ZXSDR R8882
Macro Radio Remote Unit
Hardware Installation Guide
Hardware Version: HV2.0
ZTE CORPORATION
NO. 55, Hi-tech Road South, ShenZhen, P.R.China
Postcode: 518057
Tel: +86-755-26771900
Fax: +86-755-26770801
URL: http://ensupport.zte.com.cn
E-mail: support@zte.com.cn

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ZXSDR R8882 and is the answer not in the manual?

Questions and answers

Related Manuals for Zte ZXSDR R8882

Summary of Contents for Zte ZXSDR R8882

  • Page 1 ZXSDR R8882 Macro Radio Remote Unit Hardware Installation Guide Hardware Version: HV2.0 ZTE CORPORATION NO. 55, Hi-tech Road South, ShenZhen, P.R.China Postcode: 518057 Tel: +86-755-26771900 Fax: +86-755-26770801 URL: http://ensupport.zte.com.cn E-mail: support@zte.com.cn...

  • Page 2: Connecting The Dc Power Cable

    ZTE CORPORATION is prohibited. Additionally, the contents of this document are protected by contractual confidentiality obligations. All company, brand and product names are trade or service marks, or registered trade or service marks, of ZTE CORPORATION or of their respective owners.

  • Page 3: Table Of Contents

    Contents About This Manual ..................I Chapter 1 Installation Overview ..............1-1 1.1 Device Appearance .................... 1-1 1.2 Preparation for Installation .................. 1-2 1.2.1 Environment Inspection ................1-2 1.2.2 Equipment Table ..................1-2 1.2.3 Tools and Meters List................1-2 1.3 Installation Space Requirement................1-3 1.4 Unpacking Inspection ..................
  • Page 4 4.2 Connecting the Protective Grounding Cable ............4-2 4.3 Connecting the DC Power Cable ................. 4-3 4.4 Connecting the Optical Fiber ................4-7 4.5 Connecting the Monitoring Cable................. 4-9 4.6 Connecting the AISG Cable ................4-11 4.7 Connecting the Feeder Jumper ................. 4-12 Chapter 5 Post-Installation Check ............

  • Page 5: About This Manual

    About This Manual Purpose This manual describes how to install the ZXSDR R8882(take ZXSDR R8882 S9000(C) as an example) including installation overview, PIMDC installation, device installation, cabling, and post-installation check. There are two types of protection shades which are optional parts, here we take the old type for example to describe installation steps.

  • Page 6: Chapter 6 Concluding Routines

    Appendix B, Labeling Specifications Describes labeling specifications. Appendix C, Assembling the Portal Frame Describes how to install the portal frame. Conventions ZTE documents employ the following typographical conventions. Typeface Meaning Italics References to other Manuals and documents. “Quotes” Links on screens.

  • Page 7: Chapter 1 Installation Overview

    Table of Contents Device Appearance ....................1-1 Preparation for Installation..................1-2 Installation Space Requirement ..................1-3 Unpacking Inspection ....................1-5 Installation Flow ......................1-7 1.1 Device Appearance Figure 1-1 shows the ZXSDR R8882 device appearance. Figure 1-1 ZXSDR R8882 SJ-20111021104623-004|2012–01-30 (R1.1) ZTE Proprietary and Confidential...

  • Page 8: Preparation For Installation

    Before installing the device, installation personnel should make sure that the site environment is inspected and the Environment Acceptance Report is issued. 1.2.2 Equipment Table This table gives the Materiel Description and Quantity required installing a ZXSDR R8882. Table 1-1 ZTE Parts and Equipment List for a RRU Material Name...

  • Page 9: Installation Space Requirement

    Digital multimeter, VSWR tester, earth resistance tester, base station tester, compass, field strength tester (for special purpose), and spectrum analyzer (for special purpose) 1.3 Installation Space Requirement Figure 1-2 shows the recommended space for installing ZXSDR R8882. SJ-20111021104623-004|2012–01-30 (R1.1) ZTE Proprietary and Confidential...
  • Page 10 ZXSDR R8882 Hardware Installation Guide Figure 1-2 Recommended Space for Installing ZXSDR R8882 (Unit: mm) Figure 1-3 shows the minimum space for installing ZXSDR R8882. SJ-20111021104623-004|2012–01-30 (R1.1) ZTE Proprietary and Confidential...

  • Page 11: Unpacking Inspection

    Chapter 1 Installation Overview Figure 1-3 Minimum Space for Installing ZXSDR R8882 (Unit: mm) 1.4 Unpacking Inspection 1.4.1 Counting Goods Prerequisite The goods have been delivered to the site for installation. Context The goods counting needs to be jointly completed by the engineer- ing technicians from both ZTE and the operator.

  • Page 12: Unpacking Crate

    3. If any goods missing, default, wrong equipments, inaccuracy in number or damages are found, the Feedback For Unpacking Inspection needs to be filled out by engineering supervisor with relevant reason. It should be send back to ZTE as soon as possible for processing.

  • Page 13: Acceptance And Handover

    Unpacking Inspection Report and transfer the goods to the customer. – End of Steps – 1.5 Installation Flow Figure 1-4 shows the flowchart of installing ZXSDR R8882, including PIMDC installation, device installation, and cabling. SJ-20111021104623-004|2012–01-30 (R1.1) ZTE Proprietary and Confidential...
  • Page 14 ZXSDR R8882 Hardware Installation Guide Figure 1-4 Flowchart o f I nstalling ZXSDR R8882 SJ-20111021104623-004|2012–01-30 (R1.1) ZTE Proprietary and Confidential...

  • Page 15: Chapter 2 Pimdc Installation

    If the device is configured with a PIMDC , installation personnel can install the PIMDC onto the device before installing the device. The PIMDC can be installed on the front or side of the device. SJ-20111021104623-004|2012–01-30 (R1.1) ZTE Proprietary and Confidential...

  • Page 16: Installing The Pimdc On The Front Of The Device

    ZXSDR R8882 Hardware Installation Guide 2.2 Installing the PIMDC on the Front of the Device Steps 1. Put the PIMDC mounting piece in place and align the holes on the PIMDC mounting piece with the mounting holes on the device.
  • Page 17 3. Place the PIMDC on the mounting piece and tighten the two captive screws with a screwdriver, as shown in Figure 2-5. Figure 2-5 Securing the PIMDC on the Side of the Device – End of Steps – SJ-20111021104623-004|2012–01-30 (R1.1) ZTE Proprietary and Confidential...
  • Page 18 ZXSDR R8882 Hardware Installation Guide This page intentionally left blank. SJ-20111021104623-004|2012–01-30 (R1.1) ZTE Proprietary and Confidential...

  • Page 19: Wall-Mounted Installation

    Portal Frame-Mounted Installation................3-23 Installing the Protection Shade .................3-26 3.1 Overview Depending on the configured installation assemblies, installation personnel can install ZXSDR R8882 in one of the following modes: Wall-mounted installation Pole-mounted installation Portal frame-mounted installation The following table describes the installation positions supported by the installation assemblies of ZXSDR R8882.
  • Page 20 3.2 Installation Assemblies Based on the installation mode and installation assembly, installation personnel can install ZXSDR R8882 in one of the following six ways: Use mounting kit 1 to mount the device on a wall. Use mounting kit 2 to mount the device on a wall.
  • Page 21 It is used to mount ZXSDR R8882 on a wall. RRU mounting base It is installed on the back or side of ZXSDR R8882 to secure ZXSDR R8882 on the wall mounting assembly, pole mounting assembly, parallel mounting base, or pole mounting clamp.
  • Page 22 RRU mounting base and pole mounting piece. RRU mounting base It is installed on the back or side of ZXSDR R8882 to secure ZXSDR R8882 on the wall mounting assembly, pole mounting assembly, parallel mounting base, or pole mounting clamp.
  • Page 23 It is fixed on the indoor floor to mount the mounting panel. Mounting panel It is installed on the portal frame to secure ZXSDR R8882. Device hook (U-shaped hook) Install two U-shaped hooks at the back of the device to...
  • Page 24 ZXSDR R8882 Hardware Installation Guide Installation Assemblies of Mounting Kit 2 (Portal Frame-Mounted) Table 3-7 describes the installation assemblies of mounting kit 2 for portal frame-mounted installation. Table 3-7 Installation Assemblies of Mounting Kit 2 (Portal Frame-Mounted) Name Appearance Function...
  • Page 25 Chapter 3 Device Installation Name Appearance Function RRU mounting base It is installed on the back or side of ZXSDR R8882 to secure ZXSDR R8882 on the wall mounting assembly, pole mounting assembly, parallel mounting base, or pole mounting clamp.
  • Page 26 7. Expansion bolts 3. Flat washer assembly 4. Install device hooks (two U-shaped hooks): Use the 12 M16 bolts disassembled from the ZXSDR R8882 to secure the two U-shaped hooks to the back of the device. See Figure 3-3. SJ-20111021104623-004|2012–01-30 (R1.1)
  • Page 27 Chapter 3 Device Installation Figure 3-3 Install Device Hooks (Two U-shaped Hooks) 5. Mount the device on the wall mounting assembly: Hang ZXSDR R8882 on the hook on the wall mounting assembly, as shown in Figure 3-4. Figure 3-4 Mounting the Device on the Wall Mounting Assembly 6.

  • Page 28: Using Mounting Kit 2 To Mount The Device On A Wall

    ZXSDR R8882 Hardware Installation Guide Figure 3-5 Securing the Device – End of Steps – 3.3.2 Using Mounting Kit 2 to Mount the Device on a Wall Steps 1. Identify the installation position on the wall and draw lines: Draw lines on the wall by...
  • Page 29 3. Secure the wall mounting assembly: Secure the wall mounting assembly on the wall with the nuts removed from the expansion bolts, as shown in Figure 3-7. 3-11 SJ-20111021104623-004|2012–01-30 (R1.1) ZTE Proprietary and Confidential...
  • Page 30 ZXSDR R8882 Hardware Installation Guide Figure 3-7 Securing the Wall Mounting Assembly 4. Install the RRU mounting base on the back of the device: Align the holes on the back of the device with the holes on the RRU mounting base and secure the RRU mounting...
