- Page 1 GT 970 INSTALLATION AND USER MANUAL http://jablotron.nt-rt.ru/...
- Page 2 Ульяновск (8422)24-23-59 Екатеринбург (343)384-55-89 Магнитогорск (3519)55-03-13 Рязань (4912)46-61-64 Уфа (347)229-48-12 Иваново (4932)77-34-06 Москва (495)268-04-70 Самара (846)206-03-16 Челябинск (351)202-03-61 Ижевск (3412)26-03-58 Мурманск (8152)59-64-93 Санкт-Петербург (812)309-46-40 Череповец (8202)49-02-64 Казань (843)206-01-48 Набережные Челны (8552)20-53-41 Саратов (845)249-38-78 Ярославль (4852)69-52-93 сайт: www.jablotron.nt-rt.ru || эл. почта: jnb@nt-rt.ru...
-
Page 3: Table Of Contents
SUMMARY 1.0 - GENERAL DESCRIPTION Page 2 2.0 - INSTALLATION AND CONNECTIONS Page 2 3.0 - CONNECTION DIAGRAM Page 3 4.0 - ALARM POSITIONING Page 4 5.0 - SET FUNCTIONS Page 4 6.0 - USER MANUAL Page 7 7.0 - MAINTENANCE AND WARNINGS Page 10 8.0 - COMPLIANCE DECLARATION Page 11... -
Page 4: Connection Diagram
- Connect the BROWN wire (power supply negative) to the negative terminal of the vehicle’s battery - Connect the RED wire (12V positive power supply) to the positive terminal of the vehicle’s battery using the 3A fuse. - Connect the RED/WHITE wire (indicators 12V positive) to the positive terminal of the vehicle’s battery using the 15A fuse. -
Page 5: Alarm Positioning
4.0 - ALARM POSITIONING The system is equipped with a “SENSOR” which allows to detect possible motor vehicle shocks/ movement. For an optimum operation pay attention to the fixing positions indicated below. WARNING: - Before carrying out the definitive fixing it is suggested to place temporary the alarm and check the correct operation of the shocks/movement sensor. - Page 6 To come out from the SET FUNCTIONS: Wait the end of the signal and place the GT889 handsets contacts to the receptacle (not during the Function No. 3 - HANDSETS SELF-CODING). The exit is confirmed by the Led switching off and by 5 beeps. In the “FUNCTIONS TABLE”...
- Page 7 - HANDSETS SELF-CODING (Function No.3). With the function No. 3 it is possible to self-code new handsets to the control unit up to a max. of 8. 1 - Select the function and press the “ON” button to be self-coded. 2 - The system confirm the correct handset self-coding by a flash of the GREEN LED and by a beep.
-
Page 8: User Manual
6.0 - USER MANUAL HANDSET DESCRIPTION. GT884 GT889 (Opzional) 3 buttons with electronic key incorporated. GT889: multifunction button (Optional). GT884N: t integrates a sensor which keeps the “LINK” transmission active. If the sensor doesn’t detect vibrations for more than BUTTON SERVICES BUTTON 2 minutes, it reduces the transmissions and so the battery... - Page 9 - EMERGENCYDISARMING. In case of emergency (i.e. handset low battery) it is possible to disarm the system placing on the RECEPTACLE the electronic key integrated in the GT889 handset. - IN CASE OF ALARM. - Pressing the “OFF” handset button or approach with the handset in AUTOMATIC-TRANSMISSION- LINK mode”...
- Page 10 5 - Release the "OFF" button and close the remote control handset. 6 - To change the function state repeat the procedure from the point 1 (at each repetition of the procedure the function changes state). - PROTECTIONS. When the system is armed the status check LED switches constant on, after 30 seconds the LED flashes.
-
Page 11: Maintenance And Warnings
ANOMALIES SIGNALS TABLE ALARMS SIGNALS TABLES Status check LED Cause which has Status check LED Input which has flashes number generated the anomaly flashes number generated the alarm RED/GREEN HANDSETS SHOCKS/MOVEMENT BATTERY SENSOR PAUSE SEAT or BONNET or SYSTEM STATE TABLE PAUSE SIDESTAND LED Colour... -
Page 12: Compliance Declaration
- HOW TO REPLACE THE HANDSETS BATTERY. \ WARNING: the batteries selling off has to always occur in appropriate way and it has to be in compliance with the local rules in force. - With care lever the front case for the WARNING! printed circuit - The battery negative terminal has to be... -
Page 13: Warranty Conditions
10.0 - WARRANTY CONDITIONS This Certificate should be kept in a safe place and produced for verification should technical assistance be required. Inability to produce this Certificate may affect your warranty rights. Warranty period bengins from date of purchase and is valid for 24 months. Should technical assistance be required during the warranty period, you should take your vehicle and this Certificate to either the original installer or the nearest GT Auto Alarm Service Centre for inspection. - Page 14 Ульяновск (8422)24-23-59 Екатеринбург (343)384-55-89 Магнитогорск (3519)55-03-13 Рязань (4912)46-61-64 Уфа (347)229-48-12 Иваново (4932)77-34-06 Москва (495)268-04-70 Самара (846)206-03-16 Челябинск (351)202-03-61 Ижевск (3412)26-03-58 Мурманск (8152)59-64-93 Санкт-Петербург (812)309-46-40 Череповец (8202)49-02-64 Казань (843)206-01-48 Набережные Челны (8552)20-53-41 Саратов (845)249-38-78 Ярославль (4852)69-52-93 сайт: www.jablotron.nt-rt.ru || эл. почта: jnb@nt-rt.ru...
