External Views; Front And Rear Views - NEC N8141-69F Configuration Manual

CONFIGURATION GUIDE

External Views

Front and Rear Views

Front View
Legend
A.
Power Switch 1
B.
Ready LED
C.
Power Unit 1 Status LED
D.
Fan Unit 1 Status LED
E.
Power Switch 2
Rear View
Legend
A. AC Inlet
B. AC Inlet (Optional)
C. External Connector 2
NEC Corporation
–
1U Device Expansion Unit
B
C
Revision 3.0 – August, 2017
A B C D E
I F G H
F.
Error Status LED
G.
Power Unit 2 Status LED
H.
Fan Unit 2 Status LED
I.
Drive Bays
D
D. External Connector 1
E. External Connector 3
I
A
E
4
