CONFIGURATION GUIDE
Unit Configuration
1 External Tape Drive Enclosure
1.1 Tape Drive Configuration
Refer to the section in accordance with type of tape drives installed and number of host adapters.
Type of Tape Drives
Internal LTO
Internal RDX
Mixing internal LTO and RDX Drives
The tape drive enclosure can be shared with up to two servers, HBAs. See the figures below for typical
tape drive bays configuration.
Two HBA Configuration
To HBA
To HBA
NEC Corporation
–
1U Device Expansion Unit
One SAS HBAs
Two SAS HBAs
One USB HBAs
Two USB HBAs
One SAS and one /USB HBAs
SAS Interface
SAS Interface
Revision 3.0 – August, 2017
Number of Host Adapters
Section
1.2.1
1.2.2
1.3.1
1.3.2
1.4
