Description
Meter Description
1.
Microphone Connector
2.
USB Interface (Side)
3.
LCD Display
4.
Power Button
5.
Microphone and wind screen
6.
Navigation Buttons
7.
Start / Pause Button
8.
Microphone Cable
9.
REC/MEM Button
10. ENTER Button
11. SET Button
12. Stop Button
Display Description
nd Quality Products Online at:
Battery Status
Auto Power Off Enabled
Pause
115dB indicator (SPL)
Stop
140 dB indicator (Peak)
GlobalTestSupply
www.
1
2
3
5
4
6
7
3
.com
8
9
10
6
11
12
SL400‐en‐GB_V1.0 2/16
