ZXSDR R8882
Macro Radio Remote Unit

Product Description

Hardware Version: HV2.1
ZTE CORPORATION
No. 55, Hi-tech Road South, ShenZhen, P.R.China
Postcode: 518057
Tel: +86-755-26771900
Fax: +86-755-26770801
URL: http://support.zte.com.cn
E-mail: support@zte.com.cn

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ZXSDR R8882 and is the answer not in the manual?

Questions and answers

Related Manuals for Zte ZXSDR R8882

Summary of Contents for Zte ZXSDR R8882

  • Page 1: Product Description

    ZXSDR R8882 Macro Radio Remote Unit Product Description Hardware Version: HV2.1 ZTE CORPORATION No. 55, Hi-tech Road South, ShenZhen, P.R.China Postcode: 518057 Tel: +86-755-26771900 Fax: +86-755-26770801 URL: http://support.zte.com.cn E-mail: support@zte.com.cn...
  • Page 2 ZTE CORPORATION is prohibited. Additionally, the contents of this document are protected by contractual confidentiality obligations. All company, brand and product names are trade or service marks, or registered trade or service marks, of ZTE CORPORATION or of their respective owners.

  • Page 3: Table Of Contents

    Contents About This Manual ..................I Chapter 1 Product Overview ..............1-1 1.1 Position of the ZXSDR R8882 in the Radio Network ..........1-1 1.2 Product Features....................1-1 1.3 Services and Functions ..................1-3 1.4 Product Specifications ..................1-5 1.5 Installation Scenarios ..................1-7 Chapter 2 System Structure ..............
  • Page 4 This page intentionally left blank. SJ-20150104112914-001|2015-01-04 (R1.0) ZTE Proprietary and Confidential...

  • Page 5: About This Manual

    The ZXSDR R8882 works with a to constitute the distributed BTS, that is, ZXSDR of ZTE. This manual provides a general description of the ZXSDR R8882, covering the product features, services and functions, system architecture, operation and maintenance, networking, and technical specifications. Intended Audience...
  • Page 6 Note: Provides additional information about a certain topic. Checkpoint: Indicates that a particular step needs to be checked before proceeding further. Tip: Indicates a suggestion or hint to make things easier or more productive for the reader. SJ-20150104112914-001|2015-01-04 (R1.0) ZTE Proprietary and Confidential...

  • Page 7: Position Of The Zxsdr R8882 In The Radio Network

    Figure 1-1 Position of the ZXSDR R8882 in the Radio Network 1.2 Product Features The ZXSDR R8882 is an outdoor Radio Remote Unit (RRU) with dual transmitters. The ZXSDR R8882 works with a Baseband Unit (BBU) to provide all logical functions of a BTS. SJ-20150104112914-001|2015-01-04 (R1.0) ZTE Proprietary and Confidential...
  • Page 8 Based on the digital intermediate frequency and multi-carrier technologies, the ZXSDR R8882 is capable of transmitting dual channels of radio signals and receiving four channels of radio signals. The ZXSDR R8882 can act as an independent remote RF unit for Global System for Mobile Communication (GSM)/Universal Mobile Telecommunication System...

  • Page 9: Services And Functions

    Easy installation and maintenance Easy installation and maintenance due to compact size and light weight. 1.3 Services and Functions Services The ZXSDR R8882 works with BBUs to provide the following services: Full Rate (FR) voice service à Enhanced Full Rate (EFR) voice service à...
  • Page 10 The ZXSDR R8882 works with BBUs to constitute the distributed BTS system. The ZXSDR R8882 forwards signals that are received or to be transmitted to the BBU for further processing. By connecting to the BBU, the ZXSDR R8882 provides the...

  • Page 11: Product Specifications

    120 km. Supports the Co-BCCH technology. à UMTS mode When working in UMTS mode, the ZXSDR R8882 provides the following functions: Supports UMTS frequency bands. à Supports UMTS R99, R4, R5, R6, R7, and R8. à...
  • Page 12 ZXSDR R8882 Product Description Product Specifications Description ZXSDR R8882 S1800 (C) Three optical ports; a maximum of 6 Gbps; GSM single mode, 1800 MHz frequency band; 2 × 60 W ZXSDR R8882 S9000 (B) Two optical ports; a maximum of 3 Gbps; GSM single mode, UMTS single mode, or GSM/UMTS dual mode;...

  • Page 13: Installation Scenarios

    L-shape gantry-mounting. Wall-mounting The ZXSDR R8882 can be wall-mounted indoor or outdoor. Pole-mounting In pole-mounting installation, you can install one, two, three, or four ZXSDR R8882 devices on one pole. L-shape gantry mounting SJ-20150104112914-001|2015-01-04 (R1.0) ZTE Proprietary and Confidential...
  • Page 14 ZXSDR R8882 Product Description This page intentionally left blank. SJ-20150104112914-001|2015-01-04 (R1.0) ZTE Proprietary and Confidential...

  • Page 15: Chapter 2 System Structure

    Hardware Subsystem ....................2-1 Software Subsystem ....................2-2 2.1 Hardware Subsystem Figure 2-1 takes the ZXSDR R8882 with three optical ports for example to show the general hardware architecture. Figure 2-1 ZXSDR R8882 Hardware Subsystem Note: The OPT3 interface is not available for a ZXSDR R8882 with two optical interfaces.

  • Page 16: Software Subsystem

    Protects AISG signals (AISG power, half-duplex 485 signal). Performs dry contact protection. Protects the RS485 monitoring signals. Provides adaptation for external MON interface, AISG interface, and power interface. 2.2 Software Subsystem Figure 2-2 shows the software subsystem of the ZXSDR R8882. SJ-20150104112914-001|2015-01-04 (R1.0) ZTE Proprietary and Confidential...

  • Page 17: Figure 2-2 Software Architecture

    SJ-20150104112914-001|2015-01-04 (R1.0) ZTE Proprietary and Confidential...
  • Page 18 ZXSDR R8882 Product Description This page intentionally left blank. SJ-20150104112914-001|2015-01-04 (R1.0) ZTE Proprietary and Confidential...

  • Page 19: Chapter 3 Operation And Maintenance

    In remote maintenance mode, the NetNumen™ M3 OMC of ZTE is connected to the BSC/RNC/BBU, and then connected to the ZXSDR R8882 through the Abis/Iub/CPRI interface. In this way, you can operate and maintain the ZXSDR R8882 through the OMC. Figure 3-1 shows the networking.

  • Page 20: Operation And Maintenance Functions

    Figure 3-2 Local Maintenance Mode Through the LMT, you can query the power, increase or decrease the power, and perform calibration on the ZXSDR R8882. Through the LMT, you can maintain the entire BTS. 3.2 Operation and Maintenance Functions The NetNumen™ M3 OMC provides a topological view on the GUI interface. Through the GUI interface, users can view the information about all the NEs in the entire network.
  • Page 21 Chapter 3 Operation and Maintenance which helps the operation and maintenance personnel to determine the equipment faults and maintain the equipment. SJ-20150104112914-001|2015-01-04 (R1.0) ZTE Proprietary and Confidential...
  • Page 22 ZXSDR R8882 Product Description This page intentionally left blank. SJ-20150104112914-001|2015-01-04 (R1.0) ZTE Proprietary and Confidential...

  • Page 23: Chapter 4 Networking

    CDMA Star Networking support support support support Cascade support(4 grades) support(4 grades) support(6 grades) not support Networking 4.2 Star Networking Figure 4-1 shows the star networking of a BBU and multiple RRUs (ZXSDR R8882). SJ-20150104112914-001|2015-01-04 (R1.0) ZTE Proprietary and Confidential...

  • Page 24: Cascade Networking

    ZXSDR R8882 Product Description Figure 4-1 Star Networking 4.3 Cascade Networking Figure 4-2 shows the cascade networking of a BBU and multiple RRUs (ZXSDR R8882). Figure 4-2 Cascade Networking 4.4 Ring Networking Ring networking is only available for CRAN. Figure 4-3 shows the ring networking of a BBU and multiple RRUs (ZXSDR R8882).

  • Page 25: Figure 4-4 Ring And Chain Networking (With Three Optical Ports)

    Chapter 4 Networking Figure 4-4 Ring and Chain Networking (with Three Optical Ports) SJ-20150104112914-001|2015-01-04 (R1.0) ZTE Proprietary and Confidential...
  • Page 26 ZXSDR R8882 Product Description This page intentionally left blank. SJ-20150104112914-001|2015-01-04 (R1.0) ZTE Proprietary and Confidential...
  • Page 27 S2: 165 W S3: 185 W S11: 210 W Average power consumption in S22: 265 W UMTS single mode(900 MHz) S33: 310 W S1 MIMO: 210 W S2 MIMO: 265 W S3 MIMO: 315 W SJ-20150104112914-001|2015-01-04 (R1.0) ZTE Proprietary and Confidential...
  • Page 28 ZXSDR R8882 Product Description Item Specifications S1: 130 W S2: 150 W S3: 180 W S11: 200 W Average power consumption in S22: 215 W UMTS single mode(2100 MHz) S33: 265 W S1 MIMO: 170 W S2 MIMO: 215 W...

  • Page 29: Chapter 5 Technical Specifications

    UMTS single antenna: -125.8 dBm UMTS dual antennas: -128.5 dBm Static receiver sensibility CDMA: –115 dBm LTE single antenna: -106 dBm LTE dual antenna: -108.6 dBm 5.3 Interfaces The ZXSDR R8882 provides the following interfaces: SJ-20150104112914-001|2015-01-04 (R1.0) ZTE Proprietary and Confidential...
  • Page 30 Item Specifications ZXSDR R8882 S9000(C) Provides three optical ports: OPT1: the interface through which the ZXSDR R8882 is cascaded to a BBU OPT2: the interface through which the ZXSDR R8882 is cascaded to an RRU OPT3: the interface through which the ZXSDR R8882 is cascaded...
  • Page 31 One AISG interface, which is used for the electrical tilt tunable antenna. Power interface One power interface, which provides external power input. Protective Earth (PE) inter- One PE interface, through which the ZXSDR R8882 is connected to the face SJ-20150104112914-001|2015-01-04 (R1.0) ZTE Proprietary and Confidential...
  • Page 32 ZXSDR R8882 Product Description This page intentionally left blank. SJ-20150104112914-001|2015-01-04 (R1.0) ZTE Proprietary and Confidential...

  • Page 33: Chapter 6 Fcc&Ic Statement

    Operation of this equipment in a residential area is likely to cause harmful interference in which case the user will be required to correct the interference at his own expense. SJ-20150104112914-001|2015-01-04 (R1.0) ZTE Proprietary and Confidential...
  • Page 34 ZXSDR R8882 Product Description This page intentionally left blank. SJ-20150104112914-001|2015-01-04 (R1.0) ZTE Proprietary and Confidential...

  • Page 35: Figures

    Figures Figure 1-1 Position of the ZXSDR R8882 in the Radio Network ........ 1-1 Figure 2-1 ZXSDR R8882 Hardware Subsystem ............2-1 Figure 2-2 Software Architecture................2-3 Figure 3-1 Remote Maintenance Mode (Taking CDMA and GSM for Example) ... 3-1 Figure 3-2 Local Maintenance Mode .................
  • Page 36 Figures This page intentionally left blank. SJ-20150104112914-001|2015-01-04 (R1.0) ZTE Proprietary and Confidential...

  • Page 37: Tables

    Tables Table 1-1 Product Specifications ................1-5 Table 4-1 Networking Description................4-1 SJ-20150104112914-001|2015-01-04 (R1.0) ZTE Proprietary and Confidential...
  • Page 38 Tables This page intentionally left blank. SJ-20150104112914-001|2015-01-04 (R1.0) ZTE Proprietary and Confidential...

  • Page 39: Glossary

    - Digital Output - Digital Pre-Distortion - Digital Signal Processing - Discontinuous Transmission - Enhanced Full Rate - Frequency Division Duplex FPGA - Field Programmable Gate Array - Full Rate GPRS - General Packet Radio Service SJ-20150104112914-001|2015-01-04 (R1.0) ZTE Proprietary and Confidential...
  • Page 40 ZXSDR R8882 Product Description - Global System for Mobile Communications - Half Rate HSDPA - High Speed Downlink Packet Access HSUPA - High Speed Uplink Packet Access - Local Maintenance Terminal - Long Term Evolution MBMS - Multimedia Broadcast/Multicast Service...
  • Page 41 - Remote Radio Unit RSSI - Received Signal Strength Indicator - Round Trip Time - Software Defined Radio - Standing Wave Ratio - Timing Advance UMTS - Universal Mobile Telecommunication System VSWR - Voltage Standing Wave Ratio SJ-20150104112914-001|2015-01-04 (R1.0) ZTE Proprietary and Confidential...
