered on, at this moment, BNC outputs HDCVI signal. -
Page 12: Device Installation
3 Device Installation 3.1 Preparation before Installation 3.1.1 Check Installation Space and Intensity Make sure the installation site has enough space to hold the device and its mounting structural components. Please make sure the ceiling and wall where the bullet is installed can sustain at least 8x weight of bullet and its mounting structural components. -
Page 13: Install Device
Figure 3-1 Note Long press the reset button for 4~5 seconds to realize device reset function. Step 2 Insert the SD card into the slot, the card slot is elastic, so you only need to press the SD card slightly to install the SD card. - Page 14 Step 1 Fix the device on the mounting surface. 1. Select a flat mounting surface (wall or ceiling and so on); stick the installation position map on the proper position. 2. Dig holes according to the four mounting hole sites marked on the installation position map. The size and depth of hole diameter need to be matched with expansion bolts, make sure there is no deviation for the hole sites.
- Page 15 1. Keep the convex groove outward and install the rubber ring into the network port, keep the smaller hole of the rubber ring outward and install the fixing rubber ring into the main body of the waterproof connector. 2. Pull the network cable without crystal head through main body of waterproof connector, fixing rubber ring and waterproof locking cover, make the crystal head of network cable, and then insert it into the network cable.
-
Page 16: Device Configuration
4 Device Configuration 4.1 Device Initialization It needs to set the user password when logging in for the first time (the username is admin by default). The figures listed in the following chapter are for reference only. There is difference about interface between different devices, please refer to the actual device for more details. -
Page 17: Modify Ip Address
Step 3 Click Save to complete initialization. 4.2 Modify IP Address In order to make the camera get access to network smoothly, please plan IP address reasonably according to the actual network environment. Step 1 Log in camera WEB interface in the IE browser. Note ... -
Page 18: Alarm Setup
IP address is the one which has been modified. Default user is admin; the password has been set during device initialization. Step 2 Click Login and the system will display the WEB main interface, which is shown in Figure 4-3. Note It will prompt you to install plug-in for the first system login, please save and install plug-in according to prompt. - Page 19 The interface of alarm setup is shown in Figure 4-4. Alarm input is corresponding to the alarm input port of device I/O cable. It is to set corresponding NO and NC according to the high and low level signal generated by alarm input device when alarm occurs. ...
- Page 20 Alarm output: port ALARM_OUT and ALARM_COM form a switch, which can be used to provide alarm output. Normally the switch is on, the switch will be off when there is alarm output.
-
Page 21: Appendix Ⅰ Lightening Protection And Surge Protection
5 Appendix Ⅰ Lightening Protection and Surge Protection This series speed dome adopts TVS lighting protection technology. It can effectively prevent damages from various pulse signals below 6000V, such as sudden lighting and surge. While maintaining your local electrical safety code, you still need to take necessary precaution measures when installing the speed dome in the outdoor environment.
