Summary of Contents for NEC N8141-69F
-
Page 1: Configuration Guide
1U Device Expansion Unit Configuration Guide Introduction This document contains product and configuration information that will enable you to configure your system. The guide will ensure fast and proper configuration of your storage system. August 30, 2017 Revision 3.0 NEC Corporation... -
Page 2: Table Of Contents
Tape Drive Configuration ....................... 6 SAS Tape Drive Configuration ....................7 USB RDX Drive Configuration ....................9 SAS and USB Tape/RDX Drive Configuration ..............11 COPYRIGHT NOTICE AND LIABILITY DISCLAIMER ..........13 REVISION HISTORY ..................... 14 Revision 3.0 – August, 2017 NEC Corporation... -
Page 3: Technical Specification
Superior reliability with redundant power supplies Specification Model 1U Device Expansion Unit Part Number N8141-69F 5-inch Media Bays Redundant Power Supply Optional, non-hot plug Power Supply 100-240 VAC ± 10% 50 / 60 Hz ± 3 Hz Dimensions (W x D x H ) 424.0 x 578.1 x 44.0 mm / 16.7 x 22.7 x 1.7 in (1U) -
Page 4: External Views
Power Unit 1 Status LED Fan Unit 2 Status LED Fan Unit 1 Status LED Drive Bays Power Switch 2 Rear View Legend AC Inlet External Connector 1 AC Inlet (Optional) External Connector 3 External Connector 2 Revision 3.0 – August, 2017 NEC Corporation... -
Page 5: Dimensions (Mm)
– CONFIGURATION GUIDE 1U Device Expansion Unit Dimensions (mm) Revision 3.0 – August, 2017 NEC Corporation... -
Page 6: Unit Configuration
The tape drive enclosure can be shared with up to two servers, HBAs. See the figures below for typical tape drive bays configuration. Two HBA Configuration SAS Interface To HBA SAS Interface To HBA Revision 3.0 – August, 2017 NEC Corporation... -
Page 7: Sas Tape Drive Configuration
2 m, 1 x SFF-8088 to 1 x SFF-8088 External SAS cable K410-322(02) 2 m, 1x Mini SAS HD -1x Mini SAS Enclosure 1U Device Expansion Unit N8141-69F Required 2 x 5-inch media bays Power Supply Power Unit N8181-124F Recommended... - Page 8 2 m, 1 x SFF-8088 to 1 x SFF-8088 External SAS cable K410-322(02) 2 m, 1x Mini SAS HD -1x Mini SAS Enclosure 1U Device Expansion Unit N8141-69F Required 2 x 5-inch media bays Power supply Power Unit N8181-124F Recommended...
-
Page 9: Usb Rdx Drive Configuration
USB3.0,1.17 m, 1 x external USB to 1 x USB device, mount bracket included NOTE: The cable is required to connect with a USB3.0 port. Enclosure 1U Device Expansion Unit N8141-69F Required 2 x 5-inch media bays Power Supply Power Unit N8181-124F... - Page 10 USB3.0,1.17 m, 1 x external USB to 1 x USB device, mount bracket included NOTE: The cable is required to connect with a USB3.0 port. Enclosure 1U Device Expansion Unit N8141-69F Required 2 x 5-inch media bays Power Supply Power Unit N8181-124F...
-
Page 11: Sas And Usb Tape/Rdx Drive Configuration
USB3.0,1.17 m, 1 x external USB to 1 x USB device, mount bracket included NOTE: The cable is required to connect with a USB3.0 port. Enclosure 1U Device Expansion Unit N8141-69F Required 2 x 5-inch media bays Power Supply Power Unit N8181-124F... - Page 12 K410-322(02): N8803-041, N8103-197, and N8103-184 Choose an appropriate USB cable according to the USB connector on the server. Refer to the system configuration of the server to select the appropriate internal RDX drive. Revision 3.0 – August, 2017 NEC Corporation...
-
Page 13: Copyright Notice And Liability Disclaimer
All other products, brands, or trade names used in this document are trademarks or registered trademarks of their respective holders. NEC shall not be liable for technical or editorial errors or omissions contained herein. Revision 3.0 – August, 2017 NEC Corporation... -
Page 14: Revision History
Added SAS Controller and cable information for new servers. New products added: July 20, 2016 Internal LTO (SAS) / N8151-136 Others: Added SAS Controller and cable information for R320e. October 23, 2015 Initial release Revision 3.0 – August, 2017 NEC Corporation...
