- Page 1 Fast EthErnEt OFFicE switch usEr manual Model 523929 INT-523929-UM-1107-01...
- Page 3 Thank you for purchasing the INTELLINET NETWORK SOLUTIONS ™ Fast Ethernet Office Switch, Model 523929. This 24-port rackmount device is a high-performance 10/100 Mbps LAN switch with auto-sensing and auto negotiation on every port. The space- saving, cost-effective design allows you to connect up to 24 devices to your local area network while only taking up one slot in your network rack or cabinet.
-
Page 4: Connections & Indicators
cOnnEctiOns & indicatOrs LEDs The front panel LED indicators provide at-a-glance network status and real-time connectivity info, as detailed in the chart below. NOTE: The mini-GBIC slots share LEDs with the Gigabit RJ-45 (copper) ports: 25X/26X. Port Status Operation Power Green The switch is on. -
Page 5: Installation
Ports The auto-negotiation feature of the Fast Ethernet Office Switch allows ports to operate in the following modes. NOTE: With the Gigabit ports, when both the fiber and copper interfaces are connected, the system adopts the fiber interface and disables the corresponding copper port automatically. - Page 6 Desktop Placement • Affix the provided rubber pads to the bottom of the switch to protect it from scratches and prevent slipping. • Make sure the surface can support the weight of the switch. • Position the switch for easy and secure access to AC power. Rackmounting •...
-
Page 7: Specifications
spEciFicatiOns Standards - 2 SFP mini-GBIC transceiver • IEEE 802.3 (10Base-T Ethernet) module slots • IEEE 802.3ab (Twisted Pair • Certifications: FCC Class A, CE Gigabit Ethernet) Mark, VCCI Class A • IEEE 802.3u (100Base-TX Fast LEDs Ethernet) • Power •... - Page 8 INTellINeT NeTWoRK SolUTIoNS offers a complete line ™ of active and passive networking products. Ask your local computer dealer for more information or visit www.intellinet-network.com Copyright © INTELLINET NETWORK SOLUTIONS All products mentioned are trademarks or registered trademarks of their respective owners.
